Roland VersaSTUDIO BN-20D User manual

Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read through this manual com-
pletely and store it in a safe location.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The specifications of this product and the contents of this operation manual are subject to change without notice.
• The operation manual and the product have been prepared and tested as much as possible. If you find any misprints or errors, please
inform us.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through use of this product,
regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur with respect to any article made
using this product.
FA03468
R1-230118
https://www.rolanddg.com/
Copyright © 2023 Roland DG Corporation

Before Installation ..................................................................................................... 2
Checking the Included Items ...................................................................................................... 3
Temperature and Humidity........................................................................................................ 4
Emplacement and Installation .................................................................................................... 5
Installation Space ................................................................................................................... 6
Installing the Machine ................................................................................................. 7
Removing the Retainers............................................................................................................ 8
Connecting the Cables ............................................................................................................. 9
Proceeding to Software Installation ............................................................................................10
Contents
1

Before Installation
Checking the Included Items........................................................................... 3
Temperature and Humidity ............................................................................ 4
Emplacement and Installation......................................................................... 5
Installation Space........................................................................................ 6
2 Before Installation

The following items are included with the machine. Make sure they are all present and accounted for.
Power cord/power plug adapt-
er*1
USB cable Dummy cartridges (4) Blade holder/blade/pin
Wiper Felt wiper Cleaning sticks Media flanges (2)/media bar/
mounting pin
Tweezers Quick Access Guide Safety Precautions
*1 Included only with 100 V specifications
Checking the Included Items
Before Installation 3

Maintain the specified temperature and humidity even when the machine is not in use. Failure to do so
may result in malfunction.
Temperature
20°C to 32°C (68°F to 89.6°F)
(During non-operation: 5°C to 40°C [41°F to 104°F])
Humidity
35%RH to 80%RH
(During non-operation: 20%RH to 80%RH)
* No condensation
Temperature and Humidity
4 Before Installation

Install the machine in a level, stable location offering good operating conditions. An unsuitable location
can cause accidents, fire, faulty operation, or breakdown.
Install in a level and stable location.
Failure to do so may result in falling of the machine, leading to injury.
CAUTION
Environments or locations where installation is not possible
• Locations subject to large fluctuations in temperature or humidity
• Locations subject to shaking or vibration
• Locations where the floor is tilted, not level, or unstable
• Dusty locations
• Locations exposed to direct sunlight
• Locations near air-conditioning or heating equipment
• Locations exposed to water or moving air
• Locations exposed to considerable electrical or magnetic noise or other forms of electromagnetic en-
ergy
Unloading and emplacement are operations that must be performed by 2 persons or more.
Tasks that require undue effort when performed by a small number of persons may result in physical injury. Also, if
dropped, such items may cause injury.
CAUTION
When lifting the machine, hold the locations shown in the figure.
CAUTION
Do not hold the cover. Doing so may result in faulty operation or breakdown.
IMPORTANT
Emplacement and Installation
Before Installation 5

The space shown in the figure is required in order to use this machine.
Install the machine so that it is at least 0.6 m (23.6 in.) above the work floor. This machine is desktop type. Install the
machine in a location that allows easy access to areas such as the power switch and other controls during operation.
IMPORTANT
Installation Space
6 Before Installation

Installing the Machine
Removing the Retainers ................................................................................ 8
Connecting the Cables .................................................................................. 9
Proceeding to Software Installation .................................................................10
Installing the Machine 7

This work must be performed before connecting the power cord.
The power turning on inadvertently during these operations may result in pinched hands or other injury.
WARNING
Be sure to remove the retainers.
Any that remain may cause faulty operation or breakdown when the power is switched on.
Store the retainers carefully because they are needed again when transporting the machine.
Removing the Retainers
8 Installing the Machine

Perform this task with all power switches left switched off.
Otherwise sudden movement of the machine may cause injury.
WARNING
*1: Included only with 100 V specifications
Connecting the Cables
Installing the Machine 9

After installing this machine, install the software.
The software installation must be performed on a computer.
MEMO
If you are viewing this manual on your computer
• Click the following URL to check the software installation method.
https://downloadcenter.rolanddg.com/contents/manuals/BN-20D_INS2_JP/index.html
If you are viewing this manual on your mobile device
• Enter the following URL in your computer's web browser.
https://downloadcenter.rolanddg.com/contents/manuals/BN-20D_INS2_JP/index.html
Proceeding to Software Installation
10 Installing the Machine
