Sega D2 Reference manual

Initial D & Initial D2
All Models
Problem:
Solution: Using the attached instructions, remove the 2ea Allen Bolts, clean
and reinstall using Blue Loctite (242) on the threads. Tighten the
screws. As a precaution, it is recommended to use Loctite on all
screws during reassembly. When the Wheel is re-assembled, be
sure to tighten the M12 Nut to 88 foot pounds (lbf/ft squared).
Torque wrench is advised, and Loctite (242) is to be used.
November, 24 2003
First issued 1/03
If you have any questions or need further assistance, contact your Authorized Sega
Distributor or Sega Technical Services at [phone] M-F 7:30am to 4:00pm PST.
137
Field Service Bulletin
Screws come loose on the stop mechanism of the Steering Assy.
This causes the shaft to rotate unchecked (Steering Wheel will
rotate farther than designed) and can cause damage to other parts
of the assembly. Also, Steering Wheel hub may become damaged
if the M12 nut that secures it comes loose.
Be certain to secure
these screws with
Loctite 242
Top View of Assembly
Screws are beneeth this
plate.
[P 1/6]

Control Panel removal and dissassembly.
A 5 mm allen wrench is required for the following procedure.
Turn off the power.
Remove the 6 allen screws from the Control Panel.
Unplug the 5 connectors and
remove the Control Panel. Be
careful not to damage any of the
wiring.
ALLEN SCREW (total 6), black
CONNECTOR (5)
BROWN: 4P
YELLOW: 10P,12P
RED: 3P,6P
[P 2/6]

remove the 3 screws located here with a 2.5 allen .
then remove the M12 nut securing the steering wheel to
the shaft with a 19mm socket.
Remove the Hardware from the control panel
plate and separate the Steering Handle Assy
from the plate.
[P 3/6]
IMPORTANT !!!!!!
Use Blue Loctite (242) and
secure M12 Steering wheel
nut to 88 lbf/foot pounds
squared upon reassembly !!!

TOOLS NEEDED:
SOCKET WRENCH
13mm SOCKET
10mm SOCKET
2mm Allen Wrench
Remove these 4 13mm bolts to
remove the stopper plate
from the assembly.
Remove these 4 10mm bolts
Slide the front plate off the assembly
and off the shaft. Then remove the
belt from the two pullys of the motor
and the shaft.
Slide the shaft out of the housing
having a care for the volume pot in
the rear. Using a 2mm Allen wrench,
remove the pully from the shaft.
[P 4/6]

These are the two bolts which require Loctite
(242). Reassemble by following these instruc-
tions in reverse having a care for the gold and
black spacers.
CENTERING AND SETTING THE VOLUME FOR THE STEERING ASSEMBLY:
[P 5/6]
Be sure to center the shaft with the cam in the upwards
position and the Stopper dangling downwards.
Cam
Stopper
Key
Left Screw
Then turn the motor until the key points to the left
screw on the motor.
Now to put the belt on at this time allow enough roll
in the pully for the belt to go on over the pully and still
line up.
Check after the belt is on that the shaft is still centered
and the key points to the left screw.

Tighten the 2 screws and secure the VR Base.
After making adjustments, use the Volume Setting Screen to set the Volume. The recommended
value for the handle Volume is "80H" when the handle is set straight.
Verify that the value decreases when the handle is rotated to the left and increases when rotated to the
right. Use the Test Mode to view the Volume value.
Center the Steering Wheel. Loosen the 2 screws that secure the VR Bracket and move the VR
Bracket off the shaft gears to adjust the angle and condition of the gear alignment.
With an Ohm’s meter, measure between the pink and green wires on the 5kΩ pot to a measurement
of 2500Ω.
Twist the bracket back up and allow the teeth to mesh between the gear and the shaft.
[P 6/6]
