Royalcraft Sorrento User manual

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 2 / 7
www.royalcraft.co.uk
Before you start
Dos
Don’ts
Two people
Time to assemble
30 Minutes
Tools required
Warnings
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
See enclosed instructions for assembly, safety and care
information.
Failure to follow the warnings could result in serious injury.
Handle heavy parts with care.
Ensure that this product is fully assembled as illustrated before use.
Keep small parts out of reach of children.
This product is intended for domestic use only.
Ensure the product is always placed on level ground.
Furniture can be dangerous if incorrectly used. No liability will be
accepted for damage or injury caused by incorrect use of this
product.
When you are ready to start, make sure that you have the right
tools, plenty of space and a clean, dry area for assembly.
Unwrap all packaging materials and place the components on a
suitable surface to prevent scratching your product.
Check all contents are present prior to assembly as per the parts
list provided. In the event of problems or missing parts, please
contact the seller.
Check all screws and bolts are tightened and inspect regularly.
Cover furniture when not in use to add additional protection to your
product.
Frames are manufactured using powder coated aluminum tubing.
Any scratches on the paintwork should be touched up immediately
with metal paint to prevent corrosion.
During severe weather conditions, including high winds, rain, hail,
thunderstorms, extreme heat and cold temperatures, the product
should be stored inside in a cool, dry place.
To best preserve this product, please use a protective cover when
your furniture is not in use. We would also recommend using a
gazebo or parasol over your furniture during the summer period and
prolonged sunny spells. This will help prevent harmful UV rays from
damaging and discolouring the material.
Ensure that the product is clean and dry before storage.
Clean your product with a sponge and warm soapy water then wipe
with a clean, dry cloth.
This product is suggested to be assembled at the place of use.
Where instructions as to the; storage, commissioning, installation,
use and maintenance of the goods or (if there is none) good
trade practice are not followed and a defect arises this will void
the 12 month manufacturer's guarantee on the product.
Never tilt the chair during use.
Do not stand or climb onto the product.
Do not use power tools to construct this product.
Do not sit or lean onto the rims of this product.
Do not use this product if parts are missing, damaged or worn.
Never use scourers, abrasives or chemical cleaner.
Do not use this product as a ladder as this could lead to the
product becoming unbalanced and overturning.
Do not place very hot or very cold items on the glass surface
unless adequately thick table-mats are used to prevent such
items from coming into contact with the glass.
Do not use the glass top as a chopping surface
Do not strike glass with hard or pointed items.
Never drag furniture when moving it, always lift it.
Number of people required for assembly
Tips:
It is best not to fully tighten the nuts and bolts until
they are all correctly located. Only carefully tighten
them when you are satisfied with the alignment of all
components.
Be careful not to overtighten.
Sorrento Companion Set
Assembly Instructions

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 3 / 7
www.royalcraft.co.uk
Components, fixtures & fittings (not actual size)
Parts List
Part
No. Diagram Qty. Part No. Diagram Qty.
A
Left Armrest/Leg
1 PC B
Right
Armrest/Leg
1 PC
C
Seat Frame
1 PC D
Coffee Table
Frame
1 PC
E
Coffee Table
Supporting Bar
4 PCS F
Left Seat
1 PC
G
Right Seat
1 PC H
Adjustable Bar
2 PCS
I
Glass Top
1 PC J
M6*15mm Bolt
8 PCS
mm
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
0
Sorrento Companion Set
Assembly Instructions

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 4 / 7
www.royalcraft.co.uk
Parts List
Part
No. Diagram Qty. Part No. Diagram Qty.
K
M6*20mm Bolt
6 PCS L
M6*40mm Bolt
12 PCS
M
M6*55mm Bolt
2 PCS N
Female Bolt
2 PCS
O
M6*25mm Bolt
2 PCS P
Washer
30PCS
Q
Bolt Head Cap
30PCS R
Female Bolt
Head Cap
2 PCS
S
Allen Key
1 PC T
Socket Wrench
1 PC
Sorrento Companion Set
Assembly Instructions

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 5 / 7
www.royalcraft.co.uk
Step by step assembly instructions
Step One
Place the Coffee Table Frame (D) upside down on a
soft and level surface.
Assemble Coffee Table Supporting Bar (E) onto the
Coffee Table Frame (D) using
Washers (P), Bolts (J) and Bolt Head Caps (Q).
Step Two
Assemble Seat Frame (C) onto the Part (E)
using Washers (P), Bolts (L) and Bolt Head Caps (Q).
At this stage, please don’t tighten the bolts,
just let all bolts are in place and turn freely.
Step Three
Place the partly-assembled parts in
the upright position.
Assemble the Left and Right Armrest/Leg( A & B)
to above partly-assembled parts using
Washers (P), Bolts (K) and Bolt Head Caps (Q).
At this stage, please don’t tighten the bolts,
just let all bolts are in place and turn freely.
Q
J
P
E
D
E
D
Q
L
P
C
E
C
D
E
B
A
A
C
D
E
C
KQ P
AKQ P
C
Sorrento Companion Set
Assembly Instructions

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 6 / 7
www.royalcraft.co.uk
Step Four
Turn the Seat (F & G) upside down.
Connect them with the partly-assembled frame
as per steps showed in the diagram.
Sequence : Connect the Part (C) and Part (G)
using Washers (P), Bolts (O) and
Bolt Head Caps (Q).
Sequence : Connect the Part (C) and Part (G)
using Washers (P), Bolts (L) and
Bolt Head Caps (Q).
Sequence 





: Connect the Part (D) and Part (G)
using Washers (P), Bolts (L) and
Bolt Head Caps (Q).
Repeat above setps for another Seat (F).
Step Five
Continually Connect Seat (F & G) with
the partly-assembled frame
as per steps showed in the diagram.
Sequence : Connect the Part (F) and Part (A)
using Washers (P), Bolts (M), Bolt Head Caps (Q)
and Female Bolt( N), Female Bolt Head Cap (R).
Sequence : Connect the Part (F) and Part (A)
using Washers (P), Bolts (L),
Bolt Head Caps (Q).
Sequence : Connect the Part (F) and Part (A)
using Washers (P), Bolts (L) and
Bolt Head Caps (Q).
Repeat above steps for another Seat (G).
Sequence 

:
There is one Adjustable Bar (H) to extend each Backrest.
Please pay attention to the picture 5-3, 5-1 and 5-2.
Rotate the supporting bar and insert it into the holes of the backrest.
Make sure it is reasonably tight.
QOP
C
G
QPL GD
QLP G D
F
G
QM P A
B
A
C
C
NR
QPFA
L
QPFA
L
H
5-1 5-25-3
F

Sorrento Companion Set
Assembly Instructions

Produced in China for A. Mir & Co., Ltd.
© A. Mir & Co., Ltd. 7 / 7
www.royalcraft.co.uk
Step Six
When you are satisfied all components,
tighten all Bolts with provided tools (S & T).
Do not over-tighten.
Cover each Bolt with Bolt Head Cap (Q).
Lift the product in the upright position, carefully
Place the Glass Top (I) onto the frame.
Your Companion Seat is now ready for use.
Never tilt this product during use.
Ensure this product is always placed firmly
on the ground.
Note: This seat is not designed to hold the parasol separately.
Parasol base with suitable weight should always be used.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
