SCANGRIP NOVA 4 SPS User manual

NOVA 4 SPS
03.6000/03.6000AU/03.6000UK
Light control app
INCL.SPSBATTERY4Ah
ITEMNO. 03.6003
Powerbank
Max 30W-10o to +40o C IK07
IP67
1.5-15h
Backup:
2.5h@10%/400lm
1.5h@80%
240x230x104mm 1.97kg
600-6000lux
@0.5m
4000lm@100%
3000lm@75%
2000lm@50%
1000lm@25%/400lm@10%
11.1V / 4000 mAh
Backup:
7.4V/1000mAh
Work light specifications
INCL. SPS CHARGER 35W
ITEM NO. 03.6006
INPUT: 100-240VAC 50/60HZ
OUTPUT: 12.6VDC 2.8A
CABLE: 5m 2x0.75mm²H05RN-F
Above specifications apply tothe work light only
High efficiency
COB LED 175lm/W

UK
• Always respect applicable legislation for working with electrical equipment in order to reduce the
risk of accidents
• Avoid looking directly into the beam of light, as this will result in dazzling
• Do not use the lamp near a naked flame
• Protect the mains cable from oil, heat and sharp edges
• Only use SCANGRIP SPS battery packs. Internal backup battery must be replaced with an original
SCANGRIP battery
• Do not leave the battery flat, as this could render it INCAPABLE of being charged again
• The light source of this luminaire is not replaceable; when the light source reaches its end of life
the whole luminaire shall be replaced
• Luminaire is only suitable for direct mounting on non-combustible surfaces
• The luminaire is designed to work with all SCANGRIP SPS battery packs. Likewise, the battery
chargers can be used to power the luminaire
•
•
•
If the lamp is disconnected from mains and the battery is discharged, push the power button to
enable internal back up battery. 10% LED will blink to indicate back up mode
• Built-in power bank with USB outlet to charge mobile devices
• Output: 5V, 1A
• Turn lamp on/off or adjust lamp output
• Connect up to 4 lamps together
• Assign pincode to prevent other users from controlling the lamp
Discarded electrical products must not be disposed of together with household waste. Please
use recycling facilities. Ask your local authority or retailer foradvice on recycling.
- The battery must be removed from the devicebefore it is broken up
- The device must be disconnected from the mains when the battery is removed
- Please dispose of the battery safely
NOVA 4 SPS
WARNING / BATTERY TIPS
Power bank
Integrated BLUETOOTH light control
Compliant with iPhone 5 or higher / Android 5.0 or higher. Go to iTunes App Store / Download the app from
our website
The power bank will automatically shut down when the battery pack is discharged or removed.When using
the power bank while the power supply is connected, the luminous output will be reduced to 75%.
0.1m
WARNING-Risk of fire
Minimum distance from
lighted objects 0.1m
• Turn on the Bluetooth function
• Press the Bluetooth button for 10 second
• The pin code is reset
The process to delete the pin code is:
The red charging indicator lights up during charging
The green charging indicator lights up when charging is completed
