Sauder 419198 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-14
Français p 15-17
Español p 18-20
Lot # 371387 03/31/15
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
4-Drawer Chest
Soft Modern Collection | 419198
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
The dresser's
not-so-distant cousin.

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
3
4
5-14
15-17
18-20
21-22
23
419198 www.sauder.com/servicesPae 2

åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification
A
B
C
D
E
F
D
H
D985
D30
D80
D31 G
419198www.sauder.com/services Pae 3
M67
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (2)
E BACK (1)
F SKIRT (1)
G DRAWER FRONT (4)
H HANDLE (4)
D30 RIGHT DRAWER SIDE (4)
D31 LEFT DRAWER SIDE (4)
D80 DRAWER BACK (4)
D985 DRAWER BOTTOM (4)
M67 DRAWER BRACE (4)

åScrews are shown actual size. You may receive extra hardware with your unit.
Hardware Identification
30S BLACK 1-9/16" FLAT HEAD SCREW - 20
10A SLIDE CAM - 8
BLACK 9/16" LARGE HEAD SCREW - 1
1S
3S GOLD 5/16" FLAT HEAD SCREW - 36
1F HIDDEN CAM - 8 2F CAM DOWEL - 8 10F TWIST-LOCK®
FASTENER - 4
SILVER 1-1/8" FLAT HEAD SCREW - 12
10S
METAL PIN - 6
1R
1N NAIL - 41
SAFETY
BRACKET - 1
1G
BLACK 1-7/8" FLAT HEAD SCREW - 1
2S
BROWN 1-5/8" FLAT HEAD SCREW - 3
55S
35GA CABINET RIGHT -4 35GB CABINET LEFT - 4 35GC DRAWER RIGHT - 4 35GD DRAWER LEFT - 4
(Refer to the last step for
proper location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent tip-
over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do
not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
5L WARNING LABEL - 1
419198 www.sauder.com/servicesPae 4

Step 1
åAssemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
åTo begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (10F) into the large holes in the ENDS (A and B).
10F
B
A
Do not tihten the TWIST-LOCK® FASTENERS in this step
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
419198www.sauder.com/services Pae 5

Step 2
å Push eiht HIDDEN CAMS (1F) into the BOTTOMS (D) and
DRAWER BRACES (I). Then, insert the metal end of a CAM
DOWEL (2F) into each HIDDEN CAM.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tihten the HIDDEN CAMS in this step.
(8 used)
Arrow
1F
2F
Arrow
1F
2F
D
D
I
I
I
I
419198 www.sauder.com/servicesPae 6

å Fasten four CABINET RIGHTS (35GA) to the RIGHT END (A)
and four CABINET LEFTS (35GB) to the LEFT END (B). Use
sixteen GOLD 5/16" FLAT HEAD SCREWS (3S) throuh holes
#1 and #3.
Step 3
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
Roller end
Finished ede
Roller end
Finished ede
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
A
B
419198www.sauder.com/services Pae 7
Remember:
Rihty tihty.
Lefty loosey.

å Fasten one of the BOTTOMS (D) to the SKIRT (F). Use
three BROWN 1-5/8" FLAT HEAD SCREWS (55S).
å Insert six METAL PINS (1R) into the BOTTOMS (D) and
SKIRT (F).
å Fasten the BOTTOMS (D) to the ENDS (A and B). Tihten
four HIDDEN CAMS.
å NOTE: Be sure the METAL PINS (1R) in the BOTTOMS (D)
and SKIRT (F) insert into the ENDS (A and B).
Step 4
1R
1R
Unfinished ede
Surface without TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Unfinished
ede
F
A
B
Finished surface
These edes
should be even.
D
D
D
F
Finished ede
Surface without HIDDEN CAMS
BLACK 1-5/8" FLAT HEAD SCREW
(3 used in this step)
55S
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Start Tihten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
Unfinished ede
419198 www.sauder.com/servicesPae 8

å Fasten the TOP (C) to the ENDS (A and B). Tihten four
TWIST-LOCK® FASTENERS.
Step 5
Surface with holes
C
A
B
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin the
FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Unfinished ede
419198www.sauder.com/services Pae 9
Don't worry. It isn't
Rome. This can be built
in a day.

å Unfold the BACK (E) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (E). Push
on opposite corners of your unit if needed to make it “square”.
å Fasten the BACK (E) to your unit usin the NAILS (1N).
Step 6
E
NAIL
(40 used in this step)
1N
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
419198 www.sauder.com/servicesPae 10
Printed information
must be facin up.
