Ricoh MP C4504 series Guide

Read this manual carefully before you use this machine and keep it
handy for future reference. For safe and correct use, be sure to read
the Safety Information in this manual before using the machine.
For information not in this manual, refer to
the HTML/PDF files on the supplied CD-ROM.
Using Color Controller
Getting Started
2.
1.
Start Guide
English

English

A-i
TABLE OF CONTENTS
FCC Warning ............................................................................................. A-1
Note to users in the United States of America ............................................A-1
Notes to Canadian Users of ICES-003 Conformance .................................A-2
Remarque concernant les utilisateurs au Canada ......................................A-2
User Information on Electrical and Electronic Equipment ...................A-3
Users in the countries where this symbol shown in this section has been
specified in national law on collection and treatment of E-waste ................ A-3
All Other Users ............................................................................................A-3
For Users in India ........................................................................................A-3
For Turkey only ............................................................................................A-3
Note for the Battery and/or Accumulator Symbol (For EU countries
only)...........................................................................................................A-4
Notes to users in the state of California (Notes to Users in USA) .......A-5
Safety Information....................................................................................A-6
Safety During Operation..............................................................................A-6
Safety Precautions to be Followed ..............................................................A-6
1. Getting Started
Checking the Contents .......................................................................... A-11
For the Site Administrator..........................................................................A-11
For the Service Technician ........................................................................A-11
Guide to Components............................................................................ A-12
Positioning Color Controller.................................................................. A-13
Caution ...................................................................................................... A-13
Space Required for Installation .................................................................A-13
Dimensions and Weight.............................................................................A-14
Environment ..............................................................................................A-14
Moving Color Controller......................................................................... A-15
2. Using Color Controller
Color Controller Startup, Shutdown, and Restart ............................... A-17
Starting the Main Unit and Color Controller...............................................A-17
Shutting Down the Main Unit and Color Controller....................................A-17
Shutting Down Color Controller Only.........................................................A-18
Restarting Color Controller........................................................................A-18
Power Up Sequence ............................................................................... A-19

A-ii

A-1
FCC Warning
Note to users in the United States of America
vNote:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio /TV technician for help.
vCaution:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
vDeclaration of Conformity
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Responsible party: Ricoh Americas Corporation
Address: 5 Dedrick Place, West Caldwell, NJ 07006
Telephone number: 973-882-2000
Product Name: Color Controller
Model Number: E-23C

A-2
Notes to Canadian Users of ICES-003 Conformance
CAN ICES-3 (B)/ NMB-3 (B)
Remarque concernant les utilisateurs au Canada
Avertissement:
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Using the Shield Cable
Properly shielded and grounded cables and connectors must be used for con-
nections to a host computer (and/or peripheral) in order to meet FCC emission
limits.
Installing the Ferrite Core
A network interface cable with a ferrite core must be used for RF interference
suppression.

A-3
User Information on Electrical and
Electronic Equipment
Users in the countries where this symbol shown in this section has
been specified in national law on collection and treatment of E-waste
Our Products contain high quality components and are designed to facilitate
recycling.
Our products or product packaging are marked with the symbol below.
The symbol indicates that the product must not be treated as municipal waste.
It must be disposed of separately via the appropriate return and collection
systems available. By following these instructions you ensure that this product
is treated correctly and help to reduce potential impacts on the environment
and human health, which could otherwise result from inappropriate handling.
Recycling of products helps to conserve natural resources and protect the envi-
ronment.
For more detailed information on collection and recycling systems for this
product, please contact the shop where you purchased it, your local dealer or
sales/service representatives.
All Other Users
If you wish to discard this product, please contact your local authorities, the
shop where you bought this product, your local dealer or sales/service repre-
sentatives.
For Users in India
This product complies with the “India E-waste Rule 2011” and prohibits use of
lead, mercury, hexavalent chromium, polybrominated biphenyls or polybromi-
nated diphenyl ethers in concentrations exceeding 0.1 weight % and 0.01 weight
% for cadmium, except for the exemptions set in Schedule 2 of the Rule.
For Turkey only

A-4
Note for the Battery and/or Accumulator
Symbol (For EU countries only)
In accordance with the Battery Directive 2006/66/EC Article 20 Information for
end-users Annex II, the above symbol is printed on batteries and accumulators.
This symbol means that in the European Union, used batteries and accumula-
tors should be disposed of separately from your household waste.
In the EU, there are separate collection systems for not only used electrical and
electronic products but also batteries and accumulators.
Please dispose of them correctly at your local community waste collection/recy-
cling centre.

A-5
Notes to users in the state of
California (Notes to Users in USA)
Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/haz-
ardouswaste/perchlorate

A-6
Safety Information
Safety During Operation
In this manual, the following important symbols are used:
WARNING:
Indicates a potentially hazardous situation which, if instructions are
not followed, could result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if instructions are not
followed, may result in minor or moderate injury or damage to property.
Safety Precautions to be Followed
This section explains safety precautions that should always be followed when
using this machine.
Environments where the machine can be used
This section explains safety precautions about environments where the machine
can be used.
WARNING:
• Do not use flammable sprays or solvents in the vicinity of this
machine. Also, avoid placing these items in the vicinity of this
machine. Doing so could result in fire or electric shock.
• Do not place vases, plant pots, cups, toiletries, medicines, small metal
objects, or containers holding water or any other liquids, on or close
to this machine. Fire or electric shock could result from spillage or if
such objects or substances fall inside this machine.

A-7
CAUTION:
• Keep the machine away from humidity and dust. Otherwise a fire or an
electric shock might occur.
• Do not place the machine on an unstable or tilted surface. If it topples over,
an injury might occur.
• Do not place heavy objects on the machine. Doing so can cause the
machine to topple over, possibly resulting in injury.
Handling power cords and power plugs
This section explains safety precautions about handling power cords and power
plugs.
WARNING:
• The supplied power cord is for use with this machine only. Do not use
it with other appliances. Doing so could result in fire or electric shock.
• Touching the prongs of the power cable’s plug with anything metallic
constitutes a fire and electric shock hazard.
• Do not use power cords that are damaged, broken, or modified. Also,
do not use power cords that have been trapped under heavy objects,
pulled hard, or bent severely. Doing so could result in fire or electric
shock.
• It is dangerous to handle the power cord plug with wet hands. Doing
so could result in electric shock.
• Do not use extension cords. Doing so could result in fire or electric
shock.
• Do not use multi-socket adaptors. Doing so could result in fire or
electric shock.
• Do not use any power sources other than those that match the
specifications shown. Doing so could result in fire or electric shock.

A-8
CAUTION:
• If this machine is not going to be used for several days or longer at a time,
disconnect its power cord from the wall outlet.
• Be sure to push the plug of the power cord fully into the wall outlet. Partially
inserted plugs create an unstable connection that can result in unsafe
buildup of heat.
• When disconnecting the power cord from the wall outlet, always pull the
plug, not the cord. Pulling the cord can damage the power cord. Use of
damaged power cords could result in fire or electric shock.
• Be sure to disconnect the plug from the wall outlet and clean the prongs
and the area around the prongs at least once a year. Allowing dust to build
up on the plug constitutes a fire hazard.
• When performing maintenance on the machine, always disconnect the
power cord from the wall outlet.
Power Source
100-240 V, 3 A, 50/60 Hz
Please be sure to connect the power cord to a power source as above.
Handling the main machine
This section explains safety precautions about handling the main machine.
WARNING:
• The following explains the warning messages on the plastic bag used
in this product’s packaging.
• Keep the polythene materials (bags, etc.) supplied with this
machine away from babies and small children at all times.
Suffocation can result if polythene materials are brought into
contact with the mouth or nose.
• If the machine topples, or if a cover or other part gets broken, you
must turn off its power immediately. After turning off the power, be
sure to disconnect the power cord plug from the wall outlet.Then
contact your service representative and report the problem. Do not
use the machine. Doing so could result in fire or electric shock.

A-9
• If metal objects, or water or other fluids fall inside this machine, you
must turn off its power immediately. After turning off the power, be
sure to disconnect the power cord plug from the wall outlet.Then
contact your service representative and report the problem. Do not
use the machine. Doing so could result in fire or electric shock.
• Be sure to locate the machine as close as possible to a wall outlet.
This will allow easy disconnection of the power cord in the event of an
emergency.
• If the machine emits smoke or odours, or if it behaves unusually, you
must turn off its power immediately. After turning off the power, be
sure to disconnect the power cord plug from the wall outlet.Then
contact your service representative and report the problem. Do not
use the machine. Doing so could result in fire or electric shock.
• Do not touch this machine if a lightning strike occurs in the immediate
vicinity. Doing so could result in electric shock.
CAUTION:
• Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, take care that the power cord is not damaged
under the machine. Failing to take these precautions could result in fire or
electric shock.
• Contact your service representative if you need to lift the machine (such
as when relocating it to another floor). Do not attempt to lift the machine
without the assistance of your service representative. The machine will
be damaged if it topples or is dropped, resulting in malfunction and risk of
injury to users.
Handling the machine’s interior
This section explains safety precautions about handling the machine’s interior.
WARNING:
• Do not remove any covers or screws other than those explicitly
mentioned in this manual. Inside this machine are high voltage
components that are an electric shock hazard. Contact your sales or
service representative if any of the machine’s internal components
require maintenance, adjustment, or repair.
• Do not attempt to disassemble or modify this machine. Doing so risks
burns and electric shock.

A-10
Handling the machine’s supplies
This section explains safety precautions about handling the machine’s supplies.
CAUTION:
• There is a risk of explosion if a battery is replaced with an incorrect type of
battery. Dispose of used batteries according to the instructions.

A-11
Read this document before installing or using Color Controller.
rRicoh supplied and is responsible for all the material provided in this docu-
ment. If you have questions regarding the material contained in this docu-
ment, please contact Ricoh Americas Corporation.
Checking the Contents
For the Site Administrator
• Media Package
• 2 DVD-ROMs (User Software DVD, System Software DVD)
• CD-ROMs (PCL Printer Drivers CD)
• Quick Setup
• This Document (Start Guide)
• PCL Printer Driver User Software License Agreement
• Gray Scale Kit
• Ferrite Core
• Ferrite Core Installation Guide
• Virtual All Languages Readme *
* Start WebTools and open its [Home] page. When you press the [View] button
in Documentation, a new browser window that shows the document site of the
Color Controller appears, and the site becomes accessible.
For the Service Technician
• Color Controller
• Interface Cable (Gigabit Ethernet)
• Protection Plate (For Fiery Controller)
• Fiery Logo
• AC Power Cable
• Installation Procedure
• Protection Plate (For Engine)
• Memory Board (For Engine)
• Gigabit Ethernet Board (For Engine)
1. Getting Started

A-12
1
Getting Started
Guide to Components
CWB002
1. Power switch
See page A-17 “Color Controller Startup,
Shutdown, and Restart”.
2. Front side USB port
Port for installing system software, acti-
vating Fiery features, or printing from a
prepared USB flash drive.
3. Power indicator
When Color Controller is operating, the
LED is lit.
4. HDD access indicator
While Color Controller HDD is being ac-
cessed, the indicator flashes.
5. Not used (monitor port)
6. Not used (monitor port)
7. Back side USB ports
Ports for installing system software, acti-
vating Fiery features, or printing from a
prepared USB flash drive.
8. Network connector 10/100/1000Mbps
A port for connecting Color Controller to
a LAN.
9. Network connector 10/100/1000Mbps
A port for connecting Color Controller to
the main unit.
10. Power connector
11. Main power switch
See page A-17 “Color Controller Startup,
Shutdown, and Restart”.
12. Service switches (for service use
only)
13. LEDs (2-digit diagnostic display)

A-13
Positioning Color Controller
Positioning Color Controller
Caution
• Insert firmly the plug in the outlet.
• Avoid using an outlet extension plug or cord.
• Ground Color Controller. Avoid using a 3-prong adapter in a 2-hole un-
grounded outlet.
• Do not put anything on the power cord.
Space Required for Installation
Place Color Controller near the power source, providing margins as shown.
CPE003
100 mm
(4 inches)
Front Panel
Back Panel
100 mm
(4 inches)
100 mm
(4 inches)
100 mm
(4 inches)

A-14
1
Getting Started
Dimensions and Weight
• Weight:
5.5 kg (12.1 lb.)
• Dimensions:
Length: 362.5 mm (14.3 inches)
Height: 294.6 mm (11.6 inches)
Width: 124.3 mm (4.9 inches)
Environment
Environmental specifications Operating
Ambient temperature 5 °C to 40°C (41 °F to 104 °F)
Relative humidity 10% to 85% (non-condensing)
Altitude 3048 m (10,000 feet)

A-15
Moving Color Controller
Moving Color Controller
CAUTION:
• When disconnecting the power cord from the wall outlet, always pull the
plug, not the cord. Pulling the cord can damage the power cord. Use of
damaged power cords could result in fire or electric shock.
CAUTION:
• Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, take care that the power cord is not damaged
under the machine. Failing to take these precautions could result in fire or
electric shock.
CAUTION:
• Contact your service representative if you need to lift the machine (such
as when relocating it to another floor). Do not attempt to lift the machine
without the assistance of your service representative. The machine will
be damaged if it topples or is dropped, resulting in malfunction and risk of
injury to users.
rWhen moving the machine, the following precautions should always be fol-
lowed:
• Turn off the main power. See page A-17 “Shutting Down the Main Unit
and Color Controller” or page A-18 “Shutting Down Color Controller
Only”.
• Unplug the power cord from the wall outlet. When doing this, grip
the plug so as not to stress the cord, reducing the risk of fire or electric
shock.
rMove the machine carefully. If you do not, the machine might be damaged
or data lost.
rProtect the machine from impact. Shock could damage the hard disk and
result in data loss.

A-16
1
Getting Started
