Sauder 418269 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 369030 03/18/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Writing Desk
418269
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
The original desktop.

Table of Contents Assembly Tools Required
3
4
5-18
19-21
22-24
25-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
418269 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C HUTCH RIGHT END (2)
D UPRIGHT (1)
E TOP (1)
F HUTCH TOP (1)
G MODESTY PANEL (1)
H BACK (1)
I RIGHT FRONT LEG (1)
J LEFT FRONT LEG (1)
K REAR LEG (2)
L DRAWER FRONT (1)
M HUTCH LEFT END (2)
D20 DRAWER RIGHT SIDE (1)
D21 DRAWER LEFT SIDE (1)
D74 DRAWER BACK (1)
D716 DRAWER BOTTOM (1)
Now you know
our ABCs.
418269www.sauder.com/services Page 3
A
B
D
E
F
G
H
I
J
K
L
C
M
K
D74
D21
D716
D20

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
418269 www.sauder.com/servicesPage 4
35GA CABINET RIGHT - 1 35GB CABINET LEFT - 1 35GC DRAWER RIGHT - 1 35GD DRAWER LEFT - 1
BLACK 1-7/8" FLAT HEAD SCREW - 7
2S
BLACK 7/8" MACHINE SCREW - 1
37S
CAM COVER - 6
12P
7F TWIST-LOCK®FASTENER - 4
3S GOLD 5/16" FLAT HEAD SCREW - 8
10A SLIDE CAM - 2
CAM SCREW - 6
8F
KNOB - 1
25K
WOOD DOWEL - 12
15F
NAIL - 24
1N
HIDDEN CAM - 20
1F CAM DOWEL - 14 2F
GLUE - 1
54M
30S BLACK 1-9/16" FLAT HEAD SCREW - 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the large holes in the
HUTCH ENDS (C and M).
418269www.sauder.com/services Page 5
7F
Do not tighten the TWIST-LOCK® FASTENERS in this step.
C
M
C
M

Step 2
å Push twenty HIDDEN CAMS (1F) into the ENDS (A and B),
UPRIGHT (D), and MODESTY PANEL (G). Then, insert the metal
end of a CAM DOWEL (2F) into each HIDDEN CAM, except the
long edges of the ENDS (A and B).
418269 www.sauder.com/servicesPage 6
(20 used)
(14 used)
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Do not insert
CAM DOWELS
into these edges.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
A
B
D
G

å Turn six CAM SCREWS (8F) into the FRONT LEGS (I and J).
å Fasten the ENDS (A and B) to the FRONT LEGS (I and J).
Tighten six HIDDEN CAMS.
Step 3
418269www.sauder.com/services Page 7
8F
(6 used)
A
B
I
J
I
J
1
2
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Edge with HIDDEN CAMS
These surfaces
should be even.
Angled edge
Angled edge
These surfaces
should be even.

Step 4
å Fasten the REAR LEGS (K) to the ENDS (A and B). Use six
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
418269 www.sauder.com/servicesPage 8
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
2S
Angled edge
A
B
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
K
K
Some assembly
(and snacks) required.

å Fasten the CABINET RIGHT (35GA) to the RIGHT END (A)
and the CABINET LEFT (35GB) to the UPRIGHT (D). Use
four GOLD 5/16" FLAT HEAD SCREWS (3S) through
holes #1 and #3.
Step 5
418269www.sauder.com/services Page 9
1
2
3
1
2
3
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Roller end
Roller end
A
Surface with
HIDDEN CAMS
D
Edge and surface
with HIDDEN CAMS
I

Step 6
å Fasten the MODESTY PANEL (G) to the ENDS (A and B).
Tighten six HIDDEN CAMS.
418269 www.sauder.com/servicesPage 10
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
A
B
G
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Notch
