Reliable GFR User manual

The Reliable Automatic Sprinkler Co., Inc., 103 Fairview Park Drive, Elmsford, New York 10523
Model GFR
Model GFR Recessed
Quick Response
Sprinklers
Bulletin 131 Rev. J
Bulletin 131 Rev. J
Model GFR Sprinkler Types
Standard Upright
Standard Pendent
Horizontal Sidewall
HSW1 Deflector
Intermediate Level Upright
Intermediate Level Pendent
Conventional
Model GFR Recessed
Sprinkler Types
Recessed Pendent
Recessed Horizontal Sidewall
HSW1 Deflector
Approvals
Underwriters Laboratories, Inc. (UL)
Underwriters’ Laboratories of Canada (ULC)
NYC BS&A No. 587-75-SA
.....
.....
MIL-S-901C and MIL-STD-167-1
NYC MEA 258-93-E
1.
2.
3.
4.
5.
6.
7.
UL Listing Category
Sprinklers, Automatic & Open
Quick Response Sprinkler
UL Guide Number
VNIV
Product Description
Reliable Models GFR and GFR Recessed Sprinklers are
Quick Response fusible solder type automatic sprinklers.
These sprinklers have demonstrated response times in
laboratory tests which are five times faster than standard
response sprinklers.
This quick response enables the Models GFR and GFR
Recessed Sprinklers to apply water to a fire much faster
than standard response sprinklers of the same temperature
rating.
Application
Quick response sprinklers are used in fixed fire protec-
tion systems: Wet, Dry, Deluge or Preaction. Care must be
exercised that the orifice size, temperature rating, deflector
style and sprinkler spacing are in accordance with the latest
published standards of the National Fire Protection Associ-
ation or the approving Authority Having Jurisdiction. Quick
response sprinklers are intended for standard area cover-
age and standard water densities as specified in NFPA 13.
Quick response sprinklers and standard response sprin-
klers should not be intermixed.
Upright Pendent Intermediate Level
Upright
Intermediate Level
Pendent
Small Orifice
Upright
Conventional Recessed
Horizontal Sidewall
HSW-1 Deflector
Horizontal Sidewall
HSW-1 Deflector
Recessed
Pendent
Recessed FP
Pendent

2.
Model GFR Quick Response Upright, Pendent & Conventional Sprinklers
Model GFR Quick Response Upright & Pendent Intermediate Level Sprinklers
Installation Wrench: Model D Sprinkler Wrench
Installation Data:
Sprinkler Type
Nominal K
Factor
Sprinkler
Height Approvals
Sprinkler
Identification
Numbers (SIN)
US Metric SSU SSP
Standard-Upright (SSU) and Pendent (SSP)
Deflectors Marked to Indicate Position
5.6
4.2
2.8
4.2
8.0
80
60
40
60
115
27 /
8” (73mm)
27 /
8” (73mm)
27 /
8” (73mm)
73mm
215 /
16” (75mm)
1,2,3,6,7
1,2,3,7
1,2,3,7
1,2,3,7
R3125
R3123
R3121
R3124
R3127
R3115
R3113
R3111
R3114
R3117
1/2” (15mm) Standard Orifice with ½” NPT (R½) Thread
7
/
16” (11mm) Small Orifice with ½” NPT (R½) Thread (11mm)
3
/
8” (10mm) Small Orifice with ½” NPT (R½) Thread (10mm)
10mm Orifice XLH with R3 /
8Thread
17
/
32” (20mm) Large Orifice with ¾” NPT (R¾) Thread
Conventional-Install in Upright or Pendent Position
4.2
5.6
60
80
73mm
73mm
-------------
-------------
R3174
R3175
10mm Orifice XLH with R3 /
8Thread
15mm Standard Orifice with ½” NPT (R½) Thread
Installation Wrench: Model D Sprinkler Wrench
Installation Data:
Sprinkler Type
Nominal K
Factor Sprinkler
Height Approvals
Sprinkler
Identification
Number (SIN)
US Metric SSU SSP
Standard Upright (SSU) and Pendent (SSP)
Deflectors Marked to Indicate Position
5.6
8.0
80
115
27 /
8” (73mm)
215 /
16” (75mm)
1,2,3,7
1,2,3,7
R3195 R3115
1/2” (15mm) Standard Orifice with ½” NPT (R½) Thread
17
/
32” (20mm) Large Orifice with ¾” NPT (R¾) Thread R3197 R3117
NOTE: The protective shield must be assembled in the field per the assembly drawings.
Upright Pendent
Upright Pendent Small Orifice UprightConventional

3.
Model GFR Quick Response Horizontal Sidewall Sprinkler
Deflector: HSW1
Installation Wrench: Model D Sprinkler Wrench
Installation Data:
Nominal
Orifice Thread Size
Nominal K
Factor Sprinkler
Height
Approval Organization
and Type of Approval Sprinkler
Identification
Number (SIN)
US Metric Light
Hazard
Ordinary
Hazard
1/2” (15mm)
7/16” (11mm)
3/8” (10mm)
17/32” (20mm)
½” NPT (R½)
½” NPT (R½)
½” NPT (R½)
¾” NPT (R¾)
5.6
4.2
2.8
8.2
80
60
41
119
35 /
16” (84mm)
35 /
16” (84mm)
35 /
16” (84mm)
35 /
16” (84mm)
1,2,3,7
1,2,3,7
1,2,3,7
1,2,3,7
1,2,3,7
—
—
—
R3135
R3133
R3131
R3137
Model GFR Quick Response Recessed Pendent Sprinklers
Installation Wrench: Model GFR1 Sprinkler Wrench
Installation Data:
Sprinkler Type Nominal K Factor Sprinkler Height Approvals(2) Sprinkler Identification
Number (SIN)
US Metric
½” (15mm) Standard Orifice with ½” NPT (R½) Thread
7
/
16” (11mm) Small Orifice with ½” NPT (R½) Thread
3
/
8” (10mm) Small Orifice with ½” NPT (R½) Thread
10mm Orifice XLH with R3 /
8Thread
17/32” (20mm) Large Orifice with ¾” NPT (R¾) Thread
5.6
4.2
2.8
4.2
8.0
80
60
40
60
115
27 /
8” (73mm)
27 /
8” (73mm)
27 /
8” (73mm)
(73mm)
215 /
16” (75mm)
1,2,3,7
1,2,3,7
1,2,3,7
—
1,2,3,7
R3115
R3113
R3111
R3174
R3117
(1) Refer to escutcheon data table for specific escutcheon approvals and dimensions.
Model GFR Quick Response Recessed Horizontal Sidewall Sprinklers
Deflector: HSW1
Installation Wrench: Model GFR1 Sprinkler Wrench
Installation Data
Nominal
Orifice
Thread
Size
NPT
Nominal K
Factor Sprinkler
Height
Approval
Organization(2)
Type of Approval
Sprinkler
Identification
Number
(SIN)
US Metric Light
Hazard
Ordinary
Hazard
1/2” (15mm)
7/16” (11mm)
3/8” (10mm)
17/32”(20mm)
½”(R½)
½”(R½)
½”(R½)
¾”(R¾)
5.6
4.2
2.8
8.0
81.0
61.0
40.6
118.2
35 /
16” (84mm)
35 /
16” (84mm)
35 /
16” (84mm)
35 /
16” (84mm)
1,2,3,7
1,2,3,7
1,2,3,7
1,2,3,7
1,2,3,7
—
—
—
R3135
R3133
R3131
R3137
(1) Refer to escutcheon data table for specific escutcheon approvals and dimensions.
Recessed Pendent /F1 Recessed Pendent /FP

EG. Printed in U.S.A 08/10 P/N 9999970024
The Reliable Automatic Sprinkler Co., Inc.
[phone] Sales Offices
[phone] Sales Fax
[phone] Corporate Offices
www.reliablesprinkler.com Internet Address
Manufactured by
Recycled
Paper
Revision lines indicate updated or new data.
The equipment presented in this bulletin is to be installed in accordance with the latest published Standards of the National Fire Protection Association, Factory
Mutual Research Corporation, or other similar organizations and also with the provisions of governmental codes or ordinances whenever applicable.
Productsmanufactured and distributed by Reliable have been protecting life and property for over 90 years, and are installed and serviced by the most highly
qualified and reputable sprinkler contractors located throughout the United States, Canada and foreign countries.
Model GFR & GFR Recessed Quick Response Sprinklers
Finishes(1)(2)
Standard Finishes
Sprinkler Escutcheon
Bronze
Chrome Plated
Brass
Chrome Plated
Special Application Finishes
Sprinkler Escutcheon
Bright Brass
Black Plated
Satin Chrome
Bright Brass
Chrome Plated
Satin Chrome
(1) Other finishes and colors are available, consult factory for details
(2) All sprinklers have black painted solder links
Temperature Ratings
Classification
Sprinkler
Rating
Maximum Ambient
Temperature
°F °C °F °C
Ordinary 165 74 100 38
Intermediate 212 100 150 66
Escutcheon Data
Escutcheon
Model Approvals Adjustment
Face of Fitting To
Ceiling or Wall
Dimension
F1
F2
FP(1)
1,2,3
1,2,3
1,2
¾” (19mm)
½” (13mm)
¾” (19mm)
3
/
16” - 15
/
16” (5mm-24mm)
3
/
16” - 11
/
16” (5mm-18mm)
3
/
16” - 15
/
16” (5mm-24mm)
(1) Approved for Pendent only.
Installation
Quick response sprinklers are intended for standard area cov-
erage and standard water densities as specified in NFPA-13.
Quick response sprinklers and standard response sprinklers
should not be intermixed.
The Model GFR Recessed Quick Response Sprinkler is to be
installed as shown. The Model F1 or F2 Escutcheons illustrated
are the only recessed escutcheons to be used with the Model
GFR Pendent or Horizontal Sidewall Sprinklers. The use of any
other recessed escutcheon will void all approvals as a quick re-
sponse sprinkler and negate all warranties.
When installing Model GFR Sprinklers, use the Model D Sprin-
kler Wrench and when installing Model GFR Recessed Sprin-
klers, use the Model GFR1 Sprinkler Wrench. Any other type of
wrench may cause sprinkler damage.
Maintenance
The Models GFR and GFR Recessed Sprinklers should be
inspected quarterly and the sprinkler system maintained in ac-
cordance with NFPA 25. Do not clean the sprinklers with soap
and water, ammonia or any other cleaning fluids. Remove any
dust using a soft brush or gentle vacuuming. Remove any
sprinkler which has been painted (other than factory applied)
or damaged in any way. A stock of spare sprinklers should be
maintained to allow quick replacement of damaged or operated
sprinklers. Prior to installation, sprinklers should be maintained
in the original cartons and packaging until used. This minimizes
the potential for damage resulting in improper operation or non-
operation.
Ordering Information:
Specify
Sprinkler model
Sprinkler type
Orifice size
Temperature rating
Sprinkler finish
Escutcheon type
Escutcheon finish (where applicable)
Note: When Recessed Model GFR/F1 or F2 are ordered,
sprinkler and escutcheon are packaged separately.
Sprinkler Types
Standard Upright
Standard Pendent
Sidewall
— Horizontal HSW1 Deflector
Conventional
Recessed
— Pendent
— Horizontal Sidewall HSW 1 Deflector
Intermediate Level
— Upright
— Pendent
1.
2.
3.
4.
5.
6.
7.
