General Information
Purpose
The USB Deviceserver 'myUTN-50a' allows you to access non-network-ready
USB devices (e.g. hard disks, etc.) in the network. For this purpose, the USB
devices will be connected to the USB ports of the myUTN-50a. The software tool
'SEH UTN Manager' handles the access of the USB devices.
The SEH UTN Manager is installed on all clients that are intended to access a USB
device in the network. The SEH UTN Manager shows the availability of all UTN
servers in the network and establishes a connection between the client and the
USB port including the connected USB device.
The administration of the myUTN-50a is done via the 'myUTN Control Center'.
Scope of Supply
Check the package content before getting started:
UTN server USB Deviceserver 'myUTN-50a'
Quick
Installation
Guide
The Quick Installation Guide provides a brief
description of the installation of the myUTN-50a.
(This document)
Power pack External power pack

3 [de] Quick Installation Guide
Technical Data
Properties Values
Network connectorlogical:
physical: IEEE 802.3 (1000BaseT, 100BaseTX and 10BaseT) 2 × RJ-45 (STP Cat. 5)
Device connection 2 × USB 2.0 Hi-Speed
Current Input • 360 mA at 5 VDC without Load
• 1800 mA at 5 VDC with full load on the USB ports
Power consumption • approx. 3 W without load
• approx. 8 W with full load on the USB ports
• typ. approx. 26 kWh/year
Operating environment ambient temperature: 5–40 °C
relative humidity: 20–80%
Dimensions width: 98 mm
height: 31 mm
depth: 81 mm
weight: 100 g
link LED
(green)
activity LED
(yellow)
USB ports 1–2
status LED
(green)
connector for the
included power pack
reset button
Kensington security slot
network connector

Quick Installation Guide [de] 4
LED Display
The LEDs of the UTN server provide information about its status.
Type Plate
The type plate gives important product information, such as hardware and
certification information as well as the serial number. The serial number
contains the production date: nnn YYYY MM nnnnn.
This information helps you e.g. during maintenance and is needed for support
requests as well as for the guarantee extension.
LED Action Color Description
Link permanently on
permanently off
green
–
There is a connection to the network.
There is no connection to the network.
Activity blinks at
irregular
intervals
yellow Indicates the exchange of network
data packets.
Status permanently off
blinks 3 times
blinks 2 times
–
green
green
If the activity LED blinks periodically at
the same time, the BIOS mode is
signalized.
Indicates the assignment of a Zeroconf
IP address.
Indicates the assignment of an IP
address that does not correspond to
0.0.0.0 or that comes from outside the
Zeroconf range.
Important:
During the activation procedure, the behavior of the
LEDs differs from this description.

5 [de] Quick Installation Guide
Safety Regulations
UTN servers are network devices for use in office environments. The myUTN-50a
is designed for the integration of USB devices into TCP/IP networks.
• Read the documentation and make sure that your system meets the require-
ments listed therein.
• Avoid contact with humidity or liquids.
• The device must only be connected and operated if it is in perfect condition.
• Make sure that no-one steps on or stumbles over the cables.
• If the supplied power cord cannot be used in your country, acquire an appro-
priate power cord that suits national provisions. For more information, con-
sult your retailer.
• Do not connect a telephone cable to the RJ-45 connector. The RJ-45 connec-
tor may only be connected to SELV voltages. For the connection to the RJ-45
connector only STP cabling (category 5 or better) may be used. The shielding
must fit flushly to the connector.
• Do not open the housing. Unauthorized modifications to the device can af-
fect the product certification and are forbidden.
• The device must not be directly connected to outdoor lines.
• The device must only be operated using the power pack included in the
package.
• Only use a certified USB cable (< 3 m) listed at www.usb.org.
• Electrostatic discharges (ESD) may impair device performance.
• An interruption of the supply voltage may impair device performance or
cause malfunctions.
Important:
Before starting the installation and the initial setup
procedure as well during the operation of the UTN
server, note the following safety regulations. Their
purpose is to protect yourself and others from personal
injuries, and to avoid damage to the equipment.

Quick Installation Guide [de] 6
Hardware Installation
You can directly connect up to two USB devices to the myUTN-50a.
1. Connect the USB device to a USB port of the UTN server.
2. Repeat step 1 if you want to connect more than one USB device.
3. Connect the network cable (RJ-45) to the UTN server.
4. Connect the power cord to the UTN server.
The UTN server boots and then is ready for use.
Important:
USB device and UTN server can be connected via a USB
cable, if required.
Only use USB cables shorter than 3 meters.
USB devices
myUTN-50a
network
clients with software tool
'SEH UTN Manager'
USB 2.0

7 [de] Quick Installation Guide
Software Installation
The software tool ’SEH UTN Manager’ organizes the access of the USB devices.
The SEH UTN Manager is available in two versions:
•Completeversion
• Minimal version (only command-line interface)
The complete version has a graphical user interface and offers additional
features. A detailed description can be found in the myUTN User Manual.
The SEH UTN Manager is installed on all clients that are intended to access a USB
device in the network. Different installation files are available, depending on the
operating system.
First, you have to download the installation file for the SEH UTN Manager from
the website of SEH Computertechnik GmbH:
http://www.seh-technology.com/services/downloads/
download-deviceserver/myutn-50a.html
System requirements:
– Windows: XP or higher except for Windows Vista and Windows Server 20081;
OS X 10.8.x, OS X 10.9.x, OS X 10.10.x, OS X 10.11.2 and later2, or OS X 10.12.x
and later3
– The installation can only be carried out by users with administrative rights.
1. Start the installation file.
2. Install the complete version of the SEH UTN Manager (including graphical
user interface). To do so, follow the installation routine.
The SEH UTN Manager is installed on your client.
1. Windows 7 and Windows Server 2008 R2: KB3033929 (https://technet.microsoft.com/en-us/li-
brary/security/3033929) must be installed.
2. OS X 10.11.2 and later: limited USB device support
3. macOS 10.12.x and later: limited USB device support
Important:
The SEH UTN Manager is also available for selected
Linux systems.
All information necessary for installing and using the
SEH UTN Manager in Linux environments can be found
in the myUTN User Manual Linux. The documentation is
available via the link given above.

Quick Installation Guide [de] 8
Getting Started: SEH UTN Manager
After the SEH UTN Manager is started, the network will be scanned for
connected UTN servers. The network range to be scanned is freely definable.
All UTN servers found will be shown in the 'network list' together with the
connected USB devices. The required UTN servers will be selected and added to
the 'selection list'. The UTN servers listed in the selection list and the connected
USB devices can then be used by the user.
This chapter describes the first steps with the program.
• ’Starting the SEH UTN Manager’ 9
• ’Assigning an IP Address to the UTN Server’ 10
• ’Adding the UTN Server to the Selection List’ 11
• ’Connecting the USB Device to the Client’ 12
Detailed information on how to use the SEH UTN Manager can
be found in the Online Help. To start the online help, go to the
menu bar and select Help – Online Help.
Important:
Client and UTN server communicate via the UTN port
9200. This port must not be blocked by a security
software (firewall). If necessary, you can change the port
number and use a secure UTN SSL port. A detailed
description can be found in the myUTN User Manual.

9 [de] Quick Installation Guide
Starting the SEH UTN Manager
Windows
Start the SEH UTN Manager on your client via the Windows start menu.
(Start All apps SEH Computertechnik GmbH SEH UTN Manager)
Mac
To start the program, double-click the 'SEH UTN Manager.app' file.
(Applications SEH UTN Manager.app)
Important:
During the initial configuration, client and UTN server
must be assigned to the same local network segment.

Quick Installation Guide [de] 10
Assigning an IP Address to the UTN Server
Once the UTN server is connected to the network, it checks whether an IP
address can be obtained from the boot protocols BOOTP or DHCP. If this is not
the case, the UTN server assigns itself an IP address via Zeroconf from the
address range reserved for Zeroconf (169.254.0.0/16).
The UTN servers found by the program will be displayed in the network list. You
can change the TCP/IP parameters of the UTN server.
1. Confirm the note dialog Your Selection List seems to be empty with Yes.
If the note dialog is not available and the main dialog appears instead, select Selection List Edit
in the menu bar.
The Edit Selection List dialog appears.
2. In the network list, select the UTN server.
3. In the shortcut menu, select Set IP Address.
The Set IP Address dialog appears.
4. Enter the relevant TCP/IP parameters.
5. Click OK.
The settings will be saved.

11 [de] Quick Installation Guide
Adding the UTN Server to the Selection List
The selection list displays the UTN servers and the USB devices connected to
their USB ports.
Define the devices you want to use. To do this, you must add the UTN server
(and the connected USB devices) shown in the network list to the selection list.
1. In the menu bar, select Selection List – Edit.
The Edit Selection List dialog appears.
2. In the network list, select the UTN server.
3. Click Add.
4. Repeat steps 2 to 3, if necessary.
5. Click OK.
The UTN servers are shown in the selection list.
You can extend the search for UTN servers to any network
range. To do this, change the search parameters for the net-
work scan.
Windows: Via Program – Options.
Mac: Via SEH UTN Manager – Preferences.

Quick Installation Guide [de] 12
Connecting the USB Device to the Client
To use a USB device, a connection is established between the client and the USB
port of the UTN server to which the USB device is connected.
All provisions (driver installation, etc.) necessary to operate the USB device
locally (i.e. connected directly to the client) have been met on the client. Ide-
ally, the USB device has been connected and operated on the client locally
according to the instructions of the manufacturer.
The USB port is not connected to another client. A USB device that was made
available by the UTN server can only be used by one network participant at a
time.
1. In the selection list, select the port.
2. From the menu bar, select Port – Activate.
The connection will be established.
Important:
Close the connection to the USB port when you no
longer need the attached USB device. To do this, select
Port – Deactivate from the menu bar.

13 [de] Quick Installation Guide
Configuring the UTN Server
The UTN server can be configured and monitored via the ‘myUTN Control
Center‘. The myUTN Control Center is stored in the UTN server and can be
launched by means of a browser (Microsoft Edge, Firefox, Safari).
1. Open your browser.
2. Enter the IP address of the UTN server as the URL.
The myUTN Control Center appears in the browser.
If the myUTN Control Center is not displayed, check the proxy settings of your browser.
Detailed information about the configuration of the UTN
server can be found in the Online Help of the myUTN Control
Center.
To start the Online Help, click the '?' icon.

Quick Installation Guide [de] 14
Inhaltsverzeichnis
Allgemeine Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Verwendungszweck ...........................................................................................................15
Lieferumfang.........................................................................................................................15
Technische Daten ................................................................................................................16
LED-Anzeige..........................................................................................................................17
Typenschild............................................................................................................................17
Sicherheitsvorschriften . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Hardware-Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Software-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Erste Schritte mit dem SEH UTN Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SEH UTN Manager starten................................................................................................22
UTN-Server eine IP-Adresse zuweisen .........................................................................23
UTN-Server der Auswahlliste hinzufügen...................................................................24
USB-Gerät mit Client verbinden.....................................................................................25
UTN-Server konfigurieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Regulatory Compliance Information (Konformitätserklärungen) . . . . . . . .27

15 [de] Quick Installation Guide
Allgemeine Information
Verwendungszweck
Der USB Deviceserver 'myUTN-50a' erlaubt das Bereitstellen von nicht-
netzwerkfähigen USB-Geräten (z.B. Festplatten usw.) für mehrere
Netzwerkteilnehmer. Dazu werden die USB-Geräte an die USB-Ports des
myUTN-50a angeschlossen. Die Zugriffsverteilung der USB-Geräte erfolgt über
das Software-Tool 'SEH UTN Manager'.
Der SEH UTN Manager wird auf allen Clients installiert, die auf ein im Netzwerk
bereitgestelltes USB-Gerät zugreifen sollen. Der SEH UTN Manager zeigt die
Verfügbarkeit aller im Netzwerk eingebundenen UTN-Server an und stellt die
Verbindung zwischen Client und USB-Port inklusive dem daran
angeschlossenen USB-Gerät her.
Die Verwaltung des myUTN-50a erfolgt über das 'myUTN Control Center'.
Lieferumfang
Überprüfen Sie den Packungsinhalt auf Vollständigkeit, bevor Sie die
Installation beginnen:
UTN-Server USB Deviceserver 'myUTN-50a'
Quick
Installation
Guide
Der Quick Installation Guide beinhaltet eine kurze
Beschreibung der Installation des myUTN-50a.
(Dieses Dokument)
Netzteil Externes Netzteil

Quick Installation Guide [de] 16
Technische Daten
Eigenschaften Werte
Netzwerkanschluss
Logisch:
Physisch: IEEE 802.3 (1000BaseT, 100BaseTX und 10BaseT) 2 × RJ-45 (STP Cat. 5)
Geräteanschluss 2 × USB 2.0 Hi-Speed
Stromaufnahme • 360 mA bei 5 V Gleichspannung ohne Last
• 1800 mA bei 5 V Gleichspannung bei Vollast auf
den USB-Ports
Leistungsaufnahme • max. ca. 3 W ohne Last
• max. ca. 8 W bei Volllast auf den USB-Ports
• typ. ca. 26 kWh/Jahr
Betriebsumgebung Umgebungstemperatur: 5–40 °C
Relative Luftfeuchtigkeit: 20–80%
Abmessungen Breite: 98 mm
Höhe: 31 mm
Tiefe: 81 mm
Gewicht: 100 g
Link-LED
(grün)
Activity-LED
(gelb)
USB-Ports 1–2
Status-LED
(grün)
Anschluss für die
Stromversorgung über
das mitgelieferte Netzteil
Reset-Taster
Schlitz für Kensington-
Verriegelung
Netzwerkanschluss

17 [de] Quick Installation Guide
LED-Anzeige
Durch die Interpretation des LED-Leuchtverhaltens kann der Zustand des UTN-
Servers ermittelt werden.
Typenschild
Auf dem Typenschild finden Sie wichtige Angaben zu Ihrem Produkt, wie z.B.
Informationen zur Hardware und zu Zertifizierungen sowie die Seriennummer.
Die Seriennummer enthält das Produktionsdatum: nnn YYYY MM nnnnn.
Diese Angaben helfen Ihnen z.B. bei der Wartung und Sie benötigen sie für
Support-Anfragen sowie für die Garantieverlängerung.
LED Aktion Farbe Beschreibung
Link Dauer-An
Dauer-Aus
grün
–
Eine Verbindung zum Netzwerk ist
vorhanden.
Es besteht keine Verbindung zum
Netzwerk.
Activity unregelmäßiges
Blinken gelb Signalisiert den Austausch von Netzwerk-Datenpaketen.
Status Dauer-Aus
3 x Blinken
2 x Blinken
–
grün
grün
Bei gleichzeitigem zyklischen Blinken
der Activity-LED wird der BIOS-Modus
signalisiert.
Signalisiert die Vergabe einer Zeroconf-
IP-Adresse.
Signalisiert die Vergabe einer IP-
Adresse, die nicht 0.0.0.0 entspricht
oder aus dem Bereich Zeroconf kommt.
Wichtig:
Während des Einschaltvorgangs weicht das LED-
Leuchtverhalten von der Beschreibung ab.
