Sauder Via 419708 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 376837 10/05/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Lateral File Hutch
Via Collection | 419708
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Knick-knack
paddywhack,
give your stu a home.

Table of Contents Assembly Tools Required
3
4
5-19
20-22
23-25
26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
419708 www.sauder.com/servicesPage 2
Electric drill with 1/4" bit
(ONLY in indicated step)

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D UPPER SHELF (1)
E LOWER SHELF (1)
F UPPER BACK (1)
G LOWER BACK (1)
H LARGE UPRIGHT (1)
I SMALL UPRIGHT (1)
J RIGHT DOOR (1)
K LEFT DOOR (1)
L VALANCE (1)
M BULLETIN BOARD (1)
Now you know
our ABCs.
419708www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
J
K
L
M
I

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
419708 www.sauder.com/servicesPage 4
FELT DISC CARD - 1
1M
GOLD 1" MACHINE SCREW - 4
50S
BLACK 9/16" LARGE HEAD SCREW - 6
1S
ANGLE BRACKET - 3
5G
BROWN 7/16" LARGE HEAD SCREW - 4
6S
BLACK 1-7/8" FLAT HEAD SCREW - 6
2S
BLACK 2-1/4" FLAT HEAD SCREW - 4
26S
TOUCH-UP PEN - 1
10M
7F TWIST-LOCK®
FASTENER - 10 13F MINI TWIST-LOCK® FASTENER - 12
61P TWIST-LOCK®
FASTENER COVER - 10 62P MINI TWIST-LOCK® COVER - 8 METAL PIN - 6
1R
PULL - 2
12K
BLACK 1/2" FLAT HEAD SCREW - 8
11S
HINGE - 4
53H
BULLETIN BOARD
BRACKET - 4
63G
CORD COVER - 2
66P

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a MINI SAUDER TWIST-LOCK®
FASTENER (13F) into the large holes in the BACKS (F and G).
å Push a SAUDER TWIST-LOCK® FASTENER (7F) into the
large holes in the ENDS (A and B), LOWER SHELF (E), and
LARGE UPRIGHT (H).
419708www.sauder.com/services Page 5
Do not tighten the TWIST-LOCK®
FASTENERS in this step.
7F
7F
13F
13F
13F
A
B
E
F
G
H

Step 2
å Fasten the LARGE UPRIGHT (H) to the TOP (C). Tighten
two TWIST-LOCK® FASTENERS.
å Fasten the UPPER BACK (F) to the TOP (C). Tighten two
MINI TWIST-LOCK® FASTENERS.
419708 www.sauder.com/servicesPage 6
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end
F
H
C
Surface with holes
Surface with
TWIST-LOCK®
FASTENERS
Surface with MINI
TWIST-LOCK®
FASTENERS
Edge without holes

å Fasten the UPPER SHELF (D) to the LARGE UPRIGHT (H).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 3
419708www.sauder.com/services Page 7
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
H
D
Surface with
more holes
Finished edge

Step 4
å Insert two METAL PINS (1R) into the holes in the UPPER SHELF (D).
å Place the SMALL UPRIGHT (I) onto the METAL PINS (1R) in the
UPPER SHELF (D).
419708 www.sauder.com/servicesPage 8
D
I
1R
Finished edge
Edge with smaller holes

å Fasten the LOWER SHELF (E) to the UPPER BACK (F)
and SMALL UPRIGHT (I). Use four BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
å Fasten the LOWER BACK (G) to the LOWER SHELF (E).
Tighten two MINI TWIST-LOCK® FASTENERS.
Step 5
419708www.sauder.com/services Page 9
I
E
G
Surface with MINI
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
F

Step 6
å Insert four METAL PINS (1R) into the holes in the ENDS (A and B).
å Fasten the ENDS (A and B) to the TOP (C) and LOWER SHELF (E).
Tighten eight TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the ENDS insert into the holes
in the UPPER SHELF (D).
å Fasten the ENDS (A and B) to the BACKS (F and G). Fasten eight
MINI TWIST-LOCK® FASTENERS.
419708 www.sauder.com/servicesPage 10
D
E
G
F
A
B
Surface with
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Edge with
TWIST-LOCK®
FASTENERS
Edge with
TWIST-LOCK®
FASTENERS
1R
(4 used)
C
