Reliable GXLO Series Manual

Model GXLO Series Sprinklers
Upright with Factory Installed Shield
Upright Pendent
Product Description
Reliable Model GXLO (extra-large orifice) upright and
pendent sprinklers are standard coverage, standard
response sprinklers that utilize a robust center strut, solder in
compression thermal element. These sprinklers are intended
for use in hydraulically calculated control mode density area
(CMDA) storage and non-storage occupancies in accordance
with the area/density curves of NFPA 13 or other applicable
standards.
The Model GXLO sprinkler is FM Approved as a standard
response storage and non-storage sprinkler when used in
accordance with FM Global Property Loss Prevention Data
Sheets.
For new installations, the sprinkler is provided with either 3/4-
inch NPT or ISO 7-R3/4 threads. The upright version is also
available with 1/2-inch NPT or ISO 7-R1/2 threads for retrofit
installations only. Sprinklers without guards are installed using
the Model H wrench.
For use as an intermediate level sprinkler, the Model GXLO
upright sprinkler is available with a factory installed water
shield. Various other water shields, guards, or guard/shield
options are also available for both upright and pendent
models (please refer to Technical Specifications on following
pages). Sprinkler guards or guard/shields may be installed
in the field or factory installed. Use of the Model JV sprinkler
wrench is required for installation where a guard is added to
the sprinkler prior to threading the assembly into a fitting.
www.reliablesprinkler.com
Model GXLO Specifications
Style Sprinkler Identification
Number (SIN)
Listings and
Approvals Sensitivity K-Factor
Upright R2921 cULus, FM
Standard Response 11.2
(160 metric)
Pendent R2916 FM
Table A
Model GXLO Series Sprinkler
Storage and Non-Storage Sprinklers
K11.2 (160 metric)
Bulletin 129 August 2020

Model GXLO Upright Sprinkler SIN R2921
Technical Specifications
Style: Upright
Threads: 3/4” NPT or ISO 7-1R3/4
1/2” NPT or ISO 7-1R1/2 for
Retrofit Application ONLY
Nominal K-Factor: 11.2 (160 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: Solder Capsule
Sprinkler Frame: Brass Alloy
Button/Cup: Brass Alloy
Sealing Assembly: Brass with PTFE
Load Screw: Bronze
Deflector: Bronze Alloy
Levers: Bronze Alloy
Ejection Spring: Stainless Steel
Sprinkler Finishes
See Table C)
Sensitivity
Standard Response
Temperature Ratings
See Table D
Guards & Shields
D-6 Guard & Water Shield (cULus)
D-7 Guard & Water Shield (FM)
Water Shield (factory installed) (FM)
Sprinkler Wrench
Model H
Model JV (when guard is installed prior to
make-in)
Listings and Approvals
cULus Listed
FM Approved
Model GXLO Upright Components and Dimensions Figure 1
Bulletin 129
August 2020
Page 2 of 5
www.reliablesprinkler.com

Model GXLO Pendent Sprinkler SIN R2921
Technical Specifications
Style: Pendent
Threads: 3/4” NPT or ISO 7-1R3/4
Nominal K-Factor: 11.2 (160 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: Beryllium Nickel Solder Link
Sprinkler Frame: Brass Alloy
Button/Cup: Brass Alloy
Sealing Assembly: Brass Alloy with PTFE
Load Screw: Bronze
Deflector: Bronze Alloy
Levers: Bronze Alloy
Sprinkler Finishes
See Table C
Sensitivity
Standard Response
Temperature Ratings
See Table D
Guards & Shields
D-8 Guard (FM)
D-9 Guard & Water Shield (FM)
Sprinkler Wrench
Model H
Model JV (when guard is installed prior to
make-in)
Listings and Approvals
FM Approved
Bulletin 129
August 2020
Page 3 of 5
www.reliablesprinkler.com
Model GXLO Pendent Components and Dimensions Figure 2

Storage Type NFPA FM GLOBAL
Sprinkler Type CMDA Storage
Response Type SR SR
System Type Pendent - Wet
Upright - Wet, Dry, Preaction
Pendent - Wet
Upright - Wet, Dry, Preaction
Temperature Rating °F (°C) 165, 212, 286 (74, 100, 141) 165, 212, 286 (74, 100, 141)
Roof Construction See NFPA 13 See FM Global 2-0
Ceiling Slope See NFPA 13 See FM Global 2-0
Maximum Coverage Area See NFPA 13 See FM Global 2-0
Minimum Coverage Area See NFPA 13 See FM Global 2-0
Maximum Spacing See NFPA 13 See FM Global 2-0
Minimum Spacing See NFPA 13 See FM Global 2-0
Minimum Clearance to Commodity See NFPA 13 See FM Global 2-0
Sprinkler Distance to Ceiling See NFPA 13 See FM Global 2-0
Open Frame, Single, Double, Multiple
Row, or Portable Rack Storage of Class
I - IV Commodity and Group A Plastic
See NFPA 13 See FM 2-0 & 8-9
Solid Pile or Palletized Storage of Class
I - IV Commodity and Group A Plastic See NFPA 13 See FM 2-0 & 8-9
Idle Pallet Storage See NFPA 13 See FM 2-0,8-9 & 8-24
Rubber Tire Storage See NFPA 13 See FM 8-3
Rolled Paper Storage See NFPA 13 Pendent - N/A
Upright - See FM 8-21
Flammable Liquid Storage See NFPA 30 See FM 7-29 and 8-9
Aerosol Storage See NFPA 13 See FM 7-31
Auto Components in Portable Racks N/A N/A
Model GXLO Commodity Selection and Design Criteria Overview Table B
Bulletin 129
August 2020
Page 4 of 5
www.reliablesprinkler.com

Installation
Model GXLO sprinklers must be installed according to appropriate
NFPA Standards, FM Global Loss Prevention Data Sheets, and/or
the requirements of the authority having jurisdiction.
Use only the Model H sprinkler wrench for sprinkler installation
or use the Model JV wrench to install the sprinkler/guard
assembly (Figure 3). Any other type of wrench may damage
the sprinkler. Damaged sprinklers must be replaced
immediately.
A leak tight joint should be obtained with a torque of 14 to 20
lb-ft (19 to 27 N.m) for 3/4 inch NPT and ISO 7-R3/4 thread
sprinklers. For 1/2 inch NPT and ISO 7-R1/2 thread sprinklers the
recommended installation torque is 8 to 18 lb-ft (11 to 24 N.m).
Exceeding the maximum recommended torque may cause leakage
or impairment of the sprinklers.
Maintenance
Reliable Model GXLO sprinklers should be inspected and the
sprinkler system maintained in accordance with NFPA
25, as well as the requirements of any Authorities Having
Jurisdiction.
Prior to installation, sprinklers should remain in the original
cartons and packaging until used. This will minimize the
potential for damage to sprinklers that could cause improper
operation or non-operation.
Do not clean sprinklers with soap and water, ammonia liquid or
any other cleaning fluids. Remove dust by gentle vacuuming
without touching the sprinkler.
Replace any sprinkler which has been painted (other than
factory applied). A stock of spare sprinklers should be
maintained to allow quick replacement of damaged or
operated sprinklers.
Failure to properly maintain sprinklers may result in inadvertent
operation or non-operation during a fire event.
Guarantee
For the Reliable Automatic Sprinkler Co., Inc. guarantee, terms,
and conditions, visit www.reliablesprinkler.com.
Ordering Information
Specify the following when ordering.
Model GXLO Sprinkler
• [Upright] [3/4” NPT] [ISO 7-R3/4]
• [Pendent] [3/4” NPT] [ISO 7-R3/4]
• [Upright Retrofit] [1/2” NPT] [ISO 7-R1/2]
• [Upright with factory installed shield]
Temperature Rating
• [165°F (74°C)] [212°F (100°C)] [286°F (141°C)]
Finish
• See Table C
Guard/Shield
• See Technical Specifications
Sprinkler Wrench
• [Model H] [Model JV (required with pre-installed
guards)]
Standard
Finishes
Special Application
Finishes
Bronze Lead Plated (1) 165°F (74°C), 212°F (100°C) and
286°F (141°C) Temp. Ratings
Chrome (1) Wax (1) (2) 165°F (74°C) Clear Wax,
212°F (100°C) Brown Wax
Wax/Lead (1) (2) 165°F (74°C) Clear Wax,
212°F (100°C) Brown Wax
(1) cULus, upright (without shield) only.
(2) 212°F (100°C) Brown wax may be used on 286°F (141°C) Sprinklers
when maximum ambient temperatures do not exceed 150°F (66°C).
Sprinkler Finishes Table C
Wrenches Figure 3
Model H Wrench (sprinkler)
Model JV Wrench (with guard installed)
Classification
Sprinkler
Rating
Maximum
Ambient
Temperature Frame Color
°F °C °F °C
Ordinary
Intermediate
High
165
212
286
74
100
141
100
150
225
38
66
107
Uncolored
White
Blue
Temperature Ratings Table D
Bulletin 129
August 2020
Page 5 of 5
www.reliablesprinkler.com
P/N 9999970286
