Retevis RB28 User manual

User Manual

CONTENTS
Features...........................................................................................
Buttons and functions....................................................................
LCD display.....................................................................................
Battery installation.........................................................................
Battery display and low battery warning......................................
Use the charger to charge.............................................................
Turn on/off the radio.......................................................................
Volume setting................................................................................
Transmit and receive......................................................................
TOT function...................................................................................
Set the channel...............................................................................
Tone code selection.......................................................................
Set the calling tone.........................................................................
Vox function....................................................................................
Set high/low power.........................................................................
Scan function..................................................................................
Roger beep......................................................................................
Button control.................................................................................
Lock key..........................................................................................
Power saving function...................................................................
Weather forecast.............................................................................
Enter weather mode.......................................................................
Set up weather alerts.....................................................................
Headphone function.......................................................................
Specification Table.........................................................................
Programme......................................................................................
Frequency table(FRS).....................................................................
Frequency table (PMR)...................................................................
01
01
02
02
02
03
03
03
03
03
03
04
04
04
04
05
05
05
05
06
06
06
06
06
07
07
08
08

Features
• LCD backlight display
• 22 channels
• 121 subtone codes (38 analog, 83 digital)
• Busy lock
• Headphone jack
• 10 optional calling tones
• (VOX)Vox function
• High and low power
• Roger beep
• Companding function
• Battery display
• Scanning function
• Keypad lock
• Voice prompt
• Power saving function
• Low battery alarm
• Keypad tones
• TOT function
Buttons and functions
1
Antenna LCD display
Power on/off and
scan switch
Earpiece and
programme jack
Type-C charging port
Down/calling tone button
Lock and menu button
Speaker
PTT
Mic
UP/Weather

Battery installation
1) Battery: Li-ion battery.
2) Press the battery upwards to remove the battery.
3) Put the battery into the battery slot, pay attention to install the battery strictly
according to the positive + negative-instructions in the slot, and press down
firmly.
4) Reinstall the battery.
Battery display and low battery warning
The battery icon shows the battery level, from full display to space (0 battery).
The 0 battery reminds the user to charge in time, and is accompanied by a low
battery reminder (once 30 seconds). When the battery power is low, the intercom
will be shut down.
Note: When storing the radio for a long time, please remove the battery first.
Long-term corrosion of the battery will cause damage to the radio.
LCD display
Battery power
Scan
Lock
Status(tx/rx)
High power
Volume mute
Vox
2

Use the charger to charge
1) Make sure the radio is closed.
2) Insert the Type-c charging plug into the jack of the radio with the rechargeable
battery, and plug the other end of the charger into the power socket on the wall.
3) During the charging process, the battery symbol is displayed on the mobile to
indicate the charging state. When the battery is fully charged, the battery symbol
stops.
Flashing, Advise to keep the radio closed when it’s charging, if you try to perform
an intercom operation during charging, some abnormal phenomena may occur
when the battery is almost empty.
Turn on/off the radio
Press the button to turn on or off the radio. When turn on the radio, the horn of
radio sounds a boot prompt and displays all the icons on the full screen.
After the power-on done, the radio is in the walkie-talkie mode by default,
displaying the currently used channel number and subtone code, etc.
Volume setting
1) In the standby or receiving state, press the ˂ or ˃ key, the LCD of the radio will
display the current volume.
2) Then press ˂ or ˃ to increase or decrease the volume of the radio. 0,1-9 level
the volume can be adjusted.
3) Press the key to decrease the volume to level 0, the mute icon ( ) will be
displayed on the LCD of the walkie-talkie, and the speaker sound will be turned
off.
Note: When the volume is not adjusted to a proper state, Don’t put the speaker of
the walkie-talkie too close to your ears to avoid damage to your ears due to too
much sound.
Transmit and receive
1) Press and hold the [PTT] key, keep a distance of 3 to 5 cm from the micro-
phone, and talk at a normal speaking rate. When the display launches When the
icon ( ) is displayed, it means that a message is being sent. In order to avoid
cutting off your call, please press the [PTT] button to pause for a while, and then
start speaking.
2) When you finish the call, please release the [PTT] key. You can receive the
signal. When receiving, the icon ( ) will be displayed.
TOT function
When you press and hold the [PTT] button for more than 15-180 seconds, the
intercom will emit a continuous warning tone and the intercom will automatically
stop transmitting.
Set the channel
1) In the standby state of the radio mode, press the ◎ key once, the current
channel will flash.
2) Press the ˂ or ˃ key to select the channel number you want to set.
3) Press【PTT】key to save the current setting and exit the menu or press ◎
3

key to skip to the next menu setting.
4) The radio can only be communicated when the radio is set to the same
channel, and the radio is clear and no noise.
Tone code selection
The distribution of tone codes can reduce the mutual interference between
radios, but the radios with different tone codes cannot make calls. Each channel
has 0 to 121 tone codes, so that your communication is more confidential. The
analog subtone codes Code 1-38 are available, and the digital subtone codes
Code 39-121 are available. Code 0 is the closed state of the tone code.
1) In the standby mode of the radio mode, press the ◎ key twice, the current
tone code will flash.
2) Press the ˂ or ˃ key to select the tone code you want to set. Press and hold
the ˂ or ˃ key to quickly switch tones
3) Press【PTT】key to save the current setting and exit the menu or press ◎
key to skip to the next menu setting.
Set the calling tone
1) In the standby state of the radio mode, press the ◎ key 3 times, the current
call tone setting interface will flash "CA"
2) Press ˂ or ˃ to select the calling tone you want to set, and the intercom
speaker will emit the corresponding set calling tone sound
3) Press【PTT】key to save the current setting and exit the menu or press ◎
key to skip to the next menu setting.
Note: When the calling tone menu setting is set to 0, it means that the setting is
no calling tone, and the calling function will be invalid when the ˃ key is long
pressed.
Vox function
When the VOX function is set to on, you can use the radio to talk without
pressing the [PTT] key, and speaking directly into the microphone will
automatically start the transmission.
1) In the standby mode of the walkie-talkie mode, press the ◎ key 4 times, VOX
will appear on the screen, and the VOX level can be set.
2) Press ˂ or ˃ key to select sensitivity level 1-9:
9 = High sensitivity level 5 = Medium sensitivity level
1 = Low sensitivity level 0 = OFF
3) Press【PTT】key to save the current setting and exit the menu or press ◎
key to skip to the next menu setting.
Select sensitivity 0, turn off the VOX function, and the VOX icon will disappear.
4) The transmitter can be launched into the microphone. There is a short delay
between the start of speaking and the launch of the radio
5) Stop speaking, you can enter the receiving state.
Set high/low power
In the standby state of the radio mode, press the ◎ key 5 times, and "Pr" will be
displayed on the screen.
Press ˂ or ˃ key to select power LO or HI. (LO: low power / HI: high power)
Press【PTT】key to save the current settings and exit the menu.
4

Scan function
In the standby state of the radio mode, press the ◎ key 6 times, and "SC" will be
displayed on the screen.
Press ˂ or ˃ key to select on and off
Press【PTT】key to save the current settings and exit the menu to start
The scanning function of the radio scans the effective signal channels, which can
easily scan 22 channels
Note: When the scan menu setting is selected as OF, the scan function will be
invalid when you press the [Power Switch/Scan] key.
Start scanning:
1) In the radio standby mode, press the [Power Switch/Scan] key to enter the
scan mode, the channel number will be displayed in upward increments, and the
SCAN icon will be displayed on the LCD.
2) When an active channel is detected, the intercom will automatically suspend
receiving signals on this channel until the signal disappears.
Lost. After the signal disappears and wait for 5 seconds, the intercom will
continue to scan.
3) Press the [PTT] key during scanning, and the intercom will stop transmitting
on the channel that started scanning. in the case of
When a valid signal is detected and the reception is stopped, press the [PTT]
key, and the intercom will transmit on the current channel. release
Wait 5 seconds after 【PTT】key, the intercom will continue to scan
4) Press the [Power Switch/Scan] key again to exit the scan and return to the
radio standby mode.
Roger beep
1) In the standby state of the radio mode, press the ◎ key 7 times, the setting
interface of the current call end tone will display "rb".
2) Press ˂ or ˃ key to select on and off,
3) Press【PTT】key to save the current setting and exit the menu or press ◎
key to end the setting.
Note: When the call end tone is turned on, press PTT after the call ends, the
machine will give a prompt tone, and the receiver will also receive a prompt tone.
Button control
1) [Power switch/scan] key: long press this key to turn on or off the radio; short
press this key to turn on or off the scan.
2)【˂ 】key: long press this key to switch between radios and weather forecast
modes; short press this key to increase the volume.
3) 【˃ 】key: long press this key to emit the calling tone; short press this key to
decrease the volume.
4) 【◎ 】key: long press this key to operate the lock or unlock function; short
press this key to enter or exit the menu.
5) 【PTT】key can be set: transmit or save settings (in menu mode).
Lock key
The keyboard lock function is to prevent users from misoperation when they don't
want to change the settings of the radio
5

1) Press and hold the 【◎ 】key until the icon ( ) appears to enter the
keyboard lock state.
2) Long press and hold the 【◎ 】key until the icon ( ) disappears to exit the
keyboard lock state.
Note: When the keyboard is locked, except for pressing the [PTT] and [Power
Switch/Scan] keys, any key press will sound a key failure tone.
Power saving function
The radio has a unique function to extend the service life of the battery. If there is
no call or voice reception within 10 seconds, the walkie-talkie will automatically
enter the power saving mode. In this mode, the radio can still receive
information.
Headphone function
1) Connect the earphone to the walkie-talkie (radio A&B).
2) Press the PTT button of the headset of the radio A to send a voice to the MIC
of the headset, and the radio B should be able to receive normally. Repeat the
same operation on radio B.
Programme
The programming software can quickly change and expand the function.
6

Specification Table
Frequency table(FRS)
GENERAL
Frequency Rang 462.5500~467.7125MHz
Channel capacity 22 CH
Working Voltage 3.7 V
Antenna impedance 50Ω
Step frequency 12.5KHz
TRANSMITTER
Output power 2 W / 0.5 W
Adjacent channel power ≥60dB
TX current ≤1.35A
Spurious radiation ≤7.5µW
Modulation limited ≤2.5kH
RECEIVER
RF sensitivity ≤0.25uV
Opening sensitivity ≤0.20uV
Audio output ≥300mW
Receive current ≤410 mA
Waiting current ≤20mA
Channel Frequency Max Power
Output
1 462.5625MHz 2 W
2 462.5875MHz 2 W
3 462.6125MHz 2 W
4 462.6375MHz 2 W
5 462.6625MHz 2 W
6 462.6875MHz 2 W
7 462.7125MHz 2 W
8 467.5625MHz 0.5 W
9 467.5875MHz 0.5 W
10 467.6125MHz 0.5 W
11 467.6375MHz 0.5 W
Channel Frequency Max Power
Output
12 467.6625MHz 0.5 W
13 467.6875MHz 0.5 W
14 467.7125MHz 0.5 W
15 462.5500 MHz 2 W
16 462.5750 MHz 2 W
17 462.6000 MHz 2 W
18 462.6250 MHz 2 W
19 462.6500 MHz 2 W
20 462.6750 MHz 2 W
21 462.7000 MHz 2 W
22 462.7250 MHz 2 W
7

Weather channel and frequency
Channel Frequency Channel Frequency
WX1 162.550MHz WX7 162.525MHz
WX2 162.400MHz WX8 161.650MHz
WX3 162.475MHz WX9 161.775MHz
WX4 162.425MHz WX10 161.750MHz
WX5 162.450MHz WX11 162.000MHz
WX6 162.500MHz
8
Specification Table
Frequency table(PMR)
Channel Frequency Max Power
Output
1 446.00625MHz 0.5 W
2 446.01875MHz 0.5 W
3 446.03125MHz 0.5 W
4 446.04375MHz 0.5 W
5 446.05625MHz 0.5 W
6 446.06875MHz 0.5 W
7 446.08125MHz 0.5 W
8 446.09375MHz 0.5 W
Channel Frequency Max Power
Output
9 446.10625MHz 0.5 W
10 446.11875MHz 0.5 W
11 446.13125MHz 0.5 W
12 446.14375MHz 0.5 W
13 446.15625MHz 0.5 W
14 446.16875MHz 0.5 W
15 446.18125MHz 0.5 W
16 446.19375MHz 0.5 W
GENERAL
Frequency Rang 446.00625~446.19375MHz
Channel capacity 16 CH
Working Voltage 3.7 V
Antenna impedance 50Ω
Step frequency 12.5KHz
TRANSMITTER
Output power ≤0.5 W
Adjacent channel power ≥60dB
TX current ≤1.35A
Spurious radiation ≤7.5µW
Modulation limited ≤2.5kH
RECEIVER
RF sensitivity ≤0.25uV
Opening sensitivity ≤0.20uV
Audio output ≥300mW
Receive current ≤410 mA
Waiting current ≤20mA

Guarantee
Model Number:
Serial Number:
Purchasing Date:
Dealer: Telephone:
User’s Name: Telephone:
Country: Address:
Post Code: Email:
Remarks:
1.This guarantee card should be kept by the user, no replacement if lost.
2.Most new products carry a two-year manufacturer’s warranty from the date of
purchase. Further details, pls read http://www.retevis.com/after-sale/
3.The user can get warranty and after-sales service as below:
• Contact the seller where you buy.
• Products Repaired by Our Local Repair Center
4.For warranty service, you will need to provide a receipt proof of purchase from the
actual seller for verification
Exclusions from Warranty Coverage:
1.To any product damaged by accident.
2.In the event of misuse or abuse of the product or as a result of unauthorized
alterations or repairs.
3.If the serial number has been altered, defaced, or removed.
Please cut along with this line


FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for
a Class B digital device , pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
- This radio is designed for and classified as “Occupational/Controlled Use Only”,
meaning it must be used only during the course of employment by individuals
aware of the hazards, and the ways to minimize such hazards; NOT intended for
use in an General population /uncontrolled environment.
- DO NOT operate the radio without a proper antenna attached, as this may
damage the radio and may also cause you to exceed RF exposure limits. A
proper antenna is the antenna supplied with this radio by the manufacturer or an
antenna specifically authorized by the manufacturer for use with this radio.
- DO NOT transmit for more than 50% of total radio use time, more than 50% of
the time can cause RF exposure compliance requirements to be exceeded.
- This transmitter may operate with the antenna(s) documented in this filing in
Push-to-Talk and body-worn configurations. RF exposure compliance is limited to
the specific belt-clip and accessory configurations as documented in this filing
and the separation distance between user and the device or its antenna shall be
at least 2.5 cm.
Other manuals for RB28
1
Table of contents
Other Retevis Radio manuals

Retevis
Retevis RT98 User manual

Retevis
Retevis RA87 User manual

Retevis
Retevis RA87 User manual

Retevis
Retevis RT69 User manual

Retevis
Retevis NR30 User manual

Retevis
Retevis RA86 User manual

Retevis
Retevis RB39 User manual

Retevis
Retevis RT72 User manual

Retevis
Retevis RB66 User manual

Retevis
Retevis radio series User manual
