Royalcraft Devon Padded 11 Piece Set User manual

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 1 / 10

www.ro
y
alcraft.co.uk
Product size:
Dining Table: L150*W90*H70 cm
Parasol: D270*H235 cm
Chair: W55*D85*H94 cm
Footstool: W49*D47.5*H34 cm
Side Table: D46*H48 cm
The frame of this product is manufactured from mild steel coated with a weather resistant paint.
Steel has a natural tendency to rust over time and, whilst we expect you to be able to enjoy your
furniture for many years to come, we recommend that you check the product from time to time for
signs of paint damage and/ or rust. If the paint should become damaged, or if rust begins to form,
you should clean the affected area and apply a suitable “thinners based” touch-up paint.
Such paints are readily available from all good hardware and DIY stores.
This product is for Domestic Use only
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 2 / 10

www.ro
y
alcraft.co.uk
Before you start
Warnings
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
See enclosed instructions for assembly, safety and care
information.
Failure to follow the warnings could result in serious injury.
Handle heavy parts with care.
Ensure that this product is fully assembled as illustrated before
use.
This product should only be used on firm, level ground.
Keep small parts out of reach of children.
Do not stand or climb onto this product.
This product is intended for domestic use only.
Furniture can be dangerous if incorrectly used. No liability will be
accepted for damage or injury caused by incorrect use of this
product.
Dos
When you are ready to start, make sure that you have the right
tools, plenty of space and a clean, dry area for assembly.
Remove all packaging and banding and place the components
carefully on suitable surfaces to prevent damaging or scratching
them.
Check the pack and make sure you have all of the parts listed.
Check all screws and bolts are tightened and inspect regularly.
This product is suitable for all year outdoor use, but we
recommend that a furniture cover be used to add additional
protection to your product when not in use.
PLEASE NOTE - All cushions should be stored indoors after use.
THE CUSHIONS ARE NOT WATERPROOF.
During severe weather conditions and in the winter months we
recommend moving your furniture inside into a cool, dry place.
Before storage, ensure that the product is clean and dry.
To clean, wipe down with a sponge and warm soapy water and
wipe with a clean, dry cloth.
Cushions should be cleaned following the care instruction on the
label.
Don’ts
Do not use scourers, abrasives, washing powders, chemical
cleaners or any other substances containing abrasives since these
substances can damage the product, including the glass panel.
Never tilt the chair during use.
Do not place very hot or very cold items on the glass surface
unless adequately thick table-mats are used to prevent such
items from coming into contact with the glass.
Do not use the glass as a chopping surface. Do not strike glass
with hard or pointed items.
Do not strike the glass with hard or pointed items.
Do not use power tools to construct this product.
Do not use this product if parts are missing, damaged or worn.
Do not sit or lean on the table.
Do not stand or climb onto the product and do not use it as a ladder,
as this could lead to it unbalancing and overturning.
Never drag furniture when moving it, always lift it.
Number of people required for assembly
Two people
Time to assemble
40 minutes
Tools required


Tips:
Do NOT fully tighten bolts before
all components are connected.
Only fully tighten once you are
satisfied with the alignment of all
components.
Do not overtighten bolts.

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 3 / 10

www.ro
y
alcraft.co.uk
This Set is a set of 11 pieces.
Please find the member parts.
Member Part
Part No. Diagram Name Qty.
MP1
Dining Table
（In Carton 1 of 3） 1 PC
MP2
Parasol
（In Carton 2 of 3） 1 PC
MP3
Chair
（In Carton 3 of 3） 6 PCS
MP4
Footstool
（In Carton 3 of 3） 2 PCS
MP5
Side Table
（In Carton 3 of 3） 1 PC

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 4 / 10

www.ro
y
alcraft.co.uk
Components, fixtures & fittings (not actual size)
Dining Table & Side Table Parts List
Part
No. Diagram Qty. Part No. Diagram Qty.
A
Dining Table Top
1 PC B
Dining Table Leg
4 PCS
C
Connecting Ring
1 PC D
Side Table Top
1 PC
E
Side Table Leg with
higher assembly holes
2 PCS F
Side Table Leg with
lower assembly holes
2 PCS
N23
M6*28mm
8 PCS N12
M6*60mm
4 PCS
F3
M6 Washer
8 PCS F4
M6 Nut
12
PCS
F10
M6 Bolt Head Cap
12
PCS
F6
M6 Nut Cap
12
PCS
F7
Self-Tapping Screw
4 PCS AK
Allen Key
1 PC

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 5 / 10

www.ro
y
alcraft.co.uk
F1
Spanner
1 PC 

Step by step assembly instructions
MP1 – Dining Table
Step One
With the help of another person, place Dining Table Top (A) upside down on a flat,
non-abrasive surface to avoid scratching the table surface or rim.
Step Two
Locate the assembly position on the bottom side of the Dining Table Top (A).
Attach the Table Legs (B) onto the assembly position (pre-fitted plastic socket).
Fasten the self-tapping screw to fix the Table Legs (B)

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 6 / 10

www.ro
y
alcraft.co.uk
Step Three
Place the Connecting Ring(C) onto the Table Legs (B), using Bolt Head Caps (F10),
Bolts (N23), Washers (F3), Nuts (F4) and Nut Caps (F6).
Once you are satisfied with the alignment of the components, carefully tighten all bolts using
Spanner (F1) & Allen Key (AK). Do not over-tighten.
Step Four
With the help of another person, carefully turn over the table and place it in the upright position.
Your table is now ready for use.
Note: When using a parasol with this table always use a suitable base weight.

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 7 / 10

www.ro
y
alcraft.co.uk
MP2 - Parasol Parts List
Part
No. Diagram Qty. Part No. Diagram Qty.
PA
Main Parasol Part
1 PC PB
Bottom Parasol Pole 1 PC

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 8 / 10

www.ro
y
alcraft.co.uk
Assembly & Usage Steps
1. Press the button on the Bottom Pole (PB) and insert the Bottom Pole (PB) into the
Main Parasol Part (PA).
2. Rotate clockwise the Crank to spread the parasol canopy.
3. The parasol is closed by reversing above steps.
MP3 – Chair & MP4 - Footstool
No need of assembly
Safety Warning
To avoid hurting your fingers, when
you use one hand to rotate the crank
handle, another hand which is holding
the parasol pole should be placed
out of the rotating area of the crank handle.

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 9 / 10

www.ro
y
alcraft.co.uk
MP5 – Side Table
Step One
With the help of another person,
place Side Table Top (D) upside down
on a flat, non-abrasive surface to
avoid scratching the table surface or rim.
Step Two
Locate the assembly position on
the bottom side of the Side Table Top (D).
Attach the Side Table Legs (E & F)
onto the assembly position (pre-fitted plastic socket).
Please note the Legs with same height
of assembly holes should be positioned
oppositely.
Step Three
Fasten the two opposite
Side Table Legs (E) & (E)
using Bolt Head Caps (F10),
Bolts (N12), Nuts (F4) and
Nut Caps (F6).
Repeat above step for the assembly
of another pair of
Side Table Legs (F) & (F).
Once you are satisfied with
the alignment of the components,
carefully tighten all bolts
using Spanner (F1) & Allen Key (AK).
Do not over-tighten.

Devon Padded 11 Piece Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 10 / 10

www.ro
y
alcraft.co.uk
Step Four
Turn over the Side Table and place it in the upright position.
Your table is now ready for use.





Never tilt the Chair or Footstool during use.
Ensure the product is always placed firmly
on the ground.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE

