SelectBlinds CORDLESS Installation guide

CORDLESS
Installation & Care Instructions 152740
1/9/2018
Roller Shades

1
A few simple tools are required:
- Measuring tape
- Power drill, drill bits
-
1⁄4” Hex head and/or Phillips driver bit
- Pencil
GETTING STARTED
Additional fasteners other than those sent with your shade may be required
depending on the mounting surface. Wallboard and plaster require the use of
anchors such as expansion or toggle bolts. Brick, tile or stone need special plugs
and drill bits. Remember to always pre-drill holes in wood to avoid splitting.
1 1⁄4”
Hex Head
Bracket
Screw
Spacer
Block
(optional)
Le Mounting
Bracket
PN: CSRD1000W PN: 20201012 PN: CS2000
Right Mounting
Bracket with Insert
PN: CSRD1001W

2
STEP 1: BRACKET INSTALLATION
To determine bracket placement measure the length of the fascia or add 3⁄4” to
the fabric width.
Using the installation bracket as a template, measure to the edge of the bracket
and mark the hole locations with a pencil for drilling.
Brackets must be in line and level. Shim brackets on inside mounts if necessary.
e head rail must be level for the shade to operate properly.
INSIDE MOUNT
e minimum mounting depth for an
inside mount is 1”.
A minimum of 2 1⁄4”is needed to fully
recess the shade.
Make sure the brackets are level and
aligned.
Attach using two screws when possible.
You may only be able to use one screw
through the back hole on shallow
mount applications.
Inside Mount
Shallow Mount - Minimum 1” surface
Flush Mount - Minimum 2 1⁄4” surface
Fascia width
or
Fabric width plus 3/4”

3
OUTSIDE MOUNT
e minimum mounting height for
outside mounted shades is 2”.
Make sure the brackets are level and
aligned.
Attach each bracket using two screws. Outside Mount
Minimum 2” surface
SPACER BLOCKS
(OPTIONAL)
Each spacer block projects brackets 3⁄8”
away from mounting surface.
Make sure the brackets are level and
aligned.
Attach each bracket using two screws.
Screws should be long enough to secure
the bracket to the mounting surface.
Outside Mount
with Spacer Blocks
Additional 3⁄8” projection

STEP 2: SHADE INSTALLATION
With the fabric fully rolled up on the tube,
push the le end of the roller tube onto
the post on the le endcap.
Be sure the cross shapes are lined up.
Align the tabs on the bracket insert with
the slots in the end of the roller tube.
Insert the post of the right bracket insert
into the right end of the roller tube.
Next, slide the right bracket insert up into
the right bracket until it snaps into place.
1
2

5
OPERATION
To lower the shade simply pull down on the bottom rail, stopping when you’ve
reached the desired level.
To raise the shade, gently pull down on the bottom rail and release. e shade
will automatically retract.
UPSTOP ADJUSTMENT (IF NECESSARY)
Retract the shade and let it stop at the top. If you do not like where the upstop is
set, it can be adjusted by removing the shade, rolling the fabric up by hand and
reinstalling the shade.
To remove the shade, press the tab on the bottom of the right bracket toward the
center of the shade (1).
Slide the right bracket insert down out of the right bracket (2). e le end of
the shade can now be removed from the le bracket (3).
1
2
3

6
SKEW ADJUSTMENT (IF NECESSARY)
If the shade does not raise evenly, rst make sure the mounting brackets are
mounted level with each other.
If the shade is level and it still skews, operate the shade to the full down position.
Prepare a strip of masking tape approximately 5” long. On the side of the shade
opposite of the skewing direction, and as close to the end of the roller as possible,
li the fabric toward the back of the shade using your ngers and slide the tape
with the sticky side facing the roller up as far as possible. e tape should be
running parallel to the roller.
Roll the shade up and check for skewing. If the shade is still skewing, add
another strip of tape on top of the rst one. If the shade is now skewing in the
opposite direction, tear o about 1” of tape from the last strip installed. Tear the
tape o the end closest to the center of the shade.
Place tape at this end
SHADE REMOVAL
To remove the shade, press the tab on the bottom of the right bracket toward the
center of the shade (1).
Slide the right bracket insert down out of the right bracket (2). e le end of
the shade can now be removed from the le bracket (3).
1
2
3

7
CLEANING AND CARE
e shade fabric is easy to care for. Regular dusting with a feather duster or
vacuum cleaner brush is recommended. Most stains can be blotted with a damp
sponge and mild detergent. Before using anything stronger than mild detergent
and lukewarm water, test an unobtrusive corner of the shade. If you have any
questions, call your dealer for advice.

CORD LOOP
Head Rail, Fascia and No Head Rail
Installation & Care Instructions 152038 H
5/30/2017
Roller Shades

1
A few simple tools are required:
- Measuring tape
- Power drill, drill bits
-
1⁄4”Hex head and/or Phillips driver bit
- Pencil
GETTING STARTED
1 1⁄4”
Hex Head
Bracket
Screw
Head Rail
Extension
and Side
Mount Bracket
(optional)
Spacer
Block
(optional)
Additional fasteners other than those
sent with your shade may be required
depending on the mounting surface.
Wallboard and plaster require the
use of anchors such as expansion
or toggle bolts. Brick, tile or stone
need special plugs and drill bits.
Remember to always pre-drill holes
in wood to avoid splitting.
Mounting
Brackets for
Shades with
Head Rail
Hold
Down
Bracket
(optional)
STEP 1: BRACKET INSTALLATION
PN: CS5402 PN: 20201012 PN: CS1000 PN: CS2000
Shades are shipped with the required number of brackets
for proper installation. End brackets should be located
approximately 3” from either end. Depending on the width of
the shade, additional brackets may be necessary, evenly spaced
between the two end brackets.
Using the installation bracket as a template, measure to the
edge of the bracket and mark the hole locations with a pencil
for drilling.
Brackets must be in line and level. Shim brackets on inside
mounts if necessary. e head rail must be level for the shade
to operate properly.
Shade Width # of Brackets
Up to 40” 2
>40” - 72” 3
>72”- 84” 4
>84” and up 5
INSIDE MOUNT
e minimum mounting depth for an inside mount is 1”.
A minimum of 3 3⁄4”is needed to fully recess the shade.
Make sure the brackets are level and aligned.
Attach using two screws. Inside Mount
Shallow Mount - Minimum 1”surface
Flush Mount - Minimum 3 3⁄4”surface
1”
Mounting
Brackets for
Shades without
Head Rail
PN: CS1101
PN: CS5002(W or BLK)
CS5008 (W or BLK)
CS5529
CS5530
Depends on size of
shade
SHADES WITH HEAD RAIL
PN: CS563x (3”)
CS557x (3”)
CS561x (4”)
Depends on size of
shade
Mounting
Brackets for
Shades with
Fascia

2
EXTENSION BRACKETS (OPTIONAL)
Optional extension brackets are used to project the back of the
shade up to 2 1⁄2”from the mounting surface.
Attach the mounting bracket to the extension bracket with the
nut and bolt provided.
SIDE MOUNT (OPTIONAL)
Measure from window sill up to desired mounting position on
each side of the window frame. Mark position.
Mount side mount brackets on each side of window frame as
shown. Make sure to conrm the head rail will sit perfectly
level.
Once side mount brackets are installed and properly
positioned, attach the mounting brackets using the nuts and
bolts provided.
Side Mount
Minimum 2” surface height
Minimum 1 1⁄8” surface depth
Outside Mount with Extension Brackets
Minimum 2” surface
SPACER BLOCKS (OPTIONAL)
Each spacer block projects brackets 3⁄8”away from mounting
surface.
Make sure the brackets are level and aligned.
Attach each bracket using two screws. Screws should be long
enough to secure the bracket to the mounting surface.
Outside Mount with Spacer Blocks
2”
2 1⁄2”
OUTSIDE MOUNT
e minimum mounting height for outside mounted shades is
1”.
Make sure the brackets are level and aligned.
Attach each bracket using two screws. Outside Mount
Minimum 1” surface
1”
2”
1 1⁄8”

3
End Plug
Side
Foot
T-Hook
e installation brackets are always mounted so that the inner
surfaces face each other.
Brackets must be in line and level. Shim brackets on inside
mounts if necessary. e head rail must be level for the shade
to operate properly.
SHADES WITH FASCIA OR NO HEAD RAIL
Inside Mount
Minimum 1 1⁄2” surface
Outside Mount
Minimum 1 1⁄2” surface
1 1⁄2”
INSIDE MOUNT
A deduction has been made on your inside mount shade
to make sure that there is enough clearance to t inside the
window opening. In most cases the brackets will need to be
placed approximately 1⁄16” in from the window casing. Make
sure that the brackets are placed so that the shade is securely
engaged with the tabs on the brackets.
OUTSIDE MOUNT
Outside mount brackets should be installed so that the
measurement from the outside of the le bracket to the outside
of the right bracket is the ordered shade width plus 3⁄16”
Make sure the brackets are level and aligned.
Attach each bracket using two screws.
EXTENSION BRACKETS (OPTIONAL)
Optional extension roller brackets are used to provide
additional clearance.
Mount in the same manner as above.
SIDE MOUNT/EXACT (OPTIONAL)
Use this method only if shade was ordered as a side mount/
exact.
Side Mount
Control Side
T-Hook
End Plug
Side Control Side
1⁄16”1⁄16”

4
STEP 2: SHADE INSTALLATION
Push the rail back until it
is fully engaged
Center the shade in the window opening and push the head rail
into the mounting brackets as shown.
Once the brackets are secured and level, the fabric roll can be
inserted. Make sure your hands are clean to avoid soiling the
fabric.
While facing the inside of the shade, be sure the clutch and
roller end plug are inserted into the roller. Hold the shade with
the bottom of the clutch facing the oor, and the beaded cord
hanging straight down. Be sure the shade is fully rolled on the
tube.
Insert the foot of the control-side bracket into the slotted
center hole of the clutch. Set the post of the end plug into the
V of the support bracket. Rotate the T-hook on the support
bracket to lock in the post and secure the fabric roll.
Fig.15
End Plug
Post
V slot
SHADES WITH HEAD RAIL
SHADES WITH FASCIA OR NO HEAD RAIL
Bracket
No head rail bracket pictured
STEP 3: FASCIA INSTALLATION (IF ORDERED)
Attach the fascia by rst hooking the top lip of the fascia panel
onto the bracket as shown.
Swing the bottom of the fascia panel towards the bracket and
gently press at the bottom of the panel until the lip on the fascia
engages and snaps lock to the bracket.

5
OPERATION
CHILD SAFETY - INSTALL TENSION DEVICE
WARNING To avoid entanglement and strangulation, keep cords out of reach of young
children. Move cribs and furniture away from shade cords.
TENSION DEVICE
e tension device reduces the hazards of strangulation and entanglement of young children by limiting access to the
control cord.
e cord tensioner must be installed to make the shade fully operable.
Read the instructions in the mounting hardware packet prior to installing the tensioner.
SAFETY LABELS
In compliance with WCMA/ANSI safety standards, the warning labels on the bottom rail are designed to be permanent.
DO NOT remove the permanent warning label on the bottom rail. is assures that future owners of this product will be
aware of potential dangers associated with this shade.
Pulling down on the back cord will lower the shade. Pulling down on the front cord will raise the shade.
If shade was ordered as a reverse roll, the front cord will lower the shade and the back cord will raise the shade.
SKEW ADJUSTMENT (IF NECESSARY)
If the shade does not raise evenly, rst make sure the mounting
brackets are mounted level with each other.
If the shade is level and it still skews, operate the shade to
the full down position. Prepare a strip of masking tape
approximately 5” long. On the side of the shade opposite of
the skewing direction, and as close to the end of the roller as
possible, li the fabric toward the back of the shade using your
ngers and slide the tape with the sticky side facing the roller
up as far as possible. e tape should be running parallel to the
roller.
Roll the shade up and check for skewing. If the shade is still
skewing, add another strip of tape on top of the rst one. If the
shade is now skewing in the opposite direction, tear o about
1” of tape from the last strip installed. Tear the tape o the end
closest to the center of the shade.
Place tape at this end

6
HOLD DOWN BRACKETS (OPTIONAL)
Optional hold down brackets are mounted with the supplied
screws.
With the shade at its proper drop, place the pin of each hold
down into the hole in each end cap and mark the screw holes.
Make sure the pins are level and aligned.
Raise the shade, then screw the hold down bracket into the
mounting surface.
SHADE REMOVAL
HEAD RAIL
Partially lower the shade and insert a at head screwdriver as
shown.
Twist the screwdriver until the head rail disengages from the
bracket.
As you release the brackets, support the head rail to keep it
from falling.
FASCIA OR NO HEAD RAIL
Rotate the T-hook on the support bracket. Li the post up and
o the support bracket.
CLEANING AND CARE
e shade fabric is easy to care for. Regular dusting with a feather duster or vacuum cleaner brush is recommended. Most
stains can be blotted with a damp sponge and mild detergent. Before using anything stronger than mild detergent and
lukewarm water, test an unobtrusive corner of the shade. If you have any questions, call your dealer for advice.

MOTORIZED SHADE
With rechargeable motor
Installation & Care Instructions 152709I
5/1/2019
Roller Shades

1
A few simple tools are required:
- Measuring tape
- Power drill, drill bits
-
1⁄4” Hex head and/or Phillips driver bit
- Pencil
GETTING STARTED
IMPORTANT: e remote control has not been linked to the shades. Install
all shades prior to linking the remote. e lower and upper limits have been set
at the factory.
Additional fasteners other than those sent with your shade may be required
depending on the mounting surface. Wallboard and plaster require the use of
anchors such as expansion or toggle bolts. Brick, tile or stone need special plugs
and drill bits. Remember to always pre-drill holes in wood to avoid splitting.
1 1⁄4”
Hex Head
Bracket
Screw
Head rail
Extension
and Sidemount
Bracket
(optional)
Spacer
Block
(optional)
Mounting
Bracket
Hold
Down
Bracket
(optional)
PN: CS5402 PN: 20201012 PN: CS1000 PN: CS2000
Mounting
Brackets for
Shades without
head rail
PN: CS1101
PN: CS5002(W or BLK)
CS5008 (W or BLK)
CS5529
CS5530
Depends on size of
shade
Charger
PN: CS5199

2
STEP 1: BRACKET INSTALLATION
Shades are shipped with the required number of brackets for proper installation.
End brackets should be located approximately 3” from either end. Depending
on the width of the shade, additional brackets may be necessary, evenly spaced
between the two end brackets.
Using the installation bracket as a template, measure to the edge of the bracket
and mark the hole locations with a pencil for drilling.
Brackets must be in line and level. Shim brackets on inside mounts if necessary.
e head rail must be level for the shade to operate properly.
Shade Width # of Brackets
Up to 40” 2
>40” - 72” 3
>72”- 84” 4
>84” and up 5
SHADES WITH HEAD RAIL
3” 3”
INSIDE MOUNT
e minimum mounting depth for an inside
mount is 1”.
A minimum of 3 3⁄4”is needed to fully recess the
shade.
Make sure the brackets are level and aligned.
Attach using two screws.
Inside Mount
Shallow Mount - Minimum 1” surface
Flush Mount - Minimum 3 3⁄4” surface
1”
Important: If a solar recharge unit is being installed, read the section on solar
recharge on page 24 prior to installing mounting brackets.

3
OUTSIDE MOUNT
e minimum mounting height for outside
mounted shades is 1”.
Make sure the brackets are level and aligned.
Attach using two screws.
Outside Mount
Minimum 1” surface
1”
SPACER BLOCKS (OPTIONAL)
Each spacer block projects brackets 3⁄8”away from
mounting surface.
Make sure the brackets are level and aligned.
Attach using two screws. Screws should be long
enough to secure the bracket to the mounting
surface.
Outside Mount with Spacer
Blocks
Optional extension brackets are used to
project the back of the shade up to 2 1⁄2”
from the mounting surface.
Attach the mounting bracket to the
extension bracket with the nut and bolt
provided.
Outside Mount with Extension
Brackets
Minimum 2” surface
2”
2 1⁄2”
EXTENSION BRACKETS (OPTIONAL)
SIDE MOUNT (OPTIONAL)
Measure from window sill up to desired
mounting position on each side of the
window frame. Mark position.
Mount side mount brackets on each side
of window frame as shown. Make sure
to conrm the head rail will sit perfectly
level.
Side Mount
Minimum 2” surface
2”
Once side mount brackets are installed and properly positioned, attach the
mounting brackets using the nuts and bolts provided.

4
Idler Side Bracket Motor Side bracket
Foot
T-Hook
e installation brackets are always mounted
so that the inner surfaces face each other.
Brackets must be in line and level. Shim
brackets on inside mounts if necessary. e
head rail must be level for the shade to operate
properly.
SHADES WITH NO HEAD RAIL
Inside Mount
Minimum 1 1⁄2” surface
Outside Mount
Minimum 1 1⁄2” surface
1 1⁄2”
1 1⁄2”
STEP 2: SHADE INSTALLATION
Push the rail back until it
is fully engaged
Center the shade in the window opening and push the head rail into the
mounting brackets as shown.
SHADES WITH HEAD RAIL
Once the brackets are secured and level, the
fabric roll can be inserted. Make sure your
hands are clean to avoid soiling the fabric.
Insert the foot of the motor-side bracket
into the slotted center hole of the motor
end of the fabric roll. e wire should be
positioned so that it goes up on an inside
mount or back on an outside mount. is
will provide easy access to the setting button.
Nub
Support Bracket
Fig.15
Idler Post
V slot
SHADES WITH NO HEAD RAIL
Set the post of the idler end into the V of the support bracket. Rotate the
T-hook on the support bracket to lock in the post and secure the fabric roll.
