Sanipex BOTANICAL BDS-BOT-701-XX User manual

BDS-BOT-701-XX
BOTANICAL COUNTERTOP WASH BASIN DIA. 420MM
www.sanipexgroup.com

IMPORT ANT PLEASE READ


            

         

         

 
           

   




         










 of 

Drill, drill bits & hole-saw:
Required when drilling a wooden counter-top surface, for Marble/Stone
counter-tops please use specialized cutting company.
X
Place the basin on the counter-top, take notice of the spout length of the mixer
so that the distance X is correct. Mark around the perimeter of the basin and
waste hole.

Check that the waste provision is in the correct place, check the bottle trap
dimensions to ensure that the distance Y is achievable.
Drill waste hole allowing for the finished dimensions of the waste outlet. In
this instance its B=75-110 mm, please check your corresponding waste
outlet product.
Y
Ø32mm
Ø75-110mm
B

Install the waste assembly into the basin.
If required, place a few dots of silicon on the base of the basin, align, and place in
position, allow the silicon to cure for a few hours.


INSTALLATION COMPLETE!!!
Install the bottle trap onto the waste, cut the horizontal pipe to length and
install into the wall via a waste compression fitting or rubber socket.
If required run a small bead of silicon around the perimeter base.

Note:

INS-BOT-701-XX-09-21
