Ruijie Reyee RG-RAP1200-MNT Series Installation and operating manual

Ruijie Reyee RG-RAP1200(P)-
MNT Series Access Points
Hardware Installation and Reference Guide V1.0
Document Version: V1.0
Date: 2022-02-18
Copyright © 2022 Ruijie Networks

Copyright
Ruijie Networks©2022
Ruijie Networks reserves all copyrights of this document.
Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this
document or any portion of this document, in any form or by any means, without the prior written consent of
Ruijie Networks is prohibited.
Trademarks including , and are
owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services or features you purchase are subject to commercial contracts and terms. Some or all of
the products, services or features described in this document may not be within the scope of your purchase or
use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement
or guarantee for the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from time to
time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder
any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Hardware Installation and Reference Guide 1 Product Overview
1
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
The official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee
Conventions
1. Signs
The symbols used in this document are described as follows:
Danger
An alert that calls attention to safety operation instructions that if not understood or followed when operating
the device can result in physical injury.
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.
Specification
An alert that contains a description of product or version support.
2. Note
This manual provides the device installation steps, hardware troubleshooting, module technical specifications,
and specifications and usage guidelines for cables and connectors. It is intended for the users who have some
experience in installing and maintaining network hardware. At the same time, it is assumed that the users are
already familiar with the related terms and concepts.

Hardware Installation and Reference Guide 1 Product Overview
2
1 Product Overview
The AP delivers an access rate of up to RAP1200(P)-MNT is a rack specially developed and designed by Ruijie
Ruijie for wireless AP RAP1200(P). Solve the problem of difficult installation in some scenarios for users, and
the AP is not beautiful after the base is installed
1.1 Technical Specifications
Table 1-1 Technical Specifications of RG-RAP1200(P)-MNT
Model
RG-RAP1200(P)-MNT
Dimensions (L x
W x H)
126*86*5mm
Surface
treatment
technology
Ruijie Warm White W-1, fine-grained
1.2 Appearance
The RG-RAP6262(G) provides a Wi-Fi indicator, a SYS indicator, and two LAN port indicators.
Figure 1-1 Appearance

Hardware Installation and Reference Guide 1 Product Overview
3
1.3 Dimensions of the mounting bracket

Hardware Installation Guide and Reference Preparing for Installation
4
2 Preparing for Installation
2.1 Preparing the Installation Site
Do not install the AP rack in an area prone to fire or explosions.
Keep the AP rack at least 500 meters away from the ocean and do not face it towards the sea breeze.
The installation site should be protected from water and flooding, seepage, dripping, or condensation.
2.2 Installing the Device
1、USE screws to attach the mounting bracket to a US-style wall outlet box
2、Plug the cable into the POE port of the AP

Hardware Installation Guide and Reference Preparing for Installation
5
3、Attach the AP onto the mounting bracket with screws

Hardware Installation Guide and Reference Preparing for Installation
6
4、Install the top cover.
