scigiene PTL572 User manual

Part #: PTL572
LOLLIPOP
THERMOMETER
-40to+572°F/-40 to +300°C
• NSF® Certified
• 4 second response
• 1.5 mm thin tip
• 4.3"/11.0 cm stem
• Waterproof (IPX7: protected from water up to
3 feet/1 meter for 30 minutes)
• Field calibration
• High heat
• Hold mode
• Max/min mode
• Big digit
• On/off button
• Auto-off after 10 minutes
• Food-safe ABS plastic with BioCote
®
• 304 stainless steel stem
• Temperature guide on sheath
• Mounting: pocket clip
• Two LR44 alkaline button batteries included
Note: Remove label from display before initial use.
Clean the thermometer stem before each use.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that
appears on the display is shown in BOLD CAPS.
BATTERY INSTALLATION
Replace batteries when LCD becomes dim.
“ --- ” flashes on the display when the batteries
need to be replaced.
1. Power off the unit before installing the batteries.
A malfunction may occur if the power is on when
the batteries are installed. If a malfunction occurs,
restart the device.
2. Remove battery cover on the back with a coin.
3. Remove the cover completely.
4. Install two LR44 batteries with positive (+) sides up.
5. Replace the battery cover.
Important: THE WATER RESISTANT FEATURE REQUIRES
MAINTAINING THE RUBBER GASKET EVENLY WITHIN THE
GROOVE.
OPERATING INSTRUCTIONS
A. On/Off
1. Press the POWER button ( ) to turn the
thermometer on.
2. The DTL572 will automatically turn off after 10
minutes of inactivity.
3. Press the POWER button ( ) again to turn the
thermometer off and conserve battery life.
B. Temperature Scale
To select temperature reading in Fahrenheit or
Celsius:
1. Using a paperclip, press the °F/°C button inside the
battery compartment to change the scale.
2. The °F or °C symbol changes on the display.
FOR THIN CUTS OF MEAT AND
GENERAL PURPOSE COOKING

C. Temperature Measurement
Important: THE PROBE MAY BE DAMAGED IF MEASUREMENT
TEMPERATURE IS LOWER THAN -40°F/-40°C OR HIGHER THAN
+572°F/+300°C.
Note: The DTL572 is intended for food service use —do not
use for safety related applications.
3. Insert the probe at least 0.25"/6.3 mm into the
food.
4. The current cooking temperature appears on the
display.
CAUTION: Probe may be HOT after use. Always wear a heat
resistant glove to touch the stainless steel probe during or just
after cooking. Do not touch with bare hands.
D. Hold Mode
Before withdrawing the DTL572 from the food, press the
HOLD/CAL button. This will “hold” the reading until
pressed again. h flashes in the upper left corner of the
display.
E. Max/Min Mode
Max/Min Mode is always working behind the scenes,
continually storing the highest and lowest
temperatures.
5. Before using Max/Min Mode, clear the stored
MAX/MIN values by pressing and holding the
MAX/MIN button in Max or Min mode to clear
the respective stored MAX/ MIN value.
6. Press the MAX/MIN button to display the highest
temperature. H appears on the display.
7. Press the MAX/MIN button twice to display the
lowest temperature. L appears on the display.
8. The display automatically returns to the
temperature mode after a few seconds.
9. While in Max mode, press and hold the MAX/MIN
button to clear the MAX value. CLr. appears on the
display before returning to temperature mode.
10. While in Min mode, press and hold the MAX/MIN
button to clear the MIN value. CLr. appears on the
display before returning to temperature mode.
F. Field Calibration
1. Using the Scigical-2 https://www.scigiene.com/SCCAL-
2-Calibrator or Scigical-9
https://www.scigiene.com/SCCAL-9-Calibrator
thermometer calibrator you can precisely calibrate
your PT0572 thermometer using either model.
Note: It is exceedingly difficult to get a 32°F/0°C ice water temperature
using ice baths It will probably be closer to 34°F/1°C. This procedure
would then decalibrate this precise instrument
Please contact Scigiene about Scigiene Calibrators.
2. Press and hold the HOLD/CAL button. C0 appears on
the display for 3 seconds and then the current
temperature appears on the display.
3. Press the HOLD/CAL button again to calibrate to
32.0°F/0°C.
4. CAL appears on the display for 5 seconds and then
returns to the current temperature.
Note: To avoid accidental recalibration, this function only
works when the water temperature is 30 to 34°F/-1 to +1°C.
Err will appear for 2 seconds if the water is not within this
range and then return to the temperature display mode.
G. Battery Status
1. The display flashes when the voltage on the
batteries is low.
2. “ --- ”flashes on the display when the batteries
need to be replaced.
Important: DO NOT LEAVE THERMOMETER CASE IN
HOT OVEN. CASE IS NOT HEAT RESISTANT. HAND
WASH AND DRY.
Note: Remove label from display before initial use.
Clean the thermometer probe before each use.
Note for Induction Cooktops: Sometimes, the induction
cooktop magnetic field may interfere with digital
thermometers. If there is interference, briefly turn off the
induction cooktop to get a digital thermometer reading
or use a dial thermometer.
Tip: Meat should be allowed to “rest” for 10 to 15 minutes
after it is removed from oven. This allows time for the
meat’s internal temperature to stabilize and the juices
to redistribute. This will result in a roast that is both juicier
and easier to carve.
CARE OF YOUR PRODUCT
• Wipe clean with a damp cloth.
• Store the thermometer at room temperature
between -4 to +149°F/-20 to+65°C.
PRECAUTIONS
• Always wear a heat resistant glove to touch the
stainless steel probe during or just after cooking. Do
not touch with bare hands.
• Dispose of used batteries promptly and keep
the batteries and thermometer away from children.
• Avoid subjecting the probe or thermometer to an
open flame on the BBQ.
• Avoid subjecting the probe and/or thermometer to
temperatures over 572°F/300°C.
• Clean the probe and thermometer with warm soapy water
and dry thoroughly after use.
• Avoid cleaning the unit with an abrasive or corrosive
compound, which may scratch the plastic parts and corrode
the electronic circuits.
• Avoid subjecting the thermometer to excessive force,
shock, dust, temperature, direct sunlight or humidity.
This may result in thermometer malfunction, shorter
electronic life span, battery damage and/or distort
parts.
• Avoid tampering with the thermometer’s internal
components, which may cause battery damage and
distort parts.
• Do not use the thermometer in microwave oven.
• Always read the user manual thoroughly
before operating.

HIGH ALTITUDE ADJUSTMENT
FOR CANDY-MAKING
SPECIFICATIONS
Measurement Range
-40 to +572°F/-40 to +300°C
Unit of Measure
°F/°C
Resolution
0.1°F/0.1°C
Operating Range
32 to 104°F/0 to 40°C ≤90% RH
Water Resilience
IPX7 –protected from water up to 3
feet/1 meter for 30 minutes
Accuracy
-58 to -2.2°F/-50 to -18°C: ± 3.6F/2°C);
-2.2 to 212°F/-18 to 100°C: ±
0.9°F/0.5°C) 212 to 392°F/100 to 200°C:
± 1.8°F/1°C)
392 to 572°F/200 to 300°C: ± 1.8°F/2°C)
(@ ambient temperature 73°F/23°C:
± 3.6°F/2°C)
Power Supply
Two LR44 alkaline button batteries
included
Product Dimensions
1.6 W x 6.9 H x 0.7 D (in)/
4.08 W x 17.48 H x 1.77 D (cm)
Weight
1.06 oz / 30 g (including battery)
STAGE
2,000 feet
5,000 feet
7,500 feet
Soft Ball
230–236°F
224–230°F
219–225°F
Firm Ball
238–244°F
232–238°F
227–233°F
Hard Ball
246–264°F
240–258°F
235–253°F
Soft Crack
266–286°F
260–286°F
255–275°F
Hard Crack
296–306°F
290–300°F
285–295°F
Antimicrobial properties are
built-in to inhibit the growth of
bacteria that may affect this
product. According to EPA
guidelines we cannot claim that
the antimicrobial properties in this
product protect users or others
against bacteria, viruses, germs,
or other disease organisms.
This product does not protect
users or others against food-borne bacteria. Always clean and
wash this product thoroughly before and after each use.
Jelly . . . . . . . . . . . . . . . . . . . 220°F............104°C
Thread . . . . . . . . . . . . . 230–234°F ...........110–112°C
Soft Ball . . . . . . . . . . . . 234–240°F ...........112–115°C
Firm Ball. . . . . . . . . . . . 244–248°F ...........118–120°C
Hard Ball . . . . . . . . . . . 250–266°F ...........121–130°C
Soft Crack . . . . . . . . . . 270–290°F...........132–143°C
Hard Crack. . . . . . . . . . 300–310°F...........149–154°C
Caramelize . . . . . . . . .. 316–338°F...........158–170°C
CANDY TEMPERATURE GUIDE
The information in this document has been reviewed and is believed to
beaccurate.However,neither themanufacturernor itsaffiliatesassume
any responsibility for inaccuracies, errors or omissions that may be
contained herein. In no event will the manufacturer or its affiliates be
liable for direct, indirect, special, incidental or consequential damages
arisen by using this product or resulting fromany defect/omission in this
document, even if advised of the possibility of such damages. The
manufacturer and its affiliates reserve the right to make improvements
or changes to this document and the products and services described
at any time, without notice or obligation.
325–375°F/163-190°C is the normal desired
temperature for deep fry cooking.
Note: When food is added to hot oil, the temperature of the oil
immediately drops at least 50°F/28°C. You will need to bring the oil
temperature back to the desired cooking temperature. Frying at
lower temperatures results in lighter color, less flavor development
and increased oil absorption.
OIL TEMPERATURE GUIDE
Deep Fry Lo ................... 325-340°F . . . . 163-170°C
Deep Fry Hi . . . . . . . . . 340-365°F . . . . 170-185°C
Shrimp . . . . . . . . . . . . . . . . . 350°F ...........177°C
Chicken . . . . . . . . . . . . . . . . 355°F ...........180°C
Onions . . . . . . . . . . . . . . . . . 370°F ...........188°C
Fish. . . . . . . . . . . . . . . . . . . . 375°F .............191°C
Doughnuts/Fritters . . . . . . . 375°F............191°C
French Fries . . . . . . . . . . . . . 380°F ...........193°C
DEEP FRY TEMPERATURE GUIDE
Beef, Veal, Lamb –well.............. 160°F . . 71°C
Beef, Veal, Lamb –medium. . . 145°F . .63°C
Beef, Veal, Lamb –rare . . . . . . 140°F . .60°C
Poultry . . . . . . . . . . . . . . . . . . . 165°F . . 74°C
3 minutes rest time
USDA SAFE FOOD TEMPERATURES
CE Note: This device could be sensitive to electrostatic
discharge. If electrostatic discharge or malfunctioning
occurs, please re-install the battery to reset this unit.
