ZoneFlex™
7762 Series
DUAL-BAND 802.11N SMART
WI-FI OUTDOOR AP
World’s First Concurrent 2.4/5GHz 802.11n Access Point with
Adaptive Antenna Technology and Smart Wi-Fi Meshing
The ZoneFlex 7762 Series is the rst dual-band 802.11n outdoor access
point (AP) to integrate adaptive antenna technology to enable much longer
range signals, better signal penetration inside buildings, and more resilient
mesh connections that automatically adapt to interference and changing
environmental conditions.
Supporting advanced Smart Mesh Networking, the Ruckus ZoneFlex 7762
Series is perfect for service providers looking to quickly and economically
expand branded broadband services, ofoad data trafc from congested 3G
networks, deploy multimedia hotspots or offer wireless broadband services
where xed line access is limited. Separate radios for access and backhaul
trafc deliver high-throughput to clients throughout the mesh network.
The ZoneFlex 7762 Series is also ideal for hotels, resorts, multi-dwelling units,
schools, warehouses and other enterprises needing to deliver broadband
access from the outside in or to extend managed wireless LANs (WLANs)
outdoors where Ethernet cabling is not possible.
The ZoneFlex 7762 Series can be centrally managed by the ZoneDirector
Smart WLAN controller as part of a unied indoor/outdoor wireless LAN
or deployed as a standalone AP and managed individually or through the
FlexMaster remote Wi-Fi management system.
The ZoneFlex 7762 Series implements Ruckus-patented BeamFlex™ smart
antenna technology that enables consistent, high-performance, extended
coverage and multimedia support. Ruckus ChannelFly dynamic channel
management optimizes client throughput by selecting the best channel to
operate on. A Web-based wizard allows any computer user to congure
ZoneFlex 7762 Series through the ZoneDirector™ — creating a secure and
sophisticated WLAN in a matter of minutes.
BENEFITS
Unprecedented outdoor Wi-Fi performance
Advanced Smart Wi-Fi design with concurrent 802.11n
radios delivers 150 Mbps of sustained throughput
between mesh APs 300 meters apart and 50 Mbps
of sustained throughput to clients 150 meters away
Best in class channel selection technology
ChannelFly dynamic channel management, based on
throughput measurements, not just interference, chooses
the best channel to give users the highest throughput
Environmentally hardened with AC power
Enables fast and easy mounting to street lights,
trafc controls and other street furniture. Includes
hardened enclosures for outdoor deployment with
IP-67 rated enclosure
Unied, centralized Wi-Fi management
eases administration
ZoneDirector and/or FlexMaster provide a detailed view
into and control over both indoor and outdoor Smart Wi-Fi
APs enabling seamless and system-wide administration
of the entire wireless environment including carrier grade
3GPP, I-WLAN core networks and future 4G/LTE core
Unmatched Wi-Fi range and reliability
Adaptive antenna technology combined with unique
interference mitigation technology delivers up to 6 dB
of added signal gain and up to 15 dB of interference
mitigation and support for up to 500 clients in the AC
Enables a myriad of new services and
service opportunities
Smart Wi-Fi applied outdoors now enables new
revenue-generating services such as community Wi-Fi,
IP-video applications, multimedia hotspots, extended
WLAN services outdoors and wireless backhaul for
small cell cluster, and mobile data ofoad

ZoneFlex™7762 Se r i e s
DUAL-BAND 802.11N SMART
WI-FI OUTDOOR AP
• Concurrent dual-band (5 GHz/2.4 GHz) support
• Adaptive antenna technology and advanced RF management
• Up to 6 dB signal gain / 15 dB interference mitigation
• Automatic interference avoidance, optimized for high-density
environments
• Integrated smart antenna array with up to 4,000 unique patterns
for ultra reliability
• Standard 802.3af/at Power over Ethernet (PoE)
• Ruckus custom high power PoE injector available
• Standard 802.3af output for surveillance cameras
• Wall, pole or ceiling mountable
• Built-in heater for cold climate (-40° C)
• 2 to 4 times extended range and coverage
• Multicast IP video streaming
• 600 Mbps of user throughput (300 Mbps/radio)
• 16 BSSIDs with unique QoS and security policies
• Advanced QoS packet classication and automatic priority for
latency-sensitive trafc
• Dynamic, per-user rate-limiting for hotspot WLANs
• WEP, WPA-PSK (AES), 802.1X support for RADIUS and
Active Directory*
• Smart Mesh Networking*
• Zero-IT and Dynamic PSK*
• Admission control/load balancing*
• Band steering and airtime fairness support
• Captive portal and guest accounts *
*when used with Ruckus ZoneDirector controller
ZoneFlex 7762
Dual-band 802.11n
3:3x2, 600 Mbps
Smart antenna for 2.4/5 GHz
19 elements, +4000 patterns
360° coverage, optional
external 5 GHz antennas
• Optimized for enterprise apps
• Ideal for dual-band environments
(e.g., most clients are laptops)
ZoneFlex 7762-T
Dual-band 802.11n
3:3x2, 600 Mbps
Smart antenna for 2.4 GHz
12 elements, +4000
patterns, 360° coverage,
5 GHz external antennas
• Optimized for 3G ofoad
• Ideal for poles, street corners, areas where
3 APs cannot be mounted
ZoneFlex 7762-S
Dual-band 802.11n
3:3x2, 600 Mbps
Smart antenna for 2.4 GHz
12 elements, 24 patterns,
120° coverage, 5 GHz
external antennas
• Optimized for 3G ofoad
• Best 2.4 GHz coverage and capacity at 120°
• Ideal for poles, exterior walls
ZoneFlex 7762-AC, ZoneFlex 7762-S-AC
Dual-band 802.11n
3:3x2, 600 Mbps
Smart antenna for 2.4 GHz
12 elements, +4000
patterns, 360° coverage,
5 GHz external antennas
• Optimized for 3G ofoad
• Ideal for poles, street corners, areas where
3 APs cannot be mounted
• AC power for exible deployment
page 2

ZoneFlex™7762 Se r i e s
DUAL-BAND 802.11N SMART
WI-FI OUTDOOR AP
• First dual-band 802.11n smart outdoor AP with adaptive
antenna array
• Designed for extreme conditions
• Smart channel selection
• Concurrent dual-band 802.11n
• 360° “beamforming” coverage
• 19 elements, +4000 patterns
• IP-67 rated, -40°C – 65°C
• Standalone or centrally managed by ZoneDirector or FlexMaster
• First smart sector 802.11n AP
• Optimized for horizontal, long-range coverage and high-density
user environments
• Smart channel selection
• Concurrent dual-band 802.11n
• 120° smart sector 2.4GHz antenna for longer range
• External 5GHz antennas
• IP-67 rated, -40°C – 65°C
• Standalone or centrally managed by ZoneDirector or FlexMaster
• Smart antenna optimized for 2.4GHz
• 360° “beamforming” coverage
• 12 elements, +4000 patterns
• Smart channel selection
• 5GHz external antennas
• Concurrent dual-band 802.11n
• IP-67 rated, -40°C – 65°C
• Managed by ZoneDirector and FlexMaster
5GHz
5GHz
ZoneFlex 7762/7762-AC: General Purpose Outdoor, Enterprise
ZoneFlex 7762-T: Mobile Data Ofoad
120°
120°
ZoneFlex 7762-S/7762-AC: Long-range, horizontal coverage/capacity
page 3
Flexible mounting
options including
pole, ceiling or
wall mounting
(universal mounting
bracket 902-0165-
0000) for standard
series models
ZoneFlex 7762 can be deployed
in harsh environmental
conditions ranging from
-40°C – 65°C
(-40°F – 149°F)
Low prole bracket with
“Any Angle”mounting
bracket for AC models (902-
0182-0003)
Power over Ethernet (PoE)
output for metro picocell
base station

Ruckus Wireless, Inc.
350 West Java Drive
Sunnyvale, CA 94089 USA
[phone] Ph \ [phone] Fx
www.ruckuswireless.com
Copyright © 2012, Ruckus Wireless, Inc. All rights reserved. Ruckus Wireless and Ruckus Wireless design
are registered in the U.S. Patent and Trademark Office. Ruckus Wireless, the Ruckus Wireless logo, BeamFlex,
ZoneFlex, MediaFlex, MetroFlex, FlexMaster, ZoneDirector, SpeedFlex, SmartCast, and Dynamic PSK are
trademarks of Ruckus Wireless, Inc. in the United States and other countries. All other trademarks mentioned in
this document or Website are the property of their respective owners. 801-70680-001 rev 09
Specications (7762, 7762-S, 7762-T)
PERFORMANCE AND CAPACITY
TARGET UDP THROUGHPUT •
Up to 150 Mbps sustained throughput over
300 meters between mesh nodes
• Up to 50 Mbps sustained throughput over
150 meters to client devices
CONCURRENT STATIONS •
256
SIMULTANEOUS VoIP CLIENTS •
Up to 20
WI-FI
STANDARDS •
I E EE 8 0 2.11a / b /g / n
• 2.4GHz and 5GHz concurrent operation
SUPPORTED DATA
RATES
• 802 .11n: 6.5Mbps – 130Mbps (20MHz)
6.5Mbps – 300Mbps (40MHz)
• 802 .11a: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
• 802 .11b: 11, 5.5, 2 and 1 Mbps
• 802 .11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
RADIO CHAINS •
3 x 3: 2
RF POWER OUTPUT •
28 dBm/600 mW*
FREQUENCY BAND •
IEEE 802.11n: 2.4 – 2.484 GHz and 5.15 – 5.85 GHz
• IEEE 802.11a: 5.15 – 5.875 GHz
• IEEE 802.11b: 2.4 – 2.484 GHz
BSSID •
Up to eight per radio (16 total)
WIRELESS SECURITY •
WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
• Authentication via 802.1X, local authentication
database, support for RADIUS and ActiveDirectory
CERTIFICATIONS •
U.S., Europe, Australia, Brazil, Canada, China,
Egypt, Hong Kong, India, Japan, Korea, Malaysia,
Mexico, New Zealand, Philippines, Singapore, South
Africa, Taiwan, Thailand, UAE, Vietnam
• WEEE/RoHS compliance
• Wi-Fi Alliance Certication (Wi-Fi Certied
™
)
* Maximum power varies by country
PLEASE NOTE: When ordering you must specify the destination region by indi-
cating -US, -WW, or -IL
PHYSICAL CHARACTERISTICS
POWER •
Power over Ethernet and 12V DC
PHYSICAL SIZE •
23.9 cm (L), 19.5 cm (W), 14.1 cm (H)
WEIGHT •
1900 grams (4.19 lbs.)
ANTENNA •
ZF 7762: Internal software-congurable
dual band antenna array with directional
and omni high-gain elements that provide
over 4,000 unique antenna patterns
• ZF 7762-S: Internal software-congurable
2.4GHz antenna array with directional
high-gain elements that provide over 24
unique antenna patterns (requires external
antenna for 5 GHz operations)
• ZF 7762-T: Internal software-congurable
2.4GHz antenna array with directional and
omni high-gain elements that provide over
4,096 unique antenna patterns (requires
external antenna for 5 GHz operations)
ETHERNET PORTS •
2 ports, auto MDX, auto-sensing RJ-45
• 10/100/1000 Mbps Power over Ethernet
(802.3at) input
• 10/100 Mbps Power over Ethernet
(802.3af) output
ENVIRONMENTAL
CONDITIONS
• IP-67 rated
• Operating air temperature: -40°C – 65° C
(-40°F – 149°F), -20°C when heater
disabled
POWER DRAW •
12.95W (PoE)
• 15W (12V DC)
Product Ordering Information
MODEL DESCRIPTION
ZoneFlex 7762 Series 802.11n Outdoor Access Points
901-7762-XX01
7762: Centrally managed concurrent dual band 802.11n outdoor
access point, includes universal pole/wall/ceiling mounting
bracket (902-0165-0000) and power injector.
901-7762-XX91
7762-T: Centrally managed concurrent dual band 802.11n
outdoor access point, includes universal pole/wall/ceiling
mounting bracket (902-0165-0000) and power injector.
901-7762-XX51
7762-S: Centrally managed concurrent dual band 802.11n
outdoor access point, includes universal pole/wall/ceiling
mounting bracket (902-0165-0000) and power injector.
Optional Accessories
911-1212-DP01
5 GHz directional antenna, dual-polarized 12.5 dBi gain and 120
degrees 3 dBm beam width*
911-0636-VP01
5 GHz Omni-directional antenna, vertically polarized, 5.5 dBi
911-0536-HP01
5 GHz Omni-directional antenna, horizontally polarized, 5 dBi
911-0636-VH01
Bundle of one 911-0636-VP01 and one 911-0536-HP01
902-0165-0000
Universal pole/wall/ceiling mounting bracket, spare (sold in
quantities of 10)
902-0166-0000
Flat mounting bracket
902-0180-XX00
PoE injector, spare (sold in quantities of 10 or 100)
MANAGEMENT
DEPLOYMENT OPTIONS •
Standalone (individually managed)
• Managed by ZoneDirector
• Managed by FlexMaster
CONFIGURATION •
Web User Interface (HTTP/S)
• CLI (Telnet/SSH), SNMP v1, 2, 3
• TR-069 vis FlexMaster
RF (7762, 7762-S)
ANTENNA •
Adaptive antenna array that provides
4,000+ unique antenna patterns (24 for
the sectorized version)
MAXIMUM EIRP •
2.4 GHz: 35 dBm
• 5 GHz: 31 dBm
PHYSICAL ANTENNA GAIN •
Up to 12 dBi (2.4 GHz)
• Up to 10 dBi (5 GHz)
BEAMFLEX* SINR TX GAIN •
Up to 6 dB
BEAMFLEX* SINR RX GAIN •
Up to 4 dB
INTERFERENCE MITIGATION •
Up to 15 dB
MINIMUM RX SENSITIVITY •
Up to -95 dBm
*BeamFlex gains are statistical system level effects translated to enhanced
SINR here, and based on observations over time in real-world conditions with
multiple APs and many clients
RF (7762-T)
ANTENNA •
Adaptive antenna array that provides
4,000+ unique antenna patterns
MAXIMUM EIRP •
2.4 GHz: 33 dBm
• 5 GHz: 31 dBm
PHYSICAL ANTENNA GAIN •
Up to 10 dBi
BEAMFLEX* SINR TX GAIN •
Up to 6 dB
BEAMFLEX* SINR RX GAIN •
Up to 4 dB
INTERFERENCE MITIGATION •
Up to 15 dB
MINIMUM RX SENSITIVITY •
Up to -95 dBm
*BeamFlex gains are statistical system level effects translated to enhanced
SINR here, and based on observations over time in real-world conditions with
multiple APs and many clients

Ruckus Wireless, Inc.
350 West Java Drive
Sunnyvale, CA 94089 USA
[phone] Ph \ [phone] Fx
www.ruckuswireless.com
Copyright © 2012, Ruckus Wireless, Inc. All rights reserved. Ruckus Wireless and Ruckus Wireless design
are registered in the U.S. Patent and Trademark Office. Ruckus Wireless, the Ruckus Wireless logo, BeamFlex,
ZoneFlex, MediaFlex, MetroFlex, FlexMaster, ZoneDirector, SpeedFlex, SmartCast, and Dynamic PSK are
trademarks of Ruckus Wireless, Inc. in the United States and other countries. All other trademarks mentioned in
this document or Website are the property of their respective owners. 801-70680-001 rev 09
PERFORMANCE AND CAPACITY
TARGET UDP THROUGHPUT •
Up to 150 Mbps sustained throughput over
300 meters between mesh nodes
• Up to 50 Mbps sustained throughput over
150 meters to client devices
CLIENT SUPPORT •
500
SIMULTANEOUS VoIP CLIENTS •
Up to 20
WI-FI
STANDARDS •
I E EE 8 0 2.11a / b /g / n
• 2.4GHz and 5GHz concurrent operation
SUPPORTED DATA
RATES
• 802 .11n: 6.5Mbps – 130Mbps (20MHz)
6.5Mbps – 300Mbps (40MHz)
• 802 .11a: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
• 802 .11b: 11, 5.5, 2 and 1 Mbps
• 802 .11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
RADIO CHAINS •
3 x 3:2
RF POWER OUTPUT •
28 dBm/600 mW
FREQUENCY BAND •
IEEE 802.11n: 2.4 – 2.484 GHz and 5.15 – 5.85 GHz
• IEEE 802.11a: 5.15 – 5.875 GHz
• IEEE 802.11b: 2.4 – 2.484 GHz
BSSID •
Up to eight per radio (16 total)
POWER SAVE •
Supported
WIRELESS SECURITY •
WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
• Authentication via 802.1X, local authentication
database, support for RADIUS and ActiveDirectory
CERTIFICATIONS •
U.S., Europe, Australia, Brazil, Canada, China,
Egypt, Hong Kong, India, Japan, Korea, Malaysia,
Mexico, New Zealand, Philippines, Singapore, South
Africa, Taiwan, Thailand, UAE, Vietnam
• WEEE/RoHS compliance
• Wi-Fi Alliance Certication (Wi-Fi Certied
™
)
PLEASE NOTE: When ordering you must specify the destination region by indicating
-US, -WW, or -IL
PHYSICAL CHARACTERISTICS
POWER •
Power over Ethernet and 100-240 VAC,
50/60Hz
PHYSICAL SIZE •
23.9 cm (L), 19.5 cm (W), 14.1 cm (H)
WEIGHT •
2177 grams (4.8 lbs.)
ANTENNA •
ZF 7762-AC: Internal software-
congurable dual band antenna array with
directional and omni high-gain elements
that provide over 4,000 unique antenna
patterns
• ZF 7762-S-AC: Internal software-
congurable 2.4 GHz antenna array
with directional high-gain elements that
provide over 24 unique antenna patterns
(requires external antenna for 5 GHz
operations)
ETHERNET PORTS •
2 ports, auto MDX, auto-sensing RJ-45
• 10/100/1000 Mbps Power over Ethernet
(802.3at) input
• 10/100 Mbps Power over Ethernet
(802.3af) output
ENVIRONMENTAL
CONDITIONS
• IP-67 rated
• Operating air temperature: -40°C – 65° C
(-40°F – 149°F), -20°C when heater
disabled
POWER DRAW •
12.95W (PoE)
• 14W typical / 43W peak (AC)
Product Ordering Information
MODEL DESCRIPTION
ZoneFlex 7762-AC and 7762-S-AC 802.11n Outdoor Access Points
901-7762-XX03
7762-AC: Centrally managed concurrent dual band 802.11n
outdoor access point, includes any angle pole/wall
mounting bracket (902-0182-0003)
901-7762-XX53
7762-S-AC: Centrally managed concurrent dual band
802.11n outdoor access point, includes any angle pole/wall
mounting bracket (902-0182-0003)
Optional Accessories
902-0182-0003
Spare outdoor mounting bracket, bare metal, any angle
902-0180-XX00
60W PoE injector 10/100/1000 Mbps with country-specic
power cord
902-0183-0000
Spare data connector with weatherizing cable gland
902-0185-0000
Spare weatherized AC connector
MANAGEMENT
DEPLOYMENT OPTIONS •
Standalone (individually managed)
• Managed by ZoneDirector
• Managed by FlexMaster
CONFIGURATION •
Web User Interface (HTTP/S)
• CLI (Telnet/SSH), SNMP v1, 2, 3
• TR-069 vis FlexMaster
RF (7762-AC)
ANTENNA •
Adaptive antenna array that provides
4,000+ unique antenna patterns
MAXIMUM EIRP •
31 dBm
PHYSICAL ANTENNA GAIN •
Up to 8 dBi (2.4 GHz)
• Up to 10 dBi (5 GHz)
BEAMFLEX* SINR TX GAIN •
Up to 6 dB
BEAMFLEX* SINR RX GAIN •
Up to 4 dB
INTERFERENCE MITIGATION •
Up to 15 dB
MINIMUM RX SENSITIVITY •
Up to -95 dBm
*BeamFlex gains are statistical system level effects translated to enhanced
SINR here, and based on observations over time in real-world conditions with
multiple APs and many clients
RF (7762-S-AC)
ANTENNA •
Adaptive antenna array that provides 24
unique antenna patterns
MAXIMUM EIRP •
2.4 GHz: 35 dBm
• 5 GHz: 31 dBm
PHYSICAL ANTENNA GAIN •
Up to 12 dBi (2.4 GHz)
• Up to 10 dBi (5 GHz)
BEAMFLEX* SINR TX GAIN •
Up to 6 dB
BEAMFLEX* SINR RX GAIN •
Up to 4 dB
INTERFERENCE MITIGATION •
Up to 15 dB
MINIMUM RX SENSITIVITY •
Up to -95 dBm
*BeamFlex gains are statistical system level effects translated to enhanced
SINR here, and based on observations over time in real-world conditions with
multiple APs and many clients
Specications (7762-S-AC & 7762-AC)
