Ryobi MHG-2000 Operation manual

MHG-2000
09-16

Fig.1
1
3
9
10
1
11 12 13 14 15 16
2
8
5
47
6
Position 1- b
Position 1- a
Position 2
17 18

Fig.3
Fig.4
2
Fig.2
Fig.6 Fig.7
Fig.5
12
1
2
5
4
1
2

THANK YOU FOR BUYING A RYOBI PRODUCT.
To ensure your safety and satisfaction, carefully read
through this OWNER’S MANUAL before using the
product.
3
General Safety Rules
SAVE THESE INSTRUCTIONS
WARNING! Read all instructions Failure to follow all
instructions listed below may result in electric shock, fire
and/or serious injury. The term “power tool” in all of the
warnings listed below refers to your mains-operated
(corded) power tool or battery-operated (cordless) power
tool.
1) Work area
a) Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
b) Use safety equipment. Always wear eye
protection.Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Avoid accidental starting. Ensure the switch is in
the off-position before plugging in.Carrying
power tools with your finger on the switch or
plugging in power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
awayfrom moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
these devices can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tools operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc., in accordance with these instructions and in
the manner intended for the particular type of
power tool, taking into account the working
conditions and the work to be performed. Use of
the power tool for operations different from intended
could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power tool
is maintained.

Voltage
Power input
Air flow
Temperature
I
II
III
Net weight
230V~50Hz
2000W
500L/min
50 °C
400 °C
600 °C
0.9kg
Check the following:
4
SPECIFICATIONS
DESCRIPTION
WHEN USING THE APPLIANCE
Replacing cables or plug
Using extension cables
Immediately switch off the appliance when:
ADDITIONAL SAFETY INSTRUCTIONS FOR
HEAT GUNS
BEFORE USING THE APPLIANCE
1. Make sure the voltage of the hot air gun corresponds
with the power voltage;
– Are the mains lead and the mains plug in a good state:
strong, without ravels or damages.
– Caution is advised when using long extension cables
2. Do not use the appliance under moist circumstances.
3. The metal mouthpiece gets hot. Watch out and do not
touch the metal mouthpiece.
4. Prevent damage of the heating element. Do not lock or
block the mouth piece.
5. Do not leave the appliance when switched on.
6. When in operation do not point the device at people or
animals.
7. Never look into the hot air nozzle.
8. Do not use this device in rain or damp surroundings, or
near explosive or flammable products.
9. Do not use the device on or near very dry spots to avoid
fire.
10. Always remove the plug from the socket when not
using the device, when replacing the nozzles or during
maintenance of the device.
11. Do not point the device at the same place for longer
periods of time.
12. Do not hold the device too close to the surface about
to be worked on as the device can overheat.
13. Pay attention to the direct / indirect workspace as the
heat can ignite flammable materials, which are close
by but not necessarily in view.
14. Do not allow the hot parts of the device to touch the
cord or other flammable materials.
15. The device should always be clean, dry and free of
grease and oil.
16. Do not use the appliance for purposes other than for
which it is intended.
1. If you are going to use the hot air gun, vapor and gas can
be released during a short time. This can be harmful for
your health. Asthmatics can suffer hindrance of it;
2. Before connecting the plug to the mains voltage you
have to check if the switch is in position “0”;
3. Keep the mains lead always away from the mouthpiece
of the hot air gun;
4. Keep children and animals away from the appliance if
you are using it.
5. Keep all parts of the body away from the metal heating
head. Do not touch it before it is cooled down.
6. Carry the appliance by the handle when the metal heating
head is cooled down.
7. Hold the appliance by insulated gripping surfaces only,
because the metal heating head may contact hidden
wiring or its own cord.
Plug and/or cable are defective or damaged;
The switch is defective;
You smell or see smoke caused by scorched insulation
from the hot air gun.
10. Stand
11. Weed killer nozzle
12. BBQ charcoal lighting nozzle
13. Hook nozzle
14. Flat nozzle
15. Glass protection nozzle
16. Concentration nozzle
17. Scraper
18. Chisel
1. Temperature adjustment lever
2. On / off switch
3. Hot air nozzle
4. Handle
5. Lock button for twisting handle
6. Extension handle grip
7. Extension handle tube
8. Lock button for extension handle
9. Cap
If the power cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person, in order to avoid a hazard.
Immediately throw away old cables or plugs when they have
been replaced by new ones. It is dangerous to insert the
plug of a loose cable in the wall outlet.
Only use an approved extension cable suitable for the
power input of the machine. The minimum conductor size is
1.5 mm2. When using a cable reel always unwind the reel
completely Inadequate extension cords can be dangerous. If
an extension cord is used, it shall be suitable for outdoor
use, and the connection has to be kept dry and off the
ground. It is recommended that this is accomplished by
means of a cord reel which keeps the socket at least 60 mm
above the ground.
This appliance operates at a temperature of 600 degrees
without visible signs of this temperature (no flames), still
there is a chance of fire risk. Watch out for the hot air stream
from the mouth piece. This air stream can cause burns.
WARNING!

WARNING!
TEMPERATURE SETTING (Fig. 3, 4)
5
STANDARD ACCESSORIES
APPLICATION
OPERATION
Weed killer nozzle, BBQ lighter nozzle, Hook nozzle,
Flat nozzle, Glass protection nozzle, Concentration
nozzle, Scraper, Chisel
• Removing paint or vanish,
• Defrosting frozen pipes
• Soldering pipe work
• Bending plastics
• Heat-shrinking electrical parts
• Killing weeds
• Lighting charcoal
HEAT GUN (Fig. 7)
Use as heat gun is always without use of the extension
handle for various purposes, such as:
• Removing old paint and gloss
• Removing self-adhesive labels
• Bonding of PVC labels
• Removing vinyl wallpaper
• Fast drying of damp equipment
• Shrink packaging
• Defrosting of water pipes
• Loosening of nuts and bolts
Always use with caution! Do NOT cover the ventilation openings
during use as it causes a risk of burns! Do not touch the hot
nozzle!
CAUTION!
To avoid overheating of the BBQ or Fireplace do not use the
device for longer than necessary.
With the temperature adjustment lever (1) you can select from
three temperature settings depending on application.
The nozzles can easily be pushed over the hot air nozzle (3).
Never touch the nozzles during operation or right after use
of the device. The nozzles are very hot.
The device has two handle positions. Position 1-a is suitable
for killing weeds and Position 1-b is for lighting charcoal. In
position 2, the device can be used as a heat gun.
To change the handle positions, twist the handle (4) while
pressing the lock button for twisting handle (5).
To remove the extension handle, pull the extension handle
from the tool while pressing the lock button (8) for extension
handle.
5. Check to ensure the nozzle is not blocked before
turning the device on.
6. Set the temperature to setting III.
7. Press the On/Off switch.
8. Allow the device about 45 seconds to warm up.
9. To eliminate weeds, hold the nozzle over the weeds for
about 5 seconds.
During these 5 seconds the cell structure of the weed is
destroyed. As a result, the weed dies within a few days.
It is not necessary to completely burn the weeds, 5 seconds
is more than sufficient.
For an efficient treatment the nozzle should be held
around 0 to 5cm above the weeds.
The effects are not visible immediately but will take a while
before they can be seen. It is more of a long-term effect.
1. Ensure the extension handle is firmly fixed onto the
device and that the device is turned off.
2. Turn the device to position 1-a.
3. Attach the weed killer nozzle (11) to destroy weeds.
4. Insert the plug into the socket.
If using the tool as a weed killer you must use the extension
handle.
The BBQ and fireplace lighter is always to be used without
the extension handle.
1. Remove the extension handle.
2. Turn the handle to position 1-b.
3. Attach the BBQ lighting nozzle onto the tool.
4. Place the nozzle under the coal or the wood, and make
sure it is properly positioned.
5. Insert the plug into the socket.
6. Check to ensure the nozzle is not blocked before
turning the switch on.
7. Set the temperature adjustment lever to I, II or III.
8. Press the On/Off switch.
9. Remove the device from the coals or the wood as soon
as it starts to glow, and blow hot air into the coals or wood
from a distance of around 5-10cm, until the coals or wood
is burning properly.
This will help to avoid damaging the nozzle attachment.
Exposing the nozzle to high temperatures for a prolonged
period of time could cause the material to melt. Please
follow these instructions to achieve long-term enjoyment
with the product.
SWITCHING ON AND OFF (Fig. 3, 4)
• To switch the tool on, press the on / off switch (2)
• To switch the tool off, press the on / off switch again
1. Remove the extension handle
2. Turn the handle to position 2
3. Attach the desired nozzle onto the tool.
4. Insert the plug into the socket
1. The extension handle consists of the extension handle
grip (6) and the extension handle tube (7). Connect both
parts and tighten the connection.
2. Make sure that the extension handle firmly clicks into
position.
WEED KILLER (Fig. 5)
INSTALLING NOZZLES
ROTATING HANDLE (Fig. 1, 2)
ATTACHING THE EXTENSION HANDLE
REMOVING THE EXTENSION HANDLE
BBQ LIGHTER (Fig. 6)

6
COOLING
AFTER USE
CLEANING
CAUTION!
Make sure that the device has completely cooled down before
storing.
Keep the ventilation slots of the machine clean to prevent
overheating of the engine. Regularly clean the machine
housing with a soft cloth, preferably after each use. Keep
the ventilation slots free from dust and dirt. If the dirt does
not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water,
etc. These solvents may damage the plastic parts.
1. Before switching off the tool, it must be cooled first. Select
temperature setting I for at least one minute before switching
off.
2. Place the tool on its stand (10) after use and allow it to cool
down before storage.
5. Check to ensure the nozzle is not blocked before turning
the device on.
6. Set the temperature adjustment lever to I, II or III.
7. Press the On/Off switch.
MAINTENANCE
To ensure safety and reliability, all repairs should be
performed by an AUTHORIZED SERVICE CENTER or
other QUALIFIED SERVICE ORGANIZATION.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING!
After use, check the tool to make sure that it is in top
condition. It is recommended that you take this tool to a
RYOBI Authorized Service Center for a thorough cleaning
and lubrication at least once a year.
DO NOT MAKE ANY ADJUSTMENTS WHILE THE
MOTOR IS IN MOTION.
ALWAYS DISCONNECT THE POWER CORD FROM THE
RECEPTACLE BEFORE CHANGING REMOVABLE OR
EXPENDABLE PARTS (BLADE, BIT, SANDING PAPER
ETC.), LUBRICATING OR WORKING ON THE UNIT.
