Sauder 408726 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English.................... Page 1-18
Français...............Pages 19-21
Espanol.............Páginas 22-24
Lot #: 345014 04 / 16 / 12
Date Purchased: ____________________
408726
Computer Desk

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-18
Français..............................19-21
Espanol...............................22-24
Safety .................................25-26
Warranty...................................27
Page 2 www.sauder.com/services 408726

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A2 RIGHT END 1
B LEFT END 1
C LOWER RIGHT END 1
D2 UPRIGHT 1
E2 SMALL UPRIGHT 1
F2 TOP 1
G2 DESK TOP 1
H3 SHELF 1
I BOTTOM 1
J BACK 1
K2 SMALL BACK 1
L MODESTY PANEL 1
M KEYBOARD SHELF 1
N DOOR 1
A2
B
C
D2
E2
F2
G2
H3
I
J
K2
L
M
N
Page 3
www.sauder.com/services408726

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
BLACK 1-1/8" PAN HEAD SCREW - 1
KK
BLACK 7/8" FLAT HEAD SCREW - 2
FF
WASHER - 1
Y
PIVOT HINGE - 2
X
BROWN 7/16" LARGE HEAD SCREW - 2
HH
BLACK 1-7/8" FLAT HEAD SCREW - 8
DD
CAM COVER - 7
BB
CORD CLIP - 1
AA
BROWN 1" FLAT HEAD SCREW - 4
EE
SCREW COVER - 11
CC
GOLD 5/16" FLAT HEAD SCREW - 4
II
HANDLE - 1
Z
MAGNETIC CATCH - 1
V2
NAIL - 12
JJ
BLACK 1/2" FLAT HEAD SCREW - 1
GG
BLACK 1-15/16" FLAT HEAD SCREW - 7
LL
STRIKE PLATE - 1
W
RIGHT CABINET RAIL - 1
OLEFT CABINET RAIL - 1 P Q RIGHT DRAWER SLIDE - 1
RLEFT DRAWER SLIDE - 1
Page 4 www.sauder.com/services 408726
HIDDEN CAM - 10
S2 CAM DOWEL - 10 T2

1
1
S
t
e
p
Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push ten HIDDEN CAMS (S2) into the ENDS (A2, B, and C), UPRIGHT (D2), SMALL UPRIGHT (E2), and SMALL BACK (K2).
Then, insert the metal end of the CAM DOWEL (T2) into each HIDDEN CAM.
Do not tighten the HIDDEN CAMS in this step.
(10 used)
B
C
A2
D2
E2
K2
Page 5
www.sauder.com/services408726
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
S2
T2

Fasten the CABINET RAILS (O and P) to the LEFT END (B) and UPRIGHT (D2). Use four GOLD 5/16" FLAT HEAD SCREWS (II).
NOTE: The CABINET RAILS are marked “CR” and “CL” for easy identification.
2
2
S
t
e
p
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
II
Finished edge
Finished edge
Roller end
Roller end
Page 6 www.sauder.com/services 408726
O
P
B
D2

Fasten the SMALL UPRIGHT (E2) to the SMALL BACK (K2). Use a BLACK 1-15/16" FLAT HEAD SCREW (LL).
3
3
S
t
e
p
Finished edge
Finished edge
Surface with
HIDDEN CAM
Surface without
HIDDEN CAM
LL
BLACK 1-15/16" FLAT HEAD SCREW
(1 used in this step)
E2
K2
Page 7
www.sauder.com/services408726

Fasten the SMALL UPRIGHT (E2) and SMALL BACK (K2) to the TOP (F2). Tighten two HIDDEN CAMS.
4
4
S
t
e
p
E2
K2
F2
Page 8 www.sauder.com/services 408726
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Maximum
210 degrees
Arrow
Minimum
190 degrees
Arrow
Finished edge
Finished edge
Surface with
HIDDEN CAM

Fasten the DESK TOP (G2) to the SMALL UPRIGHT (E2) and SMALL BACK (K2). Use two BLACK 1-15/16" FLAT HEAD
SCREWS (LL).
5
5
S
t
e
p
K2 E2
G2
Unfinished surface
Long finished edge
LL
BLACK 1-15/16" FLAT HEAD SCREW
(2 used in this step)
For support, place packing foam or magazines here.
Page 9
www.sauder.com/services408726

Carefully turn your unit onto its front edges.
Fasten LEFT END (B) and UPRIGHT (D2) to the DESK TOP (G2). Tighten four HIDDEN CAMS.
6
6
S
t
e
p
B
D2
G2
Maximum
210 degrees
Minimum
190 degrees
Arrow
Unfinished edge
Page 10 www.sauder.com/services 408726Page 10 www.sauder.com/services 408726
