Rointe Sygma SRI0330RAD2 User manual

SYGMA
INSTRUCTION MANUAL
DIGITAL ELECTRONIC RADIATOR
Information, operation & installation

SYGMA
2
Contents:
1. Product information and operation .................................................................................................... 2
1.1. Control panel ............................................................................................................................... 2
1.2. Switching on and off (stand-by) ................... ............................................................................... 4
1.3. Adjust the day and time ............................................................................................................... 4
1.4. Adjust the temperature ................................................................................................................ 4
1.5. Lock the control panel ................................................................................................................. 4
1.6. Adjust the display backlight brightness......................................................................................... 4
1.7. MANUAL / AUTOMATIC functions................................................................................................... 5
1.8. OPEN WINDOWS function........................................................................................................... 6
1.9. Optimizer Energy Plus technology .............................................................................................. 7
2. Installation and mounting ................................................................................................................... 7
3. Maintenance and cleaning ................................................................................................................. 9
4. Installation and safety precautions ................................................................................................... 9
5. Rointe Product Guarantee................................................................................................................ 10
6. European Directive..................................................................................................................................12
7. Dimensions & Technical Characteristics .......................................................................................... 12
8. Certificate of Guarantee..........................................................................................................................13
1. Product information and operation
1.1. Control panel
1.1.1. Keypad
ICON DESCRIPTION
On / Off button
Accept / Confirm button
Decrease temperature button
Move left button
Increase temperature button
Move right button
Menu button
Move upwards button
MANUAL / AUTOMATIC button
Move downwards button

3
1.1.2. Display panel
NO. DESCRIPTION
1Programming
2Days of the week
3Time of day
4Temperature selected
5Control panel locked / unlocked
6MANUAL / AUTOMATIC function indicator
7COMFORT / ECO / ANTI-FROST mode indicator
8Optimizer Energy Plus technology indicator
9Heating element active indicator
10 OPEN WINDOWS function indicator
1.1.3. Symbol information
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
OPEN WINDOWS function - active AUTOMATIC function active
Heating element active MANUAL function active
COMFORT mode active Optimizer Energy Plus technology active
ECO mode active Control panel locked through keypad
ANTI-FROST mode active
1.2. Switching on and off (stand-by)
To switch the product on, please press the button once. After 5 seconds the temperature, time and
days of the week will be show on the display panel.
To switch the product off, please press the button again once. The product will go into stand-by
mode with the word ‘STAND-BY’ displayed on the display panel.

SYGMA
4
1.3. Adjust the day and time
To adjust the day and time, please ensure you are in MANUAL function (see section 1.7.) Then press
and hold the button on the keypad for 3 seconds. Use the buttons and to set the hour,
then press to confirm. Then use the and buttons to set the minutes and press to
confirm. Finally, use the and buttons to set the day (1 = Monday, 2 = Tuesday etc.) and confirm
by pressing the button. You will then return to the main display panel.
1.4. Adjust the temperature
To change the temperature, please press the or the button. To decrease the temperature
press the button and to increase the temperature press the button. When the room temperature
is lower than the set temperature on the display panel, the product will come on with the symbol
appearing in the top right of the display panel. When the Optimizer Energy Plus technology is activated
the symbol will replace the symbol in the top right of the display panel. To learn more
about Optimizer Energy Plus please see section 1.9.
1.5. Lock the control panel
To lock the keypad manually, please hold and press the button AND the button TOGETHER
for 3 seconds. The symbol will appear on the display panel and the keys will not respond. To unlock
the keypad manually, please hold and press the button AND the button TOGETHER for 3
seconds.
1.6. Adjust the Display Panel brightness
To change the brightness of the display panel you must be in MANUAL function (see section 1.7). Press
and hold the button for 3 seconds. Then with the buttons and you can switch between
the two options for the display panel brightness. With the buttons and you can increase or
decrease the brightness as you wish. The cursor indicates the intensity of the light. Once you have set
the required brightness do not touch any buttons on the keypad for 10 seconds and you will return to
the main display.
1.7. MANUAL/AUTOMATIC functions
To change or choose the MANUAL or AUTOMATIC function, press the button on the keypad.
You can change from AUTOMATIC to MANUAL and vice versa by pressing the button again.
On the display panel, the symbol will appear for the AUTOMATIC function and the symbol for
the MANUAL function.
MANUAL AUTOMATIC
This function allows you to change the product
between the COMFORT, ECO and ANTI-FROST
modes and to change the temperature.
This function will activate the programming that
has previously been set in the product.

5
1.7.1 MANUAL function
This function enables you to choose between the COMFORT, ECO and ANTI-FROST modes of your
product. Here you can adjust the temperature of these modes.
COMFORT ECO ANTI-FROST
From 20ºC to 30ºC From 15ºC to 19.5ºC 8ºC
To adjust the temperature when in MANUAL function see section 1.4. The icons for COMFORT, ECO
and ANTI-FROST will appear when the temperature is changed to the ranges above.
1.7.2 AUTOMATIC function
To program the AUTOMATIC function, see section 1.7. to put the product into AUTOMATIC function.
Then press and hold the button for 3 seconds to begin programming.
• STEP 1 - Select COMFORT mode temperature
COMFORT mode will be programmed first. Select the COMFORT mode temperature between
20ºC and 30ºC using the and buttons. The icon and the temperature will flash. Press the
button to confirm.
• STEP 2 - Select ECO mode temperature
ECO mode will be programmed next. Select the ECO mode temperature between 15ºC and 19.5ºC.
The icon and the temperature will flash. Press the button to confirm.
• STEP 3 - Select the Days
The days of the week will start flashing on the display panel and show as DAY 1, DAY 2, DAY 3 etc.
Use the and buttons to move forwards or backwards through the days. Press to select
the day or days that you wish to include in your AUTOMATIC program. The day will stop flashing once
selected. Repeat for all the days you wish to program with the same settings and once all days are
selected press the button to move onto setting the hour.
• STEP 4 - Select the Hours
Once step 3 has been completed, 0h appears on the display panel. 0h is equal to the time, midnight.
Use the or buttons to select the hour you wish to change. Use the button to change the
mode (COMFORT, ECO or ANTI-FROST) for the hour you wish to modify for all the days selected in
step 3. The corresponding icon for that mode will appear at the top of the screen.
To finish the programming press or leave for 30 seconds without pressing any buttons. To change
the programming go back to step 1 and proceed as described before.
*If you wish to have individual days with different programming within your program you will need to
modify each day separately, starting from the Main Menu again for each day/days. Follow Steps 1 to
4 above to program multiple differing days/hours/temperatures.

SYGMA
6
1.8. OPEN WINDOWS function
This function is activated when the temperature sensor detects a drop of 4ºC from the set temperature
within a 30 minute time period. The OPEN WINDOWS function will be active for 2 hours. If the
button is pushed during this period the product will switch off. Pushing the button again will
switch on the product without the OPEN WINDOWS function being switched on.
When this function is activated by the sensor, the following image will appear on the product display
panel for 5 seconds:
When the OPEN WINDOWS function is activated, the product will move into ANTI-FROST mode at
8ºC. The icon will appear on the product display panel showing that the ANTI-FROST mode is
active.
1.9. Optimizer Energy Plus technology
Optimizer Energy Plus is a technology developed by Rointe that bases its operation on thousands of
micropulses being sent to the product to keep a stable temperature with a consumption as low as
possible. When the icon on the display panel is replaced with the icon on the display pan-
el, then the Optimizer Energy Plus technology has been activated and is working.
2. Installation and mounting
2.1. Mounting instructions
The product must never be installed directly below a power point. In bathrooms, the product must
never be installed where the switches and/or other products may be within the reach of someone in
the shower or bathtub.
The product works using natural air convection (Figure 1). In order to achieve optimial performance
and an even distribution of heat, the product must be positioned according to the following table
(Table 1). See Figure 2 for positioning.
Table 1:
PRODUCT
PART
MINIMUM (cm) MAXIMUM (cm)
DISTANCE FROM FLOOR / WALL /
BRICKWORK
Lower 10 - 12 30
Sides 10 - 12 -
Upper 10 - 12 -

7
Figure 1: Figure 2:
2.2. Installation and fixing the supports
Inside the product packaging you will find a fixing kit so you can mount the product to the wall. Please
follow these instructions carefully.
Choose the right part of the wall
(see section 2.1. for minimum
distance from wall).
Place the mounting stencil on the
wall, marking the places for the
holes.
Once you have marked the holes,
remove the stencil and make the
holes in the wall.
Fix the supports using the plugs
and screws provided (or others
suitable for the wall type).
Check the positioning is correct
of the lower support.
Align the product with the top
supports.
Once aligned, place the product
in the supports.

SYGMA
8
Installing Template measurements dependent on the model:
SRI0330RAD2 SRI0550RAD2 SRI0770RAD2
SRI0990RAD2 SRI1210RAD2 SRI1430RAD2 / SRI1600RAD2
3. Maintenance and cleaning
The product does not require any type of regular maintenance. However, we recommend that all parts
of the product are kept clean (behind, underneath, along the upper fins etc.). Do not use any abrasive
product on the aluminium. Clean the aluminium with a damp cloth and a pH neutral soap. Clean the
control panel with a dry cloth.
4. Installation and safety precautions (EN 60335 Standards)
Before switching on the product, please read the “Installation & Safety Precautions” in detail first to
ensure the correct operation of the product.
4.1. Installation precautions
The product is designed for household or residential use only. You are advised to have the product
installed by an authorized professional installer. Please contact Rointe by telephoning 0203 321 5928
to find your nearest installer. Make sure the product is properly connected to 230V and is earthed.

9
4.2. Safety precautions
The product can be used by children aged from 8 years and above and by persons with
reduced physical sensory or mental capabilities or lack of experience and knowledge,
if they are supervised or have been given instruction concerning use of the product in a
safe way and understand the hazards involved. The product is not a toy, children should
not play with the product. Cleaning and user maintenance should not be carried out by
children without supervision. Children must be supervised at all times to ensure that they
do not interfere with the product.
The product is filled with a precise amount of special thermal oil that
does not need or require any maintenance. Any repairs requiring the
opening of the oil tank must only be done by ROINTE or its official
after-sales service personnel, who should also be notified should an oil leak be noticed.
The regulations on discarding oil when the heater is being disposed of must be observed.
If the power cable is damaged, it must be replaced by the manufacturer, its after-sales
service or authorized personnel in order to avoid any damage.
WARNING - In order to avoid overheating, do not cover the product. Do not insert any kind
of object in the air vents. Never use with wet hands. Do not place any containers with water,
such as glasses or vases etc. on or near the product. Do not use insecticides, paints or
aerosols on or near the product. Do not sit on the product or place anything in front of it.
5. Rointe Product Guarantee
In this section, we hereby describe the guarantee conditions, which the buyer acquires, on buying this
product from ROINTE. These conditions comply with all the rights construed in the national legislation
in force, as well as any additional rights and guarantees, which are offered by ROINTE.
Any incident that you might detect in your ROINTE product can be sorted by the product seller or
quickly by the manufacturer. Please contact ROINTE by telephoning 0203 321 5929 for Technical
Support. Alternatively, you can email ROINTE at suppor[email protected], through which we will
instruct you on how to solve the incident.
You will need to state the product reference (located on the label indicating product features),
serial number, proof of purchase and the type of incident at hand when contacting us so that
we can check the guarantee. In addition, please attach a copy of the product invoice.

SYGMA
10
5.1. ROINTE guarantees that there are no material defects of design or manufacture at the time of
original acquisition and guarantees the aluminium body for a period of 120 months and any electronic
and electrical components for 24 months, provided that they have not been modified in any way.
5.2. If during the guarantee period, the product does not work correctly under normal use, and any
design, material or manufacturing defect is found, ROINTE will repair or substitute the product as it
may see fit, in accordance with the terms and conditions as follows:
5.2.1. The guarantee is only applicable if the original guarantee is issued by the seller and when the
said guarantee is filled in correctly including product reference, series number (marked on the product’s
label indicating technical features), purchase date and the seller’s stamp, and either registered on our
website at www.rointe.co.uk or returned completed to ROINTE within 90 days of installation. ROINTE
reserves the right to reject the guarantee service when this information has been removed or modified
after the original product purchase.
5.2.2. The guarantee is only applicable if the product has been installed by a competent person in
accordance with this installation manual and all current regulations and codes of practice at the time
of installation.
5.2.3. The guarantee is only applicable to those cases that concern material, design and manufacturing
defects, and under no circumstances covers damage to the product for the following reasons:
5.2.3.1 Damage caused by negligence and/or misuse of the product, i.e. used for other
purposes that are not construed as its normal use or for not respecting the instructions of use and
maintenance given by ROINTE as well as incorrect installation or use of the product that may not
comply with the current technical standards of safety.
5.2.3.2. Corrosion of any part of the product caused by direct exposure to salt water. When
the product is installed no more than 200m from the coast the guarantee for damages caused by
corrosion the period will be reduced by 50%.
5.2.3.3. Any unauthorised modification of the product or repairs of the product carried out
by third parties or unauthorised technicians or opening of the product by third parties or unauthorised
people.
5.2.3.4. Any accidents that are deemed outside the control of ROINTE, such as (but not limited
to): lightning, fires, floods, natural disasters, public disorder, atmospheric or geologic phenomena etc.
5.2.3.5. Faults that result from an incorrect installation. Guidance can be found within the
recommendations for installation, by Rointe and in the installation manual. If in doubt, please contact
ROINTE.
5.2.4. Any repairs or substitutions that are included in this guarantee do not allow any additions or
new periods of guarantee.

11
5.2.5. Any repairs or substitutions covered under this guarantee must be parts that are functionally
equivalent. The defective parts or parts removed or replaced shall become the property of ROINTE.
5.2.6. The product must be installed in a way that allows access for our technicians should they
need to gain access to the product for repair or maintenance. The user/client is responsible for any
costs or organisation required to provide access to the products for their repair and/or substitution.
5.3. The Technical Service department of ROINTE will advise you if you need to purchase any parts
not covered under the guarantee or out of guarantee.
5.4. This guarantee will be null and void if the product: has been manipulated, modified and/or repaired
in any way and/or by unauthorised persons. This guarantee will also be void if the product is not
correctly installed.
5.5. This guarantee is not transferable and does not include claims due to frost or limescale damage.
5.6. Proof of purchase will be required to ROINTE for any claim.
5.7. This guarantee does not affect your statutory rights.
5.8. This guarantee does not affect the buyer’s legal rights stipulated in the current national legislation,
nor affects those rights against the distributor or installer that could come forth in compliance with
the purchase contract.
5.9. In the absence of a national legal legislation applicable, this guarantee shall prevail and may be
construed as the buyer’s only protection. ROINTE, its offices, distributors and installers may not be
held responsible for any accidental damage that emerges due to infringement of any rules implicitly
related to this product.
For help about the product or guarantee, please contact ROINTE by telephoning 0203 321 5929
for Technical Support or by email to [e-mail].
6. European Directive (WEEE) 2012/19/UE
Under the European Directive 2012/19/UE on Waste Electrical and Electronic
Equipment (WEEE), the product cannot be disposed in the usual council bins and
containers. They must be separated to optimize the recovery and recycling of all
of the components and materials and reducing the impact to human health and
the environment. The symbol of the container crossed out over a horizontal line
is marked on all of ROINTE products to remind the consumer of the obligation to
separate them on disposal. The consumer should contact the local authority or
original point of sale to learn more about the correct disposal of this product.

12
SYGMA
7. Dimensions & Technical Characteristics
MODEL SRI0330RAD2 SRI0550RAD2 SRI0770RAD2 SRI0990RAD2 SRI1210RAD2 SRI1430RAD2 SRI1600RAD2 No. Elements 3 5 7 9 11 13 15 DIMENSIONS Width (mm) 345 505 667 827 1,010 1,180 1,330 Height (mm) 575 575 575 575 575 575 575 Depth (mm) 98 98 98 98 98 98 98 Installed Depth (mm) 120 120 120 120 120 120 120 WEIGHTS & FINISHES Weight (kg) 8 12 16 20 24 28 32 Finish White RAL 9010 ELECTRICAL CHARACTERISTICS Nominal Power (W) 330 550 770 990 1,210 1,430 1,600 Effective Power (W) 132 220 308 396 484 572 640 Voltage (V) 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V 230 ~V Current (A) 1.5 2.4 3.4 4.3 5.3 6.2 7.0 Power per Elem.(W/ Element) 110 110 110 110 110 110 110 PERFORMANCE & SECURITY Safety thermostat        Protection Grade IP21 IP21 IP21 IP21 IP21 IP21 IP21 INSTALLATION Template & Installation Kit        EAN CODES 8436045914828 8436045914835 8436045914842 8436045914859 8436045914866 8436045914873 8436045914880

CERTIFICATE OF GUARANTEE
Cut along the dotted line
In the event of any defect being detected in the product within the period of guarantee, you must fill in the below Certificate of Guarantee and send it to us stamped together with a copy of the sales invoice via email to suppor[email protected] or to the following postal address: INDUSTRIAS ROYAL TERMIC, S.L., C/E, Parcela 43, 30140 Santomera (Murcia, Spain).
CERTIFICATE OF GUARANTEE REFERENCE: Nº SERIES: PURCHASE DATE: USER: HOME ADDRESS: TOWN: POSTCODE: COUNTY: COUNTRY: TELEPHONE: EMAIL: SELLER’S STAMP:
NB: This certificate of Guarantee MUST be completed in full in order to obtain guarantee rights. The purchase date and seller’s stamp are compulsory. Please attach a copy of your sales invoices. In addition, for new constructions include the Certificate of First Occupation.
13

SYGMA
14
NOTES:

15
Thank you for choosing Rointe. We hope you enjoy your product.
If you require further assistance or information, please contact our Technical Service
Department by telephoning 0203 321 5929 or email [email protected].

MSRUK17V2
ROINTE UK
Catalyst House,
720 Centennial Court, Centennial Park
Elstree, Herts, WD6 3SY
T. 0203 321 5928
F. 0208 953 5861
Technical Support
T. 0203 321 5929
E: suppor[email protected].uk
www.rointe.co.uk
