Sauder Craft Pro 421405 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-445-1527.
Share your journey!
sauder.com
Treat yourshelf.
Open Storage Cabinet
Craft Pro Series Collection | Model 421405
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-12
Français pg 13-14
Español pg 15-16
Lot #: 509766
Date Purchased: __________________
11/03/17
Be sure to give us a ring before
making any returns. 1-800-445-1527

Table of Contents Assembly Tools Required
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4
5-12
13-14
15-16
17-18
19
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Page 2 www.sauder.com 421405

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D UPRIGHT (1)
E LEFT BOTTOM (1)
F RIGHT BOTTOM (1)
G ADJUSTABLE SHELF (6)
H BASE (1)
I UPPER BACK (1)
J LOWER BACK (1)
A
B
C
D
E
F
G
H
I
J
G
G
G
G
G
Page 3www.sauder.com421405

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
HIDDEN CAM - 17
1CAM SCREW - 17 2
CAM COVER CARD - 1
6
WOOD DOWEL - 9
3
SILVER 1/2" FLAT HEAD SCREW - 26
7
METAL PIN - 24
5
SILVER 1/2" PAN HEAD SCREW - 8
8
METAL BRACKET - 4
4
Page 4 www.sauder.com 421405

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
B
A
D
E
F
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push seventeen HIDDEN CAMS (1) into the ENDS (A
and B), UPRIGHT (D), BOTTOMS (E and F).
1
Arrow
(17 used)
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
Page 5www.sauder.com421405

Step 2
å Turn seventeen CAM SCREWS (2) into the ENDS (A and B),
TOP (C), UPRIGHT (D), and BASE (H).
B
A
C
D
H
2
(17 used)
Page 6 www.sauder.com 421405
2

Step 3
å Insert two WOOD DOWELS (3) into the LEFT END (B) and
UPRIGHT (D).
å Fasten the LEFT END (B) and UPRIGHT (D) to the LEFT
BOTTOM (E). Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the LEFT END and
UPRIGHT insert into the holes in the LEFT BOTTOM.
Finished edge
Finished edge
Surface with
HIDDEN CAMS
3
B
E
D
These holes must
be facing up.
Page 7www.sauder.com421405

Step 4
Finished edge
Surface with
HIDDEN CAMS
3
FA
4
å Fasten the RIGHT BOTTOM (F) to the UPRIGHT (D). Tighten two HIDDEN CAMS.
å Insert one WOOD DOWEL (3) into the RIGHT END (A).
å Fasten the RIGHT END (A) to the RIGHT BOTTOM (F). Tighten two HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWEL in the RIGHT END inserts into the hole in the
RIGHT BOTTOM.
å Fasten four METAL BRACKETS (4) to the BOTTOMS (E and F). Use four SILVER
1/2" PAN HEAD SCREWS (8).
D
SILVER 1/2" PAN HEAD SCREW
(4 used in this step)
8
Page 8 www.sauder.com 421405
E
Slotted hole

Step 5
å Insert three WOOD DOWELS (3) into the ENDS (A and B)
and UPRIGHT (D).
å Fasten the BASE (H) to the ENDS (A and B) and
UPRIGHT (D). Tighten three HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the ENDS and
UPRIGHT insert into the hole in the BASE.
å Fasten the BASE (H) to the BOTTOMS (E and F). Use four
SILVER 1/2" PAN HEAD SCREWS (8).
3
A
D
B
H
SILVER 1/2" PAN HEAD SCREW
(4 used in this step)
8
F
E
Flat edge
Page 9www.sauder.com421405

Step 6
å Insert three WOOD DOWELS (3) into the center holes
in the TOP (C).
å Fasten the TOP (C) to the ENDS (A and B) and
UPRIGHT (D). Tighten six HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the TOP
insert into the hole in the ENDS and UPRIGHT.
A
D
B
C
3
Meet Part (C). This component has been
engineered to be lighter, stronger, faster…
well ok. Not technically faster. But
definitely makes for a sturdier Storage
Cabinet that’s easier to assemble and
friendlier to the environment.
Page 10 www.sauder.com 421405
Edge without holes
