Reison 10-353 User manual

1
Arthroscopy support 10-353 including versions
Version
Description
10-353
Post Ø20 mm, V-shaped side
10-353-18
Post Ø18 mm
10-353-18-B
Post Ø18 mm, plane side
10-353-US
Post Ø18 mm, excl. pads
10-353-XL
Post Ø20 mm, V-shaped side. Adaptation for larger legs
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2020-10-30
Document number: M10-353EN rev.01
Arthroscopy support 10-353
ENGLISH

2
Intended use
Arthroscopy support for fixation and positioning of patients leg during surgery in the knee area. The
product is to be used by medical professionals within a medical facility.
Safety regulation
Maximum load: 40 kg, corresponding to a patient weight of 215 kg, according to EN 60601-1 and EN
60601-2.
Before use, ensure correct function!
When loosening the lock lever to adjust the positioning, support underneath, to prevent the
Arthroscopy support from uncontrolled descend into the bottom position.
To prevent pressure injuries on the patient the pads on the vertical supports may not be compressed
more than 20% when fixating the patients leg.
Service and preventive maintenance shall be performed by authorized personnel.
MAX 40 kg (MAX 215 kg )

3
User instruction
Installation
Position adjustment
C.
A.
D.
B.
A.
B.
C.
D.

4
Maintenance
Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel
only. Altering the construction without a written consent from the manufacturer, is strictly forbidden.
Cleaning
Clean with antiseptic detergent with pH 6 –8 and warm water. Ethanol can be used on metal surfaces.
Wipe dry with soft cloth. Do not use strong acidic or alkaline detergent.
Control
Check that there are no loose parts and that there is no damage to any part. Check the lock- and
positioning function of the Arthroscopy support. Check that the pads are clean and are not damaged.
Annual service
Once a year the Arthroscopy support shall be carefully cleaned, moving parts shall be lubricated, the
locking- and positioning function shall be tested.

5
Spare parts
Version:
10-353
10-353-18
10-353-18-B
10-353-US
10-353-XL
Description
Pcs
Article no.
Article no.
Article no.
Article no.
Article no.
1.
Support tube
1
10376
10376
10376
10376
10376
2.
Adjusting screw
1
10382
10382
10382
10382
10382
3.
Nut
1
10383
10383
10383
10383
10383
4.
Driving plate pin
1
10887
10887
10887
10887
10887
5.
Support movable
1
10371
10371
10371
10371
11776
6.
Lid
1
10407
10407
10407
10407
10407
7.
Support fixed
1
10372
10372
10372
10372
11775
8.
Pad holder
1
10442
10442
10442
10442
10442
9.
Plastic plug IFR 25x25x2
1
-
-
-
-
-
10.
Plastic plug
1
10888
10888
10888
10888
10888
11.
Washer BRB 10,5x20x2 nylon
1
-
-
-
-
-
12.
Crank GN 471B
1
-
-
-
-
-
13.
Pad
2
10125
10125
10125
-
11785
14.
Fitting movable
1
10379
10379
10379
10379
10379
15.
Adjustable lock lever GN300 S63-8
1
-
-
-
-
-
16.
Clamp fitting
1
10386
10624
11479
10624
10386
17.
Set screw PSS M8x10 nylon
2
-
-
-
-
-
18.
Screw MF6S M4x16 A2
12
-
-
-
-
-
19.
Pad
1
10441
10441
10441
-
10441
20.
Set screw MSK6SS M6x8
1
-
-
-
-
-
21.
Washer
1
10003
10003
10003
10003
10003
22.
Screw MF6S M5x16 A2
1
-
-
-
-
-
23.
Plastic plug IKPT 85,5 S
1
-
-
-
-
-

6
Technical specification
Maximum workload
40 kg, corresponding to a patient weight of 215 kg, according to EN 60601-
1 and EN 60601-2
Material arthroscopy support
Stainless steel
Version
UDI-DI
Weight
Dimension (H x W x L)
10-353
07350111831431
4,3 kg
265 x 130 x 465 mm
10-353-18
07350111831448
4,3 kg
265 x 130 x 465 mm
10-353-18-B
07350111831455
4,3 kg
265 x 130 x 465 mm
10-353-US
07350111831462
4,3 kg
265 x 130 x 465 mm
10-353-XL
07350111831479
4,5 kg
340 x 130 x 465 mm

7
Reison Medical AB
Eriksbergsvägen 32A
734 92 Hallstahammar
SWEDEN
[phone] [e-mail] [e-mail]
