Reison 10-398 User manual

10-398 Edit.4 Page 1( 4)
USERS MANUAL
10-398 ARM & HAND
SURGERY TABLE
GMDN 62599
PID 102286

10-398 Edit.4 Page 2( 4)
INTRODUCTION
The 10-398 Arm & Hand surgery table is designed to fit several different operating tables when arm
and hand surgery shall be performed. The table is made from carbon fiber laminate for excellent x-ray
fluoroscopy facilities. The thin plate with cutouts gives very good access for the surgeon
On the rear end, there is an accessory rail for infusion stand and anesthetic frame.
ABOUT USER MANUAL
This user manual is for clinical personnel, service personnel and others who need the knowledge about
and understanding of how the arm & hand surgery table works and how it shall be used.
❖Read user manual carefully before use of the equipment.
❖Always follow the instructions in user manual.
❖Always keep user manual close to the equipment.
INSTALLATION
At the unpacking, check that there are no damages to the equipment and that there are no loose parts in
the box. The packing material consists of cardboard and plastic which can be recycled.
IMPORTANT SAFETY DIRECTIONS
❖When attaching the arm & hand surgery table to the operating table, the responsible personnel
must be sure of that the arm & hand surgery table is securely locked to the operating table by
tightening the two locking knobs.
❖Check before every use that there are no damages that can make the use hazardous.
❖The arm & hand surgery table is designed for a Safe Working Load of 32kg. To keep the valid
safety factor according to the European standards 60601-1 and 60601-2-46 the Safe Working
Load shall not be exceeded. Overload can cause injuries to the patient or the personnel and
damage to the equipment
❖If a mobile operating table with adapted arm operating table is to be moved, the arm
operating table must be removed, to avoid collision causing damage to the arm operating
table or to other equipment.

10-398 Edit.4 Page 3( 4)
MAINTENANCE AND CARE
Cleaning
Clean with mild soap detergent with PH 6-8 and warm water. Dry with soft cloth. Do not
use alcohol or strong detergents containing strong acids or bases.
Control
Check daily for any kind of damage that can make the use hazardous. Also check the
locking function.
Annual service
Once a year the arm & hand surgery table shall be carefully cleaned. Threads shall be
lubricated with thin waterproof grease. Locking functions shall be tested. Damaged or
worn parts shall be replaced.
Service, preventing maintenance and all kind of repair must only be done by for this purpose educated
personnel. Changing of any part of the construction without a written permission from the
manufacturer is strictly forbidden. Transgression will be prohibited.
GENERAL DESCRIPTION
This part of the plate shall be put
under the mattress of the back
section of the operating table
Knobs for clamping against the
underside of the back section of
the operating table
Rail for accessories
Maximum load 32kg evenly applied

10-398 Edit.4 Page 4( 4)
SPARE PARTS
TECHNICAL DATA
Length 137cm
Width 52cm
Thickness of plate 1,3cm
Height 14cm
Weight 5,1kg
Box 240 Eriksbergsvägen 32 A
734 25 Hallstahammar
Sweden
Phone: [phone] Fax: [phone]
E-mail: [email protected]e
www.reison.se
1. Bracket 11427 2pcs.
2. Adjustable glide SF 3222 M8 70S 2pcs.
3. Knob VC 192-40 B-M8 2pcs.
4. Screw MF6S M6x16 A2 8pcs.
5. Rail 11428 1pc.
6. Screw MF6S M8x20 A2 2pcs.
7. Plate 11384 1pc.
