RiverRidge SOMERSET SPACESAVER06-040 XS User manual

ASSEMBLY INSTRUCTIONS
RiverRidge® SOMERSET SPACESAVER
ITEM #: 06-040 XS WHITE
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of the small parts. Care should be
taken in unpacking and assembling this item to keep the small parts away from children.
WARNING
Young children can be seriously injured or killed, if furniture tips over.
Don’t use this item for a TV stand.
Use angle-braces or anchors to secure furniture to the wall.

Send requests for missing or damaged parts replacements by email to :
[email protected] or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS. DO
NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS. IF LOADED WITH MORE THAN 25
POUNDS PER SHELF AS THIS MAY CAUSE DAMAGE TO THE SHELF AND MAY CAUSE SERIOUS
INJURY OR DEATH.

PARTS LIST

TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF POWER SCREWDRIVER IS NOT RECOMMENDED.

STEP 1
STEP 1
1.Attach 1 magnet plate (F) to left door (1) by inserting 1 wood screw (D) through hole on magnet plate(F) then
tighten to left door (1) by using a Philips screwdriver.
2.Attach 1 Handle (K) to left door (1) by inserting 2 Machine screw (J) through the holes on left door (1) then
tighten to Handle (K) by using a Philips screwdriver.
3.Repeat the above steps to assemble another Magnet plate (F) & Handle (K) to right door (2).
STEP 2
STEP 2
1. Insert 2 wood dowels (A) into dowel holes on the right support board (13) .
2. Screw in 3 cam bolts (B) into the pre-threaded holes on the right support board (13) by using a Philips
screwdriver.
3. Attach 2 Hinges (E) to the right support board (13).
4. Insert 4 wood screws (D) through holes on the Hinge (E) then tighten to the right support board (13) by using a
Philips screwdriver.
5. Repeat the above step to assemble left support board (14) and another 2 Hinges (E).

STEP 3
STEP 3
1.Attach right support board (13) to upper right side panel (3) by inserting 2 wood dowels (A) into dowel holes and
inserting 3 cam bolts (B) into cam lock holes in the upper right side panel (3).
2. Insert 3 cam locks (C) into the cam lock holes on the upper right side panel (3) then rotate clockwise to secure
cam bolts (B) in place by using a Philips screwdriver.
3. Repeat the above step to assemble upper left side panel (4) and right support board (14).
STEP 4
STEP 4
1. Screw in 2 cam bolts (B) into the pre-threaded hole on upper left side panel (4) and upper right side panel (3) .
2. Insert 8 wood dowels (A) into dowel holes on upper left side panel (4) and upper right side panel (3).
3. Attach the upper section cross bar (5) to upper left side panel (4) by inserting 2 wood dowels (A) into dowel
holes on the upper section cross bar (5).
4.Attach the shelf (6) to upper left side panel (4) by inserting 1 cam bolt (B) and 2 wood dowels (A) into holes on
the shelf (6), then insert 1 cam lock (C) into cam lock hole on the shelf (6) and rotate clockwise to secure the cam
bolt (B) in place.
5.Attach upper right side panel (3) to the upper section cross bar (5) and shelf (6) by inserting 4 wood dowels (A)
into holes on the upper section cross bar (5),shelf (6) and inserting cam bolt (B) into holes on the shelf (6).
6. Insert 1 cam lock (C) into the cam lock hole on the shelf (6) and rotate clockwise to secure the cam bolt (B) in
place by using a Philips screwdriver.

STEP 5
STEP 5
1.Attach the Magnet (H) to the bottom of top board (7) by inserting 2pc wood screw through the holes on the
Magnet (H) and tighten to the top board (7).
2.Screw in 4pc cam bolt (B) into the pre-threaded holes on the top board (7).
3.Attached the top board (7) to the upper left side panel (4) and upper right side panel (3) by inserting the cam
bolt (B) into the cam lock holes on the upper left side panel (4) and upper right side panel (3).
4.Inert 4pc cam lock (C) into the cam lock holes on the upper left side panel (4) and upper right right side panel
(3), then rotate clockwise to secure the cam bolt (B) in place by using a Philips screwdriver.
STEP 6
STEP 6
1. Screw in 4pc cam bolt (B) into the pre-threaded holes on the lower left side panel (18) and lower right side
panel (17).
2. Attach 2pc lower section top cross bars (15) to lower left side panel (18) by insert the cam bolt (B) into the cam
lock holes.
3. Insert 2pc cam locks (C) into the cam lock holes on the lower section top cross bars (15), then rotate
clockwise to secure the cam bolt (B) in place by using a Philips Screwdriver.
4. Attach the rear lower cross bar (16) to lower left side panel (18) by insert the dowels into the holes on the
lower left side panel (18).
5. Attach the lower right side panel (17) to lower section top cross bars (15) and lower cross bar (16) by insert the
cam bolt (B) into the cam lock holes on the lower section top cross bars (15) and inert the dowels into the
dowel holes on the lower section top cross bar (15) and lower right side penal (17).
6. Insert 2pc cam locks (B) into the cam lock holes on the lower section top cross bars (15) then rotate clockwise
to secure the cam bolt (B) in place by using a Philips Screwdriver.

STEP 7
STEP 7
1. Screw in 2pc cam bolt (B) into the pre-threaded holes on the middle connection board (8).
2. Insert 8pc wooden dowels (A) into the holes on the lower left side panel (18), lower right side panel (17) and
lower section top cross bars (15).
3. Turn over board(8) over and attach to pre-assembled lower left side panel (18), lower right side panel (17) and
lower section top cross bars (15) by insert the wood dowel (A) into the dowel holes and insert the cam bolt
(B) into the cam lock holes on the lower left side panel (18), lower right side panel (17) and lower section top
cross bars (15).
4. Insert 2pc cam locks (C) into the cam lock holes on the lower left side panel (18) and lower right side panel
(17), then rotate clockwise to secure the cam bolt (B) in place by using a Philip Screwdriver.
5. Screw 4pc wooden screws (O) through the holes on the lower left side panel (18) and lower right side panel
(17) and tighten to rear lower cross bar (16).

STEP 8
STEP 8
1. Screw in 4pc cam bolt (B) into the pre-threaded holes on the middle connection board (8).
STEP 9
STEP 9
1. Attach the upper assembled section to lower assembled section by insert 4 cam bolt (B) into the cam lock
holes on the
upper left side panel (4) and upper right side panel (3).
2. Insert 4pc cam locks (C) into the cam lock holes on the upper left side panel (4) and upper right side panel (3),
then rotate
clockwise to secure the cam bolt (B) in place by using a Philips Screwdriver.

STEP 10
STEP 10
1.Attach upper back board (9) & middle back board (10) together sliding into plastic connection strip (N).
2.Attach upper back board (9) and middle back board (10) to the cabinet by inserting 8 wood screws (G) through
holes on upper back board (9) then tighten into the cabinet, and inserting 4 wood screws (G) through holes on
the middle back board (10) then tighten into the cabinet by using a Philips screwdriver.
3.Attach lower back board (11) to the cabinet by inserting 8 wood screws (G) through holes on lower back board
(11) then tighten into the cabinet by using a Philips screwdriver.
4.Insert 2 wood screws (G) through holes on the joint area of middle back board (10) and lower back board (11)
then tighten into the cabinet by using a Philips screwdriver.
STEP 11
STEP 11
1. Attach left door (1) to left side panel (3) by inserting 4 wood screws (D) through holes on the hinge (E) then
tighten into left door (1) by using a Philips screwdriver.
2 . Repeat the above step to assemble the right door (2).

STEP 12
STEP 12
1. Place the drawing with hole position on the wall that you desire to fix the spacesaver, drill 2 holes on the wall.
2. Insert 2 plastic anchor (L) into the holes on the wall
3. Attach the pre-assembled Spacesaver in place w/holes, then insert 2 long wood screws (M) through holes on
the upper section cross bar (5) and tighten into 2 plastic anchors (L) in the wall.
STEP 13
STEP 13
1. Insert 4 shelf holders (I) into holes on upper left side panel (3) and upper right side panel (4).
2. Make sure these 4 shelf holders (I) are on the same height.
3. Put the adjustable shelf (12) onto the shelf holders (I).

ENJOY YOUR NEW RiverRidge® CABINET NOW !
Attention Adults: The cabinet should be checked periodically for damage or loose screws/parts.
Take appropriate action necessary to correct the hazard such as tightening of screws and taking
any damaged parts away from the children.
Thank you for purchasing this RiverRidge® Home Products item. We hope you enjoy it, and
consider purchasing other RiverRidge® items.
Send requests for missing or damaged parts replacements by email to :
[email protected] or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016.
