ReelCraft G3050 User manual

Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: [phone]
Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com
Form #TB0023 Rev: 4/2012
Tech Bulletin
G3050 Grounding Reel Cable
Tensioning Instructions
Tools required (not included):
- 14mm Open-End Wrench
- #1 Phillips Screw Driver
CAUTION: Never add or remove tension when the cable is extended from the reel. The cable must always be
fully wound on the reel.
TENSION ADJUSTMENT:
1. Remove (1) screw from hub using screw driver.

G3050 Cable Tensioning Instructions
Page 2 www.reelcraft.com
2. While holding shaft with wrench, remove second screw from hub using screw driver.
3. Using wrench, turn shaft counter-clock wise to decrease cable tension or turn shaft clock wise to increase
cable tension.
Decrease
Cable
Tension
Increase
Cable
Tension
4. Replace the (2) screws in reverse order of step 1 and step 2.
