Technical Bulletin PAGE: 1/1
Model: Stella-C1 Date: 21-Feb-02 No.: RB044003
Subject: Notice at installing the FAX option Prepared by: M.Ishihara
From: Technical Services Dept., GTS Division
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Other ( )
S-C1a (B045) S-C1aF (B049) S-C1b (B044) S-C1bF (B046) S-F1 (H555)
When installing the fax option, please note the following:
For Australia:
Units must be connected to a telecommunications network through a line that
complies with the ACA Technical Standards TS008.

T echnical B ulletin
PAGE: 1/1
Model: Model S-C1 Copy model Date: 18-Dec-03 No.: RB044009
Subject: Com SW16 setting at FAX option installation Prepared by: A. Ishiyama
From: 1st Tech. Support Sec. Service Support Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Other ( )
S-C1a (B045) S-C1aF (B049) S-C1b (B044) S-C1bF (B046) S-F1 (H555)
Important setting for model S-C1 fax option installation
When installing the fax option (new FCU board, NCU board) on the Stella-C1, be sure to
perform the following to ensure the fax function is properly enabled.
1. As described in the Installation Manual, first back up the SRAM data on the original
FCU board for installation to the new fax option FCU board.
2. Replace the FCU with new FCU board in accordance with the installation procedure,
and then upload the SRAM data backed up in Step 1 to the new FCU board.
3. Change Com SW16 to a setting of 1.
Communication Switch 16
No FUNCTION COMMENTS
0 Standard G3 (NCU)
0: Disabled
1: Enabled
0: Change this bit to 0 if you wish to disable the
standard G3 line.
1: Change this bit to 1 to enable the standard G3
line when installing the fax option.

T echnical B ulletin
PAGE: 1/4
Reissued: 22-Oct-04
Model: Model S-C1 Date: 14-Sep-04 No.:
RB044013a
RTB Correction
The items in bold italics have been corrected or added.
Subject: Fax Option Firmware History (FCU Board) Prepared by: A.Ishiyama
From: 1st Tech. Support Sec. Service Support Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Other ( )
S-C1a (B045) S-C1aF (B049) S-C1b (B044) S-C1bF (B046) S-F1 (H555) S-F2 (H556/H557)
The following is the printer controller firmware history for the Model S-C1 fax option.
(Until now, the firmware history was attached to the firmware file as “Readme.txt”. So, all
history has been gathered here in this RTB.)
A. File Information
[EU/Asia Models]
EU1/Asia EU2 EU3 EU4
Part Number Part Number Part Number Part Number
Version
Sum 1 Sum 2 Sum 1 Sum 2 Sum 1 Sum 2 Sum 1 Sum 2
Production
H5557200M H5557201M H5557202M H5557203M
91
5974 DF65 304C 3A1F A31C 3E58 5E19 CDD3
Aug ‘04
H5557200L H5557201L H5557202L H5557203L
90
6650 4CE7 904C A7F5 9331 ABC3 F8A0 3B7E
March ‘03
H5557200K H5557201K H5557202K H5557203K
88
_180
F1EB 7988 F592 2A97 6928 0B66 D54E 698A
Oct. ‘02
H5557200K H5557201K H5557202K H5557203K
87
9F20 1BD9 AF6A 1D21 6669 A773 38B7 63DF
Aug ‘02
H5557200J H5557201J H5557202J H5557203J
84
E14C 2E5E F2E6 82CB 2776 1E78 27DF 8E28
Mar ‘02
H5557200G H5557201G H5557202G H5557203G
78
3B4B 7A70 5711 082A 44D8 D6C0 5F4B A577
Oct ‘01
H5557200F H5557201F H5557202F H5557203F
77
A122 3611 2475 A054 D1F2 F0E4 290E DF4F
1st Mass Production.
[NA Model]
Part Number
Version
Sum 1 Sum 2
Production
H5557205M
91
D2E5 3B6D
Aug ‘04
H5557205L
90
D3CD A8EA
March ‘03
H5557205K
88 _180
B1F3 DF53
Oct. ‘02
Note:Sum 1 = Check Sum on IC card (8 bit),
Sum 2 = Total Check Sum on machine (16 bit)

T echnical B ulletin
PAGE: 2/4
Reissued: 22-Oct-04
Model: Model S-C1 Date: 14-Sep-04 No.:
RB044013a
Part Number
Version
Sum 1 Sum 2
Production
H5557205K
87
5863 F943
Aug ‘02
H5557205J
84
8E4C 770E
Mar ‘02
H5557205G
78
B84E 0AE7
Oct ‘01
H5557205F
77
4A29 3027
1st Mass Production.
[China/Korea Models]
CHINA KOREA
Part Number Part Number
Version
Sum 1 Sum 1 Sum 1 Sum 1
Production
H5557206C H5557208C
91
20E7 5969 5969 FA01
Aug ‘04
H5557206B H5557208B
90
C9CA 812A 812A 617E
March ‘03
H5557206A H5557208A
88 _180
F28C 8ED8 8ED8 E14D Nov ‘02
H5557206A H5557208A
87
CA8A C69C C69C 8547 Aug ‘02
H5557206 H5557208
85
5C49 C9BA C9BA F7D5
1st Mass Production.
[Russia Model]
Part Number
Version
Sum 1 Sum 2
Production
H5557207B
91
E406 C7D8
Aug ‘04
H5557207A
90
88C2 37C8
March ‘03
H5557207
88 _180
8038 00E7
Nov ‘02
H5557207
87
DC9D 1DE0 1st Mass Production.
[Hong Kong Model]
Part Number
Version
Sum 1 Sum 2
Production
H5557209
86
EB9A 9909
Jun ‘02

T echnical B ulletin
PAGE: 3/4
Reissued: 22-Oct-04
Model: Model S-C1 Date: 14-Sep-04 No.:
RB044013a
[Language List]
The following table lists the entire array of firmware versions:
No. Language NA EU1/Asia EU2 EU3 EU4 China Russia Korea HK
1 English O O O O O O O O O
2 French O O
3 Spanish O O
4 German O
5 Italian O
6Dutch O
7 Danish O
8 Swedish O
9 Norwegian O
10 Finnish O
11 Portuguese O O
12 Polish O
13 Hungarian O
14 Czech O
15 Simplified
Chinese O
16 Russian O
Total/Firmware
*1
4 5 3 5 4 2 2 1 1
*1: “Total/Firmware” indicates the total number of languages stored in a particular firmware version.
B. Change Descriptions
Symptom Corrected / Other Changes Version
! Sometimes, the operator can clear a fusing SC error with power Off/On (see
RTB RB044014 for details).
Important: After you install this firmware, clear the SC history. There are two
ways to do this:
1. Execute Sp5-810, OR
2. Change Plotter bit SW01, bit 0 to a value of: “1”
91
! Offset images 90
! Offset images on the right side only. 88
_180
! Italian wording mistake:
Incorrect: Original jam
Correct: Copy paper jam
! Software changed to decrease unnecessary occurrences of SC551.
87
! Change due to request from the field (Hong Kong only):
The value of the total counter can be printed out in UP Mode. 86

T echnical B ulletin
PAGE: 4/4
Reissued: 22-Oct-04
Model: Model S-C1 Date: 14-Sep-04 No.:
RB044013a
Symptom Corrected / Other Changes Version
v78 to 81:
1. The machine changes to Memory Reception when Polling Reception is selected.
2. The printer ROM P/N is not printed correctly on the SMC.
3. The printer stalls if the front door or right door is opened when printing
starts.
4. Half-letter sized paper is not counted.
5. SC547 (caused by CIOP failure).
v81 to 84:
6. Translation errors in display messages (Swedish, German).
7. Copies cannot be made from the bypass tray when the operator does the
following:
- Loads 5 originals in the ADF, 3 sheets in the bypass tray
- Selects another tray after the machine feeds the bypass sheets.
- Loads more paper in the bypass tray
84
1. The machine stays in Copy mode even when the toner bottle or THM is
removed, and triggers a false SC322 detection.
2. Fax: Sometimes there are some images missing on the transmission
report, or the report cannot be printed out at all.
3. Fax: Sometimes the line connection is cut when the page memory is full.
78
