Schlage Dexter 605 User manual

Benefits:
— Eliminates deadbolt replacement
and re-keying costs
— Reduces key management costs
— Prevents unauthorized key duplication
— Improves building security
— Manages property liability
— Increases property value
— Potential new revenue streams
Markets:
— Multi-family Residential
— Healthcare
— Universities
— Military
The Programmable Electronic Deadbolt is the newest member of
Schlage’s total access control solution. This computer-managed,
stand-alone locking system offers the latest technology for key
management and access control. Using the simple Security
Management System Express software, credentials can be added or
deleted from the lock within minutes. Your residents and employees
will appreciate the convenient access to all areas of the property with
just one credential.
For the property manager, the Programmable Electronic Deadbolt
saves time and money by eliminating the need to re-key or replace
locks due to turnover or lost/stolen keys. And, when used in
conjunction with other Schlage locking solutions, every door of your
property can be properly secured and managed with one security
management system.
The Programmable Electronic Deadbolt delivers the latest features in
security innovation to give both you and your residents the peace of
mind that comes with real security.
Programmable Electronic Deadbolts
Computer Managed Locking System

Features:
— Time and date controlled access
— Easy to install – fits on standard residential door
preps
— User-friendly Security Management System Express
software from Schlage (sold separately)
— Vandal-resistant, free-spinning deadbolt turn
— Up to 1,000 users
— Audit trail reports up to 1,000 events
— Eight time zone capability
— Battery powered – no wiring required
— Average three-year battery life
— 100-day low battery warning
— iButton credential required (sold separately)
— Hidden back-up mechanical key override
© 2008 Ingersoll-Rand Company SC-5138 Rev 3/08
Specifications:
•Latch: 1” x 2-1/4” radius corner faceplate
1” housing diameter - requires
1” edge bore
1” throw with Triple-Option™
square corner, radius corner
and circular drive-in faceplates
•Strikes: 1-1/8” x 2-3/4”, square corner,
no box, latch strike
•Backset: Adjustable backset,
fits 2-3/8” to 2-3/4” backsets
•Cylinder: 5-pin solid brass, keyed 5-pin,
C keyway, keyed different (KD)
•Door Range: 1-3/8” to 1-3/4”
•Keys: 5-pin, C-section
•Hole Distance: Minimum 5-1/2” center-to-center
distance between cross
bore holes
•Battery: 9-volt battery included with
average three-year battery life
•Construction: All-metal chassis and escutcheons
•Button Silicone rubber, wear-resistant
with LED backlight
•Available UL Listed
•A 156.5-2001 Grade 2 auxiliary locks or
Grade 2 ANSI/BHMA certified
•FCC Part 15
•CE Mark
800-847-1864 • 800-900-4737 (Canada) • Schlage.com
605
Bright Brass
609
Antique Brass
613
Oil-Rubbed Bronze
716
Aged Bronze
619
Satin Nickel
620
Antique Pewter
625
Bright Chrome
626
Satin Chrome
Both styles available in all finishes.
BE367 CAM BE367 PLY
