INSTRUCTIONS FOR:
LONG STROKE AIR HAMMER
Model: SA11/S
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
pWARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
pWARNING! Disconnect the hammer from the air supply before changing accessories, servicing or performing any maintenance.
3Keep the hammer clean and maintain it in good condition (use an authorised service agent).
3Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
3Keep the work area clean and uncluttered. Ensure that there is adequate lighting.
3Ensure chisels are correctly rated for the job. DO NOT use damaged or suspect chisels.
pWARNING! Wear approved safety eye or face protection, ear defenders and, if dust is generated, respiratory protection.
3Keep hands and body clear of the work when operating the hammer.
3Maintain correct balance and footing. Ensure that the floor is not slippery and wear non-slip shoes.
3Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain
and/or tie back long hair.
3Keep children and unauthorised persons away from the work area.
3Check moving parts alignment on a regular basis.
3Secure unstable workpiece with a clamp, vice or other adequate holding device.
3Avoid unintentional starting.
pWARNING! Ensure that the correct air pressure is maintained and not exceeded.
3Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use
and ensure that all connections are secure.
7DO NOT use the hammer for a task it is not designed to perform.
7DO NOT operate the hammer if any parts are damaged or missing as this may cause failure and/or personal injury.
pWARNING! DO NOT chisel into any materials containing asbestos.
7DO NOT switch the hammer on whilst the chisel is in contact with the workpiece.
7DO NOT carry the by the hose, or yank the hose from the air supply.
7DO NOT hold the workpiece by hand. Use clamps or a vice (not included) to secure the workpiece. Available from your Sealey dealer.
7DO NOT allow untrained persons to operate the hammer.
7DO NOT operate the hammer when you are tired or under the influence of alcohol, drugs or intoxicating medication.
7DO NOT use hammer where there is flammable liquid, solid or gas such as paint solvent, including waste wiping or cleaning rags etc.
7DO NOT leave the hammer operating unattended.
7DO NOT carry the hammer with your finger on the trigger.
7DO NOT direct air from the air hose at yourself or others.
3When work is complete ensure that the air supply is turned off.
3When not in use disconnect from the air supply and store in a safe, dry, childproof area.
The recommended hook-up is shown in fig. 1.
2.1. Ensure the trigger is in the "off" position before connecting to the air supply.
2.2. You will require an air pressure of 90psi and an available air flow of 4cfm to operate the unit.
2.3. pWARNING! Ensure the air supply does not exceed 120psi while operating the hammer. Too high an air pressure and/or unclean air
will shorten the product life due to excessive wear and may be dangerous, causing damage and/or personal injury.
2.4. Drain the air tank daily. Water in the air line will damage the hammer.
2.5. Clean the air inlet filter screen weekly.
2.6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should
be 10mm I.D. and fittings must have the same inside dimensions.
2.7. Keep hose away from heat, oil and sharp edges.
Check hoses for wear, and make certain that
all connections are secure.
2. AIR SUPPLY
fig. 1
1. SAFETY INSTRUCTIONS
SA11/S - 1 - 091101

Note: Numbers in brackets refer to item numbers in the parts list.
The air hammer is designed primarily for use on vehicle bodywork. We do not recommend any other use. Ensure you read, understand and
follow the safety instructions in Section 1.
4.1. Attach the retaining spring (17) by screwing it onto the Cylinder (16).
4.2. Insert the chisel using the hooked end of the spring to hold the chisel in place.
4.3. Attached the tool to the air supply (see Section 2).
4.4. To operate the hammer, squeeze the trigger (6). The air regulator (5) may be used as a means of throttle control.
pWARNING! Disconnect the hammer from the air supply before changing chisels, servicing or performing any maintenance.
5.1. Keep the hammer oiled for optimum performance.
Lubricate with a good grade of air tool oil such as Sealey ATO/500 or ATO/1000. If there is no oiler in the air system then a teaspoon of
oil can be poured into the air inlet of the hammer, or into the hose at the nearest connection to the air supply. Then run the hammer for
a short time.
Note: The following external factors may cause loss of power and effect hammer performance:
The air supply
Reduced compressor output, excessive drain on the air line, moisture or restrictions in air pipes or the use of hose connectors
having too small a bore. Correct as necessary.
The hammer
Grit or gum deposits in the tool. Correct by cleaning the air strainer and flushing out the tool with gum solvent oil or an equal mixture of
SAE No.10 oil and kerosene.
If, despite taking action as above, the tool function is still impaired, contact your local Sealey service agent.
GS/TUV approved quality long stroke air hammer supplied in carry case. Kit also includes spare retainer spring, long blade panel cutter, special
panel cutter, panel cutter, muffler tail pipe remover, cold chisel, air hose connector and air tool lubricating oil.
4. OPERATING INSTRUCTIONS
6. PARTS LIST
7. DECLARATION OF CONFORMITY
5. MAINTENANCE
3. INTRODUCTION & SPECIFICATION
Chisel Shank . . . .0.401 Parker Taper
Speed . . . . . . . . . . . . . . . . . .3500bpm
Stroke . . . . . . . . . . . . . . . . . . . .20mm
Operating Pressure . . . . . . . . . . .90psi
Air Consumption . . . . . . . . . . . . .4cfm
Air Inlet . . . . . . . . . . . . . . . . . .1/4BSP
Weight . . . . . . . . . . . . . . . . . . . .1.5kg
Vibration . . . . . . . . . . . . . . . . . .18m/s2
Noise Level . . . . . . . . . . . . .99.9dB(A)
SPECIFICATION
LONG STROKE AIR HAMMER
Model SA11/S
98/37/EC Machinery Directive
93/68/EEC CE Marking Directive
Declaration of Conformity We, the sole importer into the UK, declare that the product listed here is in conformity with the following standards and directives.
The construction file for this product is held by the Manufacturer and may be inspected, by a national authority, upon
request to Jack Sealey Ltd.
For Jack Sealey Ltd. Sole importer into the UK of Sealey Power Tools.
12th November 2001Signed by Mark Sweetman
Item Part No. Description
1 SA11R/01 Housing
2SA11R/02 Pin
3SA11R/03 Ball Seat
4 SA11R/04 0-ring
5 SA11R/05 Air Regulator
6 SA11R/06 Trigger
8SA11R/08 Valve Stem
9 SA11R/09 Bushing
10 SA11R/10 Spring
11 SA11R/11 Air Inlet
12 SA11R/12 Valve Case
15 SA11R/15 Piston
16 SA11R/16 Cylinder
17 SA11R/17 Spring
Issue No: 1
Date Issued: 091101
