Sauder Jaclyn Smith Gatsby 415693 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 358697 01/10/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Night Stand
Jaclyn Smith Gatsby Collection | 415693
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Sweet stand.
Sweet dreams.

Table of Contents Assembly Tools Required
3
4
5-15
16-18
19-21
22
23
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
415693 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F FRONT SKIRT (1)
G2 DRAWER FRONT (1)
H BOTTOM MOLDING (1)
I2 DRAWER MOLDING (2)
D12 RIGHT DRAWER SIDE (1)
D13 LEFT DRAWER SIDE (1)
D158 DRAWER BACK (1)
D964 DRAWER BOTTOM (1)
415693www.sauder.com/services Page 3
A
B
C
D
E
F
G2
H
I2
I2
D13
D12
D158
D964

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
415693 www.sauder.com/servicesPage 4
(EXTENSION SET SHOWN SEPARATED)
EXTENSION RAIL - 2
JEXTENSION SLIDE - 2 K
BLACK 9/16" LARGE HEAD SCREW - 8
1S
ANGLE BRACKET - 4
5G
SILVER 1-1/8" FLAT HEAD SCREW - 4
10S
BLACK 7/8" MACHINE SCREW - 1
37S
3S GOLD 5/16" FLAT HEAD SCREW - 8
10A SLIDE CAM - 2
NAIL - 16
1N
30S BLACK 1-9/16" FLAT HEAD SCREW - 4
HIDDEN CAM - 10
1F
CAM DOWEL - 10
2F PULL - 1 82K

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push ten HIDDEN CAMS (1F) into the ENDS (A and B)
and BOTTOM (D). Then, insert the metal end of a CAM
DOWEL (2F) into each HIDDEN CAM.
415693www.sauder.com/services Page 5
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
(10 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
B
D

Step 2
415693 www.sauder.com/servicesPage 6
å Separate the EXTENSION SLIDES (K) from the
EXTENSION RAILS (J) as shown in the upper diagram. Be
prepared, the parts are greasy.
å Fasten the EXTENSION RAILS (J) to the ENDS (A and B).
Use four GOLD 5/16" FLAT HEAD SCREWS (3S).
å NOTE: For each EXTENSION RAIL, turn a SCREW into
the hole shown in the enlarged diagram. Then, slide the
innercartridge of the EXTENSION RAIL in to find the other
hole that lines up with the hole in the END. Turn a SCREW
into this hole.
Open end
Open end
Finished edge
Finished edge
JK
Push the release lever in and pull the SLIDE from the RAIL.
A
B
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
J
J

å Fasten the ENDS (A and B) to the BOTTOM (D). Tighten
four HIDDEN CAMS.
Step 3
415693www.sauder.com/services Page 7
A
B
D
Surface with HIDDEN CAMS
Surface without HIDDEN CAMS
Surface
with
HIDDEN
CAMS
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Finished edge
Finished edge
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Edge with CAM DOWELS

Step 4
å Fasten the TOP (C) to the ENDS (A and B). Tighten four
HIDDEN CAMS.
å Fasten the BOTTOM MOLDING (H) to the BOTTOM (D).
Tighten two HIDDEN CAMS.
415693 www.sauder.com/servicesPage 8
Angled edge
Rounded edge
Surface with holes
Unfinished surface
A
B
C
D
H
Arrow
Minimum
190 degrees
Maximum
210 degrees

å Fasten four ANGLE BRACKETS (5G) to the ENDS (A and B) and
BOTTOM (D). Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the FRONT SKIRT (F) to the ENDS (A and B) and BOTTOM (D).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S) through the ANGLE
BRACKETS and into the FRONT SKIRT.
Step 5
415693www.sauder.com/services Page 9
F
AB
D
5G
5G
5G
Flat edge
Finished surface
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S

Step 6
415693 www.sauder.com/servicesPage 10
NAIL
(16 used in this step)
1N
å Carefully turn your unit over onto its front edges. Unfold the
BACK (E) and lay it over your unit.
å Make equal margins along all four edges of the BACK (E). Push
on opposite corners of your unit if needed to make it “square”.
å Fasten the BACK (E) to your unit using the NAILS (1N).
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Unfinished surface
E
