Sega MARIO & SONIC AT THE OLYMPICS GAMES TOKYO... User manual

IMPORTANT
• Before using this product, read this manual carefully to understand the
contents herein stated.
• After reading this manual, be sure to keep it near the product or in a
convenient place for easy reference when necessary.
OWNER'S MANUAL 420-0038UKMARIO AND SONIC AT THE TOKYO OLYMPICS 2020
OPERATOR AND SERVICE
MANUAL
Sega Amusements International Limited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
[email protected] segaarcade.com
Sega Games Co,. Ltd.
1-2-12, Haneda, Ota-ku, Tokyo, 144-8531. Japan.
Telephone: [phone] Facsimile: [phone]
sega-games.co.jp
© SEGA
Errors and omissions excepted (E&OE)
1at PRINTING
FEBRUARY 2020

ii
INTRODUCTION
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage:
The following instructions are intended for the users, operators and the personnel in charge of the operation of the
product. After carefully reading and suciently understanding the warning displays and cautions, handle the product
appropriately. Be sure to keep this manual close to the product or in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the product by disregarding this pictograph will cause severe injury or death.
Indicates that mishandling the product by disregarding this warning will cause a potentially hazardous
situation which can result in death or serious injury.
Indicates that mishandling the product by disregarding this caution will cause a slight hazardous
situation which can result in personal injury and/or material damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and equipment, this display is attached to
places where the instruction manual should be referred to.
Indicates a "protective earth terminal." Before operating the equipment, be sure to connect it to the ground (this step
may be omitted for products in which a power cable with earth is used).
• Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention. Failing to perform work as per
the instructions can cause accidents. In the case where only those who have technical expertise should perform the work to
avoid hazardous situation, the instructions herein state that the site maintenance personnel should perform such work.
• Besuretoturno󰀨thepowerbeforeworkingonthemachine.
To prevent an electric shock, be sure to turn o the power and unplug the power cable before carrying out any work that
requires direct contact with the interior of the product. If the work is to be performed in the power-on status, the instruction
manual herein always states to that eect.
• Besuretogroundtheearthterminal(thisisnotrequiredinthecasewhereapowercablewithearthisused).
This product is equipped with the earth terminal. When installing the product, connect the earth terminal to the "accurately
grounded indoor earth terminal" by using an earth wire. Unless the product is grounded appropriately, the user can be subject
to an electric shock. After performing repair, etc. for the control equipment, ensure that the earth wire is rmly connected to
the control equipment.
• Ensurethatthepowersupplyusedisequippedwithanearthleakagebreaker.
Using a power supply which is not equipped with the earth leakage breaker can cause a re when earth leakage occurs.
• Besuretousefuseswhichmeetthespeciedrating(onlyforthemachineswhichusefuses).
Using fuses exceeding the specied rating can cause a re and an electric shock.

INTRODUCTION
iii
• Specicationchanges(removalofequipment,conversionsandadditions)notdesignatedbySEGAarenot
allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It is very hazardous to operate
the product by removing parts and/or modifying the circuits. Should doors, lids and protective parts be damaged or lost, refrain
from operating the product, and contact where the product was purchased from or the oce herein stated.
SEGA shall not be held responsible for any accidents or compensation for damage to a third party resulting from the
specications not designated by SEGA.
• Ensurethattheproductmeetstherequirementsofappropriateelectricalspecications.
Before installing the product, check for electrical specications. SEGA products have a nameplate on which the electrical
specications are described. Ensure that the product is compatible with the power supply voltage and frequency requirements
of the location. Using any electrical specications dierent from the designated specications can cause a re and an electric
shock.
• Installandoperatetheproductinplaceswhereappropriatelightingisavailable,allowingwarninglabelsto
beclearlyread.
To ensure safety for the customers, labels and printed instructions describing potentially hazardous situations are applied to
places where accidents can be caused. Ensure that where the product is operated has sucient lighting allowing the warnings
to be read. If any label is peeled o, apply it again immediately. Please place an order with where the product was purchased
from or the oce herein stated.
• Whenhandlingthemonitor,beverycareful(appliesonlytoproductswithmonitors).
Some of the monitor parts are subject to high tension voltage. Even after turning o the power, some portions are still subject
to high tension voltage. Monitor repair and replacement should be performed only by those technical personnel who have
knowledge of electricity and technical expertise.
• Besuretoadjustthemonitorproperly(appliesonlytoproductswithmonitors).
Do not operate the product leaving on-screen ickering or blurring as it is. Using the product with the monitor not properly
adjusted may cause dizziness or a headache to an operator, a player, or customer.
• Whentransportingorresellingthisproduct,besuretoattachthismanualtotheproduct.
* In the case where commercially available monitors and printers are used in this product, only the contents relating to this
product are explained herein. Some commercially available equipment has functions and reactions not stated in this manual.
Read this manual together with the specic instruction manual of such equipment.
* Descriptions herein contained may be subject to improvement changes without notice.
* The contents described herein are fully prepared with due care. However, should any question arise or errors be found, please
contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after transporting to the location.
Nevertheless, an irregular situation may occur during transportation. Before turning on the power, check the following points to
ensure that the product has been transported in a satisfactory status:
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are casters and adjusters damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct way, connector connections can
not be made accurately. Do not insert connectors forcibly.
Do power cables have cuts and dents?
Are all accessories available?
Can all doors and lids be opened with the accessory keys? Can doors and lids be rmly closed?

iv
INTRODUCTION
INTRODUCTION
This manual is intended to provide detailed descriptions together with all necessary information covering the general
operation of electronic assemblies, electromechanical, servicing control, spare parts, etc. for the product:
"MARIO AND SONIC AT THE TOKYO OLYMPICS 2020"
This manual is intended for the owners, personnel managers in charge of operation of this product.
Operate the product after carefully reading and suciently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a technician
to touch the internal system. Turn o the power to the machine, making sure to unplug the electrical cord from the
outlet, and contact the oce listed below or the point-of-purchase for this product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that require special
attention are indicated by bold text, the words "STOP, IMPORTANT or CAUTION” and the symbols below.
Indicates important information that, if ignored, may result in the mishandling
of the product and cause faulty operation or damage to the product.
Indicates a warning or caution that, if ignored, may result in the mishandling
of the product and cause faulty operation or damage to the product.
SegaAmusementsInternationalLimited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
European Sales: [phone] Facsimile: [phone]
USA Sales: +00 (1) 224 265 4287
STS (Spares): [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com
SPECIFICATIONS
Standard Cabinet
Machine Dimensions: 0.81m (31.8in) [Width] x 1.4m (55.1in) [Depth]
Machine Height: 2.3m (90.5in) (Installed)
Machine Weight: 283kg Approx (Installed)
Power, maximum current: -200w-
Rating: 3.15A @ 230vac

INTRODUCTION
v
Parts replacement, maintenance inspections and troubleshooting should be carried out by site maintenance personnel
or other qualied professionals. This manual includes directions for potentially dangerous procedures which should
only be carried out by professionals with the appropriate specialised knowledge.
The site maintenance personnel or other qualied professionals mentioned in this manual are dened as follows:
Site maintenance personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working under the super-
vision of the owner/operator of this product to maintain machines within amusement facilities or similar premises by
carrying out everyday procedures such as assembly, maintenance inspections, and replacement of units/expendable
parts.
Activities to be carried out by site maintenance personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of units/expendable
parts.
Other qualied professionals:
Persons employed by amusement equipment manufacturers, or involved in design, production, testing or mainte-
nance of amusement equipment. The individual should have either graduated from technical school or hold similar
qualications in electrical/electronics/mechanical engineering.
Activities to be carried out by other qualied professionals:
Amusement equipment/vending machine assembly, repair/adjustment of electrical/electronic/mechanical parts.
Copyright
TMC IOC/TOKYO2020/USOC 36USC220506. © 2019 International Olympic Committee (“IOC”). All rights
reserved. SUPER MARIO Characters © NINTENDO. Trademarks are property of their respective owners.
SONIC THE HEDGEHOG characters © SEGA. SEGA, the SEGA logo and Sonic The Hedgehog are either
registered trademarks or trademarks of SEGA Holdings Co., Ltd. or its aliates.
Denitionof'SiteMaintenencePersonnel’orOtherQualiedIndividualsDenitionof'SiteMaintenencePersonnel’orOtherQualiedIndividuals
Procedures not described in this manual or marked as ‘to be carried out by site
maintenance personnel or other qualied professionals’ should not be carried
out by personnel without the necessary skill or technological experience. Work
carried out by unqualied persons may cause serious accidents, including
electrocution.

vi
INTRODUCTION
WasteofElectricalandElectronicEquipment(WEEE)Statement.WasteofElectricalandElectronicEquipment(WEEE)Statement.
The WEEE (Waste of Electrical and Electronic Equipment) directive places an obligation on all EU based
manufacturers and importers of Electrical and Electronic Equipment (EEE) to ensure waste equipment is disposed of
in accordance with the directive at the end of their useful life.
The symbol shown below will be placed on all products manufactured from 13th August 2005, which indicates this
product must NOT be disposed of with other normal waste. Upon purchasing any EEE from SEGA Amusements
International Ltd. The user accepts responsibility to dispose of their waste equipment by arranging to return it to a
designated UK collection point (AATF) or an Approved Exporter (AE) for the correct recycling of waste electrical
and electronic equipment.
For more information on Approved Authorised Treatment Facilities (AATF) within the UK please consult the
government website www.gov.uk
For users outside of the UK EEE should be disposed of in accordance with the local policy on the recycling of Waste
Electrical and Electronic Equipment.
BatteryRecyclingStatement.BatteryRecyclingStatement.
The EC Directive on Batteries and Accumulators (2006/66/EC) aims to minimise the impact of batteries on
the environment and encourage the recovery of the materials they contain. To achieve increased collection and
recycling of waste batteries, the Directive places ‘producer responsibility’ obligations on manufacturers and
importers of portable, industrial and automotive batteries.
The symbol shown below will be on all equipment tted with batteries from 26th September 2008 and indicates
they must NOT be disposed of with other normal waste. Instead, it is the user’s responsibility to dispose of used
batteries by arranging to return them to a designated collection point for the correct recycling.
For more information about where you can send your waste batteries for recycling contact your local authority
oce.
REGISTERED IN ENGLAND REGISTERED NO. 1711515
REGISTERED OFFICE: BLOCK C 42 BARWELL BUSINESS PARK, CHESSINGTON, SURREY KT9 2NY

1
TABLE OF CONTENTS
INTRODUCTION iii
HANDLING PRECAUTIONS 1
PRECAUTIONS REGARDING INSTALLATION
2-1 Before Operation
2-2 Area of Operation
6
7
PRECAUTIONS REGARDING OPERATION
3-1 Before Operation
3-2 Paying Attention to Customers
9
9
11
PARTS DESCRIPTION 13
ACCESSORIES 14
ASSEMBLY AND INSTALLATION
6-1 Installing the Floor
6-2 Installing the Pipes
6-3 Securing the Floor
6-4 Installing the Billboard and Pop Panel
6-5 Components that Change State Upon Power
6-6 Fixation to Site
6-7 Connection of Power Cables
6-8 Linking Cabinets
6-9 Conrmation of Installation
15
16
18
20
20
22
23
24
26
28
PRECAUTIONS REGARDING MOVING 29
GAME DESCRIPTION
8-1 Game Outline
8-2 Game Flow
32
32
32
TEST AND SERVICE DATA
9-1 SW Unit and Coin Meter
9-2 Game Test Mode
9-3 Bookkeeping
9-4 Input Test
9-5 Output Test
9-6 Game and Coin Assignments
35
36
37
38
40
41
42
MONITOR
10-1 General Description
10-2 Cleaning the Screen
43
43
44
CONTROLLER UNIT
11-1 Removing the Buttons
45
46
COIN HANDLING
12-1 Cleaning the Coin Selector
12-2 Fault Finding
12-3 Adjusting the Price of Play
48
48
51
52
2
10
4
3
6
9
5
7
8
12
11

LAMPS AND LIGHTING
13-1 Coin Door Lamp
13-2 LED Layout
53
53
54
PERIODIC INSPECTION 55
TROUBLESHOOTING
15-1 Troubleshooting (No Error)
58
58
GAME BOARD
16-1 Removing the Game Board
16-2 Composition of the Game Board
16-3 Error Messages
16-4 System Test Mode
60
61
63
64
73
DESIGN RELATED PARTS 79
PARTS LIST 80
COLOUR CODE 105
SCHEMATIC DIAGRAMS 106
15
18
14
17
13
16
19
20

HANDLING PRECAUTIONS
1
11
1HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that
the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary matters
herein stated can cause personal injury or damage to the machine.
Before performing work, be sure to turn the power off. Performing the work
without turning the power off can cause an electric shock or short circuit.
In cases where work should be performed in the status of power on, this
manual always states to that effect.
To avoid an electric shock or short circuit, do not plug in or unplug quickly.
To avoid an electric shock, do not plug in or unplug with a wet hand.
Do not expose power cords or earth wires on the surface, (oor, passage,
etc.) If exposed, the power cords and earth wires are susceptible to
damage. Damaged cords and wires can cause an electric shock or short
circuit.
To avoid causing a fire or an electric shock, do not put things on or
damage the power cords.
When or after installing the product, do not unnecessarily pull the power
cord. If damaged, the power cord can cause a re or an electric shock.
In case the power cord is damaged, ask for a replacement through where
the product was purchased from or the ofce herein stated. Using the cord
as is damaged can cause re, an electric shock or leakage.
This product MUST be Earthed. Inappropriate Earthing can cause an
electric shock.
Be sure to use fuses meeting the specied rating. Using fuses exceeding
the specied rating can cause a re or an electric shock.
Be sure that connections such as IC BD are made properly. Insufficient
insertion can cause an electric shock.
Specication changes, removal of equipment, conversion and/or addition,
not designated by SEGA are not permitted.
Failure to observe this may cause a fire or an electric shock. Non-
compliance with this instruction can have a bad inuence upon physical
conditions of the players or the onlookers, or result in injury during play.
SEGA shall not be held responsible for damage, compensation for damage
to a third party, caused by specication changes not designated by SEGA.
Do not perform any work or change parts not listed in this manual. Doing
so may lead to an accident.
If you need to perform any work not listed in this manual, request work
from the ofce indicated in this manual or the point of purchase, or inquires
for details.
Be sure to perform periodic maintenance inspections herein stated.

2
HANDLING PRECAUTIONS
11
For the IC board circuit inspections, only the use of a logic tester is
recommended. Using a Multi Tester or General Purpose Tester may result in
damage to IC Circuits. Static electricity from your body may damage some
electronics devices on the IC board. Before handling the IC board, touch a
grounded metallic surface so that the static electricity can be discharged.
Some parts are not designed and manufactured specifically for this game
machine. The manufacturers may discontinue, or change the specications of
such general-purpose parts. If this is the case, SEGA cannot repair or replace
a failed game machine whether or not a warranty period has expired.
CONCERNING THE STICKER DISPLAY
This SEGA product has stickers attached describing the product manufacture No. (Serial No.) and Electrical
Specications. It also has a Sticker describing where to contact for repair and for purchasing parts.
When inquiring about or asking for repairs, mention the Serial No. and Name of Machine indicated on the Sticker.
The Serial Number indicates the product register. Identical machines could have dierent parts depending on the
date of production. Also, improvements and modifications might have been made after the publication of this
manual. In order to ensure you order the correct parts, mention the Serial No. when contacting the applicable places.
CONCERNING WARNING DISPLAYS
This SEGA product has warning displays on stickers, labels and/or printed instructions adhered/attached to or
incorporated in the places where a potentially hazardous situation could arise. The warning displays are intended
for accident prevention for customers and for avoiding hazardous situations relating to maintenance and servicing
work. Some portions of the cabinet contain high voltage and may cause accidents if touched. When performing
maintenance, be very careful of the warning displays. It is especially important that any complex repair and
replacement work not mentioned herein should be performed by those technical personnel who have knowledge of
electricity and technical expertise.
In order to prevent accidents, caution any customer ignoring the warnings to cease and desist immediately.
VIDEO GAME-INDUCED SEIZURES (VGS) AND PHOTOSENSETIVE EPILEPSY (PSE)
This SEGA product has warning displays on stickers which outline the risk of epilepticform and photosensetive
seizures. These warning displays on stickers are applied close in proximity of the device which may promote
symptoms of either video game-induced seizures or epilepsy. The warning displays are supplied in several languages
and form part of the Installation kit supllied with this product. It is standard practice for the English version of this
label to be applied during manufacture, however it is especially important for the operator to apply the same said
label in the lanuguage of the country of operation.
