1. OVERVIEW
• We appreciate the trust you have placed in us by purchasing this device. You have pur-
chased a high-quality product that has been manufactured in strict compliance with recog-
nized technical regulations regarding safety, and in accordance with EC standards.
• Read this instruction booklet carefully, since it contains important information for your sa-
fety during the installation, use and maintenance of this product. Keep this booklet in case
you need to consult it in the future.
• We ask that you make sure the equipment is in perfect condition when you unpack it, since
any existing defect is covered by the S&P warranty.
• Technicians responsible for installing, start-up and maintenance must read the instruc-
tions and be familiar with them before starting work.
2. SAFETY STANDARDS AND “EC” MARKING
• S&P engineers are firmly committed to research and development to achieve products with
improved efficiency that complies with current safety standards.
• The standards and recommendations indicated below reflect current standards in the field
of safety, and therefore are based primarily on meeting standards of a general nature.
Consequently, we recommend that all personnel exposed to risks adhere strictly to local
regulations in force regarding hazard prevention.
• S&P is in no way responsible for any damage or injury caused to persons or objects resul-
ting from failure to comply with safety standards, and any possible modifications to the pro-
duct. The EC seal and statement of conformity serve as proof of the product’s compliance
with applicable European Community standards.
3. GENERAL STANDARDS
• Product risks have been analysed pursuant to the provisions of the Machinery Directive.
This manual contains information intended for all personnel exposed to hazards, with the
goal of preventing personal injuries or damage to objects resulting from mishandling or
improper maintenance. All maintenance service work (corrective and preventive) must be
performed with the equipment stopped and disconnected.
• To avoid danger of possible accidental start up ensure that the equipment is electrically
isolated and locked. If this is not possible, warning signs should be placed on main distri-
bution console that state:
“WARNING: controls disconnected for maintenance”
• Before connecting the power cable to the motors, make sure that the voltage on the line
matches the voltage indicated on the unit’s identification plate.

17
4. UNIT LABELING
• The unit comes with a variety of labels that must not be removed. Here with sample labels
and meaning:
ICON / LABEL MEANING
Signing on fan access door. Indicates that
the unit must be disconnected, followed by
a waiting period, since there are moving
parts that constitute danger to entry.
Indicates direction of airflow in the unit.
Made in Spain
TIPO: UVF-1200/250 F7 ECOWATT
V: 230
HZ: 50/60 IP: 44
A: 1,4
KW: 0.22 Insul.CI B
RPM: 2650
REF: 000 Working Temp -15/55°C
Unit identification plate. This indicates:
- Model
- Serial number
- Date of manufacture
- Maximum absorbed current of motor (A)
- Power of installed electric heater
- Electrical supply
5. TECHNICAL CHARACTERISTICS
Model Power
supply
Maximum
absorbed power
(W)
Maximum
current
(A)
RPM
UVF-400/160 ECOWATT 230/1/50-60 100 0.5 3900
UVF-600/200 ECOWATT 230/1/50-60 115 0.57 3300
UVF-1100/250 ECOWATT 230/1/50-60 210 1.1 2800
UVF-1500/315 ECOWATT 230/1/50-60 235 1.4 2300
UVF-2500/355 ECOWATT 230/1/50-60 355 1.39 1900
UVF-3000/400 ECOWATT 230/1/50-60 360 1.45 1800

18
6. HANDLING
• The UVF ECOWATT units are supplied packed in a single cardboard box.
• When unit received, unpack and make sure the packaging is intact; any defect may indicate
damage to the unit. Review it carefully to make sure that no parts are missing.
• If there is any damage to the unit or the shipment is not complete, write down the problems
on the delivery slip and send a claim to the carrier. Also report any problems to S&P.
• The unit should be handled carefully and only horizontally.
• Manipulate the unit by hand. If using a forklift, place the box on a pallet. Do not manipulate
the box directly with the blades of the forklift.
7. INSTALLATION
7.1. OVERVIEW
• The technician responsible for unit receipt must ensure that the characteristics of the exis-
ting power supply agree with the electrical data on the unit’s identification plate.
• Before installing the unit in its final position, make sure that the place where it will be lo-
cated is strong enough to support its weight.
• Under no circumstances should these units be installed in flammable or explosive environ-
ments, in environments that contain oil vapours, salt air, or corrosive environments.
• Equipment installation can present hazards due to the material used, pressures in the
system and the electrical components. For this reason, only trained and qualified service
personnel may install service or repair the equipment.
• As a precaution, when performing operations inside the equipment, shut off the power at a
main breaker. This serves to prevent any accidents involving the equipment’s moving parts,
which can start accidentally, well as to prevent any direct or indirect contact with live parts.
• he unit must also be disconnected by the cut-off switch integrated in the terminal b ox of
the product.

19
7.2. IDENTIFICATION UNIT PARTS
The main module may consist of three different sections: filter, coils and fans. However, one
of the first two sections may not be included. The following illustration identifies the main
components of the main module.





 

Support ceiling mounting
Technical plate and
arrow air sense
Terminal box*
Cover fan access
Cover filter access
* In the small models UVF-400/160, UVF-600/200 and UVF-1100/250 the terminal box is remote, supplied with a
650mm long hose cable.
7.3. INSTALLATION SITE
The unit must be installed so that the airflow is upright vertical position: Bottom air intake
and top discharge.
• Avoid installing the unit in areas near heat sources or in damp areas where the unit might
come in contact with water or the relative humidity is close to 100%.
• It is recommended that the unit be installed in a place that is easily accessible for the ins-
tallation. Provide sufficient room for maintenance, connection and drainage of condensate.

20
7.4. DIMENSIONS AND SPACE FOR MAINTENANCE
The installer must provide spaces free of obstruction and be able to freely access the unit for
maintenance.
   
  

  

  
 


 
 



  




   

 
 







Model A B C D E F d G H I Weight
(kg)
UVF-400/160 ECOWATT 692 313 259 160 718 278 9 468 52 52** 9
UVF-600/200 ECOWATT 728 363 309 200 754 350 9 468 52 52** 9,5
UVF-1100/250 ECOWATT 770 413 334 250 795 400 9 468 52 52** 12
UVF-1500/315 ECOWATT 836 513 409 315 862 500 9 468 52 77 13
UVF-2500/355 ECOWATT 932 613 459 355 957 600 9 468 52 77 15
UVF-3000/400 ECOWATT 932 613 459 400 957 600 9 468 52 77 15
Dimensions (mm)
* Dimension F: Filter maintenance free distance
** Models UV-400/160 to UVF-1100/250 with remote terminal box

21
7.5. UNIT INSTALLATION
The unit can be mounted on floor, wall and false ceiling. To prevent the transmission of vibra-
tions, appropriate anti-vibration mounts must be installed in the mounting position and the type
of surface on which the unit is mounted.For wall mounting, the unit must be supported on the
4 existing support points.
7.6. ASSEMBLY OF ADDITIONAL FILTERS / DISASSEMBLY OF FILTERS
Depending on the version, the unit is supplied with one or two filters located inside it.In the
versions with a filter it is possible to add a second filter (order as accessory).In all the versions
it is possible to locate a prefilter.To mount the additional filters, follow the following sequence:
Mounting an additional filter
The UVF-ECOWATT ventilation boxes allow the assembly of up to 3 stages of filtration inside,
located as follows:
A. Filter holder with clamping arms in which it is located
the filter supplied as standard and that has capacity to
have a second filter.
B. Guide filter holder in which it is possible to locate a pre-
filter (G4 or M5).
To add a second filter it is necessary to follow the following steps:
Remove the filter registration cover by turning the exis-
ting closing hands on the side and back loosened of
these (1). Then, tilt the lid towards the side opposite the
closing hands (2).

22
To release the filter or filters, loosen the two threaded
knobs that hold each support (a), and move the arms un-
til leaving enough space to remove the filter or filters (b).
Remove used filters
and replace them with
the new ones, respec-
ting the sense date of
airflow found in the
frame.
The microfilters used in the UVF-ECOWATT boxes are high efficiency filters that can not be
cleaned. Cleaning these filters can damage them and affect the degree of filtration.
Disassembly the prefilter:
Rotate the lower stops with shape
triangular (a) holding the prefilter.
Release the prefilter, making it slide by
the guides (2).

23
7.7. CONNECTING THE UNIT TO THE DUCT SYSTEM
• Never use the unit as a support or weight-bearing structure for ductwork.
• Connect the unit to the air ducts using flexible connectors to prevent vibrations from
being transmitted to the duct system.
• Check to make sure air intake and flow are not being blocked and that there are no
obstacles impeding good air circulation. Failure to do so will affect the efficiency of
the system.
7.8. ELECTRICAL CONNECTION
IMPORTANT!
To avoid contamination of the filters included in the unit, they are supplied in plastic bags.
Prior to the start-up of the unit, it is necessary to remove these bags and reassemble the
filters making sure that the air sense matches the one indicated in the filter frame.
• Before putting the unit in place, make sure that the nominal supply voltage matches that
listed on the unit’s identification plate.
• It should be installed with cables whose cross-section meets current regulations and pre-
vents overheating and voltage drops that exceed permissible limits. Current regulations
must be obeyed, and the designer’s instructions must be followed at all times.
• Before connecting the cables, make sure that the electricity is turned off and that there is
no voltage present in any of them.
• The installer must keep the following points in mind when performing the electrical con-
nections:
− After these steps are performed, check to make sure all electrical connections are secu-
re (loose wiring connections can cause irreparable damage).
− As a safety measure, if there is no power to the fan, the necessary interlocks must be
performed so that all other electrical components are also de-energised.
The power supply is made in the external terminal box. In no case it is necessary open the
fan access register during electrical connection work.This record should only be opened
in annual maintenance tasks to verify the state of the fan or in case it requires its replace-
ment.

24
7.9. CONNECTING THE PRESSURE SENSORS
7.9.1. Dirty filters
The unit is equipped with 2 pressure taps on each side of the filters so that a pressure switch
can be installed to control dirt levels in the filters.
Section 9.3. presents a table with the values recommended for filter replacement.
8. ADJUSTING OF THE FAN SPEED
All models of the UVF-ECOWATT range have an integrated potentiometer inside the electrical
cabinet that allows the manual adjustment of the fan speed.
It is not necessary to open the fan access register during connection workelectric.
Depending on the existing jumper position next to the potentiometer, it is possible to select
the type of regulating element between the manual potentiometer integrated in the plate, or
an external control signal of type 0-10V.

25
Speed adjustment through potentiometer integrated in the plate
Position of J1 and J2 jumpers
for speed adjustment by
potentiometer integrated
in the plate
230V ± 10% 50/60Hz
Speed adjustment by external potentiometer / external 0-10V signal
Position of J1 and J2 jumpers
for speed adjustment by 0-10V
external signal
230V ± 10% 50/60Hz
Using the control accessory AERO-REG CONTROL, it is possible to control the speed of
the fans from an external sensor (CO2, humidity, pressure). See the details on connec-
tion in the AERO-REG CONTROL instructions.

26
9. PREVENTIVE MAINTENANCE
In these operations we must take into account the following aspects:
9.1. MOTORS
• Check the power consumption has not increased.
• Periodically check the electrical connections are making good contact; this will prevent
breakdowns.
• We recommend checking the fan mounting periodically.
9.2. FANS
• Every three months, clean the dirt from the fan blades and bearings, since dirt can not only
reduce airflow but also lead to unbalanced operation and increase noise.
• Periodically, test the airflow on each fan.
9.3. FILTERS
• To make sure that the filters are working properly, the pressure loss across the filter must
be monitored precisely (since this is an indicator of dirt levels). The following table indicates
the maximum recommended values for pressure loss before filter replacement.
Filter G4 M5 M6 F7 F8 F9
Loss of charge (Pa) 150 200 200 200 225 225
• Even if the maximum pressure loss has not been reached, filters should be inspected each
month to make sure that the filter and filter housing are sealed.
• It is not recommended that filters be washed, since they will never recover their initial
efficiency and doing so can produce wear on the filters. Although washing or vacuuming in
the opposite direction from normal air circulation can achieve an optimal finish, it is recom-
mended that you always have a set of replacement filters on hand. Under no circumstances
should the unit be run without filters, since this can introduce dirt into vital components of
the unit and lead to equipment wear and loss of efficiency.
Filter parts table
Model G4 M5 F7 F9 Quantity Dimensions
(mm)
UVF-400/160 ECOWATT AFR UVF-400 G4 AFR UVF-400 M5 AFR UVF-400 F7 AFR UVF-400 F9 1 300x250x48
UVF-600/200 ECOWATT AFR UVF-600 G4 AFR UVF-600 M5 AFR UVF-600 F7 AFR UVF-600 F9 1 350x300x48
UVF-1100/250 ECOWATT AFR UVF-1100 G4 AFR UVF-1100 M5 AFR UVF-1100 F7 AFR UVF-1100 F9 1 400x325x48
UVF-1500/315 ECOWATT AFR UVF-1500 G4 AFR UVF-1500 M5 AFR UVF-1500 F7 AFR UVF-1500 F9 1 500x400x48
UVF-2500/355 ECOWATT AFR UVF-2500/3000 G4 AFR UVF-2500/3000 M5 AFR UVF-2500/3000 F7 AFR UVF-2500/3000 F9 1 600x450x48
UVF-3000/400 ECOWATT AFR UVF-2500/3000 G4 AFR UVF-2500/3000 M5 AFR UVF-2500/3000 F7 AFR UVF-2500/3000 F9 1 600x450x48

S&P SISTEMAS DE VENTILACIÓN, S.L.U.
C. Llevant, 4
Polígono Industrial Llevant
08150 Parets del Vallès
Barcelona - España
Tel. [phone]
Fax [phone]
www.solerpalau.com
Ref. 9023085600
