Reison 10-390 Series Installation instructions

1
Arm surgery table 10-390 including versions
Version
Description
10-390
Clamp (EU 25x10 mm rail)
10-390-S
Clamp (EU 25x10 mm rail), excl. mattress
10-390-US
Clamp (US 1⅛ ’’ x ⅜ ’’ rail)
10-390-UK
Clamp (UK 1¼ ” x ¼ ” rail)
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-21
Document number: M10-390EN rev.01
Arm surgery table 10-390
ENGLISH

2
Intended use
Arm surgery table for placement of patient arm during surgical treatment of arm and hand. The
product is to be used by medical professionals within a medical facility.
Safety regulation
Maximum load: 15 kg in even distribution, corresponding to a patient weight of 200 kg, according to
EN 60601-1 and EN 60601-2.
Before use, ensure correct function!
When loosening the lock lever to adjust the height, support underneath the arm table, to prevent it
from uncontrolled descend into the bottom position.
Remove the arm surgery table during transport!
Service and preventive maintenance shall be performed by authorized personnel.
MAX 15 kg (MAX 200 kg )

3
User instruction
Installation
1.
2.
90o
A.
B.
A.
C.
B.
D.

4
Maintenance
Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel
only. Altering the construction without a written consent from the manufacturer, is strictly forbidden.
Cleaning
Clean with antiseptic detergent with pH 6 –8 and warm water. Ethanol can be used. Wipe dry with
soft cloth. Do not use strong acidic or alkaline detergent.
Control
Check that there are no loose parts and that there is no damage to any part. The lock function is
checked by locking and unlocking the top in different positions. If a cushion is used check that it is clean
and is not damaged.
Annual service
Once a year the arm table shall be carefully cleaned, moving parts shall be lubricated, the locking
function shall be tested.

5
Spare parts
Version:
10-390
10-390-S
Description
Pcs.
Article no.
Article no.
1.
Frame
1
10056
10056
2.
Plate
1
10045
10045
3.
Blind rivet AS 4,8x12-F
12
-
-
4.
Knob VC 192/40 B M8
2
-
-
5.
Washer
2
10004
10004
6.
Screw MF6S M6x12 A2
2
-
-
7.
Clamp body
2
EU: 10031
US: 10547
UK: 10543
EU: 10031
8.
Supporting leg
1
11041
11041
9.
Adjustable lock lever
2
6.593.65
6.593.65
10.
Guide
2
10053
10053
11.
Spring
2
10013
10013
12.
Pressure pin
2
10012
10012
13.
Plunger
2
10711
10711
14.
Lock lever
2
10014
10014
15.
Ball
2
K20M8S
K20M8S
16.
Eccentric
2
11165
11165
17.
Shaft
2
10009
10009
18.
Screw MC6S M6x35 FZ
4
-
-
19.
Plastic plug UKB22S
1
-
-
20.
Mattress
1
10-397
-
21.
Attachment patch
4
11364
-
19

6
Technical specification
Maximum work load
15 kg in even distribution, corresponding to a patient weight of 200 kg,
according to EN 60601-1 and EN 60601-2
Weight
13 kg
Dimension (H x W x L)
700-1150 x 525 x 820 mm
Material arm surgery table
Stainless steel
High pressure laminate
Version
UDI-DI
10-390
07350111830724
10-390-S
07350111830762
10-390-US
07350111830793
10-390-UK
07350111830779
