NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 570163 07/13/21
Purchased: __________________
Library Hutch
Cannery Bridge Collection | Model 429554
For things 'n such.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
Table of Contents Assembly Tools Required
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Hammer
Not actual size
3
4
5
6-22
23-25
26-28
29-30
31
Page 2 www.sauder.com/service 429554
Pencil
Electric drill with 1/8" or 3/8" bit
(ONLY in indicated step)
Scissors
Masking Tape

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A LEFT END (1)
B RIGHT END (1)
C TOP (1)
D TOP BRACE (2)
E SHELF (2)
F BACK (1)
J BOTTOM BRACE (1)
Page 3www.sauder.com/service429554
A
B
C
D
E
F
J
E
D

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
HIDDEN CAM - 24
2
WOOD DOWEL - 10
1CAM SCREW - 24
3
2-1/2" FLAT HEAD SCREW - 2
15
1/2" PAN HEAD SCREW - 4
13 3/4" PAN HEAD SCREW - 8 14
6NAIL - 28 TIE PLATE - 2
7APPLIQUE CARD - 2
9FURNITURE TIPPING
RESTRAINT KIT - 1
96
Page 4 www.sauder.com/service 429554

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Page 5www.sauder.com/service429554

Step 1
å NOTE: You will need someone's help later in assembly.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push fourteen HIDDEN CAMS (2) into the TOP (C) and
TOP BRACES (D).
å NOTE: Be sure the HIDDEN CAMS are completely
inserted into the holes.
å Turn six CAM SCREWS (3) into the TOP BRACES (D).
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code. 1
Page 6 www.sauder.com/service 429554
2
Arrow
Arrow
2
2
Arrow
3
(14 used)
Arrow
2
(6 used)
C
D
D
Remember:
Righty tighty.
Lefty loosey.

å Insert four WOOD DOWELS (1) into the TOP BRACES (D).
å Fasten the TOP BRACES (D) to the TOP (C). Tighten six
HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the BRACES insert
into the TOP.
Step 2
Page 7www.sauder.com/service429554
1
C
D
D
Surface with
HIDDEN CAMS
1
These surfaces
should be even.
1

å Open the FURNITURE TIPPING RESTRAINT KIT (96),
and fasten the SAFETY STRAP to the TOP (C). Use the
provided SHORT SCREW.
å Turn nine CAM SCREWS (3) into the exact holes shown in
the LEFT END (A).
Step 3
Page 8 www.sauder.com/service 429554
96
C
Surface without
HIDDEN CAMS
Use the SHORT SCREW
from the RESTRAINT KIT.
SAFETY STRAP
1
3
(9 used)
This hole must be here.
A

å Insert two WOOD DOWELS (1) into the LEFT END (A).
å Fasten the LEFT END (A) to the TOP (C) and TOP
BRACES (D). Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the END insert
into the TOP.
Step 4
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Page 9www.sauder.com/service429554
1
1
C
Surface with
HIDDEN CAMS
SAFETY STRAP
This hole
must be here.
A
D
D

å Push ten HIDDEN CAMS (2) into the SHELVES (E) and
BOTTOM BRACE (J).
å NOTE: Be sure the HIDDEN CAMS are completely
inserted into the holes.
å Insert one WOOD DOWEL (1) into the LEFT END (A).
å Fasten the SHELVES (E) and BOTTOM BRACE (J) to
the LEFT END (A). Tighten five HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWEL in the END inserts
into the BOTTOM BRACE.
Step 5
Page 10 www.sauder.com/service 429554
1
2
Arrow
(10 used)
Arrow
2
1
A
J
E
E
J
E
Surface with
HIDDEN CAMS
Unfinished edge
E
Surface with
HIDDEN CAMS
Surface with HIDDEN CAMS
Meet Part (E). This component
has been engineered to be lighter,
stronger, faster… well ok. Not
technically faster. But definitely
makes for a sturdier Library Hutch
that’s easier to assemble and
friendlier to the environment.

Step 6
å Turn nine CAM SCREWS (3) into the exact holes shown in
the RIGHT END (B).
å Insert three WOOD DOWELS (1) into the RIGHT END (B).
å Fasten the RIGHT END (B) to the TOP (C), SHELVES (E),
and BOTTOM BRACE (J). Tighten nine HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the END insert
into the TOP and BOTTOM BRACE.
Page 11www.sauder.com/service429554
1
1
1
J
E
E
C
B
B
3
(9 used)
Hey! It's starting to look
like something!

å Unfold the BACK (F) and lay it over your unit.
å Fasten the lower edge of the BACK (F) to the BOTTOM
BRACE (J). Use four 1/2" PAN HEAD SCREWS (13).
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
å Finish fastening the BACK (F) to your unit using
the NAILS (6).
å NOTE: Be sure to tap NAILS into the holes that line up
over the SHELVES (E).
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Step 7
Page 12 www.sauder.com/service 429554
J
1/2" PAN HEAD SCREW
(4 used in this step)
13
These holes must line up
over the SHELVES (E).
Unfinished surface
F
1st
2nd
NAIL
(28 used in this step)
6

å You have the option to fasten your Hutch to the 429514, 429515, or the 431315.
å The same attachment method is used for all base units. This book will show your
Hutch being fastened to the 429514
.
Step 8
Page 13www.sauder.com/service429554
429514
429515
431315

Step 9
Page 14 www.sauder.com/service 429554
å 1st- Go to Pages 16-17 and cut out the templates for attaching your Hutch to the base unit.
å 2nd- Use masking tape to fasten the templates to the edges and surface of the base unit top.
å 3rd- Drill a 1/8" hole through each of the two marked locations on the templates and into the base top.
å 4th- Remove the templates.
With someone's help, place the Hutch onto the base top. Center the Hutch on the base unit
with the back edges even with the back edge of the base top.
å 5th- Fasten the ENDS (A and B) to the base top. Use two 2-1/2" FLAT HEAD SCREWS (15).
Electric drill with 1/8" bit
3rd
4th
2nd
Tape each template to
the corresponding corner
of the base unit top.
A
B
2-1/2" FLAT HEAD SCREW
(2 used in this step)
15
After drilling each 1/8"
hole into the base top,
remove the templates.
5th

Page 15www.sauder.com/service429554
This page was intentionally left blank.
Cette page a été intentionnellement laissée vierge.
Esta página fue dejada en blanco intencionalmente.

1) Carefully remove Pages 15-18 from the book and cut
along all dashed lines on this template.
1) Retirez soigneusement les pages 15-18 du livret et
découpez le long des lignes en pointillés sur ce gabarit.
1) Retire con cuidado las páginas 15-18 del libro y corte
a lo largo de todas las líneas discontinuas en esta plantilla.
Page 16 www.sauder.com/service 429554
BACK EDGE OF BASE TOP BORD ARRIÈRE DU DESSUS DE L’UNITÉ DE BASE BORDE POSTERIOR DEL PANEL SUPERIOR DE LA UNIDAD BASE
LEFT EDGE OF BASE TOP
BORD GAUCHE DU DESSUS DE L’UNITÉ DE BASE
BORDE IZQUIERDO DEL PANEL SUPERIOR DE LA UNIDAD BASE
RIGHT EDGE OF BASE TOP
BORD DROIT DU DESSUS DE L’UNITÉ DE BASE
BORDE DERECHO DEL PANEL SUPERIOR DE LA UNIDAD BASE
BACK EDGE OF BASE TOP BORD ARRIÈRE DU DESSUS DE L’UNITÉ DE BASE BORDE POSTERIOR DEL PANEL SUPERIOR DE LA UNIDAD BASE

2) You will use this template in Step 9.
2) On utilisera ce gabarit à l’Étape 9.
2) Usará esta plantilla en el Paso 9.
2) You will use this template in Step 9.
2) On utilisera ce gabarit à l’Étape 9.
2) Usará esta plantilla en el Paso 9.
Page 17www.sauder.com/service429554
First, tape the cut-out template to the BACK and RIGHT edges and surface of
the base unit top.
Next, drill a 1/8" hole through this location.
Tout d'abord, coller le gabarit de découpe aux bords ARRIÈRE et DROIT et à la
surface du dessus de l'unité de base.
Ensuite, percer un trou de 3 mm à travers cet emplacement.
Primero, pegue con cinta adhesiva la plantilla recortada a los bordes
POSTERIOR y DERECHO y a la superficie del panel superior de la unidad base.
A continuación, taladre un agujero de 3 mm a través de esta ubicación.
First, tape the cut-out template to the BACK and LEFT edges and surface of the
base unit top.
Next, drill a 1/8" hole through this location.
Tout d'abord, coller le gabarit de découpe aux bords ARRIÈRE et GAUCHE et à la
surface du dessus de l'unité de base.
Ensuite, percer un trou de 3 mm à travers cet emplacement.
Primero, pegue con cinta adhesiva la plantilla recortada a los bordes
POSTERIOR y IZQUIERDO y a la superficie del panel superior de la unidad base.
A continuación, taladre un agujero de 3 mm a través de esta ubicación.

This page was intentionally left blank.
Cette page a été intentionnellement laissée vierge.
Esta página fue dejada en blanco intencionalmente.
Page 18 www.sauder.com/service 429554

å 1st- Fasten two TIE PLATES (7) to the back edges of the ENDS (A
and B). Use four 3/4" PAN HEAD SCREWS (14).
å There are no pre-drilled holes in the back edges of the base unit.
å 2nd- Drill a 1/8" hole through each of the bottom holes in the TIE
PLATES and into the back edges of the base unit.
å 3rd- Fasten the TIE PLATES (7) to the base unit. Use four 3/4" PAN
HEAD SCREWS (14).
Step 10
7
If you're doing this to
help a friend, don't
leave without a bite.
Page 19www.sauder.com/service429554
Electric drill with 1/8" bit
2nd
and
3rd
1st
B
A
3/4" PAN HEAD SCREW
(8 used in this step)
14
Fasten the TIE PLATE
to the base unit.

Step 11
Page 20 www.sauder.com/service 429554
96
å Place your unit in its final location.
å NOTE: The following instructions show your unit being fastened to a wall stud. If you are not fastening your unit to a
wall stud, go to the next step now.
å 1st- Locate the center of a stud in your wall near your unit and mark it with a pencil.
å 2nd- Drill a 1/8" hole on the mark and into the stud in your wall.
å 3rd-
Fasten the unit to the wall. Use the LONG SCREW through the other end of the SAFETY STRAP and into the 1/8" hole.
1st
3rd
Mark and drill
a 1/8" hole into
the wall stud. Electric drill with 1/8" bit
2nd
