ASSEMBLY INSTRUCTIONS
RiverRidge® Ashland Spacesaver
ITEM #: 06-090 White
ITEM #: 06-091 Gray
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF 60
POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS. IF LOADED WITH
MORE THAN 20 POUNDS PER SHELF AS THIS MAY CAUSE DAMAGE TO THE SHELF
AND MAY CAUSE SERIOUS INJURY OR DEATH.

PARTS LIST
NO
QTY
DESCRIPTION
1
1PC
Top Board
2
1PC
Top Left Side Panel
3
1PC
Top Right Side Panel
4
1PC
Bottom Left Side Panel
5
1PC
Bottom Right Side Panel
7
1PC
Adjustable Shelf
8
1PC
Fixed Shelf
9
1PC
Middle Connection Board
10
1PC
Front Middle Cross Bar
11
1PC
Rear Middle Cross Bar
12
1PC
Rear Bottom Cross Bar
13
1PC
Upper Back Board
14
1PC
Middle Back Board
15
1PC
Lower Back Board
16
1PC
Left Door
17
1PC
Right Door

NO
PART
QTY
DESCRIPTION
A
18PCS
Wood Dowel
B
4PCS
Cam Bolt
C
4PCS
Cam Lock
D
6PCS
Screw (4x40mm)
E
4PCS
Screw (4x50mm)
F
4PCS
Machine Screw (6x65mm)
G
4PCS
Metal Nut
H
2PCS
Screw (3x14mm)
I
1PC
Allen Wrench
J
1PC
Magnet
K
2PCS
Magnet Plate
L
18PCS
Screw (3x10mm)
M
4PCS
Metal Hinge
N
2PCS
Machine Screw (4x15mm)
O
2PCS
Knob
P
4PCS
Shelf Holder
Q
2PCS
Plastic Anchor
R
1PC
Plastic Connection Strip
S
2PCS
Screw (4x30mm)
T
2PCS
Adjustable Anchor Bracket
U
2PCS
Screw (4x10mm)
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
To order replacement parts at no cost to you, email [e-mail], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.

STEP 1
1. Screw 1 cam bolt (B) into cam bolt hole on top left side panel (2).
2. Insert 4 wood dowels (A) into dowel holes on end of top left side panel (2).
3. Repeat above steps for top right side panel (3).
STEP 2
1. Insert 2 wood dowels (A) into dowel holes on bottom left side panel (4) and bottom
right side panel (5).

STEP 3
1. Attach 2 adjustable anchor brackets (T) to top board (1) by inserting 2 screws (U) through
holes on adjustable anchor brackets (T), then tighten to top board (1).
2. Screw 2 cam bolts (B) into cam bolt holes on top board (1).
3. Attach magnet (J) to top board (1) by inserting 2 screws (H) through holes on magnet (J)
and tighten to top board (1).
4. Insert 4 wood dowels (A) into dowel holes on end of fixed shelf (8).
STEP 4
1. Insert 2 wood dowels (A) into dowel holes on end of front middle cross bar (10) and rear
middle cross bar (11).
2. Insert 2 metal nuts (G) into holes on front middle cross bar (10) and rear middle cross
bar (11).

STEP 5
1. Attach magnet plate (K) to left door (16) by inserting 1 screw (L) through hole on magnet
plate (K) and tighten to left door (16).
2. Attach 2 metal hinges (M) to left door (16) by inserting 4 screws (L) through holes on
metal hinges (M) and tighten to left door (16).
3. Attach knob (O) to left door (16) by inserting 1 machine screw (N) through hole on left
door (16) and tighten to knob (O).
4. Repeat above steps for right door (17).
STEP 6
1. Attach top left side panel (2) and top right side panel (3) to fixed shelf (8) by inserting
cam bolt (B) into cam lock hole and inserting wood dowels (A) into wood dowel holes.
2. Insert 2 cam locks (C) into cam lock holes on fixed shelf (8) and rotate clockwise to
secure cam bolt in place.

STEP 7
1. Slide lower back board (15) into grooves on top left side panel (2), top right side panel (3)
and fixed shelf (8).
2. Attach middle connection board (9) to top left side panel (2), top right side panel (3) and
lower back board (15) by inserting lower back board (15) into groove on middle connection
board (9) and wood dowels into wood dowel holes on middle connection board (9).
3. Insert 2 wood screws (D) through holes on middle connection board (9) and tighten to top
left side panel (2) and top right side panel (3).
STEP 8
1. Slide middle back board (14) into grooves on top left side panel (2) and top right side
panel (3).
2. Add 1 plastic connection strip (R) on middle back board (14) and slide upper back board
(13) into grooves on top left side panel (2) and top right side panel (3).
3. Attach top board (1) to top left side panel (2), top right side panel (3) and upper back board
(13) by inserting upper back board (13) into groove on top board (1) and wood dowels into
wood dowel holes on top board (1).
4. Insert 2 cam locks (C) into cam lock holes on top left side panel (2) and top right side
panel (3) and rotate clockwise to secure cam bolts in place.

STEP 9
1. Attach front middle cross bar (10) and rear middle cross bar (11) to bottom left side panel (4)
and bottom right side panel (5) by inserting wood dowels (A) into wood dowel holes on
bottom left side panel (4) and bottom right side panel (5).
2. Insert 4 machine screws (F) though holes on bottom left side panel (4) and bottom right side
panel (5) then tighten to the metal nuts (G) using Allen wrench (I).
STEP 10
1. Attach upper assembled unit to lower assembled unit by inserting wood dowels (A) into
wood dowel holes on middle connection board (9).
2. Insert 4 screws (D) through holes on bottom left side panel (4) and bottom right side
panel (5) and tighten to middle connection board (9).

STEP 11
1. Attach rear bottom cross bar (12) to bottom left side panel (4) and bottom right side panel
(5) by inserting 4 screws (E) through holes on bottom left side panel (4) and bottom right
side panel (5) and tighten to rear bottom cross bar (12).
2. Attach left door (16) to top left side panel (2) by inserting 4 screws (L) through holes on
metal hinges (M) and tighten to top left side panel (2).
3. Attach right door (17) to top right side panel (3) by inserting 4 screws (L) through holes on
metal hinges (M) and tighten to top right side panel (3).
STEP 12
1. Insert 4 shelf holders (P) into holes on top left side panel (2) and top right side panel (3).
2. Place adjustable shelf (7) onto shelf holders (P).

STEP 13
Option #1: Securing to Drywall
1. Position spacesaver against wall in desired location. Using a pencil, make 2 small marks on
wall through holes on anchor brackets (T). Move cabinet away from wall and screw 2 plastic
anchors (Q) into wall on pencil marks.
2. Place cabinet against wall, insert 2 screws (S) through holes on anchor brackets (T), then
tighten to plastic anchors (Q).
Option #2: Securing to Drywall and Wood Stud
1. Position spacesaver against wall in desired location. Insert 2 screws (S) through holes on
anchor brackets (T), then tighten through drywall and into wood stud.
*Tip: Anchor brackets (T) can be adjusted to correct distance from wall to cabinet as needed. Once
adjusted, be sure to re-tighten brackets inside cabinet for stability.
ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure your item is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

Enjoy your new RiverRidge® Spacesaver!
Thank you for purchasing this RiverRidge® Home item. We hope you
enjoy it and consider purchasing other RiverRidge® items.
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016
