Securam ProLogic L22 User manual

ProLogic L22 Operation Instructions
1
ProLogic L22 Operation Instructions
Document No: EC-0601A-L22-180911
Version No: V1.01
1.0 System Installation
1.1 System Components
1.2 Pairing the EntryPad with the Lock(s)
1.3 Lock and EntryPad Installation
1.4 Installing Battery
1.5 Test Lock Operation
2.0 Code Length Options
2.1 PW L – 6 / Users 10
2.2 PW L – 8 / Users 30
2.3 PW L – 6 / Users 30
3.0 Lock Operation
3.1 Opening the Lock
3.2 Opening the Lock in Time Delay
3.3 Opening the Lock Under Duress
3.4 Opening the Lock in Dual Control
3.5 Opening the Lock with a Multi-Lock System
4.0 Set Date and Time
4.1 Set Clock Time
4.2 Show Clock Time
4.3 DayLight Savings Time
5.0 Code Management
5.1 Enrolling New Users
5.2 Change Code
5.3 Delete One User
5.4 Delete All Users
5.5 Disable/Enable User
5.6 Obfuscate Code Entry
5.7 Set ID01 to Master
6.0 System Identification
6.1 System Info
7.0 Time Delay
7.1 Set/Cancel Time Delay
8.0 Audit Trail Functionality
8.1 Show Audit Trail
9.0 Manager Mode
9.1 Enable Manager Mode
9.2 Disable Manager Mode
10.0 Single or Dual Control
10.1 Enable Dual Mode
10.2 Dual Mode Group ID
11.0 Door Management
11.1 Max. Door Open Time
11.2 Configuring a Multi-lock system
11.3 Set Number of Locks
11.4 Numbering Locks
11.5 Authorize Locks
11.6 Enable Sequence
12.0 Duress Management
12.1 Duress Setup and Wiring Configuration
12.2 Duress Code Shift
13.0 Device Management
13.1 Set Device ID
14.0 Data Management
14.1 Encryption Key Set
15.0 Recovering the System – Reset to Default
15.1 Recovery Code Set
15.2 Recover System
15.3 Disable Recover
15.4 Mechanical Reset
16.0 System Testing
16.1 Cycle Testing
16.2 Hardware Testing
17.0 Menus
17.1 The ProLogic L22 Menus

ProLogic L22 Operation Instructions
2
IMPORTANT: It is imperative that all programming be completed with the safe
door in its open position, such that the programmer can gain access to the lock
body in the event of an incorrect programming.
1.0 System Installation
1.1 System Components
The system consists of (1) EntryPad – Part # EC-0601A-L22 plus (1) or more Lock bodies as follows:
 SwingBolt – Part # EL-0601
 SwingBolt with Status Sensor – Part # EL-0601-S
 DeadBolt – Part # EL-0701
 SpringBolt – Part #EL-0801
Note: The ProLogic L22 can control up to 4 locks when used in conjunction with the Expansion Box –
Part # CB11-1T4. (If setting up a multi-lock system, please refer to Section 11.2 – Multi-Lock Systems)
1.2 Pairing the EntryPad and the Lock
SecuRam safe lock systems can operate in two different modes depending upon the type of EntryPad
being used with the lock body. The ProLogic L22 is a digital lock system and therefore the lock must also
be programmed in digital mode. Both modes follow the same steps to reset / set which is done by
following the steps detailed below:
Step 1: Ensure the battery is connected to the EntryPad.
Step 2: Ensure the lock cable is disconnected from the lock body.
Step 3: Locate the Reset Hole on the back of the lock (under the QC sticker).
Step 4: Inside the reset hole is a reset button. Use a paper clip to depress the reset button 3
times. This dissipates any latent energy in the lock.
Step 5: Now depress the reset button and hold.
Step 6: While continuing to depress the reset button, connect the lock cable to the lock body.
Step 7: Continue to hold down the reset button for 5 seconds and then release.
Step 8: Verify that the pairing has been completed, by opening the lock with the default code
111111.
Step 9: Press any button on the EntryPad to initiate a lock communication test. The EntryPad
will display the following information:

ProLogic L22 Operation Instructions
3
Followed by:
Enter a valid code to test the lock.
The Default codes are as follows:
 Super Code (ID00) is 111111
 Manager Code (ID01) is 123456
Upon entry of a valid code, the lock will open. If the lock does not open and the LCD screen
displays the message “Fail to Link with Lock”, repeat the reset procedure. Be sure to hold down
the reset button through steps 5-7.
If you have difficulty resetting the lock, please call SecuRam Tech Support at [phone] or email
[e-mail].
1.3 Lock and EntryPad Installation
Included within your installation kit are (2) shoulder bolts and (3) lock mounting bolts.
 Install the shoulder bolts on the safe door in the pre-drilled holes above and below the spindle
hole.
 Now insert the lock cable (attached to the EntryPad) through the spindle hole.
 On the backside of the safe door, you will see the lock mounting plate and the predrilled lock
mounting holes.
 Connect the lock cable to the lock body and position the lock body appropriately on the lock
mounting plate.
 Ensure that the lock cable is positioned so that it lies in the channel on the back of the lock. This
channel is provided to protect the lock cable from damage or crimping during installation.
 Using the provided lock bolts, secure the lock body to the mounting plate.
Note: it is very important to ensure that there is an adequate gap between the lock bolt and the bolt
work. This gap must be 0.125”.
1.4.1 Installing the Battery – Standard Battery Compartment (located on the back of the EntryPad)

ProLogic L22 Operation Instructions
4
 Connect the battery terminal clip to the 9V battery. (Duracell or Energizer brands are
recommended).
 Position the battery so that the terminals are in the downward position and push the battery
into the battery compartment. See Fig. 1.
 Carefully tuck the excess lock cable into the cavity on the back of the EntryPad and install the
EntryPad on the shoulder bolts. See Fig. 2.
 Be careful not to crimp or damage the lock cable upon EntryPad installation.
1.4.2 Installing the Battery – SureLock Battery Compartment (removable battery compartment)
 Locate the SureLock Battery Compartment at the 5 o’clock position of the EntryPad. See Fig. 3.
 Release the latch of the battery compartment, by pulling lever downward. See Fig 4.
 Pull out the battery compartment from the bottom of the EntryPad. See Fig 5.
 Install a new 9V alkaline battery (Duracell or Energizer brands are recommended) into the
compartment. The battery compartment will only receive the battery when the positive and
negative terminals are oriented correctly. See Fig. 6
 Put the battery compartment back into the EntryPad. Push the latch of the battery
compartment up until it snaps closed. See Fig. 3

ProLogic L22 Operation Instructions
5
1.5 Testing the Lock Operation
The ProLogic L22 comes with two factory default codes:
• Super Code (ID00) is 111111
• Manager Code (ID01) is 123456
Enter one of the valid codes to verify that the communication between the lock and EntryPad. The lock
will open.
2.0 Code Length Options
IMPORTANT: This must be completed before any programming.
The ProLogic L22 allows you the ability to select the code length for all safe lock operators and the total
number of users allowable on the lock. Setting the code length and number of Users is a global setting
and applies to all safe lock operators.
Note: If you skip this step and program the lock, you can change the Code Length/Number of Users at a
later time. All safe doors must be opened to make this change as a reset will be required on all lock
bodies. All programming will be deleted and the lock will be set back to default.
There are 3 options available as follows:
 Code Length 6 digits – 10 total codes available - This is the default mode and meets the UL
requirement.
 Code Length 8 digits – 30 total codes available – This mode also meets the UL requirement.
 Code Length 6 digits – 30 total codes available – This mode does not meet the UL requirement.
2.1 PW L – 6; Users – 10 – This is the default mode
NOTE: This operation must be performed with the SAFE DOOR OPEN and with access to the back of
the lock, as a mechanical reset must be performed during this programming sequence.
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter the Super Code (ID00) only .
This function is not available to Manager Codes ID01 or ID02. The “Select Menu” message will
be displayed as follows:
Step 4: Scroll  and  to the menu selection “PW L – 6; Users – 10” and Press OK

ProLogic L22 Operation Instructions
6
Step 5: The LCD will display a warning followed by “Delete All Users?”, press OK to confirm.
All users have been deleted.
IMPORTANT: The LCD will advise if a reset is required to finalize the programming. If required, follow
the Mechanical Reset procedure outlined in 15.4 Mechanical Reset.
The code length will now be 6 digits and the total available users will be 10.
The Super Code ID00 will now be 1-1-1-1-1-1
The Manager Code ID01 will now be 1-2-3-4-5-6
The Default Recovery Code will be 9-9-9-9-9-9
The Default Encryption Code will be 6-8-5-1-9-8
2.2 PW L – 8; Users – 30
NOTE: This operation must be performed with the SAFE DOOR OPEN and with access to the back of
the lock, as a mechanical reset must be performed during this programming sequence.
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter the Super Code (ID00) only .
This function is not available to Manager Codes ID01 or ID02. The “Select Menu” message will
be displayed as follows:
Step 4: Scroll  and  to the menu selection “PW L – 8; Users – 30” and Press OK

ProLogic L22 Operation Instructions
7
Step 5: The LCD will display a warning followed by “Delete All Users?”, press OK to confirm.
All users have been deleted.
IMPORTANT: The LCD will advise if a reset is required to finalize the programming. If required, follow
the Mechanical Reset procedure outlined in 15.4 Mechanical Reset.
The code length will now be 8 digits and the total available users will be 30.
The Super Code ID00 will now be 1-1-1-1-1-1-0-0
The Manager Code ID01 will now be 1-2-3-4-5-6-0-0
The Default Recovery Code will be 9-9-9-9-9-9-0-0
The Default Encryption Code will be 6-8-5-1-9-8-0-0
2.3 PW L – 6; Users – 30
NOTE: This operation must be performed with the SAFE DOOR OPEN and with access to the back of
the lock, as a mechanical reset must be performed during this programming sequence.
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter the Super Code (ID00) only .
This function is not available to Manager Codes ID01 or ID02. The “Select Menu” message will
be displayed as follows:
Step 4: Scroll  and  to the menu selection “PW L – 6; Users – 30” and Press OK

ProLogic L22 Operation Instructions
8
Step 5: The LCD will display a message to indicate that this setting does not meet the UL
requirement.
Step 6: The LCD will then display a warning followed by “Delete All Users?”, press OK to
confirm.
All users have been deleted.
IMPORTANT: The LCD will advise if a reset is required to finalize the programming. If required, follow
the Mechanical Reset procedure outlined in 15.4 Mechanical Reset.
The code length will now be 6 digits and the total available users will be 30.
This mode is not certified by UL.
The Super Code ID00 will now be 1-1-1-1-1-1
The Manager Code ID01 will now be 1-2-3-4-5-6
The Default Recovery Code will be 9-9-9-9-9-9
The Default Encryption Code will be 6-8-5-1-9-8
3.0 Lock Operation
Upon initial power up, the LCD screen starts a communications test as shown below:
 Including Model Number
 Software Version Number
 No. of Users/ No. Users Programmed
 Lock ID#/Host ID#
 Model Name
 No. of Audit Events

ProLogic L22 Operation Instructions
9
After this initial power up it will also check to ensure that the system is communicating correctly. The
display will read “Link with Lock OK”.
If the Display reads: “Fail to Link with Lock” proceed to Section 1.2 entitled “Pairing the EntryPad and
the Lock”
3.1 Opening the Lock
The safe lock system has two default codes installed as follows:
• Super Code (ID00) 1-1-1-1-1-1
• Manager Code (ID01) 1-2-3-4-5-6
Step 1: Enter a valid code – for example ID00.
The display will read “ID00 Verified”.
And the Lock will open.
The display will read:
The lock will relock after 6 seconds.
Note: Time to relock is hard coded and cannot be changed.
3.2 Opening Lock with Time Delay Programmed
When Time Delay has been programmed, the user must enter a valid code.
Note: Users are defined as ID03- ID30
Wait through the preprogrammed time delay period, then enter the code again to open the lock safe, as
follows:
Step1: Enter a valid code
Note: ID00, ID01 and ID02 are Administrator users and will bypass Time Delay.
ID00

ProLogic L22 Operation Instructions
10
Step 2: Display will read “Time Delay Start”
Step 3: Display will flash on every 15 seconds, counting up until it reaches the preprogrammed
time delay value.
Note: Administrators can override Time Delay to open lock anytime.
Step 4: When Time Delay expires, the EntryPad will beep twice then display: “Time Window
XX:00”, indicating the length of time the User has to enter a valid user code to gain entry.
Note: The Counter will count down until the Time Window has expired. A user code is used to
open the lock.
Step 5: Enter a valid Code to open the lock.
3.3 Opening the Lock Under Duress
The ProLogic L22 has a Duress Feature, which allows a User or Admin to open the lock and send a silent
Duress signal indicating that you are in danger. By default, the duress function is active. It can be
disabled by changing the Duress Code Shift Value to 00. Refer to Section 12.2.
In Order to send a signal, the system must have a CB10 junction box installed and must be connected to
an alarm panel.
To Open the Lock under Duress:
Step 1: Enter a valid Code, but add or subtract 1 from the code. The Lock will open as normal and a
silent alarm will be issued.
Note: This will be logged as “Duress Unlock” in events.
For example, if your code is 123456; under Duress, enter 123455 or 123457 to send silent alarm.
Note: The ProLogic L22 has a function called “Duress Code Shift”. This function allows you to turn off
the duress function. See Section 12.2.

ProLogic L22 Operation Instructions
11
3.4 Opening the Lock in Dual Control
The ProLogic L22 can be programmed so that two User codes are required to open the lock. This
function is called “Enable Dual Mode”, see Section 10.1.
To Open a Lock under Dual Control:
Step 1: Enter User code
The display will read “IDXX Verified”.
For example, ID03 will display “ID03 Verified”.
The display will then read:
“Enter 2
nd
User Code”
For example, using ID04 for 2
nd
code will read “ID04 Verified”.
The lock will open and relock in 6 seconds.
3.5 Opening the Lock with a Multi-Lock System
The ProLogic L22 can operate up to 4 locks. See 11.2 “Configuring a Multi-Lock System” to set up this
option.
To Open a Lock with a Multi-Lock System:
Step 1: Enter a valid code
The display will read “IDXX Verified”.
Step 2: The system will now prompt you to select the number of the Lock to be opened.
4.0 Set Date and Time
The ProLogic L22 is an audit lock and it tracks events based on user, activity, date, and time. In order to
set the system date and time complete the following process.
4.1 Set Clock Time
Step1: Press the Menu/OK button

ProLogic L22 Operation Instructions
12
Step 2: Using the  and, scroll to the System Menu and press OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01). The “Select Menu” message will be displayed as follows:
Step 4: Scroll  to the menu selection “Set Clock Time” and Press OK
Step 5: Press OK
Step 6: Each of the elements of the date and time will flash when it is available to be set. Use the
 and  to scroll to the correct value and Press OK to move to the next element.
4.2 Show Clock Time
Step1: Press the Menu/OK button
Step 2: Using the  and, scroll to the System Menu and press OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01). The “Select Menu” message will be displayed as follows:
Step 4: Scroll  to the menu selection “Show Clock Time” and Press OK
Step 5: The LCD will display the current system date and time, as follows:
4.3 DayLight Savings Time

ProLogic L22 Operation Instructions
13
The ProLogic L22 can be set to manage Daylight Savings Time and automatically updating preset date
and time. Using this menu selection, you can turn on Daylight Savings Time management or turn it off.
**Note: The example below shows that Daylight Savings Time will start in March (3
rd
month), 2nd full
week at 2:00 am on the first day of the week (Sunday). And Day Light Savings Time will end in
November (11
th
month), 1
st
full week at 2:00 am on the first day of the week (Sunday).
Step1: Press the Menu/OK button
Step 2: Using the  and , scroll to the System Menu and press Menu/OK
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01). The “Select Menu” message will be displayed as follows:
Step 4: Scroll  to the menu selection “Daylight Savings TM” and Press OK
Step 5: Press the  button to turn Daylight Savings Time Management on. (To turn it off, press
the  button)
Step 6: (Starting Month) The system will now request the month in which Daylight Savings Time
is to begin. The default is North American DST Month 3 – March. To change press the  and 
to set the Month; and press OK
Step 7: (Starting Week) The system will now request the week of the month in which Daylight
Savings Time is to begin. The default is North American DST Week 2 – note – the system
calculates this as the 2
nd
full week in this month. To change Press the  and  to set the Week;
and press OK

ProLogic L22 Operation Instructions
14
Step 8: (Starting Time) The system will now request the Time on the first day of the week
(Sunday) at which Daylight Savings Time is to begin. The default is North American DST Time 2 –
2:00am. To change Press the  and  to set the Time; and press OK
Step 9: (Ending Month) The system will now request the month in which Daylight Savings Time
is to end. The default is North American DST Month 11 – November. To change press the  and
 to set the Month; and press OK
Step 10: (Ending Week) The system will now request the Week in which Daylight Savings Time is
to end. The default is North American DST Week 1 – note – the system calculates this as the 1
st
full week in this month. To change Press the  and  to set the Week; and press OK
Step 11: (Ending Time) The system will now request the Time on the first day of the week
(Sunday) at which Daylight Savings Time is to end. The default is North American DST Time 2 –
2:00am. To change Press the  and to set the Week; and press OK
Therefore to set to the North American DST, just select “Y” on the first display screen and then accept
the defaults for all other settings by pressing OK.
5.0 Code Management
The ProLogic L22 comes with two default codes:
• Super Code (ID00) is 111111
• Manager Code (ID01) is 123456
Note: It is strongly recommended that both these default codes are changed before the lock system is
put into service.
The ProLogic L22 has the capability to add up to 29 codes, in addition to the default codes.
 ID02 is a Manager Code and therefore has management functionality (the same as ID01).
 ID03-30 are User Codes.
 ID03-ID04 are Time Management Supervisory Codes. These codes are access codes but also
have the ability to manage and adjust Time.

ProLogic L22 Operation Instructions
15
 ID05-30 are User Codes.
5.1 Enrolling New Users
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK
Step 3: The display will prompt you to enter a valid Administrator code
 Enter either the Super Code (ID00) or the Manager Code (ID01 or ID02). The “Select Menu”
message will be displayed as follows:
Step 4: Scroll  to the menu selection “Enroll New User” and Press OK
Step 5: The next available ID position is displayed. To select this ID, Press OK; or to select a
different ID position, Press  to desired ID and press OK
Step 6: Now enter a 6 digit code
Step 7: Repeat new code
Step 8: System will verify that code has been saved.
The new code is now enrolled and available to be used to open the lock
5.2 Change Code
Step1: Press the Menu/OK button
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK

ProLogic L22 Operation Instructions
16
Step 3: The display will prompt you to enter a valid code. Enter the code to be changed
The “Select Menu” message will be displayed as follows:
Step 4: Scroll  to the menu selection “Change Code” and Press OK
Step 5: The display will show this message on the display “Set Code of IDXX” to be changed.
Step 6: Enter the new 6 digit code.
Step 7: Repeat the new code.
The New Code has now been saved and is available for use.
5.3 Delete One User
Step1: Press the Menu/OK button
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01 or ID02).
The “Select Menu” message will be displayed as follows:
Step 4: Scroll UP to the menu selection “Delete One User” and Press OK
Step 5: Press OK

ProLogic L22 Operation Instructions
17
Step 6: The system will ask which User Code is to be deleted. Press  and  until the desired
USER ID is reached.
Step 7: Press OK.
This User Code is now deleted from the system.
5.4 Delete All Users
This feature is used to delete all users from the system. Upon executing this command, all users will be
deleted and Manager Code will be reset as follows:
 Manager Code (ID01) is 123456
 Note: Super Code will not be reset to default. The Recover System function is used to reset the
Super Code to default.
Step1: Press the Menu/OK button
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01 or ID02). The “Select Menu” message will be displayed as follows:
Step 4: Scroll UP to the menu selection “Delete All Users” and Press OK.
Step 5: The system will request a Confirmation. Press OK.
The system will verify that all User Codes have been deleted.
The only remaining code will be the default code as follows:
• Manager Code (ID01) is 123456
5.5 Disable/Enable User Codes

ProLogic L22 Operation Instructions
18
This feature would be used in order to disable a user code as opposed to deleting it. Disable/Enable
user codes options may be used when a user’s access rights are temporarily revoked. (i.e. the user may
be on vacation or otherwise away from the business.)
After the code has been disabled, it can be enabled at a later time, following the same process by
selecting “Enable User”.
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01 or ID02). The “Select Menu” message will be displayed as follows:
Step 4: Scroll  and  to the menu selection “Disable User” and Press OK
Step 5: The system will ask which User to disable. Scroll  and to the desired USER ID and
press OK.
Step 6: The system will verify the User has been disabled.
5.6 Obfuscate Code Entry
This feature would be used in order to obfuscate the code as it is entered on the LCD screen.
In normal operation, as the user enters the code, the digit of the code pressed is visible on the LCD until
the next digit is entered. The subsequent digit turns to an “*”.
With the Obfuscate Code Entry feature, every digit that is entered is displayed as an “*” immediately
upon entry, so that your code is always obscured from view on the LCD.
To Obfuscate Code Entry, follow this procedure:

ProLogic L22 Operation Instructions
19
Step1: Press the Menu/OK button.
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00) or
the Manager Code (ID01 or ID02). The “Select Menu” message will be displayed as follows:
Step 4: Scroll  and  to the menu selection “Obfuscate Code Entry” and Press OK
All digit entries will now be display as “*” immediately upon entry.
To revert from this mode, follow the same process but select “Show Code Entry”.
5.7 Set ID01 to Master
This programming command would be used in order to establish a hierarchy within the Manager
(ID01)/Supervisor (ID02) code permissions.
When Set ID01 to Master is enabled:
 ID02 cannot Delete ID01
 ID02 cannot Disable ID01
 ID02 Manager functions are removed from the System Menu. ID02 can ONLY:
o Enroll New User
o Delete One User
o Enable User
o Disable User
o Change Code
o Show Audit Trail
o System Info
o Show Clock Time
 ID02 will no longer be a Dual Mode Override and will abide by Dual Mode rules, whereby ID02 must
enter his code in conjunction with another valid user to open the lock.

ProLogic L22 Operation Instructions
20
Step1: Press the Menu/OK button
Step 2: Using the  and , scroll to the System Menu and Press Menu/OK.
Step 3: The display will prompt you to enter a valid code. Enter either the Super Code (ID00).
The “Select Menu” message will be displayed as follows:
Step 4: Scroll  to the menu selection “Set ID01 to Master” and Press OK.
The system will confirm that ID01 is now the Master Code.
To cancel this programming command, select “Set ID01 to Manager”, and the management
menu will be restored to default for ID02.
6.0 System Info - System Identification
This menu feature would be used to determine the type of safe lock system being used. Many of the
SecuRam ProLogic EntryPads look the same, but the features sets and capabilities vary greatly
depending upon the software being utilized. To determine the type of ProLogic Safe Lock system, follow
this process:
System Info:
Step1: Press the Menu/OK button.
Step 2: Using the  and  scroll to the “System Info” and Press OK.
The system will display Information about the system, including the model number of the
ProLogic EntryPad.
