Sauder Carson Forge Technology Pier 412923 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 357478 12/11/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Technology Pier
Carson Forge Collection | 412923
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Spruce up. Chare up.

Table of Contents Assembly Tools Required
3
4
5-19
20-22
23-25
26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
412923 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E SHELF (1)
F SMALL BACK (1)
G LARGE BACK (1)
H DOOR (1)
I ADJUSTABLE SHELF (1)
J RIGHT FRONT LEG (1)
K LEFT FRONT LEG (1)
L REAR LEG (2)
M TOP FRONT MOLDING (1)
N UPPER END MOLDING (2)
O LOWER END MOLDING (2)
P TOP SIDE MOLDING (2)
412923www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
I
J
K
L
MN
O
P
L
N
O
P

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 1-7/8" FLAT HEAD SCREW - 3
GG
BLACK 2-1/4" FLAT HEAD SCREW - 4
FF
PULL - 1
CC RUBBER SLEEVE - 4 EE
METAL PIN - 4
DD
TWIST-LOCK®
FASTENER - 8
Q
SILVER 1/2" MACHINE SCREW - 4
KK
NAIL - 22
LL
BLACK 1/2" FLAT HEAD SCREW - 4
JJ
BLACK 9/16" LARGE HEAD SCREW - 13
HH BLACK 9/16" FLAT HEAD SCREW - 8 II
SAFETY BRACKET - 1
W
ANGLE
BRACKET - 6
VCORD CLIP - 2 X
UHINGE - 2
FOOT - 4
Z
CAM COVER - 6
BB
DOOR STOP - 1
AA
YCORNER ACCENT - 2
HIDDEN CAM - 9
1F CAM DOWEL - 5
2F
CAM SCREW - 4
8F
412923 www.sauder.com/servicesPage 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (Q) into the large holes in the ENDS (A and B)
and BOTTOM (D).
412923www.sauder.com/services Page 5
Q
Q
A
B
D
Do not tighten the TWIST-LOCK® FASTENERS in this step.

Step 2
å Push nine HIDDEN CAMS (1F) into the ENDS (A and B),
SMALL BACK (F), and LEGS (J, K, and L). Then, insert the
metal end of a CAM DOWEL (2F) into the HIDDEN CAMS
in the SMALL BACK (F) and LEGS (J, K, and L).
412923 www.sauder.com/servicesPage 6
A
B
J
K
L
L
F
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not insert
CAM DOWELS
into these parts.
Arrow
1F
Arrow
1F
(9 used)
(5 used)

å Turn four CAM SCREWS (8F) into the
FRONT LEGS (J and K).
Step 3
412923www.sauder.com/services Page 7
J
K
8F

Step 4
å Fasten a CORNER ACCENT (Y) to each FRONT LEG (J and K).
Use two SILVER 1/2" MACHINE SCREWS (KK).
å Fasten the ENDS (A and B) to the FRONT LEGS (J and K).
Tighten four HIDDEN CAMS.
412923 www.sauder.com/servicesPage 8
Y
J
K
A
B
Y
Surface
with
TWIST-LOCK®
FASTENERS
Surface
without
TWIST-LOCK®
FASTENERS
Angled edge
Edge with
TWIST-LOCK®
FASTENERS
Edge with
TWIST-LOCK®
FASTENERS
Angled edge
SILVER 1/2" MACHINE SCREW
(2 used in this step)
KK
12

å Fasten the BOTTOM (D) to the ENDS (A and B). Tighten
four TWIST-LOCK® FASTENERS.
å Fasten the SHELF (E) to the ENDS (A and B). Tighten four
TWIST-LOCK® FASTENERS.
Step 5
412923www.sauder.com/services Page 9
A
B
D
E
Surface
with
TWIST-LOCK®
FASTENERS
Unfinished
surface
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end
Notch
Rounded edge
Notch
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

Step 6
å Turn eight BLACK 9/16" FLAT HEAD SCREWS (II) into the
ENDS (A and B) until the shoulder of the SCREWS rest on
the surface of the ENDS.
å Line up the groove in the MOLDINGS over the head of the
SCREWS in the ENDS. Slide the END MOLDINGS (N and O)
onto the ENDS (A and B).
412923 www.sauder.com/servicesPage 10
A
B
N
O
N
O
Shoulder
Apply pressure with your hands as
you guide the MOLDINGS over the
SCREWS and onto the ENDS.
The LOWER END MOLDINGS (O) are wider
than the UPPER END MOLDINGS (N).
BLACK 9/16" FLAT HEAD SCREW
(8 used in this step)
II

å Fasten the REAR LEGS (L) to the ENDS (A and B). Use
four BLACK 2-1/4" FLAT HEAD SCREWS (FF).
å Fasten the SMALL BACK (F) to the SHELF (E). Use two
BLACK 1-7/8" FLAT HEAD SCREWS (GG).
Step 7
412923www.sauder.com/services Page 11
A
B
L
L
F
E
Angled edge
Angled edge
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
GG
Small holes
must face up.
BLACK 2-1/4" FLAT HEAD SCREW
(4 used in this step)
FF

Step 8
å Position the BACK (G) over your unit.
å Make equal margins along the top and bottom edges of the BACK (G).
Push on opposite corners of your unit if needed to make it "square".
å Fasten the BACK (G) to your unit using the NAILS (LL).
å NOTE: Perforations have been provided for access through the BACK.
Carefully cut out the holes needed.
å Turn two CORD CLIPS (X) into the SMALL BACK (F).
å NOTE: The CORD CLIPS are used to hold your cord against the BACK.
412923 www.sauder.com/servicesPage 12
Unfinished surface
G
X
F
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(22 used in this step)
LL

å Carefully stand your unit upright.
å Fasten the TOP (C) to the LEGS (J, K, and L) and SMALL
BACK (F). Tighten five HIDDEN CAMS.
Step 9
412923www.sauder.com/services Page 13
C
J
L
L
F
Flat edge
Start Tihten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
K

Step 10
å Carefully position your unit on the TOP (C).
å Fasten six ANGLE BRACKETS (V) to the TOP (C). Use six BLACK 9/16"
LARGE HEAD SCREWS (HH).
å Fasten the TOP MOLDINGS (M and P) to the TOP (C). Use six BLACK
9/16" LARGE HEAD SCREWS (HH) through the ANGLE BRACKETS and
into the TOP MOLDINGS.
å NOTE: There are no pre-drilled holes in the MOLDINGS.
The SCREWS will tighten into the groove.
å Using your hammer, gently tap a FOOT (Z)
onto each LEG (J, K, and L).
412923 www.sauder.com/servicesPage 14
J
K
L
L
Z
C
M
P
P
V
V
V
BLACK 9/16" LARGE HEAD SCREW
(12 used in this step)
HH

å Carefully stand your unit upright.
å The DOOR (H) can open from the left or right side. Refer to the diagrams below to
determine your preference.
å Push the DOOR STOP (AA) into one of the holes in the SHELF (E). Follow the diagrams
below to be sure you are using the correct hole location.
å NOTE: The following steps show the DOOR on the right.
Step 11
412923www.sauder.com/services Page 15
 DOOR ON LEFT 
 DOOR ON RIGHT 
AA
AA
E
E
- OPTION PAGE -
Do not fasten the door in this step.

Step 12
å Fasten two HINGES (U) to the DOOR (H). Use four BLACK
1/2" FLAT HEAD SCREWS (JJ).
412923 www.sauder.com/servicesPage 16
U
H
BLACK 1/2” FLAT HEAD SCREW
(4 used in this step)
JJ

å Fasten the DOOR (H) to the RIGHT END (A) or LEFT END (B).
Use the screws in the HINGES.
å NOTE: You may need to loosen the mounting screw to slide
the HINGE part way out of the slot. Retighten the mounting
screw before fastening the HINGE to the END.
å Fasten a PULL (CC) to the DOOR (H). Use two SILVER 1/2"
MACHINE SCREWS (KK).
Step 13
412923www.sauder.com/services Page 17
H
A
CC
Mounting screw
B
SILVER 1/2" MACHINE SCREW
(2 used in this step)
KK

Step 14
å Refer to the enlarged diagram to identify the parts on the HINGES.
å The DOOR may need some adjustments. Follow the text below to make needed adjustments.
å DOOR ADJUSTMENTS:
å To adjust the DOOR from side to side (horizontal), loosen the mounting screw several turns, then turn the adjusting screw
in or out. Tighten the mounting screw after making adjustments.
å To adjust the DOOR up and down (vertical), loosen both vertical adjustment screws. Move the DOOR up or down to the
desired location. Tighten the screws after making adjustments.
å To adjust the DOOR in or out (depth), loosen the mounting screw one turn and move the DOOR in or out, as needed.
Tighten the mounting screw after making adjustments.
412923 www.sauder.com/servicesPage 18
Mounting screw (depth)
(vertical adjustment)
Adjusting screw (horizontal)

å Push the RUBBER SLEEVES (EE) over the METAL PINS (DD). Insert the METAL PINS into the hole locations of your choice
in the ENDS (A and B). Set the ADJUSTABLE SHELF (I) onto the METAL PINS.
å We recommend using the SAFETY BRACKET (W) for added stability. Use a BLACK 9/16" LARGE HEAD SCREW (HH) into
the top of the unit and a BLACK 1-7/8" FLAT HEAD SCREW (GG) into a stud in your wall.
å Push a CAM COVER (BB) onto each visible HIDDEN CAM.
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
Step 15
412923www.sauder.com/services Page 19
And to celebrate, why not share your success story?
A
BI
DD
EE
C
25 lbs.
30 lbs.
40 lbs.
40 lbs.
BB
To cover HIDDEN CAMS
(4 used)
(6 used)
W
BLACK 1-7/8" FLAT HEAD SCREW
(1 used into a stud in your wall)
GG
HH
BLACK 9/16" LARGE HEAD SCREW
(1 used into the top of your unit)

A l’usage exclusif du
Canada Noter la date
d’achat de cet élément
et conserver le livret
pour future référence.
Pour contacter Sauder
en ce qui concerne cet
élément, faire référence
au numéro de lot et
numéro de modèle en
appelant notre numéro
sans frais.
Lot nº : ____________
Date de
l’achat: ____________
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS SOMMES LA POUR VOUS AIDER!
Nous faisons de notre mieux pour nous assurer que votre meuble
arrive dans d’excellentes conditions. Nos représentants du service
Clientèle sont aimables et prêts à vous aider au cas où une pièce
aurait été endommagée ou manquerait (ou si vous aviez besoin
d’aide pour l’assemblage). NE RAMENEZ PAS LE MEUBLE AU
MAGASIN. Au Canada, composez ce numéro d’appel gratuit:
1-800-523-3987
Du lundi au vendredi, de 9 heures du matin à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
Utilisez les instructions d’assemblage en français avec les
schémas étape par étape du manuel d’instruction en anglais.
Chaque étape en français correspond à la même étape
en anglais. La pièce devant être attachée à l’élément est
représentée en gris sur les schémas de chaque étape pour plus
de précision. Comparer la “Liste de pièces” ci-dessous avec
la “PART IDENTIFICATION” du manuel en anglais pour vous
familiariser avec les pièces avant l’assemblage.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À LA SÉCURITÉ.
À LIRE ET CONSERVER POUR TOUTE RÉFÉRENCE FUTURE.
Meuble pour technologie412923
Q FIXATION TWIST-LOCK®.......................................8
1F EXCENTRIQUE ESCAMOTABLE.....................9
8F VIS D'EXCENTRIQUE ...............................................4
2F CHEVILLE D'EXCENTRIQUE ..............................5
U CHARNIÈRE.....................................................................2
V CONSOLE À ÉQUERRE.........................................6
W CONSOLE DE SÉCURITÉ......................................1
X CLIP DE CORDON......................................................2
Y ACCENT D’ANGLE.....................................................2
Z PIED........................................................................................4
AA ARRÊT DE PORTE.......................................................1
BB COUVERCLE D'EXCENTRIQUE.......................6
CC POIGNÉE.............................................................................1
DD GOUPILLE EN MÉTAL.............................................4
EE MANCHON EN CAOUTCHOUC.....................4
FF VIS NOIRE TÊTE PLATE 57 mm.....................4
GG VIS NOIRE TÊTE PLATE 48 mm.....................3
HH VIS NOIRE TÊTE LARGE 14 mm.................. 13
II VIS NOIRE TÊTE PLATE 14 mm......................8
JJ VIS NOIRE TÊTE PLATE 13 mm......................4
KK VIS ARGENTÉE À MÉTAUX
13 mm..................................................................................4
LL CLOU ................................................................................ 22
A EXTRÉMITÉ DROITE..................................................1
B EXTRÉMITÉ GAUCHE...............................................1
C DESSUS...............................................................................1
D DESSOUS...........................................................................1
E TABLETTE..........................................................................1
F PETIT ARRIÈRE..............................................................1
G GRAND ARRIÈRE..........................................................1
H PORTE...................................................................................1
I TABLETTE RÉGLABLE.............................................1
J PIED AVANT DROIT....................................................1
K PIED AVANT GAUCHE.............................................1
L PIED ARRIÈRE................................................................2
M MOULURE DE DESSUS AVANT.......................1
N MOULURE D'EXTRÉMITÉ
SUPÉRIEURE...................................................................2
O MOULURE D'EXTRÉMITÉ
INFÉRIEURE.....................................................................2
P MOULURE DE DESSUS
LATÉRALE.........................................................................2
412923 www.sauder.com/servicesPage 20
