Sauder Primary Street 417912 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-13
Français pg 14-15
Español pg 16-17
Lot # 370037 03/02/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Night Stand
Primary Street Collection |Model 417912
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4
5-13
14-15
16-17
18
19
417912 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F BASE (1)
G DRAWER FRONT (1)
B31 DRAWER BOTTOM (1)
D36 RIGHT DRAWER SIDE (1)
D37 LEFT DRAWER SIDE (1)
D482 DRAWER BACK (1)
417912www.sauder.com/services Page 3
A
B
C
D
E
F
G
D36
D37
D482
B31

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
417912 www.sauder.com/servicesPage 4
DRAWER FRONT BRACKET - 1
9G
35AA UNIVERSAL CABINET RAIL - 235AC DRAWER RIGHT - 135AD DRAWER LEFT - 1
SILVER 1/2" MACHINE SCREW - 4
38S
METAL BRACKET - 3
4G
BLACK 9/16" LARGE HEAD SCREW - 6
1S 3S GOLD 5/16" FLAT HEAD SCREW - 8
NAIL - 18
1N
HIDDEN CAM - 8
1F CAM DOWEL - 8 2F
30S BLACK 1-9/16" FLAT HEAD SCREW - 4
WASHER - 4
77M

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push eight HIDDEN CAMS (1F) into the ENDS (A and B)
and BOTTOM (D). Then, insert the metal end of a CAM
DOWEL (2F) into each HIDDEN CAM.
417912www.sauder.com/services Page 5
Arrow
1F
2F
(8 used)
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
B
D

Step 2
417912 www.sauder.com/servicesPage 6
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to
the ENDS (A and B). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S).
å *patent pending glide system
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Glide end
3
2
1
1
2
3
Remember:
Righty tighty.
Lefty loosey.
Glide end
A
B
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Finished edge
Finished edge

å Fasten the ENDS (A and B) to the BOTTOM (D). Tighten
four HIDDEN CAMS.
Step 3
417912www.sauder.com/services Page 7
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
A
B
Finished edge
Finished edge
D
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with
HIDDEN CAMS
This hole must be here.

å Fasten the TOP (C) to the ENDS (A and B). Tighten four
HIDDEN CAMS.
Step 4
417912 www.sauder.com/servicesPage 8
Arrow
Minimum
190 degrees
Maximum
210 degrees
A
B
C
Surface with holes
Rounded edge

Step 5
417912www.sauder.com/services Page 9
å Fasten three METAL BRACKETS (4G) to the ENDS (A
and B) and BOTTOM (D). Use three BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the edges of the METAL BRACKETS are
even with the edges of the ENDS and BOTTOM.
å Fasten the BASE (F) to the ENDS (A and B) and
BOTTOM (D). Use three BLACK 9/16" LARGE HEAD
SCREWS (1S) through the METAL BRACKETS and into
the BASE.
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
Don't worry. It isn't
Rome. This can be built
in a day.
4G
4G
4G
Rounded edge
A
B
D
F

Step 6
417912 www.sauder.com/servicesPage 10
å Carefully turn your unit over onto its front edges. Lay the
BACK (E) over your unit.
å Make equal margins along all four edges of the BACK (E).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (E) to your unit using the NAILS (1N).
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(18 used in this step)
1N
Printed information must
be facing up.
E
