Sealey SA92.V3 User manual

1. SAFETY
9Followallworkshopsafetyrules,regulations,andconditionswhenusingthebufngkit.
WARNING!Disconnectfromairsupplybeforechangingaccessoriesorservicing.
9Maintainthebufngkitingoodconditionandreplaceanydamagedorwornparts.Use genuine parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
WARNING!Checkcorrectairpressureismaintainedandnotexceeded.Werecommend90psi.
9Keepairhoseawayfromheat,oilandsharpedges.
9Checkairhoseforwearbeforeeachuseandensurethatallconnectionsaresecure.
9Wearapprovedsafetyeye/faceshield,eardefenders,andhandprotection.
WARNING! Due to the possible presence of asbestos dust from brake linings, when working around vehicle brake systems we
recommendyouwearsuitablerespiratoryprotection.
9Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-slipshoes.
9Keepchildrenandnonessentialpersonsawayfromtheworkingarea.
8DO NOTusethebufngkitforataskitisnotdesignedtoperform.
WARNING! DO NOTusebufngkitifdamagedorthoughttobefaulty.(ContactServiceAgent).
8DO NOTusebufngkitunlessyouhavebeeninstructedinitsusebyaqualiedperson.
8DO NOTcarrythebufngkitbytheairhose,oryankthehosefromtheairsupply.
8DO NOToperatebufngkitifyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.
8DO NOTcarrybufngkitwithyourhandonthepowertriggerinordertoavoidunintentionalstarting.
8DO NOTdirectairfromtheairhoseatyourselforothers.
9Whennotinusedisconnectfromairsupplyandstoreinasafe,dry,childprooflocation.
2. INTRODUCTION
AluminiumcasedairmotorwithselectionofØ6mmshankedgrindingpoints,Ø10mmchuckandtyrebuffingcone.Kitalsoincludesspanners,
chuckkeyandairhoseadaptors.
3. SPECIFICATION
Model No:................................................................. SA92.V3
Air Consumption:............................................................ 5cfm
ChuckSize:............................................................... Ø10mm
Consumable Parts:........................... SA651/C-BufngCone
FreeSpeed:........................................................... 22000rpm
InletSize:..................................................................1/4”BSP
Noise Power/Pressure:...................................... 101/90dB(A)
Operating Pressure:...................................................... 90psi
Vibration/Uncertainty:......................................... 1.5/0.64m/s²
AIR TYRE BUFFING KIT
MODELNO:SA92.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
Weareye
protection Wearear protection
SA92.V3Issue2(H,F)23/03/23
Original Language Version
©JackSealeyLimited
Wearaface
mask Wearprotective gloves

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
4. ASSEMBLY & INSTALLATION
4.1. AIR SUPPLY
4.1.1. Ensurebufferairvalve(ortrigger)isinthe“off”positionbeforeconnectingtotheairsupply.
4.1.2. Youwillrequireanairpressureof90psi,andanairflowaccordingtospecification.
WARNING! Ensuretheairsupplyiscleananddoesnotexceed90psiwhileoperatingthebuffer.Toohighanairpressureanduncleanair
 willshortentheproductlifeduetoexcessivewear,andmaybedangerouscausingdamageand/orpersonalinjury.
4.1.3. Draintheairtankdaily.Waterintheairlinewilldamagethebuffingkit.
4.1.4. Cleanairinletfilterweekly.Recommendedhook-upprocedureisshowninfig1.
4.1.5. Linepressureshouldbeincreasedtocompensateforunusuallylongairhoses(over8metres).Theminimumhosediametershouldbe
 1/4”I.D.andfittingsmusthavethesameinsidedimensions.
4.1.6. Keephoseawayfromheat,oilandsharpedges.Checkhoseforwear,andmakecertainthatallconnectionsaresecure.
4.2. COUPLINGS
  Vibrationmaycausefailureifaquickchangecouplingisconnecteddirectlytothebuffingkit.Toovercomethis,connectaleaderhoseto
  thebuffingkit.Aquickchangecouplingmaythenbeusedtoconnecttheleaderhosetotheairlinerecoilhose.Seefig.1&2.
4.3.
5. OPERATION
WARNING! Ensure you read, understand and apply safety instructions before use.
   Note:Numbersshowninbracketsrefertoitemnumbersinthepartslist.
WARNING! Disconnectfromairsupplybeforechangingaccessoriesorservicing.
5.1.  Thebufngwheel(34)attachesdirectlytothearbor(28)andshouldbetightenedusingthewrench(33).
5.2.  Tousethegrindingstones(39)screwthe10mmdrillchuck(35)ontothearbor(28).Inserttherequiredgrindingstoneintothechuck
 andsecureusingthechuckkeyprovided.Remembertoremovethechuckkey.
5.3.  Depressthetriggertooperatethebufngkit.
6. MAINTENANCE
WARNING! Disconnect buffer from air supply before changing accessories, servicing or performingmaintenance. Replace or repair
 damagedparts.Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
6.1.  LubricatethebufferdailywithafewdropsofSealeyairtooloildrippedintotheairinlettoprolongitslife.
6.2.  Cleanthebuffingkitafteruse.DO NOTusedamagedstonewheels.
6.3.  Lossofpowerorerraticactionmaybeduetothefollowing:
a) Excessivedrainontheairline.Moistureorrestrictionintheairpipe.Incorrectsizeortypeofhoseconnectors.Toremedy
   checktheairsupplyandfollowinstructionsinsection4.
b)Gritorgumdepositsinthebuffingkitmayalsoreduceperformance.Ifyourmodelhasanairstrainer(locatedintheareaof
   theairinlet),removethestrainerandcleanit.FlushthebufferoutwithgumsolventoiloranequalmixtureofSAENo10oil
   andparaffin.
   Allowtodrybeforeuse.
6.4.  ForafullservicecontactyourlocalSealeyserviceagent.
6.5.  Whennotinuse,disconnectfromairsupply,cleanbufferandstoreinasafe,dry,childprooflocation.
fig.1
Original Language Version
©JackSealeyLimited
fig.2
REGISTER YOUR
PURCHASE HERE
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall
ourtechnicalteamon[e-mail]or01284757505.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,
takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproduct
becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand
disposeoftheproductandfluidsaccordingtolocalregulations.
SA92.V3Issue2(H,F)23/03/23
