INSTRUCTIONS FOR
COMPRESSION TEST KIT - DIESEL
MODEL NO: VSE3158
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
�DO NOT use tools if threads are damaged. Any defectives must be recified before use, to avoid incorrect readings.
9Maintain tools in a good, clean condition for the best and safest performance.
9Ensure that a vehicle that has been jacked up, is adequately supported with axle stands.
9Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.
9Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
9Ensure any disconnected fuel pipes are plugged to avoid spillage.
9Ensure that the correct connector is used for the engine being tested.
9Always release the pressure from the gauge, before disconnecting the quick release coupling.
9Account for all tools and parts being used and DO NOT leave them in or near the engine.
9Always refer to the vehicle manufacturer’s service instructions, or a proprietary manual, to establish the current procedure and data.
2. INTRODUCTION
Up-to-date kit for compression testing on diesel vehicles. Contains 17 of the most common dummy glow plugs, covering 29 glow plug types,
33 manufactures and over 500 model/engine varients from 1999 to 2015. Also includes a set of injector adaptors if an alternative method of
testing is required. See instructions on Sealey website for complete vehicle applications.
3. SPECIFICATION
Model No:................................................................ VSE3158
Glow Plug Adaptors:...............................................................
Alfa Romeo, Audi, BMW, Cadillac, Chrysler, Citroen, Dacia, Dodge, Fiat, Ford, Honda, Jaguar, Jeep, Lancia, Land Rover, Mazda,
Mercedes, MG, Mini, Mitsubishi, Nissan, Peugeot, Porsche, Renault, Rover, Saab, Seat, Skoda, Suzuki, Toyota, Vauxhall/Opel, Volvo,
VW
Gauge Pressure Range:...........................0-70bar(0-1000psi)
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves

4. CONTENTS
Item Part Number Description
1 VSE3158.01 Gauge and Hose ass (1000psi)
2 VSE3158.02 90 degree elbow
3 VSE3158.03 Injector adaptor with spacer sleeves
4 VSE3158.04 Injector adaptor clamp (51.5mm)
5 VSE3158.05 Injector adaptor clamp (64mm)
6 VSE3158.06 Injector adaptor clamp (73mm)
7 VSE3158.07 Injector adaptor nozzle (16.9/6.5mm dia)
8 VSE3158.08 Injector adaptor nozzle (17mm dia)
9 VSE3158.09 Injector adaptor nozzle (19.9/13.8mm dia)
10 VSE3158.10 Injector adaptor nozzle (24/5.7mm dia)
11 VSE3158.11 Injector adaptor nozzle (24/13.9mm dia)
12 VSE3158.12 Glow plug adaptor
13 VSE3158.12 Glow plug adaptor
14 VSE3158.14 Glow plug adaptor
15 VSE3158.15 Glow plug adaptor
16 VSE3158.16 Glow plug adaptor
17 VSE3158.17 Glow plug adaptor
18 VSE3158.18 Glow plug adaptor
19 VSE3158.19 Glow plug adaptor
20 VSE3158.20 Glow plug adaptor
21 VSE3158.21 Glow plug adaptor
22 VSE3158.22 Glow plug adaptor
23 VSE3158.23 Glow plug adaptor
24 VSE3158.24 Glow plug adaptor
25 VSE3158.25 Glow plug adaptor
26 VSE3158.26 Glow plug adaptor
27 VSE3158.27 Glow plug adaptor
28 VSE3158.28 Glow plug adaptor
29 VSE3158.W Copper Washers (not shown)
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
5. INSTRUCTIONS
5.1. Overview of Compression Testing.
  Whenanengine’sperformanceisdown,orifmisringoccurswhichcannotbeattributedtothefuelsystems,acompression 
test can provide diagnostic clues as to the engine’s condition.
  Compressionshouldbuildupquicklyinahealthyengine.Averylowcompressionreadingontherststroke,followedbygradually
  increasingpressureonsuccessivestrokes,indicateswornpistonrings.Alowcompressionreadingontherststroke,whichdoesnot
build up during successive strokes, indicates leaking valves or a faulty head gasket (a cracked head could also be the cause).Deposits
on the undersides of the valve heads can also cause low compression. If the pressure in any cylinder is considerably lower than
the others, introduce a small quantity of clean oil into that cylinder through the access hole, and repeat the test. If the addition of oil
temporarily improves the compression pressure, this indicates that bore or piston wear is responsible for the pressure loss. If there is no
improvement, it suggests that the leakage is around the valves, or a faulty head gasket. A low reading from two adjacent cylinders
  suggestsafaultyheadgasketbetweenthetwocylinders.Thepresenceofcoolantintheengineoilmayconrmthis.Ifthecompression
is unusually high, the combustion chambers are probably coated with carbon deposits. If this is the case, the cylinder head should be
removed and de-carbonised.
5.2. Compression Testing.
5.2.1. Check the engine oil is at the correct level.
5.2.2. Remove all of the glow plugs from the engine.
5.2.3.  Selecttheapplicableadaptorfromthekitandscrewitintotherstglowplugport,ensuringthereisagoodsealwiththeO-ring(if 
 tted).Connectthecouplingonthepressuregaugehosetotheadaptor,ensuringitlocksintoplace.
5.2.4. Turn over the engine using the starter motor and observe the gauge, looking for a steady increase in the reading and note the
maximum reading obtained. Refer to the vehicle/engine manufacturer’s workshop manual for compression data.
5.2.5. Push the Re-set Valve (situated under the gauge) to release the pressure. The Re-set Valve allows the test to be repeated if required
without disconnecting the tester from the glow plug port.
WARNING! Always release pressure via the Re-set Valve BEFORE disconnecting the Tester.
5.2.6. Disconnect the compression tester from the adaptor and remove the adaptor from the glow plug port. Install them into the next
cylinder’s glow plug port and repeat the tests. Continue the tests for all of the remaining cylinders in turn.
NOTE: A variation in compression readings between cylinders is often a better indication of engine problems than the individual
values of compression.

INSTRUCTIONS FOR
COMPRESSION TEST KIT - DIESEL
MODEL NO: VSE3158
Applications
Alfa Romeo
Model Engine Type Information Year Adaptor
No.
147 1.9 JTD 937A2.000 01>10 15
147 1.9 JTD16V 192A5.000 02>10 20
147 1.9 JTD 182B9.000 03>10 15
147 1.9 JTDM8V 937A3.000 05>10 15
147 1.9 JTDM16V 937A5.000 05>10 20
147 1.9 JTD16V 192B1.000 04>10 20
147 1.9 JTDM 939A7.000 04>05 15
156 1.9 JTD 937A2.000 01>06 15
156 1.9 JTD16V 192A5.000 02>06 20
156 1.9 JTD16VQ4 937A5.000 04>06 20
156 1.9 JTD 937A4.000, 937A5.000 03>06 20
156 1.9 JTD 192B1.000 02>04 20
156 2.4 JTD 839A6.000 00>06 15
156 2.4 JTD 841C000 02>06 15
156 2.4 JTD 841G.000 03>06 15
159 1.9 JTDM8V 939A1.000 05>11 15
159 1.9 JTDM16V 939A2.000, 937A8.000, 937 A8.000 05>10 20
159 1.9 JTDM8V 937A7.000, 939A1.000, 939 A7.000 08>10 20
159 2.4 JTDM 939A3.000 05>11 20
159 2.4 JTDM 939A9.000 07>08 20
159 2.4 JTDM 939B3.000, 939B4.000 09> 20
166 2.4 JTD 839A6.000 00>07 15
166 2.4 JTD 841C.000 02>07 15
166 2.4 JTD 841G.000, 841H.000 03>07 20
166 2.4 JTD 936B.000 05>07 20
Brera 2.4 JTDM20V 939A3.000, 939A9.000 06> 20
Brera 2.0 JTDM 939B3.000 09> 20
Giulietta 1.6 JTDM 940A3.000 10> 20
Giulietta 2.0 JTDM 939B3.000, 940A5.000 10> 20
GT 1.9 JTD 937A5.000 03>10 20
GT 1.9 JTD 937A6.000 08>10 20
Mito 1.6 JTDM 955A3.000, 955A4.000 09> 20
Spider 2.0 JTDM 939B3.000 09> 20
Spider 2.4 JTDM 939A3.000 07>10 20
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Audi
Model Engine Type Information Year Adaptor
No.
A1 1.6 TDI CAYC 10> 14
A1 1.6 TDI CAYB 11> 14
A1 2.0 TDI CFHD 11> 14
A1 2.0 TDI CFHB 12> 14
A2 1.2 TDI ANY 01>05 12
A2 1.4 TDI AMF, BHC 00>05 12
A2 1.4 TDI ATL 03>05 21
A3 1.6 TDI CAYB 09>12 14
A3 1.6 TDI CAYC 09>12 14
A3 1.9 TDI BKC, BLS, BXE 03>10 21
A3 2.0 TDI16V BBKD 03>12 16
A3 2.0 TDI AXV 03>12 16
A3 2.0 TDI Quattro AZV 03>08 16
A3 2.0 TDI16V Quattro BKD 04>12 16
A3 2.0 TDI CBBB, CFGB 06>12 14
A3 2.0 TDI Quattro CBBB, CFGB 06>12 14
A3 2.0 TDI BMM 05>08 21
A3 2.0 TDI Quattro BMM 06>08 21
A3 1.9 TDI BLS 08> 21
A3 2.0 TDI Quattro CBBB, CFGB 06> 14
A3 2.0 TDI CBAA, CBAB, CFFA, CFFB 08> 14
A4 2.7 TDI BPP 06>09 14
A4 3.0 TDI Quattro ASB, BKN 06>09 14
A4 1.9 TDI BKE 04>08 21
A4 2.0 TDI BNA 04>05 16
A4 2.0 TDI16V BLB 04>05 16
A4 2.7 TDI BSG 05>08 14
A4 3.0 TDI Quattro BKN 04>08 14
A4 3.0 TDI Quattro ASB 06>08 14
A4 2.0 TDI CAGA, CAGB, CJCA, CJCB, CMEA, CMFA 07> 14
A4 2.0 TDI CAGB, CAGC, CAHA, CAHB, CGLD, CJCB, CJCC 08> 14
A4 2.0 TDI Quattro CAGA, CAHA, CJCA 08> 14
A4 2.7 TDI CAMA, CGKA 07> 14
A4 2.7 TDI CAMB, CGKB 08> 14
A4 3.0 TDI Quattro CAPA, CCLA, CCWA 07> 14
A4 3.0 TDI Quattro CCLA, CAPA, CCWA, CCWB 08> 14
A4 2.0 TDI Quattro CAGA, CAHA, CAHB, CJCA, CJCB, CGLD 09> 14
A4 3.0 TDI Quattro CCWA 09> 14
A5 2.0 TDI CAHA, CAHB,CGLD O8> 14
A5 2.0 TDI Quattro CAHA 08> 14
A5 2.0 TDI CAGA, CAGB, CGLD, CAHB, CJCA, CJCB, CMEA, CMFA 09> 14
A5 2.7 TDI CAMA, CAMB, CGKA, CGKB 07> 14
A5 3.0 TDI Quattro CAPA, CCWA 07> 14
A5 3.0 TDI Quattro CCWB 08> 14
A6 1.9 TDI AJM, AVF, AWX. 00>05 12
A6 2.0 TDI BLB 04>05 16
A6 2.0 TDI BNA 04>11 14
A6 2.0 TDI CAGB 04>11 14
A6 2.0 TDI CAHA 08>11 14
A6 2.0 TDI CAHB 09>11 14
A6 2.7 TDI BPP 04>08 14
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Audi
Model Engine Type Information Year Adaptor
No.
A6 2.7 TDI BSG, CANB 04>11 14
A6 2.7 TDI Quattro BPP 04>08 14
A6 2.7 TDI Quattro BSG, CAND 05>11 14
A6 2.7 TDI CANA 08>11 14
A6 3.0 TDI Quattro BMK 04>06 14
A6 3.0 TDI Quattro BNG, CDYB 04>11 14
A6 3.0 TDI Quattro ASB 06>08 14
A6 3.0 TDI ASB 06>11 14
A6 3.0 TDI Quattro CDYA,CDYC 08>11 14
A6 2.0 TDI CGLC,CMGB 11> 14
A6 2.0 TDI CGLD 11> 14
A6 3.0 TDI CLAB 10> 14
A6 3.0 TDI Quattro CDUC, CGQB, CKVB, CLAA 11> 14
A6 2.7 TDI Quattro CANC 08>11 14
A7 3.0 TDI Quattro CDUC, CDUD, CKVB, CKVC,CLAA 10> 14
A7 3.0 TDI CLAB 10> 14
A7 3.0 TDI Quattro CGQB 11> 14
A8 3.0 TDI Quattro BNG 03>10 14
A8 4.2 TDI Quattro BMC 05>05 14
A8 4.2 TDI Quattro BVN 05>10 14
A8 3.0 TDI Quattro CDTA, CMHA 10> 14
A8 3.0 TDI CLAB 11> 14
A8 4.2 TDI Quattro CDSB 09> 14
Q3 2.0 TDI Quattro CFGC, CFGD, CLLB 11> 14
Q3 2.0 TDI CFFA, CFFB 11> 14
Q5 2.0 TDI Quattro CAHA, CAHB, CGLA, CGLB, CGLD, CMGA 08> 14
Q5 2.0 TDI Quattro CAGA, CAGB,CJCA, CJCB 09> 14
Q5 2.0 TDI CJCA, CJCB 10> 14
Q5 3.0 TDI Quattro CCWA, CCWB 08> 14
Q7 3.0 TDI BUG 06>08 14
Q7 3.0 TDI BUN, CASB 06>10 14
Q7 3.0 TDI CCMA, CJGA, CJGB, CJMA 10> 14
Q7 3.0 TDI CASA, CCMA 07>10 14
Q7 3.0 TDI CATA 09>12 14
Q7 3.0 TDI CJGD, CLZB, CRCA 11> 14
Q7 4.2 TDI BTR 07>09 14
Q7 4.2 TDI CCFA, CCFC 09> 14
Q7 6.0 TDI CCGA 08> 14
TT 2.0 TDI Quattro CBBB, CFGB 08> 14
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

BMW
Model Engine Type Information Year Adaptor
No.
1-Series 118 (E81,E87) D N47D20A, N47D20C 06>12 12
1-Series 120 (E81,E87) D N47D20A, N47D20C 06>12 12
3-Series 320 (E46) TD M47N204D4 01>05 12
3-Series 320 (E46) D M47N204D4 01>05 12
3-Series 318 (E46) D M47D20, M47204D1 02>05 12
3-Series 320 (E46) CD MM47N204D4 03> 12
3-Series 318 (E46) TD M47N204D4 03>05 12
3-Series 318 (E46) D M47N204D4 03>05 12
3-Series 330 (E46) D M57D30, 306D1 99>05 12
3-Series 330 (E46) XD M57D30 00>05 12
3-Series 330 (E46) CD M57N306D2 03> 12
3-Series 330 (E46) D M57N306D2 03>05 12
3-Series 330 (E46) XD M57N306D2 03>05 12
3-Series 320 (E90) D N47D20C, M47N204D4 05>11 12
3-Series 318 (E90) D M47N204D4, N47D20A, N47D20C 05>11 12
3-Series 330 (E90) D M57D30TU2, M57306D3 05>11 12
3-Series 330 (E90) XD M57D30TU2, M57306D3 05>11 12
3-Series 335 (E90) D M57N306D5 06>11 12
3-Series 325 (E90) D M57306D3 06>11 12
3-Series 320 (E91) D M47N204D5, N47D20A 05> 12
3-Series 318 (E91) D M47N204D4 05> 12
3-Series 320 (E91) D M47D20TU, M47N204D4 05> 12
3-Series 330 (E91) D M57306D3 05> 12
3-Series 330 (E91) XD M57D30TU2, M57306D3 05> 12
3-Series 335 (E91) D M57N306D5 06> 12
3-Series 325 (E91) D M57D30TU2, M57306D3 06> 12
3-Series 325 (E91) D M57N2306D3, N57D30A 10> 12
3-Series 335 (E92) D M57N306D5 06> 12
3-Series 330 (E92) D M57D30TU2, M57306D3 06> 12
3-Series 330 (E92) XD M57D30TU2, M57306D3 06> 12
3-Series 325 (E92) D M57D30TU2, N57N306D3 07> 12
3-Series 330 (E93) D M57D30TU2, N57N306D3 07> 12
3-Series 325 (E93) D M57D30TU2, N57306D3 07> 12
5-Series 520 (E60) D M47D20(204D4), N47D20A, N47D2 05>10 12
5-Series 525 (E60) D M57D25TU, M57N256D4 04>10 12
5-Series 525 (E60) D M57256D1 04>10 12
5-Series 530 (E60) D N57306D2 03>10 12
5-Series 535 (E60) D M57306D4 04>10 12
5-Series 530 (E60) D M57306D3 03>10 12
5-Series 530 (E60) XD M57306D3 05>10 12
5-Series 535 (E60) D M57N306D5 07>10 12
5-Series 525 (E60) D M57306D3 07>10 12
5-Series 525 (E60) XD M57306D3 07>10 12
5-Series 525 (E60) DXDrive N57306D3 08>10 12
5-Series 530 (E60) DXDrive M57N2306D3 08>10 12
5-Series 520 (E61) D M47D20(204D4), N47D20A, N47D2 05> 12
5-Series 520 (E61) D N47D20A, N47D20C 07> 12
5-Series 530 (E61) D N57306D2 04> 12
5-Series 535 (E61) D M57306D4 04> 12
5-Series 530 (E61) D M57306D3 05> 12
5-Series 530 (E61) XD M57306D3 05> 12
5-Series 525 (E61) D M57306D3 07> 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

BMW
Model Engine Type Information Year Adaptor
No.
5-Series 535 (E61) D M57N306D5 07> 12
5-Series 525 (E61) XD M57306D3 07> 12
5-Series 525 (E61) DXDrive M57306D3 08> 12
5-Series 530 (E61) DXDrive M57N2306D3 08> 12
6-Series 635 (E63,E64) D N57N306D5 07> 12
7-Series 730 (E65,E66) LD M57306D3, N57N306D2 05> 12
X3 2.0 (E83) D M47N204D4 04> 12
X3 2.0 (E83) D N47D20A 07> 12
X3 3.0 (E83) D M57N2306D2 04> 12
X3 3.0 (E83) SD M57306D5 06> 12
X5 3.0 (E53) D M57306D1 01> 12
X5 3.0 (E53) D M57N306D4 03> 12
X5 3.0 (E53) D M57N306D2 04>06 12
X5 3.0 (E70) D M57306D3 07>08 12
X5 3.0 (E70) SD M57N306D5 07>08 12
X6 3.0 (E71) D M57N2306D3 08> 12
X6 3.5 (E71) D N57N306D5 08> 12
X6 3.0 XDrive N57D30A, N57N306D5 08> 12
Cadillac
Model Engine Type Information Year Adaptor
No.
BLS 1.9 D Z19DTH 06> 20
Chrysler
Model Engine Type Information Year Adaptor
No.
300 3.0 M664 05>12 24
300 3.0 CDR M664 05>12 24
PT
Cruiser
2.2 CDR EDJ 02>10 24
Sebring 2.0 CDR ECD 09>10 24
Citroen
Model Engine Type Information Year Adaptor
No.
Berlingo 1.6 HDI DV6BTED4(9HT), DV6ATED4(9HX) 05>06 13
Berlingo 1.6 HDI DV6ETED(9HW) 05>08 13
Berlingo 1.6 HDI DV6ATED4(9HX), DV6BTED4(9HT) 06>08 13
Berlingo 1.6 HDI 9HN9DV6ETED), 9HT(DV6BTED4), 9HW(DV6ETED),
9HX(DV6ATED4), 9HZ(DV6TED4)
08> 13
Berlingo 1.6 HDI 9HX(DV6ATED4) 11> 13
Berlingo 1.6 HDI 9HP(DV6DTED), 9HX(DV6ATED4) 10> 13
Berlingo 1.6 HDI DV6C, DV6ETED 11> 13
C1 1.4 HDI DV4D 05> 13
C2 1.4 HDI 8HX(DV4TD) 03>08 13
C2 1.4 HDI 8HX(DV4TD) 09> 13
C2 1.6 HDI 9HZ(DV6TED4) 05> 13
C3 1.4 HDI 8HX(DV4TD) 04> 13
C3 1.4 HDI16V 8HY(DV4TED4) 04> 13
C3 1.6 HDI16V 9HZ(DV6TED4) 05> 13
C3 1.6 HDI16V 9HX(DV6ATED4), 9HZ(DV6TED4 05>06 13
C3 1.6 HDI16V 9HX(DV6ATED4) 06> 13
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Citroen
Model Engine Type Information Year Adaptor
No.
C3 1.4 HDI DV4TD 09> 13
C3 1.6 HDI 9HP(DV6DTED) 09> 13
C3 1.6 HDI DV6CTED4 10> 28
C3 Picasso 1.6 HDI 9HX(DV6ATED4), 9HZ(DV6TED4) 09> 13
C3 Picasso 1.6 HDI 9HR(DV6C) 10> 13
C3 Picasso 1.6 HDI DV6CTED4, DV6DTED4 10> 28
C3 Pluriel 1.4 HDI 8HX(DV4TD) 04> 13
C4 1.6 HDI 9HX(DV6ATED4), 9HY(DV6TED4), 9HZ(DV6TED4) 06> 13
C4 1.6 HDI 9HX(DV6ATED4), 9HY(DV6TED4), 9HZ(DV6TED4) 04>06 13
C4 1.6 HDI 9HJ (DV6DTEDM), 9HP (DV6DTED), 9HR (DV6C) 09> 13
C4 1.6 HDI DV6CTED, DV6DTED 11> 28
C4 2.0 HDI DW10CTED4 11> 28
C4 2.0 HDI RHF (DW10BTED4) 08> 22
C4 Grand
Picasso
1.6 HDI 9HY (DV6TED4), 9HZ (DV6TED4) 06> 13
C4 Grand
Picasso
1.6 HDI 9HR (DV6C) 10> 22
C4 Grand
Picasso
1.6 E-HDI 10> 22
C4 Grand
Picasso
2.0 HDI RHJ (DW10BTED4), RHR (DW10BTED4) 06> 22
C4 Grand
Picasso
2.0 HDI 11> 22
C4 Grand
Picasso
1.6 HDI DV6CTED 10> 28
C4 Picasso 1.6 HDI 9HY (DV6TED4), 9HZ (DV6TED4) 07> 13
C4 Picasso 1.6 HDI 9HR (DV6C) 10> 22
C4 Picasso 1.6 E-HDI 10> 22
C4 Picasso 2.0 HDI RHJ(DW10BTED4), RHR(DW10BTED4) 07> 22
C4 Picasso 2.0 HDI 11> 22
C4 Picasso 1.6 HDI DV6CTED 10> 28
C5 1.6 HDI 9HY (DV6TED4) 04>06 13
C5 1.6 HDI 9HY (DV6TED4) 06> 13
C5 1.6 HDI DV6CTED 08> 28
C5 2.0 HDI DW10CTED4 08> 28
C5 2.0 HDI RHR (DW10BTED4) 04> 22
C5 2.2 HDI DW12TED4 04> 22
C5 2.2 HDI 4HT (DW12BTED4) 06>08 13
C5 1.6 HDI 9HZ (DV6TED4) 08> 13
C5 1.6 HDI DV6C (9HL) 10> 13
C5 2.0 HDI RHF (DW10BTED4); RHR (DW10BTED4) 08> 22
C5 2.0 HDI DW10BTED4/F 09> 22
C5 2.7 HDI DT17TED4 08> 19
C6 2.7 HDI DT17ED4, UHZ (DT17BTED4) 05> 19
C8 2.0 HDI RHR (DW10BTED4) 06> 22
C8 2.0 HDI RHK (DW10UTED4) 07> 22
C8 2.0 HDI DW10CTED4 06> 28
Dispatch 2.0 HDI DW10CE,DW10CD, DW10CTED4 11> 28
DS3 1.6 HDI DV6CTED, DV6DTED 09> 28
DS4 1.6 HDI DV6CTED 11> 28
DS4 2.0 HDI DW10CTED4 11> 28
DS5 1.6 HDI DV6CTED 11> 28
DS5 2.0 HDI DW10CTED4 11> 28
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Citroen
Model Engine Type Information Year Adaptor
No.
Jumper 2.2 HDI 100 4HV (P22DTE) 06> 18
Jumper 2.2 HDI120 4HU (P22DTE) 06> 18
Jumper 1.9 D70 WJZ (DW8) 98> 12
Jumper 1.6 HDI 90 9HU (DV6UTED4) 07> 13
Jumper 2.0 HDI 120 RHK (DW10UTED4) 07> 22
Jumper 2.0 HDI 140 RHR (DW10BTED4) 07> 22
Nemo 1.4 HDI 8HS (DV4TD) 08> 13
Xsara 1.4 HDI 8HX (DV4TD) 03>05 13
Xsara 1.9 D WJY (DW8B), WJZ (DW8) 98>05 12
Xsara
Picasso
1.6 HDI 9HY (DV6TED4) 04> 13
Dacia
Model Engine Type Information Year Adaptor
No.
Duster 1.5 DCI K9K796 10> 12
Duster 1.5 DCI K9K 12> 21
Logan 1.5 DCI K9K790, 792, 796 05> 12
Logan 1.5 DCI K9K 13> 21
Logan MCV 1.5 DCI K9K792, 796 07> 12
Sandero 1.5 DCI K9K792, 796 08> 12
Sandero 1.5 DCI K9K 12> 21
Dodge
Model Engine Type Information Year Adaptor
No.
Avenger 2.0 CDR ECD 07>10 16
Caliber 2.0 CRD ECD 06>11 16
Fiat
Model Engine Type Information Year Adaptor
No
500 1.3 DMultijet 169A1.000 07> 16
500C 1.3 DMultijet 169A1.000 09> 16
Bravo 1.6 MJET 198A2.000, 198A3.000 08> 20
Bravo 1.9 DMultijet 192A8.000 07>09 15
Bravo 1.9 DMultijet 937A5.000 07> 20
Bravo 2.0 MJET 198A5.000, 844A2.000 08> 20
Croma 1.9 DMultijet 939A1.000 05> 15
Croma 1.9 DMultijet 939A2.000 05> 20
Croma 1.9 DMultijet 939A7.000 05> 15
Croma 2.4 DMultijet 939A3.000 05> 20
Doblo 1.3 JTD 16V 188A8.000; 188A9.000 04> 16
Doblo 1.3 DMultijet 223A9.000, 199A2.000 05> 16
Doblo 1.6 MJET 198A3.000, 263A4.000 10> 20
Doblo 1.9 JTD 182B9.000, 223B2.000 01> 15
Doblo 1.9 JTD 223A7.000, 223B1.000 03> 15
Doblo 1.9 DMultijet 186A9.000 05> 15
Doblo 1.3 DMultijet 199A3.000, 263A2.000 10> 16
Doblo 2.0 MJET 263A1.000 10> 20
Florino 1.3 DMultijet 199A2.000 08> 16
Grand
Punto
1.3 DMultijet 199A2.000, 199A3.000 05> 16
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Fiat
Model Engine Type Information Year Adaptor
No.
Grand
Punto
1.6 MJET 955 A3.000 09> 20
Grand
Punto
1.9 DMultijet 939 A1.000, 199 A5.000 05> 15
Idea 1.3 JTD 188 A9.000 04> 16
Idea 1.3 DMultijet 199 A3.000 05> 16
Idea 1.3 DMultijet 199 B1.000 08> 16
Idea 1.9 JTD 188 B2.000 04> 15
Linea 1.3 DMultijet 199 A3.000 07> 16
Multipla 1.9 JTD 182 B4.000, 186 A6.000, 186 A8.000, 186 A9.000 99>10 15
Panda 1.3 DMultijet 188 A8.000; 188 A9.000 03> 16
Panda 1.3 DMultijet 169 A1.000 06> 16
Punto 1.3 Multijet 199 A2.000; 199 A9.000 12> 16
Punto 1.3 JTD 188 A9.000 03> 16
Punto 1.9 JTD 188 A2.000, 188 A7.000 99> 15
Punto 1.3 DMultijet 199 A2.000; 199 A9.000 09> 16
Punto 1.3 DMultijet EVO 199 A2.000, 199 A3.000, 223 A9.000 09>12 16
Punto Evo 1.6 MJET 955 A3.000 10> 20
Qubo 1.3 DMultijet 199 A2.000 08> 16
Scudo 1.9 D WJZ (DW8) 98>06 12
Sedici 1.9 DMultijet D19AA 06> 15
Sedici 2.0 D20AA 09> 20
Siena 1.3 JTD 188 A9.000 03> 16
Stilo 1.9 JTD 192 A1.000, 192 A3.000, 937 A7.000 01>08 15
Stilo 1.9 JTD 192 A5.000 04>08 20
Stilo 1.9 DMultijet 192 A8.000 05>08 15
Stilo 1.9 DMultijet 937 A5.000 05>08 20
Stilo 1.9 DMultijet 192 A9.000 05>08 15
Stilo 1.9 JTD 192 B5.000 04>06 15
Strada 1.9 JTD 188 A2.000 03> 15
Ford
Model Engine Type Information Year Adaptor
No.
B-Max 1.5 TDCI C15DS0X 12> 28
B-Max 1.6 TDCI C16DS0X 12> 28
C-Max 1.6 TDCI GPDA; HHDA, HHDB, G8DA, G8DB, G8DD, G8DC, MTDA 07> 13
C-Max 1.8 TDCI KKDA 07> 25
C-Max 2.0 TDCI G6DA, G6DB, G6DD, G6DG 07> 22
C-Max 1.6 TDCI T3DA,T3DB,T1DA,T1DB 12> 28
C-Max 2.0 TDCI TXDB, UFDB 12> 28
Fiesta 1.4 TDCI F6JA 03>04 13
Fiesta 1.4 TDCI F6JB 09> 13
Fiesta 1.4 TDCI F6JD, KVJA 10> 13
Fiesta 1.6 TDCI HHJC, HHJD, HHJE 09> 13
Fiesta 1.6 TDCI TZJA, TZJB 10> 13
Fiesta 1.4 TDCI F6JA, F6JB 04> 13
Fiesta 1.6 TDCI HHJA 04>07 13
Fiesta 1.6 TDCI HHJB 07> 13
Fiesta 1.6 TDCI HHJF, UBJA 08> 13
Focus 1.8 Turbo DI/TDDI C9DA, C9DB, C9DC 99>04 25
Focus 1.8 Turbo DI/
TDDI16V
BHDA, BHDB 99>04 25
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Ford
Model Engine Type Information Year Adaptor
No.
Focus 1.8 TDCI F9DA, F9DB, FFDA 01>04 25
Focus C-Max 1.6 TDCI G8DA, G8DB, HHDA, HHDB 03>06 13
Focus C-Max 1.6 TDCI G8DA, G8DB, HHDA, HHDB 06>07 13
Focus C-Max 1.8 TDCI KKDA 05>07 25
Focus C-Max 2.0 TDCI G6DA, G6DB, G6DD, G6DG 03>07 22
Focus II 1.6 TDCI G8DA, G8DB, G8DC, G8DD, G8DE, G8DF, GPDA, GPDC,
HHDA, HHDB, MTDA
04>06 13
Focus II 1.6 TDCI G8DA, G8DB, G8DC, G8DD, G8DE G8DF, MTDA 06> 13
Focus II 1.6 TDCI GPDA, GPDC, HHDA, HHDB 06> 13
Focus II 1.8 TDCI KKDA, KKDB 04> 25
Focus II 2.0 TDCI G6DA, G6DB, G6DD 04> 22
Focus III 1.6 TDCI T1DA, T1DB, T3DA, T3DB 11> 13
Focus III 2.0 TDCI TXDB, UFDB 11> 13
Fusion 1.4 TDCI F6JB 04> 13
Fusion 1.6 TDCI HHJA 04>07 13
Fusion 1.6 TDCI HHJB 07> 13
Galaxy 1.9 TDI AUY, ASZ, BTB, 1Z, AHU, ANU 01>06 12
Galaxy 1.8 TDCI FFWA, QYWA 06> 25
Galaxy 2.0 TDCI AZWA, QXWA; QXWB; QXWC; UFWA 06> 22
Galaxy 2.0 TDCI KLWA; TYWA 07> 22
Galaxy 2.0 TDCI TXWA,UFWA 06> 28
Kuga I 2.0 TDCI UFDA 10>13 28
Kuga II 2.0 TDCI 12> 28
Mondeo III 2.0 DI/TDDI/
TDCI16V
D5BA, D6BA, HJBA, HJBB, HJBC, SDBA 00>07 18
Mondeo III 2.0 TDCI FMBA, N7BA 01>07 18
Mondeo III 2.2 TDCI QJBA, QJBB 04>07 18
Mondeo IV 1.8 TDCI FFBA, KHBA, QYBA 07> 25
Mondeo IV 2.0 TDCI AZBA, KLBA, LPBA, QXBA, QXBB, TYBA, UFBA 07> 22
Mondeo IV 2.0 TDCI T1BA, T1BB, TXBA 10> 28
S-Max 1.8 TDCI FFWA, QYWA 06> 25
S-Max 2.0 TDCI QXWA, QXWB, QXWC, UFWA 06>10 22
S-Max 1.6 TDCI T1BA, T1BB 10> 28
S-Max 2.0 TDCI TYWA 10> 28
S-Max 2.0 TDCI UFWA 06> 28
Toureo
Connect
1.8 DI BHPA, P7PA, P7PB, R2PA 02> 25
Toureo
Connect
1.8 Turbo DI HCPA, HCPB, P9PA, P9PB, P9PC, P9PD, R3PA, RWPE,
RWPF
02> 25
Toureo
Connect
1.8 TDCI RWPA, RWPC, RWPD 06> 25
Transit 2.0 DI ABFA, D3FA, F3FA 00>06 18
Transit 2.0 TDCI FIFA 02>06 18
Transit 2.4 DI D2FA, D2FB, D2FE, D4FA, F4FA 00>06 18
Transit 2.4 TDE DOFA 01>06 18
Transit 2.4 TDE FXFA 04>06 18
Transit 2.4 TDCI H9FA 04>06 18
Transit
Connect
1.8 DI BHPA, P7PA, P7PB, R2PA 02> 25
Transit
Connect
1.8 TDCI HCPA, HCPB, P9PA, P9PB, P9PC, P9PD, R3PA, RWPE,
RWPF
02> 25
Transit
Connect
1.8 TDCI RWPA, RWPC, RWPD 06> 25
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Honda
Model Engine Type Information Year Adaptor
No.
Civic 1.7 CTDI 4EE-2 02>05 27
Jaguar
Model Engine Type Information Year Adaptor
No.
S-Type 2.7 D AJD(DT17) 04>07 19
XJ 2.7 D AJD 05>09 19
X-Type 2.0 D FMBA, FMBB, R4-X404 03>09 18
Jeep
Model Engine Type Information Year Adaptor
No.
Commander 3.0 CRD EXL 06>10 24
Compass 2.0 CRD ECD 06> 16
Grand
Cherokee
2.7 CRD ENF 01>05 12
Grand
Cherokee
3.1 TD EXA 99>05 12
Grand
Cherokee
3.1 TD EXA 99>05 24
Grand
Cherokee
3.0 CRD EXL 05>07 24
Grand
Cherokee
3.0 CRD EXF 11> 24
Lancia
Model Engine Type Information Year Adaptor
No.
Musa 1.3 DMultijet 188A9.000 04> 16
Musa 1.3 DMultijet 199A3.000 06> 16
Musa 1.9 DMultijet 188B2.000 04> 15
Thesis 2.4 JTD 841C.000 02>09 15
Thesis 2.4 JTD 841G.000 03>09 20
Thesis 2.4 DMultijet 841P.000 06>09 20
Ypsilon 1.3 JTD 188A9.000 03>11 16
Ypsilon 1.3 DMultijet 199A2.000, 199A3.000 06>11 16
Land Roverr
Model Engine Type Information Year Adaptor
No.
Defender 2.4 TD4 244DT 07> 18
Defender 2.5 TD5 10P 98>07 23
Discovery II 2.5 TD5 10P 99>04 23
Discovery III 2.7 TD 276DT 04>09 19
Freelander 2.0 TD4 204D3, M47 00>06 12
Range Rover
III
3.0 TD6 02> 12
Range Rover
III
3.6 TD8 368DT 06> 19
Range Rover
Sport
2.7 TDVM 276DT 05> 19
Range Rover
Sport
3.6 TD8 368DT 06> 19
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Mazda
Model Engine Type Information Year Adaptor
No.
21.4 CD F6JA, F6JB 03>05 13
21.4 CD F6JA, F6JB 05> 13
21.4 MZR-CD 08> 13
21.6 MZ-CD 08> 13
31.6 DI Turbo Y601 04>09 13
31.6 MZR-CD 09> 13
Mercedes
Model Engine Type Information Year Adaptor
No.
A-Class 1.7 160 CDI 640.942 04>08 24
A-Class 1.7 180 CDI 640.94 04>08 24
A-Class 2.0 200 CDI 640.941 04>08 24
B-Class 1.7 180 CDI 640.94 05>11 24
B-Class 2.0 200 CDI 640.941 05>11 24
C-Class 3.0 320 CDI 642.96, 642.961 07>11 24
C-Class 2.2 200 CDI 646.812 (136) - E5 07>11 24
C-Class 2.2 250 CDI 651.911 (204) - E5 08>11 24
C-Class 3.0 320 CDI 4-matic 642.961 07>11 24
C-Class 2.2 220 CDI 611.962 01>08 14
C-Class 2.2 220 CDI 646.963 04>08 14
C-Class 2.2 220 CDI 646.962 01>07 14
C-Class 2.2 220 CDI 642.91 05>07 24
C-Class 2.2 200 CDI (203.004) 611.962 00>07 14
C-Class 2.2 220 CDI (203.006) 611.962 00>07 14
C-Class 2.7 270 CDI (203.016) 612.962 00>07 14
C-Class 3.0 320 CDI (203.020) 642.91 05>07 24
CLK 3.0 320 CDI (209.420) 642.91 05>09 24
CLK 2.7 270 CDI (209.316) 612.962, 612.967 02>09 14
CLK 3.0 320 CDI (209.320) 642.91 05>09 24
CLK 3.0 320 CDI (219.322) 642.920 (224) 05>10 24
CLK 3.0 350 CDI (219.322) 642.920 (224) 09>10 24
E-Class 2.2 220 T CDI (211.206) OM 646.961 03>09 14
E-Class 2.7 270 T CDI (211.216) OM 647.961 03>09 14
E-Class 3.0 320 T CDI (211.222) OM 647.961 05>09 24
E-Class 3.0 280 T CDI (211.220) 642.920 (190) - E4 05>09 24
E-Class 3.0 280 T CDI 4-matic 642.921 (190) 05>09 24
E-Class 3.0 320 T CDI 4-matic 642.921 (224) 05>09 24
E-Class 3.2 320 T CDI (211.226) 648.961 03>09 14
E-Class 3.0 280 T CDI (211.223) 648.961 04>09 14
E-Class 2.2 220 CDI (211.006) 646.961 02>08 14
E-Class 2.2 200 CDI (211.004) 646.951 02>08 14
E-Class 2.2 220 CDI (211.004) 646.951 02>08 14
E-Class 2.7 270 CDI (211.016) 647.961 02>08 14
E-Class 3.0 280 CDI (211.020) 642.920 (190) - E4 05>08 24
E-Class 3.0 320 CDI (211.022) 642.920 (224) 05>08 24
E-Class 3.0 280 CDI 4-matic 642.921 (190) 05>08 24
E-Class 3.0 320 CDI 4-matic 642.921 (224) 05>08 24
E-Class 3.0 300 BLUETEC 642.920 (190) - E4 07>08 24
E-Class 3.2 320 CDI (211.026) 648.961 02>08 14
E-Class 3.0 280 CDI (211.023) 648.961 04>08 14
E-Class 3.0 400 CDI (211.028) 628.961 03>08 14
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Mercedes
Model Engine Type Information Year Adaptor
No.
GL-Class 3.0 320 CDI (164.822) 642.940 (224) 06>09 24
GL-Class 3.0 350 CDI (164.822) 642.940 (224) 09> 24
GL-Class 4.0 420 CDI (164.828) 629.912 (306) 06>09 24
GL-Class 4.0 450 CDI (164.828) 629.912 (306) 09> 24
ML-Class 2.7 270 CDI (163.113) 612.963 99>05 14
ML-Class 3.0 280 CDI 4-matic 642.940 (190) 05>09 24
ML-Class 3.0 320 CDI 4-matic 642.940 (224) 05>09 24
ML-Class 3.0 300 CDI 4-matic 642.94 09> 24
ML-Class 3.0 350 CDI 4-matic 642.94 09> 24
ML-Class 4.0 420 CDI 4-matic 629.912/F (306) 06>09 24
R-Class 3.0 320 CDI 4-matic 642.950 (224) - E4 06>09 24
R-Class 3.0 280 CDI 4-matic 642.950 (190) - E4 06>09 24
R-Class 3.0 280 CDI (251.121,) 642.950 (190) - E4 06>09 24
R-Class 3.0 300 CDI (251.021, 251. 642.870, 642.872, 642.950 09> 24
R-Class 3.0 300 CDI 4-matic 642.95 09> 24
R-Class 3.0 350 CDI 4-matic 642.95 09> 24
R-Class 3.0 350 CDI 4-matic 642.870, 642.950 06> 24
R-Class 3.0 350 CDI 4-matic (251.02 642.872 10> 24
S-Class 3.2 400 CDI 628.96 00>05 14
S-Class 3.0 320 CDI / S 350 CDI 642.93 05>09 24
S-Class 3.0 320 CDI 4-matic 642.932 06>09 24
S-Class 3.0 420 CDI / S 450 CDI 629.911 06>09 24
Sprinter 2.2 208 CDI 611.987 00>06 14
Sprinter 2.2 211 CDI 611.981 00>06 14
Sprinter 2.1 213 CDI 611.981 00>06 14
Sprinter 2.2 216 CDI 612.981 00>06 14
Sprinter 3.0 318 CDI 642.992 (184) 06>09 24
Sprinter 3.0 319 CDI 642.896, 642.898, 642.992 09> 24
Sprinter 2.2 308 CDI 611.987 00>06 14
Sprinter 2.2 311 CDI 611.981 00>06 14
Sprinter 2.2 313 CDI 611.981 00>06 14
Sprinter 2.2 311 CDI 4x4 611.981 02>06 14
Sprinter 2.2 313 CDI 4x4 611.981 02>06 14
Sprinter 2.7 316 CDI 612.981 00>06 14
Sprinter 2.7 316 CDI 4x4 612.981 02>06 14
Sprinter 3.0 218 CDI (906.611, 906.613) 642.992 06> 24
Sprinter 3.0 219 CDI (906.111, 906.113) 642.896 09> 24
Sprinter 2.2 411 CDI 611.981 00>06 14
Sprinter 2.2 413 CDI 611.981 00>06 14
Sprinter 2.2 411CDI 4x4 611.981 00>06 14
Sprinter 2.2 413CDI 4x4 611.981 00>06 14
Sprinter 2.2 416 CDI 612.981 00>06 14
Sprinter 2.2 416 CDI 4x4 612.981 00>06 14
Sprinter 3.0 518 CDI 642.992 06> 24
Viano 2.0 CDI 646.982 03> 14
Viano 2.2 CDI 646.982 03> 14
Vito 2.1 111 CDI 646.982 03> 14
Vito 2.1 115 CDI 646.982 03> 14
Vito 2.1 109CDI 646.983 03> 14
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

MG
Model Engine Type Information Year Adaptor
No.
ZT 2.0 CDTI 204D2 02>05 12
Mini
Model Engine Type Information Year Adaptor
No.
One 1.4 D(R50, R53) 1ND-TV 03>06 26
One 1.6 D(R56) 9HZ9DV6TED4) 07>10 13
One 1.6 D9R56) N47C16 10> 14
Copper 1.6 D(R55) 9HZ(DV6TED4) 07> 13
Copper 1.6 D(R56/R57) N47C16 10> 14
Copper 2.0 D(R56/R57) N47 C20A 11> 14
Clubman 1.6 R55 N47 C16 10> 14
Clubman 2.0 R55 N47 C20A 11> 14
Countryman 1.6 R60 N47 C16 10> 14
Countryman 2.0 R60 N47 C20A 11> 14
Coupe 2.0 R58 N47 C20A 11> 14
Paceman 1.6 R61 N47 C16 12> 14
Paceman 2.0 R61 N47 C20A 12> 14
Roadster 2.0 R59 N47 C20A 12> 14
Mitsubishi
Model Engine Type Information Year Adaptor
No.
Carisma 1.9 DI-D (DA5A) F9Q1, F9Q2 00>06 12
Grandis 2.0 DI-D BSY 05>07 16
Outlander 2.0 DI-D BSY 07> 16
Nissan
Model Engine Type Information Year Adaptor
No.
Almera 1.5 DCI K9K 722 03> 12
Juke 1.5 DCI K9K 10>14 12
Kubistar 1.5 DCI K9K 704, 710, 714, 722 03> 12
Kubistar 1.5 DCI 70 K9K 700 06> 12
Kubistar 1.5 DCI 85 K9K 276 06> 12
Micra 1.5 DCI K9K 704, 722 03>10 12
Micra 1.5 DCI K9K 708, 276 05>10 12
Note 1.5 DCI K9K 276, 700 06> 12
Note 1.5 DCI K9K 292 08> 12
NV200 1.5 DCI 10> 12
Primera 1.9 DCI 03> 12
Qashqai 1.5 DCI 07> 12
Qashqai 1.5 DCI 10> 12
Qashqai 2.0 DCI M1D, M9R 07> 12
Qashqai 2.0 DCI AWD M9R/F 07> 12
Tiida 1.5 DCI K9K728 07> 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Peugeot
Model Engine Type Information Year Adaptor
No.
107 1.4 HDI 8HT (DV4TD) 05> 13
206 1.4 HDI eco 70 8HZ (DV4TD) 01> 13
206 1.4 HDI 8HX (DV4TD) 01>05 13
206 1.4 HDI 8HZ (DV4TD) 05>09 13
13206 1.6 HDI 110 9HZ (DV6TED4) 05> 13
206 1.9 D WJZ (DW8) 99>07 12
206 1.4 HDI eco 70 8HX (DV4TD), 8HZ (DV4TD 08> 13
207 1.4 HDI 8HR (DV4TD), 8HZ (DV4TD) 06> 13
207 1.4 HDI 8HZ (DV4TD) 10> 13
207 1.6 HDI 9HX (DV6ATED4), 9HY (DV6TED4), 9HZ (DV6TED4) 06> 13
207 1.6 HDI 9HZ (DV6TED4) 07> 13
207 1.6 HDI 9HP (DV6DTED), 9HR (DV6C) 09> 13
207 1.6 HDI 110 9HZ (DV6TED4) 09> 13
207 1.6 HDI DV6CTED4,DV6DTED4 10> 28
208 1.6 HDI DV6CTED4,DV6DTED4 12> 28
307 1.4 HDI 8HX (DV4TD), 8HZ (DV4TD) 01> 13
307 1.6 HDI 110 9HY (DV6TED4), 9HZ (DV6TED4) 04> 13
307 1.6 HDI 110 9HY (DV6TED4), 9HZ (DV6TED4) 04> 13
307 1.6 HDI 9HV (DV6ATED4) 05> 13
307 1.6 HDI 90 9HV (DV6ATED4) 06> 13
307 1.6 HDI 90 9HV (DV6ATED4) 05> 13
307 2.0 HDI135 RHR (DW10BTED4) 05> 22
308 1.6 HDI 9HZ (DV6TED4) 07> 13
308 1.6 HDI 9HV (DV6ATED4), 9HX (DV6ATED4) 07> 13
308 1.6 HDI 9HR (DV6C) 09> 22
308 1.6 HDI DV6CTED4,DV6DTED4 09> 28
308 2.0 HDI RHR (DW10BTED4) 07> 22
308 2.0 HDI DW10CTED4 10> 28
407 1.6 HDI 110 9HY (DV6TED4) 04>06 13
407 1.6 HDI 110 9HY (DV6TED4) 06> 13
407 2.0 HDI 135 RHR (DW10BTED4) 04> 22
407 2.0 HDI DW10CTED4 09> 28
407 2.7 HDI DT17TED4 05> 19
508 1.6 HDI 9HR (DV6C) 10> 22
508 2.0 HDI DW10CTED4 11> 28
607 2.0 HDI RHR (DW10BTED4) 05> 22
607 2.7 HDI 24V DT17TED4 04> 19
807 2.0 HDI DW10CTED4 09> 28
1007 1.4 HDI 8HX (DV4TD), 8HZ (DV4TD) 05> 13
1007 1.4 HDI 8HX (DV4TD), 8HZ (DV4TD) 05> 13
1007 1.6 HDI 9HZ (DV6TED4) 07> 13
3008 1.6 HDI 9HZ (DV6TED4) 09> 13
3008 1.6 HDI DV6CTED,DV6DTED 10> 28
3008 2.0 HDI DW10CTED4 09> 28
5008 1.6 HDI 9HZ (DV6TED4) 09> 13
5008 1.6 HDI DV6CTED,DV6DTED 10> 28
5008 2.0 HDI DW10CTED 09> 28
Bipper 1.4 HDI 8HS (DV4TD) 08> 13
Boxer 2.2 HDI100 4HV (P22DTE) 06> 18
Boxer 2.2 HDI120 4HU (P22DTE) 06> 18
Boxer 2.2 HDI130 11> 18
Expert 1.9 D70 WJY (DW8B), WJZ (DW8) 98> 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Peugeot
Model Engine Type Information Year Adaptor
No.
Expert 1.6 HDI 90 9HU (DV6UTED4) 07> 13
Expert 2.0 HDI DW10CE, DW10CD, DW10CTED4 07> 28
Partner 1.6 HDI 90 9HX (DV6ATED4) 06>06 13
Partner 1.6 HDI 90 9HX (DV6ATED4) 06>08 13
Partner 1.6 HDI 75 9HW (DV6BTED4) 06>06 13
Partner 1.6 HDI 75 9HW (DV6BTED4) 06> 13
Partner 1.9 D4x4 WJY (DW8B 04>05 12
Partner 1.6 HDI 9HT (DV6BTED4), 9HX (DV6ATED4) 08> 13
Partner Tepee 1.6 HDI 9HZ (DV6TED4) 08> 13
RCZ 2.0 HDI DW10CTED4 10> 28
Porsche
Model Engine Type Information Year Adaptor
No.
Cayenne 3.0 TDI M05.9D 09> 14
Cayenne 3.0 TDI M05.9E, MCR.CB 10> 14
Cayenne 3.0 TDI MCR.CA 11> 14
Panamera 3.0 TDI 11> 14
Renault
Model Engine Type Information Year Adaptor
No.
Clio 1.5 DCI K9K 700, 702, 704 01> 12
Clio 1.5 DCI K9K 712, 714 04> 12
Clio 1.5 DCI K9K 716 03> 12
Clio 1.5 DCI K9K 752, 740, 764, 766, 768, 772 05> 12
Clio 1.5 DCI K9K 718, 750 07> 12
Clio 1.9 DTI F9Q 780 99>05 12
Clio 1.5 DCI K9K 766, 764, 768, 772 08> 12
Clio III 1.5 DCI K9K 608, 612, 770 10> 21
Espace 1.9 DCI F9Q 680, 820, 826 02> 12
Espace 2.2 DCI G9T 742, 743 02> 17
Espace 2.2 DCI G9T 645 06> 17
Grand Scenic 1.5 DCI K9K 728 04> 12
Grand Scenic 1.5 DCI K9K 732 05> 12
Grand Scenic 1.9 DCI F9Q 812 04> 12
Grand Scenic 1.9 DCI F9Q 816, 818, 804 05> 12
Grand Scenic II 1.5 DCI K9K 728,K9K 732, K9K 832,K9K 836 09> 21
Kangoo 1.5 DCI K9K 700, 704 03>05 12
Kangoo 1.5 DCI K9K 700, 702, 704 01> 12
Kangoo 1.5 DCI K9K 702, 704, 710 02> 12
Kangoo 1.5 DCI K9K 702, 704, 710 03> 12
Kangoo 1.5 DCI K9K 714,718 05> 12
Kangoo 1.9 DCI F9Q 782, 790 01> 12
Kangoo 1.9 DCI F9Q 782, 790 03> 12
Kangoo 1.5 DCI K9K 800, 802, 804, 806 08> 12
Kangoo 1.5 DCI 85 K9K 800, 802 08> 12
Kangoo 1.5 DCI 90 K9K 808 09> 12
Kangoo Be Bop 1.5 DCI K9K 806, 808 09> 12
Laguna 1.9 DCI F9Q 670, 674, 718, 750, 752, 754 01> 12
Laguna 1.9 DCI F9Q 664 04> 12
Laguna 1.9 DCI F9Q 674, 758, 759 05> 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Renault
Model Engine Type Information Year Adaptor
No.
Laguna 2.2 DCI G9T 700, 702 01> 17
Laguna 2.2 DCI G9T 600,605, 706, 707 05> 12
Laguna 1.5 DCI K9K 780 07> 12
Master II 1.9 DTI F9Q 770 00>06 12
Master II 1.9 DCI 80 F9Q 772, 774 01> 12
Master II 2.2 DCI 90 G9T 720, 722, 750 00>06 17
Master II 2.5 DCI 120 G9U 720, 754 01> 17
Master II 2.5 DCI 100 G9U 754 03> 17
Master II 2.5 DCI G9U 632, 650, 754 06> 17
Master II 2.5 DCI G9U 750 04> 17
Megane II 1.5 DCI K9K 722 02> 12
Megane II 1.5 DCI K9K 722, 728, 729 03> 12
Megane II 1.5 DCI K9K 722, 728, 729 04> 12
Megane II 1.5 DCI K9K 724, 732, 734 05> 12
Megane II 1.5 DCI K9K 732 06> 12
Megane II 1.9 DCI K9K 728, 734 07> 12
Megane II 1.9 DCI F9Q 800, 804 02> 12
Megane II 1.9 DCI F9Q 800, 804 03> 12
Megane II 1.9 DCI F9Q 808 04> 12
Megane II 1.5 DCI F9Q 803, 804, 816, 818 05> 12
Megane III 1.5 DCI K9K 830,K9K 834,K9K 836 08> 21
Modus 1.5 DCI K9K 750, 752, 760, 762, 766, 768 04> 12
Modus 1.5 DCI K9K 764 05> 12
Modus 1.5 DCI K9K 772 07> 12
Modus 1.5 DCI K9K 770 08> 21
Scenic II 1.5 DCI K9K 722, 728, 729 03> 12
Scenic II 1.5 DCI K9K 724, 732 05> 12
Scenic II 1.5 DCI K9K 734 07> 12
Scenic II 1.9 DCI F9Q 804, 812, 816, 818, J8 03> 12
Scenic III 1.5 DCI K9K 728,K9K 830,K9K 834,K9K 836 09> 21
Thalia 1.5 DCI K9K 718, 740 08> 12
Thalia 1.5 DCI K9K 700 09> 12
Trafc 1.9 DCI 100 F9Q 760 01> 12
Trafc 1.9 DCI 80 F9Q 760, 762 01> 12
Trafc 2.0 DCI 115 M9R 780, 782, 786 06> 17
Trafc 2.0 DCI 90 M9R 780, 782 06> 17
Trafc 2.5 DCI 135 G9U 730 01> 17
Trafc 2.5 DCI 145 G9U 630 06> 17
Trafc 2.5 DCI 115 G9U 630 08> 17
Twingo 1.5 DCI K9K 718, 740 07> 12
Twingo 1.5 DCI K9K 820 10> 21
Vel Satis 2.2 DCI G9T 600, 606, 607, 700, 702, 703 02> 17
Rover
Model Engine Type Information Year Adaptor
No.
75 2.0 CDT M47R 99>05 12
75 2.0 CDTI 204D2 03>05 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited

Saab
Model Engine Type Information Year Adaptor
No.
93 1.9 TID Z19DT 04> 15
93 1.9 TID Z19DTH 04> 20
93 1.9 TID Z19DTJ 05> 20
93 1.9 TTID Z19DTR 07> 15
93 1.9 A19DTR 10> 20
93 2.2 TID D223L 02> 14
93X 1.9 TTID Z19DTR 09> 14
Seat
Model Engine Type Information Year Adaptor
No.
Alhambra 1.9 TDI AUY, BVK 00>10 12
Alhambra 1.9 TDI AUY, BVK 00>10 12
Alhambra 1.9 TDI 4 motion AUY, BVK 00>10 12
Alhambra 1.9 TDI 4 motion AUY, BVK 00>10 12
Alhambra 1.9 TDI ASZ 02>08 12
Alhambra 1.9 TDI ARL, BTB 05>07 12
Alhambra 1.9 TDI 4x4 ASZ 05>08 12
Alhambra 1.9 TDI 1Z, AHU, ANU 96>10 12
Alhambra 1.9 TDI 1Z, AHU, ANU 96>10 12
Alhambra 2.0 TDI CFFB, CFGB 10> 14
Alhambra 2.0 TDI CFFE 11> 14
Alhambra 2.0 TDI AWD CFFB 11> 14
Alhambra 2.0 TDI CFFA 10>11 14
Altea 1.6 TDI CAYC 09> 14
Altea 1.6 TDI CAYB 10> 14
Altea 1.9 TDI BJB, BKC, BLS, BXE 04> 21
Altea 1.9 TDI BXF 09> 21
Altea 2.0 TDI 16V BKD 04> 16
Altea 2.0 TDI AZV 04>09 16
Altea 2.0 TDI CEGA 06> 14
Altea 2.0 TDI BMM 10> 21
Altea XL 1.6 TDI CAYC 09> 14
Altea XL 1.6 TDI CAYB 10> 14
Altea XL 1.9 TDI BKC, BLS, BXE 06> 21
Altea XL 1.9 TDI BXF 09> 21
Altea XL 2.0 TDI 16V BKD 06> 16
Altea XL 2.0 TDI BMM 10> 21
Altea XL 2.0 TDI CEGA 07> 14
Altea XL 2.0 TDI 4x4 CEGA, CFJA 07> 14
Altea XL 2.0 TDI AZV 06>09 16
Altea XL 2.0 TDI 4x4 BMM 10> 21
Cordoba 1.4 TDI AMF 02>05 12
Cordoba 1.4 TDI BMS, BNM, BNV 05>09 12
Cordoba 1.9 TDI ASZ, ADT, AXR, BLT 02>09 12
Cordoba 1.9 SDI ASY 02>09 12
Exeo 2.0 TDI CAGA, CAGC, CJCA, CJCC 08> 14
Exeo 2.0 TDI CAHA; CGLB 09> 14
Ibiza 1.4 TDI AMF 02>05 12
Ibiza 1.4 TDI AMF 02>05 12
Ibiza 1.4 TDI BNM, BNV 05>09 12
Ibiza 1.9 TDi ASZ,ATD, AXR, BLT 02>09 12
VSE3158 | Issue 1 04/11/16
Original Language Version
© Jack Sealey Limited
