SEH Dongleserver myUTN-800 User manual

Quick Installation Guide 1
Monday - Thursday
Friday
8:00 a.m. to 4:45 p.m. and
8:00 a.m. to 3:15 p.m. (CET)
℡[phone]
@[email protected]
USB Dongleserver
myUTN-800
Quick Installation Guide
Overview [en]
This Quick Installation Guide provides
a description of the installation of the
myUTN-800. It contains the following
information:
General Information
Safety Regulations
Hardware Installation
Software Installation
Getting Started
Configuring the UTN Server
Locking the UTN Server
Mounting in a Rack
Please note the table of contents on
page 3. Should you have any further
questions, please contact our support
hotline.
Überblick [de]
Dieser Quick Installation Guide
beinhaltet eine Beschreibung der
Installation des myUTN-800. Sie
erhalten die folgenden Informationen:
Allgemeine Information
Sicherheitsvorschriften
Hardware-Installation
Software-Installation
Erste Schritte
UTN-Server konfigurieren
UTN-Server abschließen
Im Serverschrank einbauen
Beachten Sie das Inhaltsverzeichnis
auf Seite 21. Falls Sie noch Fragen
haben, kontaktieren Sie unsere
Support-Hotline.

2 Quick Installation Guide
Date of Manufacture
The serial number includes the date of manufacture.
The serial number can be found on the type plate.

Quick Installation Guide [en] 3
2 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Scope of Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
LED Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Display panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Hardware Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Getting Started: SEH UTN Manager . . . . . . . . . . . . . . . 10
Starting the SEH UTN Manager . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Assigning an IP Address to the UTN Server . . . . . . . . . . . . . . .12
Adding the UTN Server to the Selection List . . . . . . . . . . . . . .13
Connecting the USB Dongle to the Client. . . . . . . . . . . . . . . . .14
2 Configuring the UTN Server . . . . . . . . . . . . . . . . . . . . . . 15
2 Locking the UTN Server . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2 Mounting the UTN Server in a Rack . . . . . . . . . . . . . . . 17
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Prior to Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Mounting the UTN server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
 Table of Contents

4 [en] Quick Installation Guide
General Information
Purpose
The Dongleserver 'myUTN-800' gives network participants access to USB dongles.
The USB dongles will be connected to the USB ports of the myUTN-800. The
software tool ’SEH UTN Manager’ handles the access to the USB dongles.
The SEH UTN Manager is installed on all clients that are intended to access a USB
dongle in the network. The SEH UTN Manager shows the availability of all UTN
servers in the network and establishes a connection between the client and the
USB port including the connected USB dongle.
The lockable housing cover on the Dongleserver allows for a central and safe
storage of the USB dongles. The myUTN-800 itself can be mounted in a 19"
server rack.
The administration of the myUTN-800 is done via the 'myUTN Control Center'.
Scope of Supply
Please check the package content before getting started:
UTN server Dongleserver 'myUTN-800'
Quick
Installation
Guide
The Quick Installation Guide provides a brief
description of the installation of the myUTN-800.
(This document)
2 Power
cords Power supply cable
2 Mounting
brackets 65.5 mm × 43 mm × 29.8 mm
4 Screws M4 × 4 mm
SD card Inserted into SD card reader.

Quick Installation Guide [en] 5
Technical Data
Properties Values
Network connection logical:
physical: - IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT)
-2×RJ-45
Device connection - 20 × USB 2.0 Hi-Speed
- 1 × SD Card reader
Current input per supply max 1.3 A at 100–240 VAC (with full load on the USB ports)
Operating environment - Ambient temperature: 5–40 °C
- Relative humidity: 20–80 %
Dimensions - Width: 422 mm
- Height: 44 mm
- Depth: 243 mm
- Weight: 2950 g with housing cover, without mounting
brackets
(Suitable for 19" server racks.)
1) Network connector 1
(RJ-45)
2) Network connector 2
(RJ-45)
3) Activity LED (yellow)
4) Status LED (green)
5) Segment display
6) SD card reader
7) Reset button
8) Restart button
9) USB ports 1–20 with
USB port LEDs
10) Power supply 1
11) Hole for the RMK3 cable
fixture
12) Power supply 2

6 [en] Quick Installation Guide
LED Display
The LEDs of the UTN server provide information about its status.
Display panel
The display panel on the front of the UTN server provides status information.
LED Action Color Description
Activity permanently off -If the status LED blinks periodically at the
same time, the BIOS mode is signalized.
Status permanently off
blinks 3 times
blinks 2 times
-
green
green
If the activity LED blinks periodically at the
same time, the BIOS mode is signalized.
Indicates the assignment of a ZeroConfig IP
address.
Indicates the assignment of an IP address
that does not correspond to 0.0.0.0 or that
comes from outside the ZeroConf range.
USB ports 1–20 permanently off
permanently on
permanently on
-
green
orange
No USB dongle is connected to the
respective port.
A USB dongle is connected to the respective
port.
The connection to the respective port and
the attached USB dongle is activated.
Text Description
DS (Identifier)
The Dongleserver is ready to operate.
E1 One of the two power supplies is not working.
Which connection is not working is indicated by a glowing dot (left dot,
left power supply; right dot, right power supply).
E2 The SD card is formatted with an unsupported file system respectively
cannot be read and be written to.
E3 The SD card is read-only.
E4 No SD card is available in the card reader.

Quick Installation Guide [en] 7
Safety Regulations
UTN servers are network devices for use in office environments. The myUTN-800
is designed for the integration of USB dongles into TCP/IP networks.
Before starting the initial setup procedure and during the operation of the UTN
server, please note the following safety regulations. Their purpose is to protect
yourself and others from personal injuries, and avoid damage to the equipment.
Read the documentation and make sure that your system meets the
requirements listed therein.
The device must only be connected to the mains and to the network by
qualified personnel.
Avoid contact with humidity or liquids.
The device must only be connected and operated if it is in perfect condition.
Make sure that no-one steps on or stumbles over the cables.
If the supplied power cords cannot be used in your country, acquire two
appropriate power cords that suit national provisions. For more information,
please consult your retailer.
The device must be connected to two sockets with safety contact.
Position the device in a way that guarantees that the two sockets for the
connection of the power cords are in the proximity of the device and are easily
accessible. Make sure that the device can be separated easily from the mains. A
damaged power cord must be replaced immediately. For more information,
please consult your retailer.
To disconnect the device from the mains, both power cords must be separated
from the device.
Do not connect telephone cables to the RJ-45 connectors. The RJ-45
connectors may only be connected to SELV voltages. For the connection to the
RJ-45 connectors only STP cabling (category 5 or better) may be used. The
shielding must fit flushly to the connectors.
Do not open the housing. Unauthorized modifications to the device can affect
the product certification and are forbidden.

8 [en] Quick Installation Guide
Hardware Installation
You can directly connect up to twenty USB dongles to the UTN server (myUTN-
800).
Do not remove the SD card from the UTN server.
Upon delivery, the SD card is already inserted into the SD card reader and ready
for use (installation or formatting are not required).
network
clients with the software tool 'SEH UTN Manager'
myUTN-800
dongles
USB 2.0
Hi-Speed
Proceed as follows:
1. Connect the USB dongle to a USB port of the UTN server.
(Repeat this step if you want to connect more than one USB
dongle.)
2. Connect the two network cables (RJ-45) to the UTN server.
3. Connect the two power cords to the UTN server.

Quick Installation Guide [en] 9
Software Installation
The software tool SEH UTN Manager handles the access to the USB dongles. The
SEH UTN Manager is available in two versions:
Complete version
Minimal version (only command-line interface)
The complete version has a graphical user interface and offers additional
features. A detailed description can be found in the myUTN User Manual.
The SEH UTN Manager is installed on all clients that are intended to access a USB
dongle in the network. Different installation files are available, depending on the
operating system.
First, you have to download the installation file for the SEH UTN Manager from
the homepage of SEH Computertechnik GmbH:
http://www.seh-technology.com/products/usb-device-servers/products/
myutn-800-downloads.html
Scan this QR code using your smart phone to get direct access to the homepage.
System requirements:
- Windows XP or later;
Mac OS X 10.6.x, Mac OS X 10.7.x (64-bit), OS X 10.8.x, OS X 10.9.x
- The installation can only be carried out by users with administrative rights.
Proceed as follows:
1. Start the installation file.
2. Install the complete version of the SEH UTN Manager (including graphical
user interface). Follow the installation routine.
The SEH UTN Manager is installed on your client.

10 [en] Quick Installation Guide
Getting Started: SEH UTN Manager
After the SEH UTN Manager is started, the network will be scanned for connected
UTN servers. The network range to be scanned is freely definable.
All UTN servers found will be shown in the 'network list' together with the
connected USB dongles. The required UTN servers will be selected and added to
the 'selection list'. The UTN servers listed in the selection list and the connected
USB dongles can then be used by the user.
This chapter describes the first steps with the program.
’Starting the SEH UTN Manager’ 11
’Assigning an IP Address to the UTN Server’ 12
’Adding the UTN Server to the Selection List’ 13
’Connecting the USB Dongle to the Client’ 14
Client and UTN server communicate via the UTN port 9200. This port must not be
blocked by a firewall. If necessary, you can change the port number and use a
secure UTN SSL port. A detailed description can be found in the myUTN User Manual.
Detailed information on how to use the SEH UTN Manager can
be found in the Online Help. To start the Online Help, select
Help – Online Help from the menu bar.


Quick Installation Guide [en] 11
Starting the SEH UTN Manager
Windows
Start the SEH UTN Manager on your client via the Windows start menu.
(Start J All Programs J SEH Computertechnik GmbH J SEH UTN Manager)
In some cases the Windows user account control requires a confirmation if the
SEH UTN Manager is to be run.
Mac
To start the program, double-click the 'SEH UTN Manager.app' file.
(Applications JSEH UTN Manager.app)
During the initial configuration, client and UTN server must be assigned to the
same local network segment.

12 [en] Quick Installation Guide
Assigning an IP Address to the UTN Server
Once the UTN server is connected to the network, it checks whether an IP address
can be obtained from the boot protocols BOOTP or DHCP. If this is not the case,
the UTN server assigns itself an IP address via ZeroConf from the address range
(169.254.0.0/16) which is reserved for ZeroConf.
The UTN servers found by the program will be displayed in the network list. You
can change the TCP/IP parameters of the UTN server.
Proceed as follows:
1. Confirm the note dialog 'Your Selection List seems to be empty' by clicking
Yes.
If no note dialog is available and the main dialog appears, select Selection List – Edit
from the menu bar.
The Edit Selection List dialog appears.
2. Select the UTN server from the network list.
3. Select Set IP Address from the shortcut menu.
The Set IP Address dialog appears.
4. Enter the relevant TCP/IP parameters.
5. Click OK.
The settings are saved.

Quick Installation Guide [en] 13
Adding the UTN Server to the Selection List
The selection list displays the UTN servers and the USB dongles connected to their
USB ports.
Define the devices you want to use. To do this, you must add the UTN server (and
the connected USB dongles) shown in the network list to the selection list.
Proceed as follows:
1. Select Selection List – Edit from the menu bar.
The Edit Selection List dialog appears.
2. Select the UTN server from the network list.
3. Click Add.
(Repeat steps 2 and 3, if necessary.)
4. Click OK.
The UTN servers are shown in the selection list.
You can extend the search for UTN servers to any network range. To do this,
change the search parameters for the network scan.
Windows: via the Options dialog in the Program menu.
Mac: via the Preferences dialog in the SEH UTN Manager menu.

14 [en] Quick Installation Guide
Connecting the USB Dongle to the Client
To use a USB dongle, a connection is established between the client and the USB
port of the UTN server to which the USB dongle is connected.
Make sure that:
- All provisions (driver installation, etc.) necessary to operate the USB dongle
locally (i.e. connected directly to the client) should have been met on the
client. Ideally, the USB dongle has been connected and operated on the client
locally according to the instructions of the manufacturer.
- The USB port is not connected to another client. A USB dongle that was
made available by the UTN server can only be used by one network
participant at a time.
Proceed as follows:
1. Select the port from the selection list.
2. Select Port – Activate from the menu bar.
The connection will be established.
Close the connection to the USB port when the connected USB dongle is no
longer needed. Select Port – Deactivate from the menu bar.

Quick Installation Guide [en] 15
Configuring the UTN Server
The UTN server can be configured and monitored via the myUTN Control Center.
The myUTN Control Center is stored in the UTN server and can be launched by
means of a browser (Internet Explorer, Firefox, Safari).
Proceed as follows:
1. Open your browser.
2. Enter the IP address of the UTN server as the URL.
The myUTN Control Center appears in the browser.
If the myUTN Control Center is not displayed, check the proxy settings of your browser.
Detailed information about the configuration of the UTN server
can be found in the Online Help of the myUTN Control Center.
To start the Online Help, click the '?' icon.


16 [en] Quick Installation Guide
Locking the UTN Server
The lockable housing cover on the dongle server allows for a central and safe
storage of the connected USB dongles.
To close the cover, insert the three straps of the housing cover into the notches
of the housing. Use the key provided to activate the locking mechanism.

Quick Installation Guide [en] 17
Mounting the UTN Server in a Rack
For a perfect and safe storage of the UTN server, we recommend installing it in a
19" server rack.
You can mount the UTN server myUTN-800 in a 19" server rack with the two
mounting brackets included in delivery. For a more comfortable handling, we
recommend the Rack Mount Kit 3 (RMK3). It contains telescopic rails and
accessories for mounting the myUTN-800 in a 19" server rack. The RMK3 is
available as an accessory:
http://www.seh-technology.com/products/rackmount-kits.html
Scan this QR code using your smart phone to get direct access to the homepage.
Mounting the UTN server in a 19" server rack using the mounting
brackets included in delivery must only be done in the way described in
this document.
Tools Required:
2 mounting brackets (included in delivery)
4 screws (M4 × 4 mm) (included in delivery)
Slotted screwdriver
Phillips screwdriver
Fasteners for mounting the UTN server in the server rack (not included in
delivery)

18 [en] Quick Installation Guide
Prior to Mounting:
Proceed as follows:
1. Read and observe the safety regulations about the UTN server (7) and
server rack.
2. Check the size and settings of your rack unit and compare the data with
those of the mounting brackets.
3. Remove both power cords from the UTN server (interrupt the power supply).
4. Remove both network cables (RJ-45) from the UTN server.
5. Place the UTN server upside down on a solid surface.
6. Remove all rubber feet of the UTN server: Remove the pin from each rubber
foot using a small slotted screwdriver. The rubber foot detaches
automatically.
(Please keep the pins and rubber feet in a safe place for potential future use.)
7. Turn the myUTN-800 around again.
Mounting the UTN server:
Proceed as follows:
1. Place the UTN server on a solid surface.
2. Hold one mounting bracket to the side of the UTN server in such a way that
the two holes in the mounting bracket align with the holes in the UTN
server. The short mounting bracket wing faces away from the UTN server.
3. Fasten the mounting bracket to the UTN server by inserting and tightening
two provided screws (M4 × 4 mm) in the holes of the UTN server.
4. Repeat steps 2 and 3 on the opposite side of the UTN server.
5. Install the UTN server in the server rack. To do this, fasten the mounting
brackets of the UTN server to the server rack posts.
6. Connect the network cables (RJ-45) to the UTN server.
7. Connect the power cords to the UTN server (establish the power supplies).

Quick Installation Guide [en] 19

20 [en] Quick Installation Guide
