Sauder 413678 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English.................... Page 1-12
Français...............Pages 13-14
Espanol.............Páginas 15-16
Lot #: 345236 05 / 08 / 12
Date Purchased: ____________________
413678
Storage Cabinet

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-12
Français..............................13-14
Espanol...............................15-16
Safety .................................17-18
Warranty...................................19
Page 2 www.sauder.com/services 413678

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A RIGHT END 1
B LEFT END 1
C UPRIGHT 1
D TOP 1
E BOTTOM/SHELF 2
F ADJUSTABLE SHELF 4
G BACK 1
H DOOR 2
I SKIRT 1
Page 3
www.sauder.com/services413678
A
B
C
D
E
F
G
H
I
F
F
F
E
H

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
Page 4 www.sauder.com/services 413678
SAFETY BRACKET - 1
J
FELT DISC CARD - 1
M
BROWN 7/16" LARGE HEAD SCREW - 25
S
BLACK 1-7/8" FLAT HEAD SCREW - 17
Q
SCREW COVER - 12
N
RUBBER SLEEVE - 16
P
METAL PIN - 20
O
KHINGE - 6
NAIL - 36
T
SILVER 3/4” MACHINE SCREW - 4
R
LPULL - 2

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Fasten the RIGHT END (A) to the TOP (D). Use two BLACK 1-7/8" FLAT HEAD SCREWS (Q).
Page 5
www.sauder.com/services413678
A
D
Finished
Long unfinished edge
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
Q

Fasten the BOTTOM/SHELF (E) to the RIGHT END (A). Use two BLACK 1-7/8" FLAT HEAD SCREWS (Q).
Fasten the UPRIGHT (C) to the BOTTOM/SHELF (E). Use two BLACK 1-7/8" FLAT HEAD SCREWS (Q).
2
2
S
t
e
p
Page 6 www.sauder.com/services 413678
A
E
C
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
Q
Unfinished
Long unfinished edge
Edge with
three holes.
For support, place packing
foam and magazines here.

Fasten the other BOTTOM/SHELF (E) to the RIGHT END (A) and UPRIGHT (C). Use four BLACK 1-7/8" FLAT HEAD
SCREWS (Q).
Insert four METAL PINS (O) into the SKIRT (I).
Push the METAL PINS (O) in one end of the SKIRT (I) into the holes in the RIGHT END (A).
NOTE: Do now allow the SKIRT to hang freely until it is fastened to the LEFT END (B).
3
3
S
t
e
p
Page 7
www.sauder.com/services413678
A
C
E
Unfinished
I
O
(4 used)
Long unfinished edge
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
Q

Fasten the LEFT END (B) to the TOP (D) and BOTTOM/SHELVES (E). Use six BLACK 1-7/8" FLAT HEAD SCREWS (Q).
NOTE: Be sure the METAL PINS (O) in the SKIRT (I) insert into the holes in the LEFT END (B).
4
4
S
t
e
p
Page 8 www.sauder.com/services 413678
E
I
E
D
B
Long unfinished edge
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
Q

5
5
S
t
e
p
Page 9
www.sauder.com/services413678
1/4”
6”
2”
Unfold the BACK (G) and lay it over your unit.
Make equal margins along all four edges of the BACK (G). Push on opposite corners of your unit if needed to make it “square”.
Fasten the BACK (G) to your unit using the NAILS (T). The NAILS should be 6" apart, 2" from the corners, and 1/4" in from the
edges.
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(36 used in this step)
T
G
Unfinished

6
6
S
t
e
p
Page 10 www.sauder.com/services 413678
Fasten the HINGES (K) to the DOORS (H). Use twelve BROWN 7/16" LARGE HEAD SCREWS (S).
H
H
K
K
BROWN 7/16" LARGE HEAD SCREW
(12 used in this step)
S
