Roadragon G-MT008G User manual

G-MT008G User manual
0
User Manuel
G-MT008G

G-MT008G User manual
1
Contents
1 Introduction.................................................................................................................................................... 2
1.1 product description..............................................................................................................................2
2 Product Overview...........................................................................................................................................2
2.1 Product accessories............................................................................................................................. 2
2.2 Interface Definition.............................................................................................................................3
2.3 Parameters...........................................................................................................................................4
2.4 Function.............................................................................................................................................. 4
3 Getting Started............................................................................................................................................... 5
3.1 Installing a SIM Card..........................................................................................................................5
1 Preparatory work before installation............................................................................................. 5
2 installation......................................................................................................................................6
3 Definition of terminal outgoing line..............................................................................................6
3.2 Scenario...............................................................................................................................................7
3.3. terminal parameter setting................................................................................................................. 8
3.3.1. Service center number setting.................................................................................................8
3.3.2. User password modification................................................................................................... 8
3.3.3. Increase the specific number of SOS......................................................................................8
3.3..4. Query a specific number C10#.............................................................................................. 8
3.3.5. Query parameter setting CXZT.............................................................................................. 8
3.3.6.Setting GPRS transmission location data interval time.......................................................... 8
3.3.7. The interval setting of entering dormancy............................................................................. 9
3.3.8.Setting up time setting for fortification................................................................................... 9
3.3.9. language and time zone settings............................................................................................. 9
3.3.10. The IP address and port number of the server platform.......................................................9
3.3.11. Restart the terminal...............................................................................................................9
3.3.12. Restore the factory setting.................................................................................................... 9
3.4. terminal operation.............................................................................................................................. 9
3.4.1 start / turn off........................................................................................................................... 9
3.4.2 message Chinese address query.............................................................................................10
3.4.3 location network linked SMS query......................................................................................10
3.4.4 platform query........................................................................................................................10
3.4.5 fortification and withdrawal.................................................................................................. 10
3.4.6 broken off power....................................................................................................................10
3.4.7 SOS alarm.............................................................................................................................. 10
3.4.8 power off alarm......................................................................................................................10
3.4.9 shock alarm............................................................................................................................ 10
3.4.10. Vibration time setting......................................................................................................... 11
3.4.11 Voice monitor...................................................................................................................... 11

G-MT008G User manual
2
1 Introduction
1.1 product description
The G-MT008G is a simple GPS device for tracking cars and motorcycles. Track your assets in r
eal time and cut off the car's power. and the 3G version is optional.
2 Product Overview
2.1 Product accessories
Items
description
Main device
Power cord
Relay（optional）
Microphone（optional)
SOS Alarm button(optional)

G-MT008G User manual
3
Fixed magic stick
2.2 Interface Definition
Host interface

G-MT008G User manual
4
Relay connection instructions
The connection method of the oil pump circuit breaker relay: the wire ends of the coil are fine white
line (85) and the fine green line (86), the fine white line (85) is connected to the positive pole (+12V)
of the automobile power supply, and the fine green line (86) is connected to the terminal relay contr
ol line.
The oil pipe of the controlled vehicle is connected with the oil pump, which is cut off the positive co
nnection line of the oil pump. The oil pump is directly connected to the constant end of the relay (the
green line 87A), and the other end is connected to the common end of the relay (the green line 30).
Note: the product is 12V relay. Suitable for vehicles equipped with 12V battery.
If the vehicle is equipped with 24V battery car, 24V relay should be selected separately.
1. Precautions for equipment wiring
Power, ACC, oil cut electric control line (4Pin)
The standard power supply for this equipment is 9V~80VDC. Please select the power line supplied by
the original factory, the red line is the positive pole of the power supply, and the black line is the n
egative pole of the power supply. When installing the power negative pole, please choose a separate gr
ounding or grounding, and do not connect with other ground wires.
2.3 Parameters
Items
description
Size of the whole
machine size
98*53*13mm
weight
50g
Input power supply
DC 9V~80V/1.5A
Backup battery
180mAh/4.2V
Normal standby
power
< 50mA/12V's ordinary standby current
working temperature
-30 C ~75 C
Working humidity
5%~95%
Working hours
Power saving for 6 hours, normally open for 4 hours
LED indicator lamp
The 3 LED indicator indicates the GSM/GPS state and working status
Button / switch
1 SOS buttons (for short message or dialing).
GSM band
GSM 850/900/1800/1900MHz, UMTS850/2100
GPS chip
UBXLO-7020 generation high sensitivity chip
GPS sensitivity
-159dB
positioning accuracy
10 meters
2.4 Function
1. Adopt UBXLO-7020 GPS module and 3G (HSDPA/WCDMA) communication module.
2. GPS+GSM base station dual mode location
3. Data communication: SMS/GPRS/HSDPA R5/WCDMA R99/EDGE/CSD (TCP/UDP)
4. Real-time query location

G-MT008G User manual
5
5. Chinese address query
6. Timed tracking
7. Pitch tracking
8. Mobile phone positioning
9. Built-in large capacity standby battery
10. Electronic fence
11. GPS blind area alarm
12. An electric alarm
13. Speeding alarm
14. Mileage report
15. Pronunciation monitoring (selection)
16. SOS emergency alarm (selection)
17. Remotely cutting off car oil / electricity (selection)
3 Getting Started
3.1 Installing a SIM Card
1 Preparatory work before installation
1.1 Open the packing box, check whether the type of the equipment is correct, whether the accessories are
complete or not, please contact your dealer.
1.2 SIM card selection, terminal need to insert a GSM SIM card, SIM card selection, please refer to the
dealer's opinion.
1.3 SIM card installation, on the left side of the terminal has a SIM card slot, open the SIM card seal ring,
the SIM card metal face inserted into the SIM card slot (pay attention to SIM card do not reverse), insert in
place can hear click sound, otherwise the SIM positive and reverse direction should be reinserted, the back
cover back to seal the apron.

G-MT008G User manual
6
Be careful：
The terminal SIM card needs to open the GPRS function.
The terminal SIM card needs to open the caller display.
2 installation
The installation mode of the terminal is hidden installation. The hidden installation of terminal equipment
is recommended by the professional institution designated by the distributor.
2.1 in order to avoid thieves' destruction, the location of equipment should be hidden as far as possible.
2.2 avoid being placed with launch sources, such as reversing radar, burglar alarm and other vehicle
communication equipment.
2.3 can be fixed with bandage or glued with wide sponge and strong double-sided adhesive.
2.4 equipment is equipped with GSM antenna and GPS antenna. When installing, it should ensure that it is
upwards (skyward) and has no metal shielding shielding.
The front windshield is hidden beneath the plate.
The front dial dial (epidermis is non-metallic material) around the concealed place;
Underneath the rear windshield;
3 Definition of terminal outgoing line
3.1 Precautions
1, the terminal has been unable to connect to the background server after the first installation, and the
background display is not on-line.
Please check the terminal installation:
1) the main power supply wiring is correct, attention should not be connected to the internal control
line of the car.
2) whether SIM is installed correctly, please refer to the installation instructions.
3) if the ACC ignition line is connected, then insert the vehicle key and open the ACC.
4) check the status of the LED indicator. Normally, the red power status indicator lights up for 0.1
seconds to extinguish 2 seconds. The Yellow GPS status indicator is long and the blue GSM status
indicator is long and bright.
5) check if GPS has been positioned. If it is not located, go to the open space for the first time
Location.
2, the terminal displays the off-line state in the background.
First, observe whether the 3 indicators of the device are normal. Without the condition observation,
you can check the status of the card first. The steps are as follows:
1) dial the SlM card number of the device to see if you can hear the call.
2) whether the vehicle has not covered the GSM network signal in the basement.

G-MT008G User manual
7
3) observe the dropped area, whether the individual dropped or all dropped, so as to determine
whether it is the operator's network problem.
4) whether the SIM card is in arrears.
5) whether the GPRS service has been canceled (the last day of the end of the month is offline).
6) query parameter settings. See if the device serial number and GPRS transmission interval are
correct.
3, if the terminal GPS function has been activated, but it has not been positioned for a long time,
please check whether the installation location of the terminal meets the requirements:
1) when the terminal is installed, the GPS antenna should face to the sky.
2) the terminal installation position must be the place where the material (such as metal) is shielded
without electromagnetic wave absorption. In particular, attention should be paid to the vehicle glass at the
top of the terminal not attached to the explosion-proof heat insulation film (the high metal components in
the film composition will absorb the high frequency electromagnetic wave), otherwise the GPS signal will
receive a large attenuation and lead to the positioning accuracy. When it comes down, it can even make it
difficult to locate the terminal.
4, when the GPS signal reception environment is poor (surrounded by tall buildings blocking the GPS
signal), please drive to the open space to locate the sky. It takes 1-2 minutes for the first time to locate the
time.
5, when the GSM signal receives an exception, please check that the terminal's SIM card is properly
installed, or where the GSM signal may not be covered (such as in the basement), please drive to a place
where the GSM signal is covered.
6, when the center number cell phone receives a blackout warning message, determine whether to cut
the line illegally. Otherwise, please check the fuse of the power line. If the fuse is broken, please contact
your dealer to replace the same type of FUSE, and check out the internal fault after the termination of the
terminal.
3.2 Scenario

G-MT008G User manual
8
3.3. terminal parameter setting
All the following function parameters set up the letter in the instruction format. All the symbols are E
nglish punctuation. All the instructions are sent back. The parameter instruction is set successfully. Oth
erwise, it needs to be reset. Sending the corresponding query command terminal will reply to the corre
sponding query content.
3.3.1. Service center number setting
If you need to use SMS to carry out the operation of oil breaking electricity or recovery of oil and el
ectricity, you must set up the service center number first, the terminal only accept the service center n
umber sent off oil short message instruction, you can set your mobile phone number to the service cen
ter number. In order to ensure the security of users, the setting of service center numbers requires the
input of passwords. The initial password is 123456, which can be modified.
Short message instruction to add service center number: admin123456 136********#
Example: admin123456 13524258458#
If the service center number is set successfully, reply to "admin OK!".
3.3.2. User password modification
The user's initial password is 123456, and the user can modify it by itself. The number of bits is
fixed to 6 bits.
SMS instructions for modifying passwords: password123456 XXXXXX#
Example: password123456 666888#
If the password is modified successfully, reply to the "password OK password 666888" message.
3.3.3. Increase the specific number of SOS
Set the SOS number to send the following SMS through the center number mobile phone to add the
SOS number:
101#136********# then revert to the first specific number of OK, which is the same as the owner nu
mber.
102#136********# then revert to OK 102 for the first SOS specific number.
103#136********# then revert to OK 103 for second SOS specific numbers.
D101# replies to OK D101# to delete the first number
D102# replies to OK D102# to delete second numbers
D103# replies to OK D103# to delete third numbers
3.3..4. Query a specific number C10#
Example: C10# replies to 101# 102# 103#
3.3.5. Query parameter setting CXZT
When you need to query the parameters setting of the terminal device, you can write the parameter set
ting query SMS to the terminal device SIM card number, and the terminal will respond to the corresp
onding parameter settings.
Query parameter instruction format: CXZT
Example: CXZT
Reply information:XM76_GT01M_SW_1.0 2017/09/23
ID:6180125036
IP:123.1.150.82 2332
BAT:5
APN:CMNET
GPS:A-14-10
GSM:2G-25
ICCID:89860000191777041198
3.3.6.Setting GPRS transmission location data interval time
The terminal default GPRS transmission location data interval is 120S, that is, upload every
120 seconds to the background server.
Locate the data. To set the GPRS transport location data interval, you can edit the GPRS
timing setting instructions.

G-MT008G User manual
9
Upmove123456 120 reply to Set OK upload interval settings (default 120 seconds)
3.3.7. The interval setting of entering dormancy
Auto123456 reply Set OK automatic working mode (default) device without any alarm, no operation af
ter 5 minutes, the device enters the dormancy state: GPS, GPRS. Telephone or SMS or shock will wa
ke up equipment immediately.
The time interval from the working state to the dormancy state of the terminal is 5 minutes.
Instruction format: sleep,123456,10 reply OK, open sleep 10: for 10 minutes 0: means no sleep.
3.3.8.Setting up time setting for fortification
When the vehicle power is closed, the terminal ACC line is low. If the power supply is not opened w
ithin 3 minutes, the terminal will enter the fortification state. If the vehicle is set up, the vehicle will
vibrate continuously for 5 seconds and will trigger the vibration anti-theft alarm mechanism. In the nex
t 3 minutes, the power supply of the vehicle is still unopened (ACC state still is still not low). The e
nd will immediately start the shock burglar alarm.
The setting time of the guard can send SMS messages to the terminal at the time of setting up the gu
ard, and set up the new fortification time. The default automatic guard time is 3 minutes.
Fortification instruction format:
ACCLT,123456,3 reply OK (3 indicates automatic fortification after 3 minutes) SMS set up automatic f
ortification time.
3.3.9. language and time zone settings
Terminal provides Chinese and English two language display, different regions of time according to the
time zone settings.
Instruction format: 109# reply OK handover in English
Zone123456 E08 reply OK modified time zone E08: East eight district.
3.3.10. The IP address and port number of the server platform
The IP address and port number are provided by the platform operators. When purchasing this product,
OK is generally set. If the user needs to set up his own, he can consult the platform operator.
Instruction format:
IP 123.1.150.82 2332 reply to set IP OK
SMS instruction: IP+ space +IP address + space + port number
3.3.11. Restart the terminal
When the terminal works GPRS link exception, such as: the terminal parameter is set correctly, but th
e terminal is not online, you can send SMS instructions to the terminal. In order to enable the termina
l to perform remote restart, the terminal can resume normal operation.
Instruction format: CQ reply to system reset OK! Device restart
3.3.12. Restore the factory setting
When the terminal setup parameters are not properly set, you can send short message instructions to re
store terminal parameters to the default setting value of the terminal, try to restore the terminal to nor
mal work.
Restore the factory setting instruction: FORMAT
When the terminal receives the instruction, it will restore the setting parameters of the terminal to the
default value.
3.4. terminal operation
3.4.1 start / turn off
Boot: insert the valid SlM card at the terminal, then connect all the wiring. Turn on the terminal pow
er switch (back to the SIM card holder to turn on the terminal power), and the power indicator lights
up. After starting up, GSM began to search the GSM network signal. At that time, the GSM indicator
light was dark for two seconds, and the green light was in normal communication. The GPS indicator
lights up for 2 seconds. It starts searching for the GPS satellite signal. The GPS indicator light is bri
ght, indicating that the GPS has been positioned.

G-MT008G User manual
10
Turn off: remove the SIM card on the boot and turn off the terminal.
3.4.2 message Chinese address query
When you need to query the Chinese address information of the terminal device, the Chinese address
query and query message can be sent to the terminal device SIM card. The terminal will reply to the
location information of a Chinese address. If the terminal has never searched for the location informati
on, the message is returned. "The correct GPS data can not be obtained, please try again!" "!"
Instruction format: 123#
3.4.3 location network linked SMS query
When the location of the terminal device needs to be querying the location of the network link inform
ation, the position network location link query SMS can be written to the terminal device SIM card, a
nd the terminal will reply to the location information of the network link that is last located.
Instruction format G1234# replies to Google links
If your mobile phone is available on the Internet, you can open the location link in the text message,
download the map pictures with terminal location through GPRS or WIFI, 3G and other wireless intern
et access, to see the location of the terminal.
You can also input the network link in the short message to the browser of the computer to see wher
e the terminal is located.
3.4.4 platform query
Users can log on to the global positioning service platform provided by the dealer to view the location
of the vehicle. The service platform URL can consult your dealer.
3.4.5 fortification and withdrawal
When the terminal sends instructions to the fortification and withdrawing state, the terminal will trigger
the alarm when the terminal occurs. At this time, the terminal will send alarm information to the ser
vice platform and service center, upload the latitude and longitude information to the service platform,
and call the service center number, under the condition of nobody answering. Call 3 times in multiple
cycles.
The terminal will send the latest address message to the service center number.
Instruction format:
SF replies to SF OK fortification success
CF reply CF OK withdrawal success
3.4.6 broken off power
Note: in order to ensure the safety of the vehicle, the terminal is only in the effective position of GP
S, and meets the vehicle's speed less than 20KM/H, or when the vehicle is still at rest.
Instruction format: DY reply CUT OIL OK , short message oil cut KY reply RESUNE OIL OK S
MS open oil
3.4.7 SOS alarm
When you need help in an emergency, you can press the SOS button to trigger SOS emergency call.
The terminal will cycle to dial the set of three numbers, and can only cycle two times when there is
no answer.
Attention: the telephone alarm function needs to set up the SOS specific number first.
3.4.8 power off alarm
When the terminal power is cut off, the alarm will be triggered. The terminal will send the alarm info
rmation to the service platform and upload the latitude and longitude information to the service platfor
m. The service platform sends the Chinese address of the latitude and longitude information to the ter
minal, and the terminal will send a Chinese address to the set center number to send a break. Electric
alarm SMS, and circular dial the center number, in the case of no answer, the maximum frequency o
f six times, six minutes interval.
Note: SMS and telephone alarm functions need to set the center number first.
3.4.9 shock alarm

G-MT008G User manual
11
When the power of the vehicle is in the closed state, the ACC state is low at this time, when the AC
C state is low for more than 10 minutes (can be set), the terminal automatically starts fortification. If
the terminal is effective, the vehicle will vibrate many times and will trigger the vibration anti-theft ala
rm mechanism, if in the next 3 minutes, the vehicle power is still unopened (AC The C state is low),
and the terminal will activate the anti-theft alarm immediately. The terminal will send the alarm infor
mation to the service platform and upload the latitude and longitude information to the service platfor
m. The service platform sends the Chinese address of the latitude and longitude information to the ter
minal. The terminal will forward the received Chinese address to the set center number, and dials the
center number, and the maximum number of six is dialed under the condition of no one. The interval
is six minutes each time.
Instruction format:
ACCLOCK, 123456,1 reply OK SMS settings ACC automatic defense.
ACCLOCK, 123456,0 reply OK SMS, set up ACC automatic guard.
ACCLT, 123456,3 reply OK (3 indicates automatic fortification after 3 minutes) SMS set up auto
matic fortification time.
Note: 1. SMS and telephone alarm functions need to set the center specific number first.
3.4.10. Vibration time setting
Set the vibration alarm duration SMS command, 1-15 seconds n (0~15), 0 cancel the vibration ala
rm, the default is 3 seconds, that is, the vibration lasts for 3 seconds.
Instruction format: vibtime123456,n Reply vibtime set ok
3.4.11 Voice monitor
When the set monitor number is dialed to the terminal, the terminal will automatically pick up the pho
ne and enter the listening state. At this time, the caller can monitor the sound of the internal environ
ment of the vehicle.
When the non-listening number is called, the terminal will not enter the listening state.
Instruction format: 88
Note: To achieve this function, you need to set the owner number and SOS specific number first.
Note: 1. To achieve this function, you need to set the monitor number first.
1. The terminal SlM card must have the caller ID function enabled.
