ROSE DISPLAYS ANOFRAME VERSAMOUNT CEILING ANCHORS User manual

Parts
35 Congress Street, Salem MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
AnoFrame VersaMount
TM
Ceiling Anchors
split rails
solid rail
Incept-9.6.02
Figure 1
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountCeiling Anchors
Figure 3
Corner
Brackets
AnoFrame
Rails
AnoFrame
Split Rails
Figure 2
Figure 4
Screw Tabs Transitional
Collars
Instruction Sheet (page 1 of 2)
#97-0441
solid rail
solid rail
split rails
Figure 5
Vertical
Posts with
Ceiling Anchors
Instructions For Assembly
Step 1
Locate the two split rails and the solid
rail that is the same length as the split
rails.
Insert two corner brackets into each
end of the solid side Ano rail. Insert
one corner bracket into each end of
each split side Ano rail.
Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.
Step 2
Slide both screw tabs into channel of
top Ano rail. Fig. 3.
Place one near each end of frame.
Step 3
Place one transitional collar over each
screw tab and push onto frame. Fig. 4.
Step 4
Finish assembling frame following the
sequence in Fig. 5.

Parts
Step 5
Screw vertical posts with ceiling
anchors onto screw tabs on frame.
Tighten. Fig. 6
Step 6
Slide your graphic into the AnoFrame.
Fig. 7
Step 7
With your hand, twist ceiling anchors
onto ceiling grid. Fig 8
You will hear the ceiling anchors snap
into place.
Instructions For assembly
Incept-9.6.02
Figure 6
The AnoFrame VersaMount is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss
or damage resulting from the use of these products.
Part #02INSVersaMountCeilingAnchors
Figure 8
Figure 7
Finished Look
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
#97-0441
Instruction Sheet (page 2 of 2)
