Sanipex BAGNODESIGN MONROE BDR-MNR-ROUND-MIRROR User manual

BDR-MNR-ROUND-MIRROR
MONROE ILLUMINATED ROUND MIRROR WITH LED BULBS
www.sanipexgroup.com

 
            

  

  



 
     
 
  




            


 




This instaUation guide is for reference only. In case there is a discrepancy between that of the instructions and tha t of the actual product, the
fatter should be taken as standard. The rights of modifi'cation are reserved,

Mirror Dia700/1000mm
Front view
Back view
Side view
Bottom view
Aluminum
frame
Hanging hole
Wire outlet
Back cover
Touch button (on/off)
Colour change (long
press warm to cold
white)
34mm
4mm copper
free mirror
700/1000mm

Technical Details
Heated De-mister Pad
This mirror comes with a demister pad,which heats the surface of the mirror above
room temperature removing the mist on surface .
Switch On/Off, Color change and Brightness change
1st touch turn-on the light with white color, 2nd touch gives warm light, 3rd touch
gives neutral light, the 4th touch turns-off the light， keep on pressing can change
the brightness.
Electrical Safety Information
We recommend that all electrical bathroom products should only be fitted by a
qualified -Part P registered electrician in accordance with the current IEE
Regulations.
Please ensure the Mains supply is switched off before attempting installation. Before
drilling ensure there are no hidden cables or pipes in the wall.
Installation Information
We recommend that you receive the product before commencing with installation as
all sizes and measurements are approximate.
We try to ensure all measurements are as accurate as possible.

Installation Procedure
Notes: To ensure the normal use of products, it is required you set out wires as per
the regulations at the installation places. The Products are only applicable to being
installed on the indoor solid wall. The installation must be carried out by a professional
electrician and wrong installation may lead to product damage and personal injury.
1. Make certain the wall is solid, and use the flexible rule to measure the distance
between two hardy holes on the mirror frame ("a” in Fig. 1).
2. Use the flexible rule to measure the distance a on the wall and mark them out
with a pencil.
3. Choose a drill with an appropriate drill bit to make two holes at the marked
places, and use a special ceramic drill if the wall surface is made of ceramic tiles.
4. Use the hammer to strike an expansion rubber plug into the holes on the wall,
and then screw the hook into the hole (Fig. 2).
5. Switch off the power, and then use a terminal block to connect the three-core
exposed wires with those reserved on the wall (see details in Fig. 4).
6. Hang the product on a wall hook (Fig. 3).
7. Finally switch on the power, and then touch the switch sign with a finger on the
sensor to test the products.
Installation Procedure
Flexible rule Spirit level Drill Hammer Pencil
Fig. 1 Fig. 2 Fig. 3
*2 *2
Wire outlet
Back cover
Hanging hole
a
a

Wiring Diagram for Input
Waste Electrical & Electronic Equipment Regulations (WEEE) requires that any of our
products showing this mark (left) must not be disposed off with other household or
commercial waste. We do not levy any WEEE disposal charges to its customers for
affected WEEE related products. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate any such product
from other waste types and recycle it responsibly at your local facilities. Check with
your Local Authority, Recycling Center or retailer for recycling advice.
Schematic Diagram
Brown
Yellow green
Blue
Brown Yellow
green Blue
live
earth
neutral
MAINS SUPPLY LUMINAIRE
Fig. 4
LED strip
Touch Sensors
Supply Power
Deffogger Pad
LUMINAIREMAINS SUPPLY
inputinput outputoutput
Live
Earth
Neutral

Note:

INR-MNR-ROUND-MIRROR-10-22
