Rompa 16351 User manual

1. Product Name
Voice Responsive Dome by ROMPA ®
2. Product Code
16351
3. Colour
Off - white
4. Brief Description
A compact Sound–to-Light unit with an internal microphone that flashes in response to
the voice or sound.
5. Contents
1 x voice responsive dome
1 x power supply unit with plug
6. Snoezelen® Stimulations
Sight

7. Best Use
Voice Responsive Dome is ideally used in a darkened environment.
8. Compatible ROMPA® Products
Not applicable
9. Starting Up
Plug in power supply. Switch on main power supply.
10. Detailed Description
Now with coloured lights and LEDs! Makes a sound and the dome responds with an attractive
glow of light. Ideal for encouraging sounds and one to one or group interaction or turn
taking. Includes a sensitivity control which dims the lighting effect.
11. Safety
The Voice Responsive Dome is suitable for use on a level horizontal surface such as a
table top.
The use of this equipment should be supervised at all times.
For indoor use only
Use the power supply provided only
12. Technical Specification
Size: 17cmH x 30cm diameter
Power Supply: multi voltage power supply
Input: 100-240V ac 50/60Hz 0.5A
Output: 12V dc, 1.5A
CUL/UL USA and FCC approved CE Marked
Double-isolated. For indoor use only.
Electrical Specification: Low voltage 12v dc operation with separate external mains
power supply.
Light LED
Fuse: 1 x 3 Amp in plug, conforms to BS 1363 (240v version only)

13. Installation
Plug the power supply unit into the socket C on the side of the Voice Responsive Dome.
Only use the power supply provided.
Connect the Power Supply Unit to the mains electricity supply.
The unit is activated when a sound (e.g. a voice/clapping) is detected.
Please note: this product remains illuminated until switched off –it will light up when
switched on and then will go off until a noise activates it again. When there is no noise,
the product will not be activated. Each change in sound produces a different colour.
Colours follow in sequence. It is not possible to select one single colour.
The sensitivity can be controlled by adjusting the knob B on the rim of the unit.
14. Care and Maintenance
Wash the exterior of the Voice Responsive Dome with a slightly soapy cloth.
Wipe away the excess soap with a damp cloth.
Never use solvents or liquid detergents on the surface of the dome.
There is no need to attempt to access the interior of the dome –the light is produced by
LED. It is highly unlikely that these will require any maintenance. Do not remove the
securing pins A.
Once this product is eventually exhausted, please dispose of it appropriately.

15. Troubleshooting
Make sure the power supply is correctly connected to the base and plugged in at the wall
Adjust the sensitivity as required. At the lowest setting of the sensitivity range, the dome
will not react to sound. At the highest setting it will be so sensitive that it appears to be
constantly activated. There is a good range of sensitivity between the two. Experiment
until the desired level of sensitivity is reached.
The electronic components of this product have been upgraded early in 2014. The
sensitivity dial is more responsive than the earlier model. On the earlier model, the dial
had to be turned at least a quarter of a turn before the Dome reacted to any sound. Now,
even at a relatively low setting, the Dome is more likely to respond to sound. Take into
account ambient sounds and the location of the product (e.g. near a window) when
finding an appropriate sensitivity level.
Further copies of these instructions can be downloaded at www.rompa.com
We hope you find our instructions invaluable. If you have any suggestions for improving
them further your comments will be greatly received –please contact us at
[email protected]

VOICE RESPONSIVE DOME 16351, February 2014
Copyright ROMPA®Ltd
1. Produit
Dôme Vocal
2. Code
16351
3. Couleur
Blanc
4. Brève Description
Ce dôme réagit à la voix ou à tout autre bruit en s'illuminant d'une lumière très brillante.
5. Contenu
1 x dôme vocal
1 x contrôle de tension

6. Stimulations Snoezelen®
Vue
7. Usage
Pour l’usage dans l’obscurité.
8. Produits Compatibles de ROMPA®
Ne s’applique pas
9. Fonctionnement
Branchez
10. Description
Maintenant avec des lumières colorées!
Ce dôme réagit à la voix ou à tout autre bruit en s'illuminant d'une lumière très brillante. Idéal
pour les jeux interactifs de groupe.
11. Sûreté
Placez le dôme sur une surface plane et stable, comme une table.
Surveillez l’usage de ce produit.
Pour l’usage à l’intérieur seulement
N’utilisez que la contrôle de tension fournie
12. Caractéristiques Techniques
Dimensions : 17 cm de hauteur, 30 cm de diamètre
Alimentation : contrôle de tension multi voltage
Alimentation : 100-240V AC 50/60Hz 0.5A
Sortie : 12V DC, 1.5A
Doublement isolé. Pour l’usage à l’intérieur seulement
Conforme aux exigences de CE, CUL/UL USA et FCC
Basse tension
Lumière : DEL
Fusible : 1 x 5 Amp (dans la prise britannique de 240v)

13. Installation
Connectez le contrôle de tension à la prise femelle C au côté du dôme.
N’utilisez que le contrôle de tension fourni.
Branchez.
Pour activer le dôme, il faut parler ou battre les mains.
Prière de noter : ce produit s’allume pas sans cesse –il s’active en branchant et puis
s’éteint jusqu’au moment ou il y a un bruit. Sans bruit, le dôme ne s’active pas. Chaque
changement de son produit une couleur différente. Les couleurs suivent en séquence.
On ne peut pas choisir une seule couleur.
Pour ajuster la sensibilité, tournez le bouton B sur la base du dôme.
14. Soin et Entretien
Essuyez l’extérieur du dôme avec un linge humecté, et puis un linge sec.
N’utilisez pas des solvants ou des détachants abrasifs.
Ne pas essayer d’accéder à l’intérieur du dôme – il y a des DEL à l’intérieur,
mais ils ne nécessitent pas d’entretien. Ne pas enlever les fixations A.
Quand ce produit est épuisé, débarrassez-vous du produit de façon convenable.

15. En cas de problèmes
Vérifiez que le contrôle de tension est bien connecté à la prise femelle du dôme et que
le produit est branché.
Réglez la sensibilité selon besoin. Au réglage minimal, le dôme ne réagit pas au son. Au
réglage maximal, le dôme s’activera sans cesse. Il y a beaucoup de réglages entre les deux
–expérimentez pour accéder le réglage voulu.
DOME VÔCAL 16351,février 2014
Copyright ROMPA®Ltd

1. Nome do Produto
CÚPULA VOZ-INTERACTIVA
2. Código do Produto
16351
3. Cor
Branco
4. Descrição Breve
Esta cúpula com desenho simples que reage à voz, foi concebida para tirar qualquer
confusão sensorial.
5. Conteúdo
1x cúpula voz-interactiva
1x Fonte de alimentação
6. Estimulação Snoezelen®
Visão

7. Melhor Utilização
Utilize em ambientes escuros.
8. Compatibilidade com Produtos ROMPA®
Não aplicável
9. Começar
Ligue a fonte de alimentação à corrente.
10. Descrição Detalhada
Esta cúpula com desenho simples que reage à voz, foi concebida para tirar qualquer confusão
sensorial. Quando detecta um som começa a brilhar. Ideal para encorajar a fazer sons e para
a interacção um para um e em grupo.
11. Segurança
A cúpula voz interactiva é adequada para utilizar numa superfície horizontal, por exemplo
uma mesa.
A utilização deste equipamento deve ser sempre supervisionada.
Para utilizar apenas no interior
Utilize apenas a fonte de alimentação fornecida
12. Especificações Técnicas
Tamanho: Altura 17cm., diâmetro 30cm
Fonte de alimentação: Fonte de alimentação multi-voltagem
Input: 100-240V ac 50/60Hz 0.5A
Output: 12V dc, 1.5A
Aprovado por CE, CUL/UL USA e CE
Duplo isolamento. Para utilizar apenas no interior.
Funciona com 220V transformados para 12V - transformador
incluído
Luz: LED
