Sauder HomePlus 411591 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-16
Français pg 17-18
Español pg 19-20
Lot # 532704 08/15/19
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Base Cabinet
HomePlus Collection | Model 411591
Store behind
closed doors.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
3
4
5-16
17-18
19-20
21-22
23
411591 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F DOOR (2)
G ADJUSTABLE SHELF (1)
H FRONT SKIRT (1)
J TOP MOLDING (1)
R SIDE SKIRT (2)
411591www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
J
R
F
R

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
411591 www.sauder.com/servicesPage 4
REAR FOOT - 2
31E FRONT FOOT - 2 32E TWIST-LOCK®
FASTENER - 7
7F
SAFETY
BRACKET - 1
1G TIE
PLATE - 1
3G LARGE RUBBER
SLEEVE - 1
59G PULL - 2 97K
1R METAL
PIN - 4 2R RUBBER SLEEVE - 4
ADJUSTABLE
GLIDE - 4
18E
PROPEL
NUT - 4
14M
BLACK 1-7/8" FLAT HEAD SCREW - 5
2S
SILVER 1-1/8" FLAT HEAD SCREW - 2
10S
BLACK 7/8" MACHINE SCREW - 4
37S
BLACK 9/16" LARGE HEAD SCREW - 2
1S
BLACK 9/16" WAFER HEAD SCREW - 4
33S
BLACK 1/2" FLAT HEAD SCREW - 8
11S
NAIL - 30
1N
13H HINGE - 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push four SAUDER TWIST-LOCK®
FASTENERS (7F) into the large holes in the ENDS (A and B).
å Repeat this step for the TOP (C).
411591www.sauder.com/services Page 5
7F
A
B
(7 used)
Do not tighten the TWIST-LOCK® FASTENERS in this step.

å Fasten the ENDS (A and B) to the TOP (C). Tighten four
TWIST-LOCK® FASTENERS.
Step 2
411591 www.sauder.com/servicesPage 6
A
B
C
Surface with holes
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
Finished edge
Edge with TWIST-LOCK® FASTENERS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

å Fasten the BOTTOM (D) to the ENDS (A and B). Use four
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 3
411591www.sauder.com/services Page 7
Remember:
Righty tighty.
Lefty loosey.
A
B
D
Unfinished surface
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
Rounded edge

å Fasten the TOP MOLDING (J) to the TOP (C). Tighten three
TWIST-LOCK® FASTENERS.
å Slip a LARGE RUBBER SLEEVE (59G) over the TIE PLATE (3G).
The RUBBER SLEEVE will be a tight fit.
å Then, fasten the TIE PLATE (3G) to the TOP MOLDING (J). Use
a BLACK 9/16" LARGE HEAD SCREW (1S).
Step 4
411591 www.sauder.com/servicesPage 8
J
C
3G
59G
Wide edge
BLACK 9/16" LARGE HEAD SCREW
(1 used for the TIE PLATE)
1S

å Slide the FEET (31E and 32E) into the notches in the SKIRTS (H and R).
å Use a hammer to drive a PROPEL NUT (14M) into the holes in the FEET (31E
and 32E). Now, turn an ADJUSTABLE GLIDE (18E) into each PROPEL NUT.
Step 5
411591www.sauder.com/services Page 9
18E
14M
H
R
R
32E
31E
32E
31E
(4 used)

å Fasten the SKIRTS (H and R) to the BOTTOM (D). Use
four BLACK 9/16" WAFER HEAD SCREWS (33S) through
the FEET and into the BOTTOM.
å NOTE: To raise a corner of the unit, turn the ADJUSTABLE
GLIDE counter-clockwise. To lower a corner, turn the
ADJUSTABLE GLIDE clockwise.
Step 6
411591 www.sauder.com/servicesPage 10
H
R
R
D
BLACK 9/16" WAFER HEAD SCREW
(4 used in this step)
33S
Don't worry. It isn't
Rome. This can be built
in a day.
