Sauder Primary Street 418388 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-10
Français pg 11-12
Español pg 13-14
Lot # 370023 02/27/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Twin Headboard
Primary Street Collection | 418388
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Warranty
3
4
5-10
11-12
13-14
15
418388 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B LARGE PANEL (1)
C CENTER PANEL (1)
D UPPER PANEL (1)
E LOWER PANEL (1)
F RIGHT LEG (1)
G LEFT LEG (1)
H BRACE (2)
I TOP MOLDING (1)
J RED PANEL (1)
K BLUE PANEL (1)
L GREEN PANEL (1)
M YELLOW PANEL (1)
A
B
C
D
E
F
G
H
H
I
J K
OR
L M
L M
OR
OR
418388www.sauder.com/services Page 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
NUT - 4
24M
SILVER 2" BOLT - 4
94S
GOLD 1" MACHINE SCREW - 20
50S
SILVER 1-1/8" FLAT HEAD SCREW - 5
10S
BLACK 1" PAN HEAD SCREW - 12
60S
WOOD DOWEL - 8
15F
HIDDEN CAM - 20
1F CAM DOWEL - 20 2F
GLUE - 1
54M
BLACK
WASHER - 4
13M SILVER
WASHER - 20
77M
418388 www.sauder.com/servicesPage 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twenty HIDDEN CAMS (1F) into the PANELS (B, C, D,
and E). Then, insert the metal end of a CAM DOWEL (2F)
into each HIDDEN CAM.
418388www.sauder.com/services Page 5
Arrow
1F
2F
Arrow
1F
2F
(20 used)
(20 used)
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
B
C
D
E
A tracking label will be here.
Please do not remove.

å Fasten the BRACES (H) to the PANELS (B, C, D, and E).
Use twelve BLACK 1" PAN HEAD SCREWS (60S).
Step 2
418388 www.sauder.com/servicesPage 6
BLACK 1" PAN HEAD SCREW
(12 used in this step)
60S
H
H
B
C
D
E
Be sure these holes
are here approximately
1" from the edge.
These holes must be here.
Edge with CAM DOWELS

å First, fill the holes in PANELS (B, C, D and E ) facing the
LEFT LEG (G), 1/4 to 1/2 full with GLUE (54M). Then,
insert four WOOD DOWELS (15F) into the holes. Wipe
away the excess GLUE.
å Now, fill the 2nd, 5th, 8th, and 11th holes in the LEFT LEG (G)
1/4 to 1/2 full with GLUE. Then, insert the WOOD DOWELS
in the PANELS into these holes. Wipe away the excess
GLUE. Tighten eight HIDDEN CAMS.
å Repeat this step gluing the WOOD DOWELS and RIGHT
LEG (F) to the other end of the PANELS (B, C, D, and E).
Then, tighten eight HIDDEN CAMS.
Step 3
418388www.sauder.com/services Page 7
B
C
D
E
Fill the holes 1/4 to
1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely dicult.
Caution
!
54M
15F
15F
G
F
IMPORTANT
Before you fasten the LEGS (G and F), be
sure the first three holes in each LEG are
further apart and line up with the holes in
the LARGE PANEL (B).
Then, drop glue into the 2nd, 5th, 8th and
11th hole in each LEG (G and F).
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
These surfaces should
be nearly even.
1ST hole
2nd
2nd
1ST hole
These surfaces should
be nearly even.

å Fasten the TOP MOLDING (I) to the TOP (A). Use five
SILVER 1-1/8" FLAT HEAD SCREWS (10S).
å Fasten the TOP MOLDING (I) to the UPPER PANEL (D).
Tighten four HIDDEN CAMS.
Step 4
418388 www.sauder.com/servicesPage 8
Rounded edge
Finished surface
SILVER 1-1/8" FLAT HEAD SCREW
(5 used in this step)
10S
A
A
I
The rounded edges
are facing the floor.
Arrow
Minimum
190 degrees
Maximum
210 degrees
I
D

å NOTE: The GREEN PANEL (L) and YELLOW PANEL (M)
are interchangeable with each other. The BLUE PANEL (K)
and RED PANEL (J) are interchangeable with each other.
å You may need help in this step. With the colored PANELS
within reach, hold your Headboard upright while fastening
the PANELS (J, K, L, and M).
å Fasten the PANELS (J, K, L, and M) in the color
configuration of your choice. Use twenty GOLD 1" MACHINE
SCREWS (50S) through the SILVER WASHERS (77M) and
into the threaded holes in the back of the PANELS.
Step 5
418388www.sauder.com/services Page 9
J K
OR
J K
OR
L M
OR
GOLD 1" MACHINE SCREW
(20 used in this step)
50S
(20 used)
77M

å Fasten your bed frame to your Headboard. Use the SILVER
2" BOLTS (94S), WASHERS (13M), and the NUTS (24M).
å This completes assembly. Clean with your favorite
furniture polish or a damp cloth. Wipe dry.
Step 6
418388 www.sauder.com/servicesPage 10
SILVER 2" BOLT WASHER NUT
(4 of each used in this step)
94S 13M 24M
And to celebrate, why not share your success story?
94S
13M
24M
