QUICK START GUIDE
Andrew Alliance Stand+
Before you begin
If you do not have a OneLab account,
please create one by going to:
onelab.andrewalliance.com/signup

Getting started
Plug your Stand+
to a power source.
Wait the LED sign to turn blue
and blink
After a couple of minutes, the
Stand+ will inform you when it is in
installation mode.
Connect your computer, tablet or smartphone to the Stand+
Launch a web browser, type http://192.168.2.1
and follow the on-screen steps to continue installation.
A. Go to your Wi-Fi settings
and select the network named Stand-618.xxxx.xxxxx
1 2
3
4
scan me
Please take note that
the installation page
might open automatically.
If you do not have access to
a Wi-Fi compatible device,
please refer to our online help:
help.andrewalliance.com
!
!
xxxx.xxxxx is the Stand+ device serial number (you can nd it in the back of
your device)
B. The LED sign will stop blinking when it’s successfully connected.
Stand-618.xxxx.xxxxx
If the Stand+ doesn’t enter auto-
matically in installation mode,
press 5 times the push button.
!
http://192.168.2.1

Feel free to contact
the Andrew Alliance support team
Call us
[phone]
Send us an email to
[email protected]
Chat with our support team
directly in OneLab
Mon-Fri: 8:00 - 17:00 CETWe reply within 1 business day
Operations
Design your protocol
Execute experiment with
Pipette+
Follow instructions and trigger action
by clicking on the pipette operating button
Select the Pipette+ as experiment setup
then prepare all the required materials.
Our drag-n-drop editor makes it easy to
design a precise and complete protocol
with all that you need to run your
experiment perfectly.
Follow the visual instructions
based on the protocol being
used and you will be guided
throughout your experiment.
Each step of the experiment will
be traced and available in OneLab.

Product overview Technical data
Serial number
Push button
Built-in
computer
4 Andrew Alliance
pipettes holders
Built-in wireless
adapter
LED sign
Power socket
Ethernet socket
for cable
connection
USB charging
socket
(no data)
Andrew Alliance S.A.
Chemin Grenet 21
1214 Vernier (Geneve) Switzerland
Phone: [phone]
[email protected]
Sartorius Biohit Liquid Handling Oy
Laippatie 1
00880 Helsinki, Finland
Phone: [phone]
lhinfo.[email protected]
Power supply Wall / desktop power supply
with universal wall plugs
Input: 100 - 240 VAC v~50/60Hz
Output: 12 VDC, 4 A
Power supply
connector
DC plug 5.5/2.1 mm with 90
degree angle
Pipette charge
voltage
7,5 VDC, 500 mA
Weight 1.7 kg
Dimensions 395 x 314 x 170 mm (W × H × D)
Operating
temperature
+15 to +40 °C
Air humidity max 80%
LAN 10/100 Mbits/s
WiFi 802.11 ac/a/b/g/n
Bluetooth BTLE version 4.2
USB charging USB-A connector
5 VDC, 1 A
User interface 9 RGB LEDs in a form of plus
symbol
Audio 2 speakers for mono audio,
nominal power 1W
Embedded PC Freescale i.MX 7 with ARM
Cortex-A7 1 GHz CPU
SO-DIMM 204 pin connector
1GB DRAM
4GB eMMC
Operating system Linux Debian
Warranty 1 year
Ingress Protection IP40
Certication CE, FCC, RoHS II, REACH, WEEE
Cleaning Disinfectant or decontaminant
liquid such as 70% ethanol,
60% isopropanol, mild detergent
or similar
Supported pipette
models
All Andrew Alliance Pipettes
Identication Unique serial number on the
back of the stand
