Sauder 419188 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-445-1527.
Share your journey!
sauder.com
Storage Cabinet
Model 419188
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot #: 387418
Date Purchased: __________________
12/23/15
Be sure to give us a ring before
making any returns. 1-800-445-1527
Store behind
closed doors.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2-3
4
5-18
19-21
22-24
25-26
27
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F SHELF (1)
G BACK (1)
H RIGHT DOOR (1)
I LEFT DOOR (1)
J ADJUSTABLE SHELF (4)
K VALANCE (2)
L SKIRT (1)
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
Part Identification
Electric drill with 1/4" bit
(ONLY in indicated step)
Page 2 www.sauder.com 419188

Part Identification
A
BC
D
E
F
G
H
I
J
K
L
J
J
J
K
Page 3
www.sauder.com419188

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
SAFETY DRYWALL
ANCHOR - 1
5
Locate this SAFETY STRAP (6)
to be used later in assembly. Do
not accidentally throw away.
SAFETY STRAP - 1
6
1/2" PAN HEAD SCREW - 18
18
1/2" FLAT HEAD SCREW - 12
17
ANGLE BRACKET - 5
1HINGE - 6
2HINGE BRACKET - 6 3
NAIL - 40
12
1" PAN HEAD SCREW - 1
14
PULL - 2
4
APPLIQUE - 30
7METAL BRACKET - 2
8BOTTOM BRACKET - 1 9
DOOR BRACKET - 1
10 SHELF SUPPORT - 16 11
1-1/2" FLAT HEAD SCREW - 40
13
3/4" MACHINE SCREW - 4
15 5/8" PAN HEAD SCREW - 1 16
Page 4 www.sauder.com 419188
TACK GLIDE - 4
19

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Fasten five ANGLE BRACKETS (1) to the SKIRT (L). Use
five 1/2" PAN HEAD SCREWS (18).
å NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRT.
å Fasten the BOTTOM BRACKET (9) to the BOTTOM (E).
Use two 1/2" PAN HEAD SCREWS (18).
1
1/2" PAN HEAD SCREW
(7 used in this step)
18
Some assembly
(and snacks) required.
L
1
1
E
9
The molding on the other surface
of the BOTTOM should be here.
Page 5
www.sauder.com419188

å Fasten the SKIRT (L) to the BOTTOM (E). Use three 1/2" PAN
HEAD SCREWS (18) through the ANGLE BRACKETS on the
VALANCE and into the BOTTOM.
Step 2
L
E
1/2" PAN HEAD SCREW
(3 used in this step)
18
The molding on the
BOTTOM should be here.
Page 6 www.sauder.com 419188

FRONT
FRONT
FRONT
å Fasten the VALANCES (K) to the TOP (D). Use eight 1-1/2"
FLAT HEAD SCREWS (13).
Step 3
D
K
Some assembly
(and snacks) required.
Page 7
www.sauder.com419188
1-1/2" FLAT HEAD SCREW
(8 used in this step)
13
Finished surface
K
D
Unfinished surface
1st
2nd
This arrow should
be pointing up.
This arrow should
be pointing down.

Step 4
å Fasten two METAL BRACKETS (8) to the UPRIGHT (C).
Use two 1/2" PAN HEAD SCREWS (18).
å NOTE: Be sure the edges of the METAL BRACKETS are
even with the top edge of the UPRIGHT.
å Fasten the BOTTOM (E) to the UPRIGHT (C). Use two
1-1/2" FLAT HEAD SCREWS (13).
E
L
C
1-1/2" FLAT HEAD SCREW
(2 used in this step)
13
8
1/2" PAN HEAD SCREW
(2 used in this step)
18
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Page 8 www.sauder.com 419188
Top edge

Step
å Finish fastening the BOTTOM (E) to the SKIRT (L). Use
two 1-1/2" FLAT HEAD SCREWS (13).
å Fasten the SHELF (F) to the UPRIGHT (C). Use two 1-1/2"
FLAT HEAD SCREWS (13)
å Finish fastening the SHELF (F) to the UPRIGHT (C). Use
two 1/2" PAN HEAD SCREW S (18) through the METAL
BRACKETS on the UPRIGHT and into the SHELF.
å Then, peel four APPLIQUES (7) from the applique card
and stick them over the heads of the SCREWS (13).
Step 5
E
C
F
Peel the APPLIQUES
from the applique card.
7
L
1-1/2" FLAT HEAD SCREW
(4 used in this step)
13
7
The molding on the
SHELF should be here.
Page 9
www.sauder.com419188
1/2" PAN HEAD SCREW
(2 used in this step)
18

Step
å Fasten the HINGE BRACKETS (3) to the ENDS (A and B).
Use the SCREWS in the HINGE BRACKETS.
Step 6
B
A
3
3
Page 10 www.sauder.com 419188
3
